Sinclair S2PRO User manual

1
S2PRO
USER GUIDE

2
USAGE INSTRUCTIONS PLEASE READ PRIOR TO USE
CHARGING:
1. Please fully charge for four hours before first use
2. When charging, connect the DC end of the supplied 26V adapter to the battery’s charging port
and plug AC side cable into wall outlet, then turn the power switch to the ON position to
charge.
3. The LED light flashes to indicate the battery level and indicates that it is charging.
4. When all LED stop flashing and remain lit, it indicates that the battery was fully charged.
5. Battery can be recharged at any time and at any battery level.
6. It is not recommended to fully deplete the battery to the red LED level.
7. This device average run-time is about 2 hours depending on speed level and pressure applied
during using.
OPERATING:
1. Turn the power switch on the bottom of the battery to the “ON” position to start the power.
Turn the power switch to the “OFF” position to turn off the power.
2. With the power on, short-press the gear button once to turn device on to level one, twice to
turn device to level two and three times to level three. Pressing the gear button again will turn
the device off. The blue LED lights would indicate the corresponding frequency level.
3. Massage desired body part at the desired speed applying pressure as needed.
4. With power off, you can change the massage head and pull it out by hand.
MAINTENANCE, CLEANING & STORAGE:
1. Use a slightly damp towel to clean device and a dry with a soft cloth.
2. For storage or travel, remove battery and store in supplied carton box.

3
DISCLAIMER
WARNINGS & CAUTION:
1. Do not immerse in water. Keep away from liquids or heat sources. Keep ventilation ports free
from dust and debris.
2. Do not remove screws or attempt to disassemble.
3. Do not operate continuously for more than one hour. Allow device to rest for 30 minutes before
re-using.
4. Unplug the charger from device battery after charging or prior to use.
5. For adults use only. Do not use if injured. Consult your doctor before using this product.
SAFETY INSTRUCTIONS
DANGER: TO REDUCE RISKS OF ELECTRIC SHOCK, FIRE, AND PERSONAL INJURY, THIS PRODUCT
MUST USED IN ACCORDANCE WITH THE FOLLOWING INSTRUCTIONS:
1. For adult use only.
2. Use only on a dry clean surface of the body over clothing by lightly pressing and moving across
the body for approximately 60 seconds per region.
3. Use the device only on the body’s soft tissue as desired without producing pain or discomfort.
Do no use on head or any hard or bony area of the body.
4. Use only the applicators that provide the best desired effect.
5. Bruising can occur regardless of control setting or pressure applied. Check treated areas
frequently and immediately stop at first sign of pain or discomfort.
6. Keep fingers, hair or any other body part away from the shaft and backside of the applicator as
pinching may occur.
7. Do not place any objects into the ventilation holes of the device
8. Do not immerse in water or allow water to enter the ventilation holes of the device
9. Do not drop or misuse the device
10. Only recharge with supplied 24VDC device charger.
11. Carefully examine device and battery before each use.
12. Do not tamper or alter device in any way.
13. Never leave the device operating or charging unattended.

4
DISCLAIMER
PLEASE DO NOT USE THE VIBRATION DEVICE WITHOUT FIRST OBTAINING APPROVAL FROM
YOUR DOCTOR IF ANY OF THE FOLLOWING APPLY:
Pregnancy, diabetes with complications such as neuropathy or retinal damage, wear of pace makers,
recent surgery, epilepsy or migraines, herniated disks, spondylolisthesis, spondylol-ysis, or spondylosis,
recent joint replacements or IUD’s, metal pins or plates or any concerns about your physical health.
Frail individuals and children should be accompanied by an adult when using any vibration device.
These contra indications do not mean that you are not able to use a vibration or exercise device but we
advise you to consult a doctor first.
Ongoing research is being done to the effects of vibration exercise for specific medical disorders. This
will likely result in the shortening of the list of contra indications as shown above. Practical experience
has shown that integration of vibration exercise into a treatment plan is advisory in a number of cases.
This must be done on the advice of and in accompaniment with a doctor, specialist or physiotherapist.
WARRANTY
IF WITHIN SIX MONTHS FROM THE DATE OF PURCHASE, THIS PRODUCT FAILS DUE TO A
DEFECT IN MATERIAL OR WORKMANSHIP, SINCLAIR.SG WILL REPAIR OR REPLACE THE
PRODUCT, OR NECESSARY COMPONENTS FREE OF CHARGE.
THIS WARRANTY EXCLUDES:
(a) Damage caused by accident, abuse, mishandling or transport
(b) Units subjected to unauthorized repair
(c) Units not used in accordance with sinclair.sg’s care instructions
(d) Damage exceeding the cost of the product
(e) Deterioration of the delivered product resulting from abnormal storage and/or safeguarding
conditions on the client’s premises
(f) Failure to provide the dated proof of purchase
Some states and countries do not allow a limitation of damages, so the foregoing limitation
may not apply to you. This warranty guarantees specific legal rights, and but the rights may
vary from country to country and from state to state. This warranty service is available through
the operating policies and procedures of sinclair.sg and sinclair.sg international distributors. If
you are a client, please contact the appropriate sinclair.sg business entity, dealer or retailer,
from whom you directly purchased the product for warranty and return authorization
procedures. This warrant is initiated and executed by sinclair.sg.

5
Product Information
(Super silent, High frequency, High torque, Lightweight)
S2PRO is a cordless state-of-the-art vibration massage device that helps relieve muscle soreness
and stiffness. It promotes circulation and improves range of motion, improves the overall health of
the body’s soft tissues.
CORDLESS/RECHARGEABLE
24V Lithium-Ion Battery
LIGHTWEIGHT DESIGN
2.2 lbs / 1.0 kg
Specifications, technical parameters, diagram
Specifications
1. Advanced technology with powerful brushless High-Torque Motor
2. Interchangeable head attachments (x4)-Fork, Bullet, Flat, Round
3. Rechargeable Lithium-Ion battery (More than 2 Hours using time when full-charged)
4. Gear indicator
5. Speed Settings for Optimal Pressure
6. Battery indicator
7. AC interface
8. ON/OFF Power Switch
Vibration
Frequency: Level 1 - 30Hz, Level 2 - 40 Hz, Level 3 - 53 Hz
Weight: 2.2 lbs / 10 kg
Charge: 110-240V, 50/60Hz-5A, 26V-DC-1A
