SIP 06781 User manual

16
Ref: 190314
FOR HELP OR ADVISE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR
SIP DIRECTLY ON:
TEL: [phone]
EMAIL: [e-mail] or [e-mail]
www.sip-group.com
Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
environment, take the packaging to the local amenity tip and
place into the appropriate recycling bin.
1
Needle Scaler
(Pistol Type)
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.
06781

2
15
Declaration of Conformity
We
SIP (Industrial Products) Ltd
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
England
As the manufacturer's authorised representative within the EC
declare that the
Air Needle Scaler - SIP Part. No. 06781
Conforms to the requirements of the following directive(s), as indicated.
2006/42/EC Machinery Directive
Signed: …………………………………...
Mr P. Ippaso - Managing Director - SIP (Industrial Products) Ltd
Date: 06/05/2013.
And the relevant harmonised standard(s), including:
EN ISO 11148-4:2012
DECLARATION OF CONFORMITY

14
Ref No. Description SIP Part No. Ref No. Description SIP Part No.
1. Casting AI05-00530 14. Spring AI05-00764
2-4. Upper valve case AI05-00130 15. Block AI05-00765
5 Piston AI05-00531 16. Needle sleeve AI05-00766
6. Hex screw M8x6 AI05-00138 17. Needle AI05-00767
7. Cylinder AI05-00531 18. Air inlet AI05-00129
8. Circlip AI05-00760 19. Spring AI05-00128
9. Bumper AI05-00761 20. Seal AI05-00127
10. Trigger AI05-00125 21. Pin AI05-00126
11. Trigger pin AI05-00121 22. O-ring AI05-00123
12. Needle driver AI05-00762 23. Regulator AI05-00124
13. Needle seat AI05-00763 24. Pin AI05-00122
PARTS LIST
This needle scaler can also be used as an 190mm air hammer but requires additional
chisel set and spring retainer (not included), you will need to order from your distributor
the following parts.
AI05-00135 Spring retainer.
AI05-00533 5piece Chisel set.
3
CONTENTS
Page No. Description
4. Safety Symbols Used Throughout This Manual
4. Safety Instructions
7. Contents and Accessories
7. Getting to Know Your Air Needle Scaler
8. Technical Specifications
8. Guarantee
9. Operating Instructions
11. Maintenance
12. Troubleshooting
13. Exploded Drawing
14. Parts List
15. Declaration of Conformity

4
When using your needle scaler, basic safety precautions should always be followed to
reduce the risk of personal injury and / or damage to it.
Read all of these instructions before operating the needle scaler and save this user
manual for future reference.
The needle scaler should not be modified or used for any application other than that
for which it was designed.
This air tool is designed to be used as a hand held, hand controlled tool for cleaning
heavy paint and rust from metal surfaces etc.
If you are unsure of its relative applications do not hesitate to contact us and we will
be more than happy to advise you.
Before operating the needle scaler always check no parts are broken and that no
parts are missing.
Always operate the needle scaler safely and correctly.
KNOW YOUR NEEDLE SCALER: Read and understand the owner's manual and labels
affixed to the needle scaler. Learn its applications and limitations, as well as the po-
tential hazards specific to it.
KEEP CHILDREN AND UNTRAINED PERSONNEL AWAY FROM THE WORK AREA: All visitors
should be kept at a safe distance from the work area; Never allow untrained persons
to operate the needle scaler.
STAY ALERT: Always watch what you are doing and use common sense.
HAVE YOUR NEEDLE SCALER REPAIRED BY A QUALIFIED PERSON: The needle scaler is in
accordance with the relevant safety requirements. Repairs should only be carried out
by qualified persons using original spare parts, otherwise this may result in considera-
ble danger to the user and void the warranty.
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL
Danger / Caution: Indicates risk of personal injury and/or the possibility of
damage.
Note: Supplementary information.
SAFETY INSTRUCTIONS
IMPORTANT: Please read the following instructions carefully, failure to do
so could lead to serious personal injury and / or damage to the air
needle scaler.
13
EXPLODED DRAWING

12
The following form lists the common operating issues with problems and solutions.
Please read the form carefully and follow it.
If any of the following symptoms occurs during your operation, stop using the tool immediately, or serious
personal injury could result. Only a qualified person or an authorised service centre should perform repairs
of the tool. Disconnect from the air supply before attempting repairs or adjustments. When replacing O-
rings etc. lubricate with air tool oil before assembly.
TROUBLESHOOTING
PROBLEMS POSSIBLE CAUSES REMEDIES
Tool runs at normal speed
but struggles under load.
Motor parts worn. Check / have the parts checked and re-
pair / replace as necessary.
Check that the piston is well greased; Add
grease where necessary.
NOTE: Heat usually indicates insufficient
grease in gears. Severe operating condi-
tions may require more frequent lubrica-
tion.
Tool runs slowly. Air flows
slightly from exhaust.
Inlet filter restricted.
Motor parts jammed with
dirt particles.
Air flow blocked by dirt.
Check air inlet filter for blockage.
Pour air tool lubricating oil into air inlet,
operate tool in short bursts quickly.
Repeat above as needed. If this fails return
to service centre.
Tools will not run. Air flows
freely from exhaust.
Piston is stuck due to mate-
rial build up.
Pour air tool lubricating oil into air inlet,
operate tool in short bursts quickly.
Tap motor housing gently with plastic mal-
let.
If tool remains jammed return to service
centre.
Tool will not shut off.
‘O’ rings throttle valve dis-
lodged from seat inlet
valve.
Replace ‘O’ ring or return to service centre.
Note: Repairs should be carried out by a qualified person.
5
SAFETY INSTRUCTIONS….cont
DANGER! Check that the needle scaler is in sound condition and good working order;
Take immediate action to repair or replace damaged parts.
DO NOT dismantle or tamper with the needle scaler, as this may be dangerous and
will invalidate the warranty.
If a problem with the needle scaler is experienced or suspected stop using it imme-
diately and contact your distributor for repair.
Regularly inspect and lubricate the needle scaler, ensuring that it is in good working
order and condition.
Always ensure that the work area is clean and tidy, free from unrelated materials and
has adequate lighting.
Clean and stow the needle scaler correctly.
Failure to follow the warnings in this manual, may result in personal injury and/or prop-
erty damage.
DO ensure that only compressed air is used to supply the air tool.
The compressed air supply MUST be at a suitable regulated pressure. Pipe work, reg-
ulators, hoses, isolation valves and connection devices MUST be suitable for the in-
tended application correctly installed and maintained in good condition by a com-
petent person.
Appropriate personal protective equipment MUST be worn and MUST be designed
to protect against all hazards created. Severe permanent injury can result from using
inappropriate or insufficient protective equipment - Eyes in particular are at risk.
Long hair MUST be tied back; Loose clothing MUST NOT be worn. There is a severe
risk of these being drawn in or trapped by the moving parts of the air tool.
Open or damaged compressed air lines present a significant ‘whip’ hazard; Isolate
the problem hose from the air supply and repair / replace the hose immediately.
This air tool is electrically conductive DO NOT allow it to come into contact with any
source of electrical supply.
After use wait for the air tool to STOP completely before putting it aside.
When putting the air tool aside you MUST ensure that it placed in a stable position.
To avoid inadvertent operation DO NOT place the air tool where it can be knocked
or moved accidentally either directly or by the air connection hose.
If the air tool is not required or the air supply is interrupted, disconnect the air tool
from the air supply and place in secure storage to prevent unauthorised use.
Ensure the air valve (or trigger) is in the “off” position before connecting to the air sup-
ply.
Disconnect the needle scaler from the air supply before making adjustments,
changing needles etc. and before servicing the tool.
Always keep your air tool clean and lubricated. Daily lubrication is essential to avoid
internal corrosion and possible failure.
Do not overload the tool. Allow the tool to operate at its optimum speed for maxi-
mum efficiency.

6
CAUTION: The warnings and cautions mentioned in this user manual can not
cover all possible conditions and situations that may occur. It must be under-
stood by the operator that common sense and caution are factors which can-
not be built into this product, but must be applied.
We recommend wearing ear protection - particularly during extended
periods of operation.
We recommend wearing a face mask or respiratory equipment when
using any air tool; Particularly during drilling, sanding, grinding, sawing or
other operations likely to cause airborne particles.
Always wear approved safety goggles / glasses when using or maintain-
ing any air tool, everyday eyeglasses have only impact resistant lenses,
they are not safety glasses.
SAFETY INSTRUCTIONS….cont
Do not increase the air pressure above the manufacturers recommended level, as
excessive pressure can cause the tool casing to split. This can also create excessive
wear on moving parts and possible failure.
Always ensure that the work-piece is firmly secured leaving both hands free to con-
trol the needle scaler.
Always wear safety goggles or glasses during operation.
Do not wear watches, rings bracelets or loose clothing when using air tools.
Use as light weight a hose as possible from the tool to the wall or compressor cou-
pling.
In the interests of safety and possible damage to the machine/operator, always en-
sure that the needle scaler has stopped before putting it down after use.
Always ensure that the accessories such as needles are rated / designed for use with
this needle scaler as well as the required application, and are correctly and securely
fastened before connecting the tool to the air supply.
Do not carry or move the air needle scaler by its air hose.
Never allow the tool to come into contact with harsh solvents such as petrol.
11
DO NOT use the tool if it is, or has parts that are worn, damaged or missing; Re-
move from service and have the parts repaired / replaced using original spare
parts.
Ensure that the air tool is lubricated daily with a few drops of air tool oil dripped
into the air inlet.
Clean the air tool after each use.
Check hose and fittings for wear or damage before each use.
Drain the air tank / receiver of the compressor daily; Water in the air line will
damage the drill.
In the event that it becomes necessary to store the tool for an extended period
of time (overnight, weekend, etc.), it should receive a generous amount of lubri-
cation at that time. The tool should be run for approximately 30 seconds to en-
sure oil has been evenly distributed throughout the tool.
The tool should be stored in a clean and dry environment.
Disconnect the air tool from the air supply before changing accessories,
servicing or performing maintenance. Replace or repair damaged parts.
Use genuine parts only. Non-authorised parts may be dangerous and will
invalidate the warranty.
MAINTENANCE
Remove the old needles:
Unscrew the needle housing from the gun body.
REPLACING THE NEEDLES
Remove the circlip and loosen the three hex. bolts around the needle housing.
Pull out the needle holder and remove the old needles.
Fit the new needles into the holder.
Repeat the above, in reverse to secure the new needles to the needle housing.
Caution: Be extremely careful when loosening the three hex. bolts, the
needles are spring loaded.

10
CAUTION: If a filter/regulator/lubricator is not installed on the air system,
air operated tools should be lubricated at least once a day or after 2
hours work with 2 to 6 drops of oil, depending on the work environment,
directly through the male fitting in the tool housing.
An automatic in-line filter-regulator-lubricator is recommended (Fig.1) as it in-
creases tool life and keeps the tool in sustained operation. The in-line lubricator
should be regularly checked and filled with air tool oil.
Proper adjustment of the in-line lubricator is performed by placing a sheet of
paper next to the exhaust ports and holding the throttle open for approximately
30 seconds. The lubricator is properly set when a light stain of oil collects on the
paper. Excessive amounts of oil should be avoided.
In the event that it becomes necessary to store the tool for an extended period
of time (overnight, weekend, etc.), it should receive a generous amount of lubri-
cation at that time. The tool should be run for approximately 30 seconds to en-
sure oil has been evenly distributed throughout the tool. The tool should be
stored in a clean and dry environment.
It is most important that the tool be properly lubricated by keeping the air line
lubricator filled and correctly adjusted. Without proper lubrication the tool will not
work properly and parts will wear prematurely.
Use the proper lubricant in the air line lubricator. The lubricator should be of low
air flow or changing air flow type, and should be kept filled to the correct level.
Use only recommended lubricants, specially made for pneumatic applications.
Substitutes may harm the rubber compounds in the tools O-rings and other rub-
ber parts.
LUBRICATION
OPERATING INSTRUCTIONS….cont
Once the needle housing is screwed onto the gun body and is secure:
Put a couple of drops of oil down the air inlet (5).
Connect the needle scaler to the air supply via the air inlet (5).
Set the air regulator (4).
Press the trigger (6) and the tool will operate.
Release the trigger (6) and the tool will stop.
OPERATING THE NEEDLE SCALER
Note: Never start the needle scaler with the needles touching the work-
piece. Allow the tool to reach full speed before starting the descaling op-
eration.
7
Needle scaler Instruction Manual Air fitting (Euro type)
Hex. Key Small Bottle of Oil
Note: If any of the above are missing or damaged, contact your distributor
immediately.
CONTENTS AND ACCESSORIES
GETTING TO KNOW YOUR AIR NEEDLE SCALER
Ref. No. Description
1. Needle
2. Needle housing
3. Gun body
4. Air regulator
5. Air inlet
6. Trigger
1
4
6
5
2 3

8
* level of uncertainty 3 dB(A)
** level of uncertainty 1.03m/s²
TECHNICAL SPECIFICATIONS
Guarantee:
This SIP air needle scaler is covered by a 12 month parts and labour warranty covering
failure due to manufacturers defects. This does not cover failure due to misuse or op-
erating the air needle scaler outside the scope of this manual - any claims deemed
to be outside the scope of the warranty may be subject to charges Including, but not
limited to parts, labour and carriage costs.
This warranty does not cover consumable items such as oil & needles etc.
Failure to lubricate your air tool will shorten its working life and reduce performance.
The warranty does not cover rusting air tools or tools that failed due to the lack of lubri-
cation blades are also not covered by warranty.
GUARANTEE
Note: Proof of purchase will be required before any warranty can be hon-
oured.
SIP Part No. 06781
Blows Per Minute 4500
Average Air Consumption 2.8cfm (79.2 l/min)
Operating Pressure 6.3bar (90psi)
Air Inlet 1/4” bsp
Sound Pressure (LpA) * 101.5 dB(A)
Sound Power (LwA) * 112.5 dB(A)
Vibration ** 15.8 m/s²
9
1. Ensure the air trigger (6) is not depressed before connecting to the air supply.
2. You will require an air pressure of 90psi, and an air flow according to specifica-
tion.
3. WARNING! Ensure the air supply is clean and does not exceed 90psi while oper-
ating the air needle scaler. Too high an air pressure and unclean air will shorten
the product life due to excessive wear, and may be dangerous causing dam-
age and/or personal injury.
4. Drain the compressors air tank (receiver) daily; Water in the air line will damage
the air needle scaler.
5. Recommended hook-up procedure is shown in fig 1.
6. Line pressure should be increased to compensate for unusually long air hoses
(over 8 metres). The minimum hose diameter should be 3/8” I.D. and fittings
must have the highest flow rate that can be fitted to the tool.
7. Keep hoses away from heat, oil and sharp edges; Check hose for wear, and
make certain that all connections are air tight and secure.
This needle scaler is designed for cleaning heavy paint and rust from metal surfaces,
also removing the needle housing allows it to be used as an air hammer but requires
additional chisel set and spring retainer (not included).
Tool
Compressor
Quick Connector Quick Connector
Quick Coupler Quick CouplerAir Hose
Regulator
Lubricator
Filter
Cut Off Valve
Fig. 1
OPERATING INSTRUCTIONS
DESCRIPTION
AIR SUPPLY
