Skil 9781 User manual

ANGLE GRINDER
9781 (F0159781 . . )
SKIL Europe BV - Konijnenberg 60 01/13 2610Z01754
4825 BD Breda - The Netherlands
www.skilmasters.com
 ORIGINAL INSTRUCTIONS 5
NOTICE ORIGINALE 9
ORIGINALBETRIEBSANLEITUNG 15
 ORIGINELE GEBRUIKSAANWIJZING 20
BRUKSANVISNING I ORIGINtAL 26
 ORIGINAL BRUGSANVISNING 30
ORIGINAL BRUKSANVISNING 35
 ALKUPERÄISET OHJEET 40
MANUAL ORIGINAL 45
MANUAL ORIGINAL 50
ISTRUZIONI ORIGINALI 56
EREDETI HASZNÁLATI UTASÍTÁS 61
 PŮVODNÍM NÁVODEM K POUŽÍVÁNÍ 67
 ORİJİNAL İŞLETME TALİMATI 72
 INSTRUKCJA ORYGINALNA 76
 ПОДЛИННИК РУКОВОДСТВА
ПО ЭКСПЛУАТАЦИИ 82
 ОРИГІНАЛЬНА ІНСТРУКЦІЯ
З ЕКСПЛУАТАЦІЇ 89
 ΠΡΩΤΟΤΥΠΟ Ο∆ΗΓΙΩΝ ΧΡΗΣΗΣ 94
 INSTRUCŢIUNI DE FOLOSIRE
ORIGINALE 101
 ОРИГИНАЛНО РЪКОВОДСТВО
ЗА ЕКСПЛОАТАЦИЯ 106
 PÔVODNÝ NÁVOD NA POUŽITIE 112
 ORIGINALNE UPUTE ZA RAD 118
 ORIGINALNO UPUTSTVO ZA RAD 122
 IZVIRNA NAVODILA 127
 ALGUPÄRANE KASUTUSJUHEND 132
 ORIĢINĀLĀ LIETOŠANAS PAMĀCĪBA 137
 ORIGINALI INSTRUKCIJA 142
 ИЗВОРНО УПАТСТВО ЗА РАБОТА 147
 UDHËZIMET ORIGJINALE 153
 168
 165

2













19781
23
4
Watt
2000
5,9 kg
EPTA 01/2003
˃ʽʽʽƯÅÁÆ
Ɩ
ʿˀʽÅÅ
Ɩ
ʿʿÅÅ
M14
ʿʿʽ
Ƙ
ʿˁʽ

3
E
5
6
K

4
H H
7a
8
!
9
7b
0
ACCESSORIES ➞ www.SkILmAStERS.COm

5

Angle grinder 9781
INtRODUCtION
• This tool is intended for grinding, cutting and deburring
metal and stone materials without the use of water; with
the appropriate accessories the tool can also be used for
brushing and sanding
• Cuttingoperationswithabrasivecut-offwheelsare
onlyallowedwhenacut-offguard(availableas
optionalSKILaccessory2610396584)isused
• Read and save this instruction manual 3
tECHNICAL SPECIFICAtIONS 1
tOOL ELEmENtS 2
ASpindle
B Clamping ange
CSpanner
DSpindle-lock button
EAuxiliary handle
F Protective guard
G Mounting ange
H On/o safety switch
JVentilation slots
k Protective guard screw
SAFEtY
GENERAL SAFEtY INStRUCtIONS
WARNING!Readallsafetywarningsandall
instructions. Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious injury. Save
allwarningsandinstructionsforfuturereference. The
term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1)WORKAREASAFETY
a) Keepworkareacleanandwelllit. Cluttered or dark
areas invite accidents.
b) Donotoperatepowertoolsinexplosive
atmospheres,suchasinthepresenceofflammable
liquids,gasesordust. Power tools create sparks which
may ignite the dust or fumes.
c) Keepchildrenandbystandersawaywhileoperating
apowertool. Distractions can cause you to lose control.
2)ELECTRICALSAFETY
a) Powertoolplugsmustmatchtheoutlet.Never
modifythepluginanyway.Donotuseanyadapter
plugswithearthed(grounded)powertools.
Unmodied plugs and matching outlets will reduce risk of
electric shock.
b) Avoidbodycontactwithearthedorgrounded
surfacessuchaspipes,radiators,rangesand
refrigerators.There is an increased risk of electric
shock if your body is earthed or grounded.
c) Donotexposepowertoolstorainorwetconditions.
Water entering a power tool will increase the risk of
electric shock.
d) Donotabusethecord.Neverusethecordfor
carrying,pullingorunpluggingthepowertool.Keep
cordawayfromheat,oil,sharpedgesormoving
parts. Damaged or entangled cords increase the risk of
electric shock.
e) Whenoperatingapowertooloutdoors,usean
extensioncordsuitableforoutdooruse. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
f) Ifoperatingapowertoolinadamplocationis
unavoidable,useanearthleakagecircuitbreaker.
Use of an earth leakage circuit breaker reduces the risk
of electric shock.
3)PERSONALSAFETY
a) Stayalert,watchwhatyouaredoinganduse
commonsensewhenoperatingapowertool.Donot
useapowertoolwhileyouaretiredorunderthe
influenceofdrugs,alcoholormedication. A moment
of inattention while operating power tools may result in
serious personal injury.
b) Usepersonalprotectiveequipment.Alwayswear
eyeprotection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Preventunintentionalstarting.Ensuretheswitchis
intheoff-positionbeforeconnectingtopower
sourceand/orbatterypack,pickinguporcarrying
thetool. Carrying power tools with your nger on the
switch or energising power tools that have the switch on
invites accidents.
d) Removeanyadjustingkeyorwrenchbeforeturning
thepowertoolon. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
e) Donotoverreach.Keepproperfootingandbalance
atalltimes. This enables better control of the power tool
in unexpected situations.
f) Dressproperly.Donotwearlooseclothingor
jewellery.Keepyourhair,clothingandglovesaway
frommovingparts. Loose clothes, jewellery or long hair
can be caught in moving parts.
g) Ifdevicesareprovidedfortheconnectionofdust
extractionandcollectionfacilities,ensuretheseare
connectedandproperlyused. Use of dust collection
can reduce dust-related hazards.
4)POWERTOOLUSEANDCARE
a) Donotforcethepowertool.Usethecorrectpower
toolforyourapplication. The correct power tool will do
the job better and safer at the rate for which it was designed.
b) Donotusethepowertooliftheswitchdoesnotturn
itonandoff. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnecttheplugfromthepowersourceand/or
thebatterypackfromthepowertoolbeforemaking
anyadjustments,changingaccessories,orstoring
powertools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
d) Storeidlepowertoolsoutofthereachofchildren
anddonotallowpersonsunfamiliarwiththepower

6
toolortheseinstructionstooperatethepowertool.
Power tools are dangerous in the hands of untrained users.
e) Maintainpowertools.Checkformisalignmentor
bindingofmovingparts,breakageofpartsandany
otherconditionthatmayaffectthepowertool’s
operation.Ifdamaged,havethepowertoolrepaired
beforeuse. Many accidents are caused by poorly
maintained power tools.
f) Keepcuttingtoolssharpandclean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Usethepowertool,accessoriesandtoolbitsetc.,in
accordancewiththeseinstructions,takinginto
accounttheworkingconditionsandtheworktobe
performed. Use of the power tool for operations dierent
from those intended could result in a hazardous situation.
5)SERVICE
a) Haveyourpowertoolservicedbyaqualifiedrepair
personusingonlyidenticalreplacementparts. This
will ensure that the safety of the power tool is maintained.
SAFEtY INStRUCtIONS FOR ANGLE GRINDERS
1)SAFETYINSTRUCTIONSFORALLOPERATIONS
a) Thispowertoolisintendedtofunctionasagrinder,
sander,wirebrushorcut-offtool.Readallsafety
warnings,instructions,illustrationsand
specificationsprovidedwiththispowertool.Failure
to follow all instructions listed below may result in electric
shock, re and/or serious injury.
b) Thispowertoolisnotrecommendedforpolishing.
Operations for which the power tool was not designed
may create a hazard and cause personal injury.
c) Donotuseaccessorieswhicharenotspecifically
designedandrecommendedbythetoolmanufacturer.
Just because the accessory can be attached to your power
tool, it does not assure safe operation.
d) Theratedspeedoftheaccessorymustbeatleast
equaltothemaximumspeedmarkedonthepower
tool.Accessories running faster than their rated speed
can y apart.
e) Theoutsidediameterandthethicknessofyour
accessorymustbewithinthecapacityratingofyour
powertool.Incorrectly sized accessories cannot be
adequately guarded or controlled.
f) Thearboursizeofwheels,flanges,backingpadsor
anyotheraccessorymustproperlyfitthespindleof
thepowertool.Accessories with arbour holes that do
not match the mounting hardware of the power tool will
run out of balance, vibrate excessively and may cause
loss of control.
g) Donotuseadamagedaccessory.Beforeeachuse
inspecttheaccessorysuchasabrasivewheelsfor
chipsandcracks,backingpadsforcracks,tearor
excesswear,wirebrushesforlooseorcracked
wires.Ifthepowertooloraccessoryisdropped,
inspectfordamageorinstallanundamaged
accessory.Afterinspectingandinstallingan
accessory,positionyourselfandbystandersaway
fromtheplaneoftherotatingaccessoryandrunthe
powertoolatmaximumnoloadspeedforone
minute.Damaged accessories will normally break apart
during this test time.
h) Wearpersonalprotectiveequipment 4. Depending
onapplication,usefaceshield,safetygogglesor
safetyglasses.Asappropriate,weardustmask,
hearingprotectors,glovesandshopaproncapable
ofstoppingsmallabrasiveorworkpiecefragments.
The eye protection must be capable of stopping ying
debris generated by various operations. The dust mask or
respirator must be capable of ltrating particles
generated by your operation. Prolonged exposure to high
intensity noise may cause hearing loss.
i) Keepbystandersasafedistanceawayfromwork
area.Anyoneenteringtheworkareamustwear
personalprotectiveequipment.Fragments of the
workpiece or of a broken accessory may y away and
cause injury beyond the immediate area of operation.
j) Holdpowertoolbyinsulatedgrippingsurfacesonly,
whenperforminganoperationwherethecutting
accessorymaycontacthiddenwiringoritsown
cord. A cutting accessory contacting a “live” wire may
make exposed metal parts of the power tool “live” and
could give the operator an electric shock.
k) Positionthecordclearofthespinningaccessory.If
you lose control, the cord may be cut or snagged and your
hand or arm may be pulled into the spinning accessory.
l) Neverlaythepowertooldownuntiltheaccessoryhas
cometoacompletestop.The spinning accessory may
grab the surface and pull the power tool out of your control.
m)Donotrunthepowertoolwhilecarryingitatyour
side.Accidental contact with the spinning accessory could
snag your clothing, pulling the accessory into your body.
n) Regularlycleanthepowertool’sairvents.The
motor’s fan will draw the dust inside the housing and
excessive accumulation of powdered metal may cause
electrical hazards.
o) Donotoperatethepowertoolnearflammable
materials.Sparks could ignite these materials.
p) Donotuseaccessoriesthatrequireliquidcoolants.
Using water or other liquid coolants may result in
electrocution or shock.
2)KICKBACKANDRELATEDWARNINGS
• Kickback is a sudden reaction to a pinched or snagged
rotating wheel, backing pad, brush or any other accessory.
Pinching or snagging causes rapid stalling of the rotating
accessory which in turn causes the uncontrolled power
tool to be forced in the direction opposite of the
accessory’s rotation at the point of the binding.
• For example, if an abrasive wheel is snagged or pinched
by the workpiece, the edge of the wheel that is entering
into the pinch point can dig into the surface of the
material causing the wheel to climb out or kick out.The
wheel may either jump toward or away from the operator,
depending on the direction of the wheel’s movement at
the point of pinching. Abrasive wheels may also break
under these conditions.
• Kickback is the result of power tool misuse and/or
incorrect operating procedures or conditions and can be
avoided by taking proper precautions as given below.
a) Maintainafirmgriponthepowertoolandposition
yourbodyandarmtoallowyoutoresistkickback
forces.Alwaysuseauxiliaryhandle,ifprovided,for
maximumcontroloverkickbackortorquereaction

7
duringstart-up.The operator can control torque reactions
or kickback forces, if proper precautions are taken.
b) Neverplaceyourhandneartherotatingaccessory.
The accessory may kickback over your hand.
c) Donotpositionyourbodyintheareawherepower
toolwillmoveifkickbackoccurs.Kickback will propel
the tool in the direction opposite to the wheel’s movement
at the point of snagging.
d) Usespecialcarewhenworkingcorners,sharp
edgesetc.Avoidbouncingandsnaggingthe
accessory.Corners, sharp edges or bouncing have a
tendency to snag the rotating accessory and cause loss
of control or kickback.
e) Donotattachasawchainwoodcarvingbladeor
toothedsawblade.Such blades create frequent
kickback and loss of control.
3)SAFETYWARNINGSSPECIFICFORGRINDINGAND
CUttING OFF OPERAtIONS
a) Useonlywheeltypesthatarerecommendedforyour
powertoolandthespecificguarddesignedforthe
selectedwheel.Wheels for which the power tool was not
designed cannot be adequately guarded and are unsafe.
b) Theguardmustbesecurelyattachedtothepower
toolandpositionedformaximumsafety,sotheleast
amountofwheelisexposedtowardstheoperator.
The guard helps to protect the operator from broken
wheel fragments, accidental contact with wheel and
sparks that could ignite clothing.
c) Wheelsmustbeusedonlyforrecommended
applications.For example: Do not grind with the side of
a cut-o wheel. Abrasive cut-o wheels are intended for
peripheral grinding; side forces applied to these wheels
may cause them to shatter.
d) Alwaysuseundamagedwheelflangesthatareof
correctsizeandshapeforyourselectedwheel.
Proper wheel anges support the wheel thus reducing
the possibility of wheel breakage. Flanges for cut-o
wheels may be dierent from grinding wheel anges.
e) Donotuseworndownwheelsfromlargerpowertools.
A wheel intended for a larger power tool is not suitable for
the higher speed of a smaller tool and may burst.
4)ADDITIONALSAFETYWARNINGSSPECIFICFOR
CUttING OFF OPERAtIONS
a) Donot“jam”thecut-offwheelorapplyexcessive
pressure.Donotattempttomakeanexcessivedepth
ofcut.Overstressing the wheel increases the loading and
susceptibility to twisting or binding of the wheel in the cut
and the possibility of kickback or wheel breakage.
b) Donotpositionyourbodyinlinewithandbehind
therotatingwheel.When the wheel, at the point of
operation, is moving away from your body, the possible
kickback may propel the spinning wheel and the power
tool directly at you.
c) Whenthewheelisbindingorwheninterruptingacut
foranyreason,switchoffthepowertoolandholdthe
powertoolmotionlessuntilthewheelcomestoa
completestop.Neverattempttoremovethecut-off
wheelfromthecutwhilethewheelisinmotion,
otherwisekickbackmayoccur.Investigate and take
corrective action to eliminate the cause of wheel binding.
d) Donotrestartthecuttingoperationinthe
workpiece.Letthewheelreachfullspeedand
carefullyre-enterthecut.The wheel may bind, walk up
or kickback if the power tool is restarted in the workpiece.
e) Supportpanelsoranyoversizedworkpieceto
minimizetheriskofwheelpinchingandkickback.
Large workpieces tend to sag under their own weight.
Supports must be placed under the workpiece near the
line of cut and near the edge of the workpiece on both
sides of the wheel.
f) Useextracautionwhenmakinga“pocketcut”into
existingwallsorotherblindareas.The protruding
wheel may cut gas or water pipes, electrical wiring or
objects that can cause kickback.
5)SAFETYWARNINGSSPECIFICFORSANDING
OPERAtIONS
a) Whensanding,donotuseexcessivelyoversized
sandingdiscpaper.Followthemanufacturers’
recommendationswhenselectingsandingpaper.
Larger sanding paper extending beyond the sanding pad
presents a laceration hazard and may cause snagging,
tearing of the disc, or kickback.
6)SAFETYWARNINGSSPECIFICFORWIRE
BRUSHING OPERAtIONS
a) Beawarethatwirebristlesarethrownbythebrush
evenduringordinaryoperation.Donotoverstress
thewiresbyapplyingexcessiveloadtothebrush.
The wire bristles can easily penetrate light clothing and/
or skin.
b) Iftheuseofaguardisrecommendedforwire
brushing,donotallowanyinterferenceofthewire
wheelorbrushwiththeguard.Wire wheel or brush may
expand in diameter due to work load and centrifugal forces.
GENERAL
• This tool is not suitable for wet grinding/cutting
• Only use the anges which are supplied with this tool
• This tool should not be used by people under the age of
16 years
• Alwaysdisconnectplugfrompowersourcebefore
makinganyadjustmentorchanginganyaccessory
ACCESSORIES
• SKIL can assure awless functioning of the tool only
when the correct accessories are used which can be
obtained from your SKIL dealer
• For mounting/using non-SKIL accessories observe the
instructions of the manufacturer concerned
• Useonlygrinding/cuttingdiscswithamaximum
thicknessof8mmandaspindleholediameterof
22mm
• Never use reducors or adaptors to t large-hole grinding/
cutting discs
• Never use accessories with a “blind” threaded hole
smaller than M14 x 21 mm
OUtDOOR USE
• Connect the tool via a fault current (FI) circuit breaker
with a triggering current of 30 mA maximum
BEFORE USE
• Before using the tool for the rst time, it is recommended
to receive practical information
• Always mount auxiliary handle E 2 and protective guard
F 2; never use the tool without them
• Usesuitabledetectorstofindhiddenutilitylinesor
callthelocalutilitycompanyforassistance (contact
with electric lines can lead to re or electrical shock;

8
damaging a gas line can result in an explosion;
penetrating a water pipe will cause property damage or
an electrical shock)
• Donotworkmaterialscontainingasbestos (asbestos
is considered carcinogenic)
• Dust from material such as paint containing lead, some
wood species, minerals and metal may be harmful
(contact with or inhalation of the dust may cause allergic
reactions and/or respiratory diseases to the operator or
bystanders); wearadustmaskandworkwithadust
extractiondevicewhenconnectable
• Certain kinds of dust are classied as carcinogenic (such
as oak and beech dust) especially in conjunction with
additives for wood conditioning; wearadustmaskand
workwithadustextractiondevicewhenconnectable
• Follow the dust-related national requirements for the
materials you want to work with
• Be careful when cutting grooves, especially in supporting
walls (slots in supporting walls are subject to country-
specic regulations; these regulations are to be observed
under all circumstances)
• Securetheworkpiece (a workpiece clamped with
clamping devices or in a vice is held more securely than
by hand)
• Do not clamp the tool in a vice
• Use completely unrolled and safe extension cords with a
capacity of 16 Amps (U.K. 13 Amps)
DURING USE
• Inrush currents cause short-time voltage drops; under
unfavourable power supply conditions, other equipment
may be aected (if the system impedance of the power
supply is lower than 0,104 + j0,065 Ohm, disturbances
are unlikely to occur); if you need further clarication, you
may contact your local power supply authority
• If the cord is damaged or cut through while working, do
not touch the cord, but immediately disconnect the plug
• Never use the tool when cord is damaged; have it
replaced by a qualied person
• In case of electrical or mechanical malfunction,
immediately switch o the tool and disconnect the plug
• In case of current interruption or when the plug is
accidentally pulled out, release switch H 2in order to
prevent uncontrolled restarting
AFtER USE
• After switching o the tool, never stop the rotation of the
accessory by a lateral force applied against it
WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):
• Do not connect the blue (= neutral) or brown (= live) wire
in the cord of this tool to the earth terminal of the plug
• If for any reason the old plug is cut o the cord of this tool,
it must be disposed of safely and not left unattended
USE
• Mounting of accessories 2
! disconnecttheplug
- clean spindle A and all parts to be mounted
- tighten clamping ange B with spanner C while
pushing spindle-lock button D
! pushspindle-lockbuttonDonlywhenspindleA
isatastandstill
- for removing accessories handle vice-versa
! grinding/cuttingdiscsbecomeveryhotduringuse;
donottouchthemuntiltheyhavecooleddown
! alwaysmountbackingpadwhenusingsanding
accessories
! neveruseagrinding/cuttingdiscwithoutthelabel
(“blotter”)whichisgluedontoit(ifprovided)
• Mounting of auxiliary handle E 5
! disconnecttheplug
• Removing/mounting/adjusting of protective guard F 6
! disconnecttheplug
- open protective guard F by loosening screw K
- place protective guard F on the spindle collar of the
tool head and turn it to the required position
(depending on the work to be carried out)
! ensurethattheclosedsideoftheprotective
guardalwayspointstotheoperator
- fasten protective guard F by tightening screw K
• Before using the tool
- ensure that accessory is correctly mounted and rmly
tightened
- check if accessory runs freely by turning it by hand
- test-run tool for at least 30 seconds at highest no-load
speed in a safe position
- stop immediately in case of considerable vibration or
other defects and check tool to determine the cause
• On/o safety switch H 7
- switch on tool 7a
! beawareofthesuddenimpactwhenthetoolis
switchedon
! beforetheaccessoryreachestheworkpiece,the
toolshouldrunatfullspeed
- switch o tool 7b
! beforeswitchingoffthetool,youshouldliftit
fromtheworkpiece
! theaccessorycontinuestorotateforashorttime
afterthetoolhasbeenswitchedoff
• Grinding 8
- move the tool back and forth with moderate pressure
! neveruseacuttingdiscforsidegrinding
• Cutting 9
- do not tilt the tool while cutting
- always move the tool in same direction as arrow on
tool head, in order to prevent the tool from being
pushed out of the cut in an uncontrolled manner
- do not apply pressure on the tool; let the speed of the
cutting disc do the work
- the working speed of the cutting disc depends on the
material to be cut
- do not brake cutting discs with side pressure
• Holding and guiding the tool
! whileworking,alwaysholdthetoolatthe
grey-colouredgriparea(s)0
- always hold the tool rmly with both hands, so you will
have full control of the tool at all times
- provide for a secure stance
- pay attention to the direction of rotation; always hold
the tool so, that sparks and grinding/cutting dust y
away from the body
- keep ventilation slots J 2 uncovered

9
MAINTENANCE/SERVICE
• Always keep tool and cord clean (especially ventilation
slots J 2)
! donotattempttocleanventilationslotsby
insertingpointedobjectsthroughopenings
! disconnecttheplugbeforecleaning
• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool undismantled together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skilmasters.com)
ENVIRONMENT
• Donotdisposeofelectrictools,accessoriesand
packagingtogetherwithhouseholdwastematerial
(only for EU countries)
- in observance of European Directive 2002/96/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol ! will remind you of this when the need for
disposing occurs
DECLARAtION OF CONFORmItY
• We declare under our sole responsibility that this product
is in conformity with the following standards or
standardized documents: EN 60745, EN 61000,
EN 55014, in accordance with the provisions of the
directives 2004/108/EC, 2006/42/EC, 2011/65/EU
• Technicalfileat: SKIL Europe BV (PT-SEU/ENG1),
4825 BD Breda, NL
¹ÊÁÂÆιÆ¼½ÊÇǾ¼½Æ
ȽʹÌÁÇÆËŵÆ¿Áƽ½ÊÁÆ¿
ÍÊÇȽƓˁ˅ʿ˂ʽ¼¹Ɠ
Ĺ¾ÁÂÿʹ¹¾
ÈÈÊÇιÄ¹Æ¹¿½Ê
24.01.2013
NOISE/VIBRATION
• Measured in accordance with EN 60745 the sound
pressure level of this tool is 96 dB(A) and the sound
power level 107 dB(A) (standard deviation: 3 dB), and the
vibration ✱ (hand-arm method; uncertainty K = 1.5 m/s²)
✱ when surface grinding 10.1 m/s²
✱ when sanding 5.1 m/s²
! otherapplications(suchascutting-offorwire
brushing)mayhavedifferentvibrationvalues
• The vibration emission level has been measured in
accordance with a standardised test given in EN 60745; it
may be used to compare one tool with another and as a
preliminary assessment of exposure to vibration when
using the tool for the applications mentioned
- using the tool for dierent applications, or with dierent
or poorly maintainted accessories, may signicantly
increase the exposure level
- the times when the tool is switched o or when it is
running but not actually doing the job, may signicantly
reduce the exposure level
! protectyourselfagainsttheeffectsofvibration
bymaintainingthetoolanditsaccessories,
keepingyourhandswarm,andorganizingyour
workpatterns

Meuleused’angle 9781
INtRODUCtION
• Cet outil sert au meulage, au tronçonnage et à l’ébarbage
de pièces en métal et en pierre sans utiliser de l’eau;
combiné avec des accessoires spéciques, cet outil peut
également servir au brossage et au ponçage
• Lesopérationsdecoupeavecdisquesà
tronçonnerabrasifsnesontautoriséesquesiune
protectiondetronçonnage(disponibleenoption
commeaccessoireSKIL2610396584)estutilisée
• Lisez et conservez ce manuel d’instruction 3
SPECIFICAtIONS tECHNIQUES 1
ELEMENTSDEL’OUTIL2
AArbre
BBride de serrage
C Clé
DBouton de blocage de l’arbre
E Poignée auxiliaire
FProtège-main
GBride de montage
H Interrupteur marche/arrêt de sécurité
J Fentes de ventilation
kVis du protège-main
SECURItE
INStRUCtIONS GENERALES DE SECURItE
ATTENTION!Liseztouslesavertissementsde
sécuritéettouteslesinstructions. Ne pas suivre les
avertissements et instructions peut entraîner un choc
électrique, un incendie et/ou de graves blessures sur les
personnes. Conserveztouslesavertissementsettoutes
lesinstructionspourpouvoirs’yreporter
ultérieurement. La notion d’”outil électroportatif” dans les
avertissements se rapporte à des outils électriques raccordés
au secteur (avec câble de raccordement) et à des outils
électriques à batterie (sans câble de raccordement).
1)SECURITEDELAZONEDETRAVAIL
a) Maintenezl’endroitdetravailpropreetbienéclairé.
Un lieu de travail en désordre ou mal éclairé augmente le
risque d’accidents.
