Singer VC-209010-WH User manual

VC-209010-WH & VC-209020-BL
Vacuum cleaner
Ηλεκτρική σκούπα
Електрическа прахосмукачка
GB INSTRUCTION MANUAL
GR ΒΙΒΛΙΟ ΟΔΗΓΙΩΝ
BG ИНСТРУКЦИИ ЗА ЕКСПЛОАТАЦИЯ

2
ENGLISH
SAFETY INSTRUCTIONS
When using your vacuum, basic safety precautions should
always be observed, including the following:
1. Check if the voltage indicated on the appliance corresponds to
the local mains voltage before you connect the appliance.
2. Do not use with damaged cord or plug. Do not use vacuum
cleaner if it has been dropped or damaged, left outdoor or
dropped into water. Return appliance to a SINGER service
center for examination repair or adjustment.
3. Do not use the machine without dust bag and filters properly
fitted.
4. Do not leave vacuum cleaner unattended when it is plugged in.
5. Unplug from outlet when not in use and before pulling filters out.
6. To avoid the risk of electric shock-do not use outdoors or on wet
surfaces.
7. Do not allow children to use as a toy. Close attention is necessary
when used near children.
8. Use only as described in this manual. Use only manufacturer’s
recommended attachments.
9. Do not pull or carry by cord. Do not use the cord as a handle.
Do not close a door on cord or pull cord around sharp edges or
corners. Do not run appliance over cord. Keep cord away from
heated surfaces.
10. Do not unplug by pulling on cord. To unplug, grasp the plug,
not the cord.
11. Do not handle plug or vacuum cleaner with wet hands.
12. Do not put any objects into air openings. Do not use with any air
openings blocked and do not restrict airflow. Keep all openings
free of dust, lint, hair, and anything that may reduce airflow.
13. Do not pick up hard or sharp objects such as glass, nails,
screws, coins, etc.
14. Do not pick up anything that it is burning or smoking such as

3
ENGLISH
hot ashes, cigarette or matches.
15. Turn off all controls before plugging or unplugging vacuum
cleaner.
16. Use extra care when vacuuming on stairs.
17. Do not pick up toxic material (chlorine bleach, ammonia, drain
cleaner, etc.)
18. Do not use to pick up flammable or combustible liquids, such
as gasoline, or use in areas where they may be present.
19. Keep hair, loose clothing, fingers and all parts of the body away
from openings and moving parts.
20. Alwaysunplugthisappliancebeforeconnectingordisconnecting
vacuum flexible hose.
21. Do not allow plug to whip when rewinding.
22. Use only on dry, indoor surfaces.
23. Store your appliance indoor in a cool, dry area.
24. Do not immerse the machine into water or other liquids.
25. Do not use the cleaner to clean your pets or any animal.
26. Keep your face (eyes, ear, mouth, etc.) away from the openings,
when the vacuum is turned on.
27. All repairs must be carried out by an authorized SINGER
service center.
28. Useonlyoriginaldustbag,originalfiltersandoriginalaccessories
from your local SINGER dealer. Use of unauthorized dust bags
and filters will void the warranty.
29.The appliance may be used by children over the age of 8
years and by persons with reduced physical, sensory or mental
capacity or by persons with a lack of experience or knowledge
if they are supervised or have been instructed on the safe use
of the appliance and the have understood the potential dangers
of using the appliance.
30. Children must never play with the appliance.
31. Cleaning and user maintenance must never be carried out by

4
ENGLISH
children without supervision.
32.Plastic bags and films must be kept out of the reach of children
before disposal. Risk of suffocation.
IMPORTANT SAFETY INSTRUCTIONS
1. This appliance is for household only. Only dry surfaces
should be vacuumed. Do not vacuum building materials. The
manufacturer cannot be held responsible for damage caused by
noncompliance with the “Safety Instructions” and the warranty
will automatically be voided.
2. Do not vacuum toner dust. Toner, such as that used in printers
and photocopiers, can conduct electricity.
3. To avoid danger of suffocation, keep packaging material (plastic
bags, box etc) away from babies and children.
4. The partial or total non-respect of the safety instructions in the
present instruction manual will automatically release Singer of
any type of responsibility in case of malfunction of the machine
or injuries to persons or animals.
5. In case of manipulation, repairing or any modification of the
machine made by unqualified persons or in case of improper
use, the guarantee will be automatically cancelled.
SERVICE & REPAIR
1. For service or repair under warranty, please contact the authorized service
company that is mentioned on the guarantee card that accompanies the
product.
2. Do not operate any product with a damaged cord or plug. If the supply cord is
damaged, return the appliance to a SINGER service center for examination
repair or adjustment. Do not attempt to dismantle any part of the appliance.
This should only be done at an authorized SINGER service centre.
3. The partial or total non-respect of the safety instructions in the present
instruction manual will automatically release Singer of any type of

5
ENGLISH
responsibility in case of malfunction of the machine or injuries to persons
or animals.
4. In case of manipulation, repairing or any modification of the machine made
by unqualified persons or in case of improper use, the guarantee will be
automatically cancelled.
SAVE THESE INSTRUCTIONS
For household use only.
PARTS NAME
1. On/off switch pedal
2. Cord rewinder pedal
3. Power control knob
4. Full dust bag indicator
5. Telescope tube
6. Hose
7. Floor brush
8. Handle
9. Lock clip for front cover
10. Outlet grille
11. Carpet brush
12. Pet brush
13. Crevice nozzle
14. Round brush
15. Sofa brush
1
2
7
5
6
8
9
10
11
12
4
3
14
15
13

6
ENGLISH
USE AND FUNCTION:
1. Assembling the vacuum cleaner
Note:
Always remove the power plug from the wall outlet before assembling or
removing accessories.
1. Attaching the Flexible Hose into the vacuum connect the flexible hose
into the air intake duct; push in until you hear a “click”, indicating it is in its
locked position.
2. Fitting the tube to the curved wand/hose extension. Push the tube into the
curved wand/hose extension.
3. Fitting the Floor Brush to the tube. Push the tube into the floor brush.
Adjust the tube to the desired length.
2. Variable suction control
Note:
Once all attachments are in place, unwind a sufficient length of cable and
insert the plug into the wall outlet. A yellow mark on the power cord shows
the ideal cable length. Do not pull the power cord beyond this mark.
1. Insert the power plug into the wall outlet.
2. Press the power on/off button (1) located the unit to turn the vacuum
cleaner “on”.
3. To rewind the power cord, press the cord rewind button (2) with one hand
and guide the power cord with the other hand to ensure that it does not
whip causing damage or injury.
4. To adjust the suction, slide the speed control button (3) to control the
suction power of the vacuum cleaner. The suction power can also be
adjusted by using the airflow regulator on the handle: closed for maximum
suction, open for reduced suction.

7
ENGLISH
Motor thermostat
Important:
This appliance is equipped with a motor protective thermostat. If for some
reason the vacuum cleaner should overheat, the thermostat will automatically
turn the unit off. Should this occur unplug the vacuum cleaner from the wall
outlet and turn off switch, change dust bag and clean filters. Allow the unit to
cool for approximately 1 hour. To restart, re-plug into wall outlet and turn switch
back on.
3. Change dust bag
1. Open the front cover 2. Change dust bag
On/off button (1) Rewind button (2)
Speed control
button (3)

8
ENGLISH
4. Carrying and moving the cleaner
Note:
This cleaner has a convenient handle. You can use it to carry easily the cleaner
when the cleaner is in vertical position. It also has 4 small direction wheels at
the bottom for easy movement on the floor.
5. Removing & cleaning pre-motor filter and HEPA Air
Warning:
Always unplug the unit from electrical outlet before getting out the dust barrel.
a. Pre-motor filter
1. Open the front cover 2.Bring out the inlet filter grill & clean or
change filter
HEPA H13
1. Open the front cover 2. Take out the HEPA 13 air lock knob to
open it for clean and change

9
ENGLISH
Please note:
The sponge filter material in the cleaner will became dusty over time. This is
normal and will not affect the performance of the filter. If the sponge filter is
so dusty that suction does not return to 100%, then we suggest that the filter
be removed then rinsed under the faucet and allowed to dry for 24 hours by
airing not near the fire or some high temperature objects before refitting into
the vacuum. This should be done once six months or when suction appears to
be reduced obviously.
Important:
Please note that there is a safety switch inside the vacuum to prevent the unit
from being run with high vacuum rate. If the vacuum is too high, the safety
switch will be turned on. In this case, it can diminish the vacuum rate and
protect the motor from being broken.
Note:
The suction hole must be open, free of any obstructions at all times. Otherwise,
the motor will overheat and could become damaged.
Important:
All filters should be checked regularly for signs of damage, preferably after
each cleaning task.
The filters must be replaced immediately if they become damaged. Always
disconnect the vacuum from the electrical outlet when checking the filters.
EXTRA BRUSHES
PET BRUSH
This vacuum cleaner has not only great suction, but also a rotating pet brush
to help pull and remove the fur out of the carpet.
Cleaning of the pet brush
When we clean the pet brush, rotate the locker on the connector part to unlock
the upper cover. Remove the upper cover and all internal parts could be
disassembled and clean separately, including the roller brush, turbo wheel etc.
Remember to fully dry the components before re-assembling.

10
ENGLISH
Disposal of old Electrical & Electronic Equipment (Applicable in
the European Union and other European countries with separate
collection systems).
This symbol on the product or on its packaging indicates that this
product shall not be treated as household waste. Instead it shall
be handed over to the applicable collection point for the recycling
of electrical and electronic equipment. By ensuring this product is disposed
of correctly, you will help prevent potential negative consequences for
the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The recycling of materials will
help to conserve natural resources. For more detailed information about
recycling of this product, please contact your local city office, your household
waste disposal service or the shop where you purchased the product.
DECLARATION OF CONFORMITY
Herewith, G. E. DIMITRIOU S.A. states that this product, complies with the
requirements of below European directives:
EMC Directive: 2014 / 30 / EU
LVD - Low Voltage Directive: 2014/ 35 / EU
ROHS Directive: 2011 / 65 / EU
CARPET BRUSH
Since the bottom of the carpet brush is flat, it can fit the surface of the carpet
properly and perform the best dust pick up ability. This brush can operate more
smoothly on carpet than the high efficiency brush. However, this brush is for
carpet only, if we use it on hard flat floor, it is hard to operate.
