Sinbo SHB 3070 User manual

SHB 3070 KARIfiTIRICI
EN

- 1 -
Children being supervised not to play with the appliance.
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliances by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the appliance.

- 9 -
ENGLISH
SINBO SHB 3070 8 IN 1 VERTICAL MULTIFUNCTION FOOD PROCESSOR
INSTRUCTION MANUAL
IMPORTANT SAFETY INSTRUCTION
When using electrical appliances, basic safety precaution must always be followed:
1. Carefully read all instructions before operating and save for future reference.
2. This appliance is for normal household use only.
3. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
4. Young children must be supervised to ensure that they do not play with the appliance.
5. If the supply cord is damaged, it must be replaced before further use by the
manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
6. This appliance includes a safety switch which prevents operation unless the accessories
are securely installed.
7. This appliance incorporates a protective device against high temperatures. If the
temperature becomes too high, the unit will turn off automatically and will resume
operation when the motor has cooled sufficiently (after about 15 minutes).
8. Do NOT operate the appliance for more than a minute at a stretch.
9. If operation is not finished within 1 minute, turn off the machine and let it cool for 10
minutes before the next round of operation. If more than 5 rounds of operation are
required, cool the machine for 90 minutes to room temperature before the next 5 rounds.
This can lengthen lifespan of the machine.
10. The temperature of accessible surfaces may be high when the appliance is operating.
11. To protect against risk of electric shock, fire or personal injury, do not immerse power
cord, plug or motor base in water or any form of liquid.
12. Unplug when it is not in use and before cleaning.
13. Do not immerse Motor Base in water, neither rinse it under tap water.
14. Do not push food with fingers, or other objects (like knives), always use the enclosed
pusher for feeding food.
15. Be extremely careful when handling blades and inserts, especially while assembling
and disassembling, and cleaning after use. Blades are very sharp.
16. Do not let power cord hang over the edge of a table or counter, or touch any hot
surface
17. Do not place the appliance near a gas outlet, electric burner, or heated oven.
18. Please wait till all the components stop running before unplugging the power cord
and taking off the processing bowl.
19. Ensure the capacities shown in the Specifications section are not exceeded.
20. Always use a reliable earthed power supply to operate the appliance.
21. The appliances are not intended to be operated by means of an external timer or
separate remote-control system.

- 10 -
TECHNICAL SPECIFICATION
Voltage: AC 230V
Frequency: 50Hz
Power: 700W
Capacity: 2-Litre capacity for dry items
1.2-Litre capacity for liquids
OVERVIEW
1. Motor Base
2. Driver
3. Processing Bowl
4. Blade Adapter
5. Bowl Cover
6. Pusher
7. Disc Holder
8. Slicing Disc
9. Shredder Disc
10. French Fry Disc
11. Chopper
12. Kneading Disc
13. Emulsifying Disc
14. Citrus Juicing Plate
15. Citrus Juicing Head
16. Blender Measuring Cup
17. Blender Jar Cover
18. Blender Jar
19. Blender Blade
20. Transmission Head
BEFORE FIRST USE
After unpacking, disassemble unit before using first time. Refer to “HOW TO
DISASSEMBLE” for directions.
Wash all parts except motor base in warm, soapy water. Rinse and dry immediately. DO
NOT IMMERSE MOTOR BASE IN WATER.
ASSEMBLY
Chopper Assembly
1. Position Driver on motor base.
2. Position processing bowl into the Driver and turn clockwise to seat firmly on motor
base.
3. Place blade adaptor onto the Driver.
4. Place chopper onto the blade adaptor.
5. Turn the chopper to the right position.
6. Place cover on bowl, turn clockwise until cover interlocks on bowl.
7. Place pusher into feeding chute

- 11 -
ASSEMBLY
Processed Food Measurement Per per batch
Chocolate 100g
Cheese 200g
Meat 500g
Tea or Spice 50~100g
Fruit & Vegetable 100~300g
Onion 500g
Notes (Chopper) :
- Always keep the chopper inside the bowl before feeding food.
- Use pulse function for several times to avoid cutting too fine. Do not run for too long
while cutting hard cheese or chocolate. Otherwise these materials will overheat and
begin to melt.
- Standard chopping period: 30-60 sec.
Kneading Disc Assembly
1. Position Driver on motor base.
2. Position processing bowl into the Driver and turn clockwise to seat firmly on motor
base.
3. Place blade adaptor onto the Driver.
4. Place kneading disc onto the blade adaptor.
5. Turn the kneading disc to the right position.
6. Place cover on bowl, turn clockwise until cover interlocks on bowl.
7. Place pusher into feeding chute
Processed Food Measurement per batch
Flour / Soft Cheese 300g
Egg 5pieces
Notes (Kneading Disc):
- Always attach kneading disc in the bowl before feeding food.
- Standard kneading period: 30-180 sec.
Emulsifying Disc Assembly
1. Position Driver on motor base.
2. Position processing bowl into the Driver and turn clockwise to seat firmly on motor
base.
3. Place blade adaptor onto the Driver.
4. Place Emulsifying Disc onto the blade adaptor.
5. Turn the Emulsifying Disc to the right position.
6. Place cover on bowl, turn clockwise until cover locks on bowl.
7. Place pusher into feeding chute

- 12 -
ASSEMBLY
Processed Food Measurement per batch Time per batch
Egg 2~5pcs 30~70sec
Cheese 125~350ml 20sec
Notes (Emulsifying Disc):
- Emulsifying Disc can be used to mix cheese and egg, to make mayonnaise and pudding
rapidly.
- Do not use Emulsifying Disc to knead flour.
Slicing Disc, Shredder Disc & French Fry Disc Assembly
1. Position Driver on motor base.
2. Position processing bowl into the Driver and turn clockwise to seat firmly on motor
base.
3. Install desired disc onto the disc holder.
4. Place disc holder onto the Driver.
5. Place cover on bowl
6. Turn cover clockwise until cover interlocks on bowl.
7. Put food into the feeding chute.
8. Use pusher to push the food down for processing.
Notes:
- Choose desired disc according to the processed food and desired shape of food.
- Push softly when feeding food.
- Pre-cutting food into smaller pieces according to the diameter of feeding tube.
- Feed gradually for better effect. When cutting soft food, choose lower speed to avoid
the food turning soupy. If large quantity food needs to be cut, please cut it for several
batches. 1200ml for one batch.
Citrus Juicer Assembly
1. Position Driver on motor base.
2. Position processing bowl into the Driver and turn clockwise to seat firmly on motor
base.
3. Place citrus juicing plate on the bowl and turn 30 degrees clockwise.
Notes (Citrus Juicer):
- Lower speed should be chosen for citrus juicer.
Blender Assembly
1. Make sure the blade base is fixed tightly.
2. Put food into the jar.
3. Install measuring cup and cover properly.
4. Put blender jar onto motor base vertically, and then rotate the jar clockwise to fix it.

Choose PULSE function for pre-mixing is recommended before operation.
1800ML for one batch.
Make sure the blade base is installed properly before operation.
Measuring cup can be used to add ingredients during operation.
HOW TO DISASSEMBLE
1. Remove pusher. Turn cover counterclockwise, lift and remove.
2. Lift blade holder from driver.
3. Lift blade and remove from blade holder.
4. Turn bowl counterclockwise to unlock from motor base. Lift and remove.
CLEANING
Wash all parts except motor base in warm, soapy water. The discs can be disassembled
to wash with water, but be careful during disassembly.
DO NOT PUT ANY PARTS IN AN AUTOMATIC DISH-WASHER.
DO NOT IMMERSE MOTOR BASE IN WATER.
TROUBLESHOOTING
Machine does not work.
Ensure correct assembly.
Make sure power plug is plugged in properly.
Check if the mains have tripped, or if there is a power outage.
Machine stops running suddenly.
Processing bowl may loosen during vigorous processing. Please re-install the bowl cover.
Motor is running, while components do not run.
Make sure the Driver is installed correctly.
-13 -
TIPS AND WARNING

- 59 -
MÜfiTER‹ H‹ZMETLER‹
De¤erli Müflterimiz,
En uygun fiyata en iyi ürünü vermenin yan› s›ra; en iyi hizmeti vermenin de
önemli oldu¤una inan›yoruz. Bu nedenle siz bilinçli tüketicilere daha yak›n
olabilmek için, internet adresimizdeki eriflim formlar›n›n yan› s›ra, tüketici
dan›flma hattımızı da hizmetinize açm›fl durumday›z.
Tüketici Dan›flma Hattımızı,
- Hafta içi her gün 08.00-18.00 saatleri aras›nda arayabilir; istek, öneri ve
flikayetlerinizi firmam›za iletebilirsiniz.
Tüketicinin Dikkatine:
Ürünlerimizle ilgili hizmetleri tam olarak alabilmek için afla¤›daki önerilere
uyman›z› rica ederiz:
1. Ürünü ald›¤›n›zda Garanti Belgesini mutlaka yetkili sat›c›n›za onaylatt›r›n›z.
2. Ürünü kullanma k›lavuzunda belirtilen hususlara göre kullan›n›z.
3. Ürününüzle ilgili hizmet talebiniz oldu¤unda yukar›daki telefon
numaralar›ndan, Tüketici Danıflma Hattına baflvurunuz.
4. Ürünü promosyon arac›l›¤› ile edinmiflseniz, ürüne ait garanti belgesini en
yak›n yetkili servisimize giderek onaylatt›r›n›z.
5. Teknik servisteki ifliniz bitti¤inde "Yetkili Servis Hizmet Fifli" almay›
unutmay›n›z. Alaca¤›n›z bu Hizmet Fifli, ileride ürününüzde meydana
gelebilecek herhangi bir sorunda size yarar sa¤layacakt›r.
www.sinbo.com.tr
0800 211 50 21
TÜKET‹C‹
DANIfiMA HATTI
444 66 86
Kap›dan Kap›ya Ücretsiz Servis Kampanyam›z dâhilinde Yurtiçi Kargo Firmas› ile iflbirli¤i içerindeyiz. Tüketicimiz
taraf›ndan sat›n al›nan ürünün fiyat› ne olursa olsun, Tüketicimiz ürün ile ilgili garanti kapsam›na giren herhangi
bir problem yaflad›¤›nda, 444 66 86 numaral› Tüketici Danıflma Hattımızı aramas› ve kay›t b›rakmas› yeterlidir.
Bu süreçten sonra Tüketicimizin ürünü ücretsiz olarak Yurtiçi Kargo taraf›ndan Tüketicimizin bulundu¤u adresten
al›n›p, 7* ifl günü içerisinde ürün çal›fl›r bir vaziyette, yine Tüketicimize Yurtiçi Kargo arac›l›¤› ile adresine teslim
edilmektedir. 7 ifl günü içerisinde sorunu çözülemeyen ürünler ise, yenisi ve/veya bir üst modeli ile de¤ifltirilmektedir.
Tüm bu süreçte Tüketicilerimizden hiçbir ücret talep edilmemektedir.
(*Ürünün servis garanti süresi, Yurtiçi Kargo ürünü Sinbo Fabrikas›’na teslim ettikten sonra bafllar.)
SERV‹S
KAPIDAN KAPIYA
ÜCRETS‹Z
GARANT‹S‹
7 GÜNDE
TESL‹MAT
(*)

- GARANT‹ fiARTLARI -
1) Garanti süresi,mal›n teslim tarihinden itibaren bafllar ve 2 y›ld›r.
2) Mal›n bütün parçalar› dahil olmak üzere tamam› Firmam›z›n garanti kapsam›ndad›r.
3) Mal›n garanti süresi içerisinde ar›zalanmas› durumunda, tamirde geçen süre garanti
süresine eklenir. Mal›n tamir süresi, 20 iflgününü geçemez. Bu süre mala iliflkin ar›zan›n
servis istasyonuna, servis istasyonunun olmamas› durumunda, mal›n sat›c›s›, bayii,
acentesi, temsilcili¤i, ithalatç›s› veya imalatç›s›-üreticisinden birine bildirim tarihinden
itibaren bafllar. Tüketicinin ar›za bildirimini; telefon, faks, e-posta, iadeli taahhütlü mektup
veya benzeri bir yolla yapmas› mümkündür. Ancak, uyuflmazl›k halinde ispat yükümlülü¤ü
tüketiciye aittir. Mal›n ar›zas›n›n 10 ifl günü içerisinde giderilememesi halinde, imalatç›-
üretici veya ithalatç›; mal›n tamiri tamamlan›ncaya kadar, benzer özelliklere sahip baflka
bir mal› tüketicinin kullan›m›na tahsis etmek zorundad›r.
4) Mal›n garanti süresi içerisinde gerek malzeme ve iflçilik, gerekse montaj hatalar›ndan
dolay› ar›zalanmas› halinde, iflçilik masraf›, de¤ifltirilen parça bedeli ya da baflka herhangi
bir ad alt›nda hiçbir ücret talep etmeksizin tamiri yap›lacakt›r.
5) Tüketicinin onar›m hakk›n› kullanmas›na ra¤men mal›n;
• Tüketiciye teslim edildi¤i tarihten itibaren, garanti süresi içinde kalmak kayd›yla, bir y›l
içerisinde en az dört defa veya imalatç›-üretici ve/veya ithalatç› taraf›ndan belirlenen
garanti süresi içerisinde alt› defa ar›zalanmas›n›n yan› s›ra, bu ar›zalar›n maldan
yararlanamamay› sürekli k›lmas›,
• Tamiri için gereken azami süresinin afl›lmas› ,
• Firman›n servis istasyonunun, servis istasyonunun mevcut olmamas› halinde s›rayla
sat›c›s›, bayii, acentesi temsilcili¤i ithalatç›s› veya imalatç›-üreticisinden birisinin
düzenleyece¤i raporla ar›zan›n tamirini mümkün bulunmad›¤›n›n belirlenmesi, durumlar›nda
tüketici mal›n ücretsiz de¤ifltirilmesini, bedel iadesi veya ay›p oranda bedel indirimi talep
edebilir.
6) Mal›n kullanma k›lavuzunda yer alan hususlara ayk›r› kullan›lmas›ndan kaynaklanan
ar›zalar garanti kapsam› d›fl›ndad›r.
7) Garanti Belgesi ile ilgili olarak ç›kabilecek sorunlar için Gümrük ve Ticaret Bakanl›¤›
Tüketicinin Korunmas› ve Piyasa Gözetimi Genel Müdürlü¤ü’ne baflvurabilir.
- 60 -
‹THALATÇI F‹RMA
DE‹MA ELEKTROMEKAN‹K ÜRÜNLER ‹NfiAAT SPOR MALZEMELER‹ ‹MALAT SAN. VE T‹C. A.fi.
Cihangir Mh. Güvercin Cd. No:4 Haramidere Mevkii Avcılar - ‹stanbul - Türkiye
Ça¤rı Merkezi: 444 66 86
www.sinbo.com.tr - [email protected]

- SHB 3070 KARIfiTIRICI -
- GARANT‹ BELGES‹ -
‹THALATÇI F‹RMA
Ünvanı : DE‹MA ELEKTROMEKAN‹K ÜRÜNLER‹ ‹Nfi. SPOR MALZ.
‹MALAT SAN. ve T‹C. A.fi.
Adresi : Cihangir Mah. Güvercin Cad. No:4 Haramidere Mevkii
Avc›lar / ‹STANBUL
Tel. : Ça¤rı Merkezi: 444 66 86
Yetkili Kifli :
Ürünün Cinsi : KARIfiTIRICI
Markası : S‹NBO
Modeli : SHB 3070
Alt Modeli : -
Bandrol ve Seri No :
Teslim Tarihi ve Yeri :
Garanti Süresi : 2 Yıldır
Azami Tamir Süresi : 20 ‹fl Günü
Kullanım Ömrü : Bakanl›kça belirlenen ve ilan edilen kullan›m ömrü 7 y›ld›r.
(Ürünün fonksiyonlar›n› yerine getirebilmesi için gereken yedek parça temin süresi)
SATICI F‹RMA
Ünvanı :
Adresi :
Tel.Fax :
Fatura Tarihi ve No :
Teslim Tarihi ve Yeri :
‹mza ve Kafle :
Garanti Belge No : 105029
SSHY Belge No : 35274
Garanti Belge Onay Tarihi : 07/09/2011
SSHY Belge Onay Tarihi : 04/04/2012
Bu belgenin kullan›lmas›na; 4077 say›l› Tüketicinin Korunması Hakkında Kanun ve bu Kanun’a dayan›larak yürürlü¤e konulan Garanti Belgesi
Uygulama Esaslar›na Dair Yönetmelik uyar›nca, TC Gümrük ve Ticaret Bakanlı¤ı, Tüketicinin Korunması ve Piyasa Gözetimi Genel Müdürlü¤ü
tarafından izin verilmifltir.
Bu bölüm, ürünü sat›n ald›¤›n›z Yetkili Sat›c› taraf›ndan imzalanacak ve kaflelenecektir.
- 61 -
Yönetim Kurulu Baflkan›

Made in P.R.C.
‹mal Y›l› : 2013
- TEDAR‹KÇ‹ F‹RMA / EXPORTER -
United Favour Development Limited
Unit B, 10/F Lee May Building 788-790
Nathan Road, Mongkok, Kowloon, HK.
EEE Yönetmeli¤ine uygundur.
AEEE Yönetmeli¤ine uygundur.
- UYGUNLUK BEYANI / CE CONFORMITY -
Intertek Testing Services Shenzhen Ltd.,
Guangzhou Branch
Block E, No. 7-2 Guangdong Software
Science Park,Caipin Road, Guangzhou
Science City, GETDD, Guangzhou, China
