Skil 3335-01 Operating and s Quick guide

For English Version Version française Versión en español
See page 2 Voir page 18 Ver la página 34
Operating/Safety Instructions
Consignes d’utilisation/de sécurité
Instrucciones de funcionamiento y seguridad
IMPORTANT: IMPORTANT : IMPORTANTE:
Read Before Using Lire avant usage Leer antes de usar
1-877-SKIL999 (1-877-754-5999) www.skil.com
Call Toll Free for
Consumer Information
&Service Locations
Pour obtenir des informations
et les adresses de nos centres
de service après-vente,
appelez ce numéro gratuit
Llame gratis para
obtener información
para el consumidor y
ubicaciones de servicio
3335-01
SM 2610957121 05-08 6/5/08 7:35 AM Page 1

2.
Work Area
KEEP CHILDREN AWAY
Do not let visitors contact tool or extension cord. All
visitors should be kept safe distance from work area.
KEEP WORK AREAS CLEAN
Cluttered areas and benches invite accidents.
MAKE WORKSHOP KID-PROOF
With padlocks, master switches, or by removing
starter keys.
AVOID DANGEROUS ENVIRONMENTS
Don’t use power tools in damp or wet locations. Keep
work area well lit. Do not expose power tools to rain.
Do not use the tool in the presence of flammable liq-
uids or gases.
Personal Safety
KNOW YOUR POWER TOOL
Read and understand the owner’s manual and labels
affixed to the tool. Learn its application and limitations
as well as the specific potential hazards peculiar to
this tool.
DON’T OVERREACH
Keep proper footing and balance at all times.
STAY ALERT
Watch what you are doing. Use common sense. Do
not operate tool when you are tired. Do not operate
while under medication or while using alcohol or other
drugs.
WEAR PROPER APPAREL
Do not wear lose clothing, gloves, neckties, rings,
bracelets, or other jewelry which may get caught in
moving parts. Nonslip footwear is recommended.
Wear protective hair covering to contain long hair.
ALWAYS USE SAFETY GLASSES
Also use face or dust mask if cutting operation is dusty,
and ear plugs during extended periods of operation.
Everyday eyeglasses have only impact resistant lens-
es, they are NOT safety glasses.
GUARD AGAINST ELECTRIC SHOCK
Prevent body contact with grounded surfaces. For
example: pipes, radiators, ranges, refrigerator enclo-
sures.
DISCONNECT TOOLS FROM POWER SOURCE
When not in use, before servicing, when changing
blades, bits, cutters, etc.
KEEP GUARDS IN PLACE
In working order, and in proper adjustment and align-
ment.
REMOVE ADJUSTING KEYS AND WRENCHES
When not in use, before servicing, when changing
blades, bits, cutters, etc.
REDUCE THE RISK OF UNINTENTIONAL STARTING
Make sure the switch is in the “OFF” position before
plugging in tool.
GROUND ALL TOOLS
This tool is equipped with an approved 3-conductor
cord and a 3 prong grounding type plug to fit the prop-
er grounding type receptacle. The green conductor in
the cord is the grounding wire. Never connect the
green wire to a live terminal.
NEVER STAND ON TOOL OR ITS STAND
Serious injury could occur if the tool is tipped or if the
cutting tool is accidentally contacted. Do not store
materials on or near the tool such that it is necessary
to stand on the tool or its stand to reach them.
CHECK DAMAGED PARTS
Before further use of the tool, a guard or other part
that is damaged should be carefully checked to
ensure that it will operate properly and perform its
intended function. Check for alignment of moving
parts, mounting, and any other conditions that may
affect its operation. A guard or other part that is dam-
aged should be properly replaced.
All repairs, electrical or mechanical,
should be attempted only by trained
repairmen. Contact the nearest Skil Factory
Service Center, Authorized Service Station or
other competent repair service.
Use only Skil replacement parts; any
others may create a hazard.
The use of any other accessories not
specified in the current Skil catalog,
may create a hazard.
General Safety Rules
READ ALL INSTRUCTIONS. Failure to follow the safety rules listed below and other basic
safety precautions may result in serious personal injury.
“SAVE THESE INSTRUCTIONS”
WARNING
!
WARNING
!
WARNING
!
WARNING
!
SM 2610957121 05-08 6/5/08 7:35 AM Page 2

3.
Tool Use
DON’T FORCE TOOL
It will do the job better and safer at the rate for which
itwas designed.
USE THE RIGHT TOOL
Don’t force a small tool or attachment to do the job of
aheavy duty tool. Don’t used tool for purpose not
intended—for example, don’t use a circular saw for
cutting tree limbs or logs.
SECURE WORK
Use clamps or a vise to hold work. It’s safer than
using your hand and it frees both hands to operate the
tool.
NEVER LEAVE TOOL RUNNING UNATTENDED
Turn power off. Don’t leave tool until it comes to a
complete stop.
Tool Care
DO NOT ALTER OR MISUSE TOOL
These tools are precision built. Any alteration or mod-
ification not specified is misuse and may result in dan-
gerous conditions.
AVOID GASEOUS AREAS
Do not operate electric tools in a gaseous or explo-
sive atmosphere. Motors in these tools normally
spark, and may result in a dangerous condition.
MAINTAIN TOOLS WITH CARE
Keep tools sharp and clean for best and safest per-
formance. Follow instructions for lubricating and
changing accessories. Inspect tool cords periodically
and if damaged, have repaired by authorized service
facility. Inspect extension cords periodically and
replace if damaged. Keep handles dry, clean and free
from oil and grease.
Before connecting the tool to a power
source (receptacle, outlet, etc.), be
sure voltage supplied is the same as that specified
on the nameplate of the tool. Apower source with a
voltage greater than that specified for the tool can
result in serious injury to the user, as well as damage
to the tool. If in doubt, DO NOT PLUG IN THE TOOL.
Using a power source with a voltage less than the
nameplate rating is harmful to the motor .
General Safety Rules
WARNING
!
For your own safety, do not operate your scroll saw
until it is completely assembled and installed according
to the instructions...and until you have read and under-
stood the following:
1. General Safety Rules ....................................2-4
2. Motor Specifications and Electrical
Requirements ........................................................6
3. Getting to Know Your Scroll Saw....................9
4. Operating Adjustments ............................10-13
5. Basic Scroll Saw Operations ....................14-16
6. Maintaining Your Scroll Saw..........................17
7. Troubleshooting ..............................................17
8. STABILITY OF SAW
Your Scroll Saw must be bolted securely to a stand or
workbench. In addition, if there is any tendency for the
Scroll Saw to tip over or move during certain opera-
tions, such as cutting long, heavy boards, bolt your
Scroll Saw stand or workbench to the floor.
9. LOCATION
This Scroll Saw is intended for indoor use only.
10. PROTECTION: Eyes, hands, face, ears and
body.
TO AVOID BEING PULLED INTO THE BLADE—
DO NOT WEAR: Loose Fitting Gloves
Necktie
Loose Clothing
Jewelry
DO: TIE BACK LONG HAIR
ROLL LONG SLEEVES ABOVE ELBOWS
a. If any part of your saw is missing, malfunctioning,
has been damaged or broken . . . such as the motor
switch, or other operating control, a safety device or the
power cord...cease operating immediately until the par-
ticular part is properly repaired or replaced.
b. Do not cut piece too small to hold by hand.
HINT: When making a very small cut out, always
secure the workpiece to a scrap piece of plywood with
double-faced tape. This way, the work is supported and
your fingers are away from the blade.
Additional Safety Rules for Scroll Saws
SM 2610957121 05-08 6/5/08 7:35 AM Page 3

4.
Additional Safety Rules
c. Never turn your Scroll Saw on before clearing the
table of all objects (tools, scraps of wood, etc.) except
for the workpiece and related feed or support devices
for the operation planned.
d. Avoid awkward hand positions where a sudden slip
could cause a hand to move into the blade.
•ALWAYS adjust the drop foot to just clear the work-
piece to protect the operator, keep blade breakage
to a minimum and provide maximum support for
blade.
• Always adjust blade tension correctly.
•The Scroll Saw should cut on the down stroke.
Always make sure blade teeth are oriented down-
ward toward table.
•When cutting a large piece of material, make sure
it is supported at table height.
• Hold the work firmly against the table.
• Do not feed the material too fast while cutting. Only
feed the material fast enough so that the blade will
cut. Keep fingers away from the blade.
• Use caution when cutting off material which is irreg-
ular in cross section‚ it could pinch the blade before
the cut is completed. A piece of molding, for exam-
ple, must lay flat on the table and not be permitted
to rock while being cut.
• Use caution when cutting off round material such
as dowel rods or tubing. They have a tendency to
roll while being cut, causing the blade to “bite”.
e. Never leave the Scroll Saw running unattended.
Turn the saw OFF, make sure the saw has come to a
complete stop, and then remove plug from power sup-
ply before leaving the work area.
f. Do not perform layout, assembly or setup work on
the table while the cutting tool is operating.
g. Turn saw OFF and remove plug from power supply
outlet before installing or removing an accessory or
attachment.
h.Access Door must be closed before operation.
i. Quick Release Tension Lever should be in down
position before operating.
11. THINK SAFETY
SAFETY IS A COMBINATION OF
OPERATOR COMMON SENSE AND ALERTNESS
ATALL TIMES WHEN THE SCROLL SAW IS BEING
USED.
Do not allow familiarity (gained from frequent use of
your Scroll Saw) to become commonplace. Always
remember that a careless fraction of a second is suf-
ficient to inflict severe injury.
The operation of any power tool
can result in foreign objects being
thrown into the eyes, which can
result in severe eye damage.
Always wear safety goggles that
comply with ANSI Z87.1 before
commencing power tool operation.
Some dust created by power sanding,
sawing, grinding, drilling, and other
construction activities contains chemicals known
to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
•Lead from lead-based paints,
• Crystalline silica from bricks and cement and other
masonry products, and
•Arsenic and chromium from chemically treated lum-
ber.
Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your
exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such
as those dust masks that are specially designed to filter
out microscopic particles.
WARNING
!
NOTE AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS THAT APPEAR
ON OF THE SCROLL SAW HOUSING:
WARNING
!
SM 2610957121 05-08 6/5/08 7:35 AM Page 4

5.
Specific Safety Rules for Scroll Saws
Always disconnect the power cord from the
power source before making any adjustments or
attaching any accessories. Always turn off saw
before disconnecting it to avoid accidental start-
ing when reconnecting to a power source. You
may unexpectedly cause the tool to start leading to
serious personal injury.
Never leave tool running unattended. Turn power
off. Don't leave tool until it comes to a complete stop.
Never leave the switches in "ON" position. Before
plugging the tool in, check that the switches are
"OFF". Accidental start-ups could cause injury.
Do not use tool if switch does not turn it on and
off. Have broken switches replaced by an authorized
service center.
Use only Skil scroll saw blades. Use the right blade
size, style and cutting speed for the material and the
type of cut. Sharp blades minimize stalling and kick-
backs. Blade teeth should point down toward the
table.
Avoid awkward operations and hand positions
and always make sure you have good balance. A
sudden slip could cause your hand to move into the
blade.
Firmly clamp or bolt your scroll saw station to a
stable, level workbench or table. The most com-
fortable table height is approximately waist height.
Never stand on tool. Serious injury could occur if
the tool is tipped or if the blade is unintentionally con-
tacted.
Before making a cut, be sure all adjustments are
secure. Loose table or guards could shift in use and
cause you to loose control of the workpiece.
Always adjust drop foot to just clear the work-
piece. Proper adjustment of the drop foot will help
protect your fingers and keep blade breakage to a
minimum.
Always support large workpieces while cutting to
minimize risk of blade pinching and kickback.
Heavy workpiece may cause the table to slip, walk or
slide while cutting.
Be sure the blade path is free of nails. Inspect for
and remove nails from lumber or workpiece before
cutting or sanding.
Keep hands away from cutting area. Do not hand
hold pieces so small that your fingers go under the
blade guard. Do not reach underneath work or in
blade cutting path with your hands and fingers for any
reason.
Never start the tool when the blade is in contact
with the workpiece. Allow the motor to come up
to full speed before starting a cut. Blade in contact
with the workpiece on start up will cause it to jump.
Observe and follow correct direction of feed and
do not feed the material too quickly. Hold the
work firmly against the table. Feed work into a
blade against the teeth of the blade. Feeding materi-
al too forcefully may cause blade to snap.
Use caution when cutting materials with an irreg-
ular cross-section or rounds like dowel rods. If
possible lay the material on its "flat" side when
cutting. For round stock use a "Vee" block to
support the material. Wavy material like molding
will tend to rock and may bind while cutting. Rounds
will tend to roll while being cut and the blade may
"bite" and grab it from your control.
Do not remove jammed cutoff pieces until blade
has stopped. Never touch blade or other moving
parts during use. Contacting the blade or other
moving mechanism may cause injury.
Wear eye protection and respiratory protection.
Know how to shut off tool in an emergency.
Do not expose to rain or use in damp locations.
Grounding required.
SM 2610957121 05-08 6/5/08 7:35 AM Page 5

General Specifications
Voltage Rating . . . . . . . . . . . . . . . . . . .120 V, 60 Hz
Amperage Rating . . . . . . . . . . . . . . . . . . . . . . .1.2 A
No Load Speed . . . . . . . . .No500-1,700/min (SPM)
Throat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16"
Blade . . . . . . . . . . . . . . . . . . . . . . . . . . . .5” pin-end
Blade Stroke . . . . . . . . . . . . . . . . . . . . . . . . . . . .7/8"
Cutting Capacity . . . . . . . . . . . . . . . . . . . . .2" at 90°
Table Tilt . . . . . . . . . . . . . . . . . . . . . . . 0° to 45° Left
Motor Specifications
In the event of a malfunction or breakdown, grounding pro-
vides a path of least resistance for electric current to reduce
the risk of electric shock. This tool is equipped with an elec-
tric cord having an equipment-grounding conductor and a
grounding plug. The plug must be plugged into a match-
ing outlet that is properly installed and grounded in accor-
dance with all local codes and ordinances.
This Scroll Saw is designed to use a 1700 RPM motor. It is
wired for operation on 110-120 volts, 60 Hz. alternating cur-
rent. Before connecting the motor cord to power source,
make certain the switch is in the “OFF” position and be sure
the electric current is of the same characteristics as
stamped on the scroll saw nameplate.
Connection ToAPower Source
This machine must be grounded while in use to protect the
operator from electric shock.
Plug power cord into a 110-120V properly grounded type
outlet protected by a 15-amp dual element time delay fuse
or circuit breaker.
Not all outlets are properly grounded. If you are not sure
that your outlet, as pictured in Fig. 1, is properly
grounded; have it checked by a qualified electrician.
To avoid electric shock, do not touch
the metal prongs on the plug when
installing or removing the plug to or from the outlet.
Failure to properly ground this power
tool can cause electrocution or seri-
ous shock, particularly when used near metal
plumbing or other metal objects. If shocked, your
reaction could cause your hands to hit the tool.
If power cord is worn, cut or damaged
in any way, have it replaced immedi-
ately to avoid shock or fire hazard.
Your unit is for use on 120 volts; it has a plug that looks
like the one in Figure 1.
This power tool is equipped with a 3-conductor cord and
grounding type plug, approved by Underwriters
Laboratories and the Canadian Standards Association.
The ground conductor has a green jacket and is
attached to the tool housing at one end and to the
ground prong in the attachment plug at the other end.
If the outlet you are planning to use for this power tool is
of the two-prong type, DO NOT REMOVE OR ALTER
THE GROUNDING PRONG IN ANY MANNER.. Have a
qualified electrician replace the TWO-prong outlet with a
properly grounded THREE-prong outlet.
Improper connection of the equipment-grounding
conductor can result in a risk of electric shock. The con-
ductor with insulation having an outer surface that is
green with or without yellow stripes is the equipment-
conductor. If repair or replacement of the electric cord or
plug is necessary, do not connect the equipment-
grounding conductor to a live terminal.
Check with a qualified electrician or service personnel if
the grounding instructions are not completely under-
stood, or if in doubt as to whether the tool is properly
grounded.
Always use proper extension cord. The use of any exten-
sion cord will cause some loss of power. To keep this to
aminimum and to prevent overheating and motor burn-
out, use the table below to determine the minimum wire
size (A.W.G.) extension cord. Use only 3-wire extension
cords which have 3-prong grounding type plugs and 3-
pole receptacles which accept the tool’s plug. Make sure
your extension cord is in good condition.
Extension Cord Length Wire Size A.W.G.
0-25 feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
26-50 feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
51-100 feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
6.
Motor Specifications and Electrical Requirements
“SAVE THESE INSTRUCTIONS”
DANGER
!
DANGER
!
WARNING
!
FIG. 1
SM 2610957121 05-08 6/5/08 7:35 AM Page 6

7.
Table of Contents
General Safety Rules ............................................2-4
Specific Safety Rules for Scroll Saws ......................5
Motor Specifications and Electrical Requirements ..6
Table of Contents ....................................................7
Unpacking and Checking Contents ..........................8
Getting to Know Your Scroll Saw ............................9
Assembly and Adjustments ..............................10-13
Basic Scroll Saw Operation ..............................14-16
Maintaining Your Scroll Saw ..................................17
Troubleshooting ......................................................17
SM 2610957121 05-08 6/5/08 7:35 AM Page 7

8.
To avoid injury from unexpected start-
ing or electrical shock, always remove
plug from power source when tool is not in use.
Model 3335-01 Motorized Scroll Saw is shipped com-
plete in one carton.
1. Unpacking and Checking Contents. Separate all
“loose parts” from packing materials and check
each item with the “Table of Loose Parts” to make
sure all items are accounted for before discarding
any packing material.
If any parts are missing, do not
attempt to operate Scroll Saw, plug in
the power cord or turn the switch on until the miss-
ing parts are obtained and are installed correctly.
Table of Loose Parts
Item Description Qty.
A Scroll saw with light attached ..........................1
B Extra pin blade..................................................1
C Allen Wrench (4 mm)........................................1
D Operating Guide ..............................................1
NOTE: Hardware to mount this Scroll Saw to a bench
or leg set is NOT supplied.
2. If you wish, you may apply a coat of paste wax to
the table to allow the workpiece to slide easily
across the table surface. Wipe the table thorough-
ly with a clean dry cloth.
COMBINATION SQUARE MUST BE TRUE
Check its accuracy as illustrated below.
Unpacking and Checking Contents
Tools Needed
WARNING
!
WARNING
!
COMBINATION SQUARE SHOULD BE NO GAP OR OVERLAP WHEN
SQUARE IS FLIPPED OVER IN DOTTED POSITION
DRAW LIGHT LINE
ON BOARD ALONG
THIS EDGE
STRAIGHT EDGE OF
BOARD 3/4"(19mm) THICK-
THIS EDGE MUST BE
PERFECTLY STRAIGHT
PHILLIPS SCREWDRIVER
FIG. 1
A
FIG. 2
B
C
D
SM 2610957121 05-08 6/5/08 7:35 AM Page 8

9.
Getting to Know Your Scroll Saw
2
1
7
6
4
9
5
3
1
8
10
11
12
13
14
15
16
17
1Rubber bearing covers
2Blade tension lever
3Light
4Blade guard foot lock knob
5Sawdust blower
6Blade guard foot
7Table
8Lower blade holder and screw
9Table/bevel lock knob
10 Angle/bevel scale and pointer
11 Base
12 Storage area
13 Upper blade holder and screw
14 Table insert
15 Sawdust collection port
16 On/off switch
17 Speed control Dial
18 Table adjusting screw
18
SM 2610957121 05-08 6/5/08 7:35 AM Page 9

10.
Assembly and adjustments
Disconnect the plug from the power
source before making any assembly,
adjustments or changing accessories. Such preven-
tive safety measures reduce the risk of starting the tool
accidentally.
Assembly instructions
No assembly required. Prior to making adjustments you
may want to mount the scroll saw on a stable surface.
See Bench mounting the saw.
Align the bevel indicator (Fig. 3–6)
The bevel indicator has been factory adjusted. It should
be rechecked prior to use for best operation.
1. Remove the blade guard foot (1) using the hex key (2)
to loosen the screw.
2. Loosen the table bevel lock knob (3) and move the
table until it is approximately at a right angle to the
blade.
3. Loosen the locking nut (5) on the table adjusting screw
(6) under the table by turning it counterclockwise.
Lower the table adjusting screw by turning it clock-
wise.
4. Use a combination square (7) to set the table exactly
90°to the blade (8).Ifthere is space between the
square and blade, adjust the table angle until the
space is closed.
5. Lock the table bevel lock knob under the table (3) to
prevent movement.
6. Tighten the adjusting screw under the table until the
tip of the screw touches the table. Tighten the lock nut.
7. Loosen the screw (4) holding the bevel scale pointer
and position pointer to 0°. Tighten the screw.
8. Attach the blade guard foot (1) using the hex key (2),
so that the foot rests flat against the table. Tighten the
screw.
Note: Avoid setting the edge of the table against the top
of the motor, which could cause noise when the saw is
running.
FIG. 3
2
FIG. 4
1
2
FIG. 5
FIG. 6
1
4
3
6
5
7
8
WARNING
!
SM 2610957121 05-08 6/5/08 7:35 AM Page 10

11.
Assembly and adjustments
Bench mounting the saw
Before operating the saw, it must be firmly mounted to a
workbench or another rigid frame.
Use the base of the saw to mark and pre-drill the mount-
ing holes If the saw is to be used in one location, per-
manently secure it to the work surface using wood
screws if mounting to wood. Use bolts, washers, and
nuts if mounting into metal.
To reduce noise and vibration, install a soft foam pad
(not supplied) between the scroll saw and the work-
bench.
To reduce the risk of injury:
•When carrying the saw, hold it close to your body to
avoid injury to your back. Bend your knees when lifting
the saw.
•Carry the saw by the base. Do not carry the saw by the
power cord.
•Secure the saw in a position where people cannot
stand, sit, or walk behind it. Debris thrown from the saw
could injure people standing, sitting, or walking behind
it.
•Secure the saw on a firm, level surface where the saw
cannot rock and there is adequate room for handling
and properly supporting the workpiece.
Blade guard foot adjustment (Fig. 7 and 8)
When cutting at angles, the blade guard foot should be
adjusted so it is parallel to the table and rests flat
abovethe workpiece.
1. To adjust, loosen the screw (2),tilt the foot (1) so it is
parallel to the table, and tighten the screw.
2. Loosen the height adjustment knob (3) to raise or
lower the foot until it just rests on top of the workpiece.
Tighten the knob.
No assembly required. Prior to making adjustments you
may want to mount the scroll saw on a stable surface.
See Bench mounting the saw.
Adjusting the dust blower (Fig. 9)
For best results, the dust blower tube (4) should be
adjusted to direct air at both the blade and the work-
piece.
FIG. 7
1
1
FIG. 8
3
FIG. 9
4
2
WARNING
!
SM 2610957121 05-08 6/5/08 7:35 AM Page 11

12.
Assembly and adjustments
Sawdust collection port (Fig. 10 and 11)
This scroll saw allows a hose or vacuum accessory (not
provided) to be connected to the dust chute (1).
If excessive sawdust buildup occurs inside the base,
use a wet/dry vacuum cleaner or manually remove saw-
dust by removing the screws (2) and metal plate on the
left side of the saw. Reattach the metal plate and screws
before starting the saw. This will keep your saw cutting
efficiently.
Blade selection (Fig. 12)
This scroll saw accepts both both pin-end and plain-end
5" length blades, with a wide variety of blade thickness-
es and widths. The type of material and intricacies of
cutting operations will determine the number of teeth per
inch. Always select the narrowest blades for intricate
(tight radius and curves) curve cutting and the widest
blades for straight and large curve cutting operations.
The following table represents suggestions for various
materials. When purchasing blades, refer to the back of
the package for best use of blades on various materials.
Use this table as an example, but practice and your own
personal preference will be the best selection method.
When choosing a blade, use very fine, narrow blades to
scroll cut in thin wood 1/4" thick or less.
Use wider blades for thicker materials but this will
reduce the ability to cut tight curves.
Note: Thinner blades will have more possibilities for
blade deflection when cutting angles are not perpendic-
ular to the table.
FIG. 10
1
2
FIG. 11
10 - 15 15 - 28 30 - 48
FIG. 12
Teeth/ Blade Blade Blade/
Inch Width Thickness SPM Material Cut
TPI inch inch
Medium turns on
10-15 0.110 0.018 500-1200 1/4" to 1-3/4" wood,
soft metal, hardwood
Small turns on 1/8"
15-28 0.055-0.110 0.010-0.018 800-1700 to 1-1/2" wood, soft
metal, hardwood
Non-ferrous
30-48 0.024-0.041 0.012-0.019 Varies metals / hardwoods
using very slow speeds
SM 2610957121 05-08 6/5/08 7:35 AM Page 12

Blade removal and installation
(Fig. 13–15)
To reduce the risk of injury always
turn saw OFF and disconnect the plug
from the outlet before removing or replacing the
blade.
This saw uses both pin-end and plain-end blades. Pin-
end blades are thicker for stability and for faster assem-
bly. They provide faster cutting on a variety of materials.
Note: When installing pin-end blades, the slot on the
blade holder must be slightly wider than the thickness of
the blade. After the blade is installed, the blade tension
mechanism will keep it in place.
1. Release blade tension by lifting up the Quick Release
Tension Lever (1) (Fig. 13).
2. Remove the table insert. Carefully pry up on the table
insert and remove.
3. Loosen the upper blade holder screw (2) and lower
blade holder screw (3).Push down on the upper blade
holder to remove the blade from the holder. Remove
the blade from the lower blade holder.
Install the blade with the teeth pointing
downward. If the blade is installed with
the teeth pointing upward, the workpiece will tend to pull
up from the table and will lead to vibration or possible
loss of control of the workpiece.
4. To install the blade, hook the blade in the recess of the
lower blade holder.
5. While pushing down on the upper blade holder, insert-
the blade into the slot of the holder.
6. Tighten the upper and lower blade holder screws.
7. To tension blade, move Quick Release Tension Lever
(1) to “down” position. As the lever is lowered, tension
will be applied to the blade. Make sure the blade is
properly located in the blade holders. Turn the blade
tension knob an additional one full turn clockwise. This
amount of blade pressure should do well for most cut-
ting operations.
ATTENTION: Moving the lever downward should require
moderate, steady pressure only. If heavy pressure is need-
ed, the blade is too tight. Loosen tension by rotating the
Quick Release Tension Lever counterclockwise 1-2 turns,
then reset the tension lever to the “down” position. If the
tension lever is in the “down” position and the blade is too
loose, you can increase tension by leaving the tension
lever “down” and rotating it clockwise just until you feel the
slack in the blade removed. Then turn the tension lever
ONE full turn clockwise. This amount of blade pressure
should do well for most cutting operations and blades.
When the blade tension has been properly adjusted, you
should be able to lift up the Quick Release Tension Lever,
remove and install the blade, lower the lever and return the
original blade tension.
8. Snap the table insert back into place.
13.
Assembly and adjustments
FIG. 13
FIG. 14
1
2
3
FIG. 15
WARNING
!
CAUTION
!
SM 2610957121 05-08 6/5/08 7:35 AM Page 13

Recommendations for cutting
Ascroll saw is basically a curve-cutting machine. It can
also be used for straight cutting and beveling or angle
cutting operations. Please read and understand the fol-
lowing items before attempting to use the saw.
1. When feeding the workpiece into the blade do not
force it against the blade. This could cause blade deflec-
tion. Allow the saw to cut the material by guiding the
workpiece into the blade as it cuts.
2. The blade teeth cut material ONLY on the down
stroke.
3. Guide the wood into the blade slowly because the
teeth of the blade are very small and remove wood only
on the down stroke.
4. There is a learning curve for each person using this
saw. During that period of time it is expected that some
blades will break until you learn how to use the saw.
5. Best results are achieved when cutting wood one inch
thick or less.
6. When cutting wood thicker than one inch, guide the
wood very, very slowly into the blade and take extra care
not to bend or twist the blade while cutting in order to
maximize blade life.
7. Teeth on scroll saw blades wear out and the blades
must be replaced frequently for best cutting results.
Scroll saw blades generally stay sharp for 1/2 hour to 2
hours of cutting.
8.To get accurate cuts, be prepared to compensate for
the blade's tendency to follow the wood grain as you are
cutting.
9. This scroll saw is primarily designed to cut wood or
wood products. For cutting precious and non-ferrous
metals, the variable control switch must be set at very
slow speeds.
10. When choosing a blade, use very fine, narrow blades
to scroll cut in thin wood 1/4" thick or less. Use wider
blades for thicker materials but this will reduce the ability
to cut tight curves.
11. Blades wear faster when cutting plywood or very
abrasive particle board. Angle cutting in hardwoods
wears blades down faster.
12. Always use the foot to keep workpiece against table.
It must be set just above the workpiece for free scrolling
allowance, leaving no more than a gap of 1/16 inch
between the foot and workpiece.
Basic Scroll Saw Operations
14.
ON/OFF switch (Fig. 16)
1. To turn the saw ON, move the switch (1) to the (ON)
position.
2. To turn the saw OFF, move the switch to the (OFF)
position.
3. To lock the switch in the OFF position: a. Wait until the
saw has come to a complete stop.
b. Remove the safety key (2) from the switch housing.
Store the safety key in a safe place.
4. To unlock the switch and turn the saw ON, insert the
safety key into the switch, and move the switch to the
ON position.
Variable Speed Dial (Fig. 16)
1. Your saw is equipped with a variable speed dial (3).
The blade stroke rate may be adjusted by simply rotat-
ing the dial.
To increase speed, rotate dial (3) clockwise.
To reduce speed, rotate dial (3) counterclockwise.
2
FIG. 16
1
3
SM 2610957121 05-08 6/5/08 7:35 AM Page 14

Basic Scroll Saw Operations
To avoid injury from accidental start-
ups, always turn the switch OFF and
unplug the scroll saw before moving the tool,
replacing the blade, or making adjustments.
Interior cutting (Fig. 17)
1. Lay out the design on the workpiece. Drill a 1/4" hole
inthe workpiece.
2. Remove the blade. See Blade removal and installa-
tion.
3. Place the workpiece on the saw table with the hole in
the workpiece over the access hole in the table.
4. Install a blade through the hole in the workpiece.
5. Follow steps 3-7, under Freehand cutting.
6. When finished making the interior scroll cuts simply
turn the scroll saw OFF. Unplug the saw before
removing the blade from the blade holder. Remove
the workpiece from the table.
Freehand cutting (Fig. 18)
1. Lay out desired design, or secure design to the work-
piece.
2. Raise the blade guard foot (1) by loosening the height
adjustment knob (2).
3. Position the workpiece against the blade and place
the blade guard foot against the top surface of the
workpiece.
4. Secure the blade guard foot (1) by tightening the
height adjustment knob (2).
5. Remove the workpiece from the blade prior to turning
the scroll saw ON.
In order to avoid uncontrollable lifting of
the workpiece and to reduce blade break-
age, do not turn the switch on while the workpiece is
against the blade.
6. Slowly feed the workpiece into the blade by guiding
and pressing the workpiece down against the table.
Do not force the leading edge of the
workpiece into the blade. The blade will
deflect, reducing accuracy of cut, and may break.
7. When the cut is complete, move the trailing edge of
the workpiece beyond the blade guard foot. Turn the
switch OFF.
Angle cutting (bevel cutting) (Fig. 19)
1. Layout or secure design to workpiece.
2. Move the blade guard foot to the highest position by
loosening the height adjustment knob (3).Retighten.
3. Tilt the table to the desired angle by loosening the
table bevel lock handle (4) and moving the table to
the proper angle using the degree scale and the
pointer (5).
4. Tighten the table bevel lock handle (4).
5. Loosen the blade guard screw, and tilt the blade
guard to the same angle as the table. Retighten the
blade guard screw. See Hold down clamp adjust-
ment'.
6. Position the workpiece on the right side of the blade.
Lower the blade guard foot against the surface by
loosening the height adjustment knob. Retighten.
7. Follow steps 5–7 under Freehand cutting.
2
FIG. 18
1
45
30
15
3
FIG. 19
4
5
FIG. 17
WARNING
!
CAUTION
!
CAUTION
!
15.
SM 2610957121 05-08 6/5/08 7:35 AM Page 15

16.
Rip or straight line cutting (Fig. 20)
1Raise the blade guard foot (1) by loosening the height
adjustment knob (2).
2.Measure from the tip of the blade to the desired dis-
tance. Position the straight edge parallel to the blade
atthat distance.
3. Clamp the straight edge to the table.
4. Recheck your measurements using the workpiece to
be cut and make sure the straight edge is secure.
5. Position the workpiece against the blade and place
the blade guard foot against the top surface of the
workpiece.
6. Secure the blade guard foot in place by tightening the-
height adjustment knob.
7. Remove the workpiece from the blade prior to turning
the scroll saw ON.
In order to avoid uncontrollable lifting
of the workpiece and reduce blade
breakage, do not turn the switch on while the work-
piece is against the blade.
8. Position the workpiece against the straight edge prior
to touching the leading edge of the workpiece against
the blade.
9. Slowly feed the workpiece into the blade, guiding the
workpiece against the straight edge and pressing the
workpiece down against the table.
Do not force the leading edge of the
workpiece into the blade. The blade
will deflect, reducing accuracy of cut, and may
break.
10. When the cut is complete, move the trailing edge of
the workpiece beyond the blade guard foot. Turn the
switch OFF.
11. Maximum rip cut that can be performed on this saw
is 16 inch.
Basic Scroll Saw Operations
1
FIG. 20
2
Quantity Description
2 Small C-clamps
1 Ruler or measuring tape
112" straight scrap of wood
(thickness to match workpiece)
Tools needed
CAUTION
!
CAUTION
!
SM 2610957121 05-08 6/5/08 7:35 AM Page 16

17.
Maintenance
To reduce the risk of injury, turn
power switch “OFF” and remove
plug from the power source outlet before main-
taining or lubricating your Scroll Saw.
GENERAL
Frequently blow out any dust that may accumu-
late inside the motor.
An occasional coat of paste wax on the work table
will allow the wood being cut to glide smoothly
across the work surface.
Certain cleaning agents and sol-
vents damage plastic parts.
Including: gasoline, carbon tetrachloride, chlori-
nated cleaning solvents, ammonia and household
detergents that contain ammonia. Avoiding use of
these and other types of cleaning agents mini-
mizes the probability of damage.
To avoid shock or fire hazard, if the
power cord is worn, cut or damaged in
any way, have it replaced immediately.
All repairs, electrical or mechanical,
should be attempted only by trained
repairmen. Contact the nearest Skil Factory Service
Center, Authorized Skil Service Station or other com-
petent repair service. Use only Skil replacement parts;
any other may create a hazard.
Lubrication
ARM BEARINGS
Lubricate the arm bearings with oil after 10 hours of
use. Re-oil after every 50 hours of use or whenever
there is a squeak coming from the bearings.
TO LUBRICATE
1. Remove the two rubber bearing covers.
2. Turn saw on its side as shown in (Fig. 21).
3. Squirt a generous amount of SAE 20 oil around the
shaft end and bronze bearing.
4. Let the oil soak in overnight in this condition.
5. Next day repeat the above procedure for the oppo-
site side of the saw.
Use only recommended accessories. Follow instruc-
tions that accompany accessories. Use of improper
accessories may cause hazards. See page 12 for
details on recommended accessories.
Maintaining Your Scroll Saw
Troubleshooting
WARNING
!
CAUTION
!
FIG. 21
WARNING
!
WARNING
!
Turn switch “OFF” and always remove plug
from the power source before trouble
shooting.
TROUBLE: SAW WILL NOT START
PROBLEM 1. Power cord is not plugged in.
2. Fuse or circuit breaker tripped.
3. Cord damaged.
4. Burned out switch.
REMEDY 1. Plug saw in.
2. Replace fuse or reset tripped circuit breaker.
3. Have cord replaced by an Authorized Skil
Service Center or Service Station.
4. Have switch replaced by an Authorized Skil
Service Center or Service Station.
TROUBLE: BLADE DOES NOT COME UP TO SPEED
PROBLEM 1. Extension cord too light or too long.
2. Low house voltage.
REMEDY 1. Replace with adequate cord.
2. Contact your electric company.
WARNING
!
SM 2610957121 05-08 6/5/08 7:35 AM Page 17

18.
Lieu de travail
GARDEZ LES ENFANTS À UNE DISTANCE APPROPRIÉE
Ne laissez pas les visiteurs entrer en contact avec un outil ou un fil
de rallonge. Tous les visiteurs doivent être gardés à une distance
suffisante du lieu de travail pour garantir leur sécurité.
MAINTENEZ LE LIEU DE TRAVAIL PROPRE
Les zones et tables encombrées augmentent les risques
d’accidents.
ASSUREZ LA SÉCURITÉ DES ENFANTS DANS L’ATELIER
Utilisez des cadenas et/ou des coupe-circuits, ou retirez les clés de
mise en marche.
ÉVITEZ LES ENVIRONNEMENTS DANGEREUX
N’utilisez pas les outils dans des endroits humides. Gardez la zone
de travail bien éclairée. N’exposez pas les outils électriques à la
pluie. N’utilisez pas l’outil en présence de liquides ou de gaz
inflammables.
Sécurité personnelle
CONNAISSEZ VOTRE OUTIL ÉLECTRIQUE
Lisez et comprenez le mode d’emploi et les étiquettes apposées
sur l’outil. Apprenez son application et ses limitations, ainsi que
les risques spécifiques possibles associés à l’emploi de cet outil.
NE VOUS PENCHEZ PAS EXCESSIVEMENT
Maintenez toujours une bonne assise pour ne pas risquer de
perdre l’équilibre.
RESTEZ ALERTE
Faites attention à ce que vous faites. Faites preuve de bon sens.
N’utilisez pas cet outil lorsque vous êtes fatigué. Ne vous en servez
pas après avoir consommé de l’alcool ou lorsque vous prenez des
médicaments altérant votre état mental.
PORTEZ DES VÊTEMENTS APPROPRIÉS
Ne portez pas de vêtements lâches, de gants, de cravate, de
bagues, de bracelets ou d’autres bijoux qui risqueraient d’être
attrapés dans des pièces en mouvement. Il est recommandé de
porter des chaussures à semelle antidérapante. Couvrez-vous les
cheveux si vous avez les cheveux longs.
UTILISEZ TOUJOURS DES LUNETTES DE SÉCURITÉ
Utilisez aussi un masque facial ou un masque antipoussières si
l’opération de coupe produit de la sciure, et portez des bouche-
oreilles en cas d’utilisation prolongée. Les lunettes ordinaires
n’ont que des lentilles à l’épreuve des chocs – elles NE sauraient
remplacer des lunettes de sécurité.
PROTECTION CONTRE LES CHOCS ÉLECTRIQUES
Empêchez tout contact de quelconques parties de votre corps
avec des surfaces mises à la terre – par exemple : tuyaux,
radiateurs, cuisinière électrique, enceinte de réfrigérateur.
DÉBRANCHEZ LES OUTILS DE LA SOURCE
D’ALIMENTATION ÉLECTRIQUE
Lorsque l’outil n’est pas utilisé, avant une opération d’entretien,
lors du changement de lames, de mèches, de couteaux, etc.
LAISSEZ LES DISPOSITIFS DE PROTECTION À LEUR PLACE
Enbon ordre de fonctionnement, et bien ajustés et alignés
RETIREZ LES CLÉS ET CLAVETTES DE RÉGLAGE
Lorsque l’outil n’est pas utilisé, avant une opération d’entretien,
lors du changement de lames, de mèches, de couteaux, etc.
DIMINUEZ LE RISQUE DE MISE EN MARCHE ACCIDENTELLE
Assurez-vous que l’interrupteur est dans la position hors tension
(« OFF ») avant de brancher l’outil.
METTEZ TOUS LES OUTILS À LA TERRE
Cet outil est muni d’un cordon à trois conducteurs agréé et d’une
fiche de mise à la terre de type à trois broches qui sont
compatibles avec la prise de mise à la terre du type approprié. Le
conducteur vert du cordon est le fil de mise à la terre. Ne con-
nectez jamais le fil vert à une borne sous tension.
NE MONTEZ JAMAIS SUR L’OUTIL OU SUR SON SUPPORT
Vous risqueriez une blessure grave si l’outil basculait ou en cas de
contact accidentel avec l’outil. Ne placez pas de matériaux sur
l’outil ou à proximité de celui-ci de telle manière qu’il pourrait être
nécessaire de monter sur l’outil ou sur son support pour les
atteindre.
INSPECTEZ LES PIÈCES ENDOMMAGÉES LE CAS ÉCHÉANT
Avant de continuer à utiliser l’outil, inspectez attentivement tout
dispositif de protection ou autre élément endommagé pour vous
assurer qu’il fonctionne correctement et joue le rôle qu’il est censé
jouer. Vérifiez l’alignement des pièces mobiles, les mécanismes de
montage et tous les autres problèmes éventuels qui pourraient
affecter le fonctionnement. Il faut remplacer tout dispositif de
protection ou autre élément endommagé comme il se doit.
Il ne faut demander qu’à des réparateurs
ayant reçu la formation nécessaire
d’effectuer des réparations, qu’elles soient électriques ou
mécaniques. Contactez le Centre de service usine Skil, un
Centre de service après-vente agréé ou un autre service de
réparation qualifié.
N’utilisez que des pièces de rechange
Skil ; l’emploi de pièces différentes
risquerait d’être dangereux.
L’utilisation d’accessoires quelconques
qui ne figurent pas dans le catalogue Skil
actuel risquerait d’être dangereuse.
Consignes générales de sécurité
LISEZ TOUTES LES CONSIGNES. Le non-respect des consignes de sécurité indiquées ci-dessous et d’autres
précautions de sécurité de base peut entraîner des blessures corporelles graves.
«CONSERVEZ CES CONSIGNES D’UTILISATION/DE SÉCURITÉ »
AVERTISSEMENT
!
AVERTISSEMENT
!
AVERTISSEMENT
!
AVERTISSEMENT
!
SM 2610957121 05-08 6/5/08 7:35 AM Page 18

19.
Emploi de l’outil
NE FORCEZ PAS L’OUTIL
L’outil fonctionnera mieux et de façon moins dangereuse à la
vitesse pour laquelle il a été conçu.
UTILISEZ L’OUTIL QUI CONVIENT
Ne forcez pas un petit outil ou accessoire pour faire le travail d’un
outil plus robuste. N’utilisez pas d’outils à des fins pour lesquelles
ils n’ont pas été conçus – par exemple, n’utilisez pas de scie
circulaire pour couper des branches d’arbres ou des bûches.
ASSUJETTISSEZ L’OUVRAGE
Utilisez des brides ou des étaux pour maintenir l’ouvrage en place.
C’est plus sûr que d’utiliser vos mains, et cela vous permet de
vous servir de vos deux mains pour utiliser l’outil.
NE LAISSEZ JAMAIS UN OUTIL EN MARCHE SANS
SURVEILLANCE
Mettez l’outil hors tension. Ne vous en éloignez pas avant qu’il se
soit complètement arrêté.
Entretien de l’outil
N'ALTÉREZ PAS L'OUTIL ET UTILISEZ-LE CONFORMÉMENT
AUX INSTRUCTIONS
Ces outils sont construits avec une grande précision. Toute
altération ou modification non spécifiée constitue une utilisation
non conforme qui risquerait de causer des conditions
dangereuses.
ÉVITEZ D’UTILISER DANS UN ENVIRONNEMENT GAZEUX
N’utilisez pas d’outils électriques dans une atmosphère gazeuse
ou explosive. Les moteurs associés à ces outils produisent
généralement des étincelles qui risqueraient de causer des
conditions dangereuses.
ENTRETENEZ SOIGNEUSEMENT LES OUTILS
Gardez les outils bien aiguisés et propres pour obtenir le meilleur
rendement et réduire les dangers. Suivez les instructions pour
lubrifier et changer les accessoires. Inspectez périodiquement les
cordons électriques des outils et, s’ils sont endommagés, faites-
les réparer par un service de réparation agréé. Inspectez
périodiquement les fils de rallonge et remplacez-les s’ils sont
endommagés. Maintenez les poignées sèches et propres, et
assurez-vous qu’il n’y a pas de taches d’huile ou de graisse.
Avant de brancher l’outil dans une source
d’alimentation électrique (prise de
courant, connecteur de prolongation, etc.), assurez-vous que la
tension fournie est la même que celle qui est indiquée sur la
plaque signalétique de l’outil. Une source d’alimentation
électrique ayant une tension supérieure à celle qui est spécifiée
pour l’outil pourrait causer des blessures graves à l’utilisateur, ainsi
que des dommages à l’outil. Si vous avez le moindre doute, NE
BRANCHEZ PAS L’OUTIL. L’utilisation d’une source d’alimentation
électrique ayant une tension inférieure à celle de la plaque
signalétique est mauvaise pour le moteur.
Consignes générales de sécurité
AVERTISSEMENT
!
Pour votre propre sécurité, ne vous servez pas de votre scie à
chantourner avant qu’elle n’ait été assemblée complètement et
installée conformément aux instructions… et avant d’avoir lu et
compris ce qui suit :
1. Consignes générales de sécurité..........................18-20
2. Spécifications du moteur et spécifications électriques ....22
3. Connaissance élémentaire de votre scie à chantourner ..25
4. Réglages pour l’utilisation ................................26-29
5. Opérations de base avec la scie à chantourner ........30-32
6. Entretien de votre scie à chantourner ........................33
7. Guide de diagnostic..............................................33
8. STABILITÉ DE LA SCIE
Votre scie à chantourner doit être boulonnée solidement à un
support ou à un établi. De plus, si votre scie à chantourner a
tendance à basculer ou à bouger pendant certaines opérations, par
exemple lorsque vous coupez des planches longues et lourdes,
boulonnez votre établi ou le support de la scie à chantourner au sol.
9. EMPLACEMENT
Cette scie à chantournée est conçue exclusivement pour un emploi
àl’intérieur.
10. PROTECTION : yeux, mains, visage, oreilles et corps.
POUR ÉVITER D’ÊTRE HAPPÉ PAR LA LAME –
NE PORTEZ PAS : de gants lâches
de cravate
de vêtements lâches
de bijoux
FAITES CECI : ATTACHEZ VOS CHEVEUX LONGS DERRIÈRE
VOTRE DOS
REMONTEZ VOS MANCHES LONGUES AU-
DESSUS DU COUDE
a. Si un élément quelconque de votre scie est absent, fonctionne
mal ou a été endommagé ou cassé ... comme l’interrupteur du
moteur ou une autre commande affectant le fonctionnement, un
mécanisme de sécurité ou le cordon d’alimentation ... cessez
immédiatement de vous servir de la scie jusqu’à ce que l’élément en
question ait été réparé de façon appropriée ou remplacé.
b. Ne vous servez pas de la scie pour couper un ouvrage qui est
trop petit pour être tenu à la main.
SUGGESTION : lorsque vous faites une très petite coupe,
assujettissez toujours l’ouvrage à un morceau de contreplaqué avec
un ruban adhésif double. De cette manière, l’ouvrage est supporté
et vos doigts ne sont pas trop près de la lame.
Consignes de sécurité additionnelles pour les scies à chantourner
SM 2610957121 05-08 6/5/08 7:35 AM Page 19

20.
Consignes de sécurité additionnelles
c. Ne mettez jamais votre scie à chantourner en place avant
d’avoir nettoyé la table pour vous débarrasser de tous les objets
(petits outils, morceaux de bois, etc.) à l’exception de l’ouvrage et
des dispositifs de support ou d’alimentation que vous comptez
utiliser pour l’opération que vous allez réaliser.
d. Évitez de mettre les bras dans des positions excessivement
étendues telles que vos mains risqueraient d’être happées par la
lame si vous perdez l’équilibre.
• Ajustez TOUJOURS le pied tombant de façon très serrée mais
pour qu’il ne fasse pas obstacle au mouvement de l’ouvrage
afin de protéger l’opérateur, de réduire les risques de bris de
lame au minimum et d’assurer le maximum de support pour la
lame.
• Ajustez toujours la tension de la lame correctement.
•La scie à chantourner doit couper lors de la course
descendante. Assurez-vous toujours que les dents de la lame
sont orientées vers le bas, en direction de la table.
• Lorsque vous coupez un ouvrage de grandes dimensions,
assurez-vous qu’il est bien supporté à la hauteur de la table.
• Tenez l’ouvrage fermement contre la table.
•N’alimentez pas l’ouvrage trop vite pendant la coupe. Alimentez
seulement le matériau à couper assez rapidement pour que la
lame le coupe. Gardez les doigts à une distance suffisante de la
lame.
•Faites attention lorsque vous coupez un ouvrage dont la
section transversale est irrégulière car il risque de pincer la
lame avant la fin de la coupe. Par exemple, une moulure doit
être posée à plat sur la table de façon à ne pas se balancer
pendant l’opération de coupe.
•Faites attention lorsque vous coupez un ouvrage circulaire tel
qu’un tube ou un goujon. Ces ouvrages ont tendance à rouler
pendant l’opération de coupe, ce qui peut entraîner la lame à
«mordre » le matériau.
e. Éteignez la scie (OFF), assurez-vous qu’elle s’est complètement
arrêtée et retirez la fiche de la prise de courant avant de quitter le
lieu de travail.
f. N’effectuez pas de tâches de configuration, d’assemblage ou de
montage sur la table pendant l’outil de coupe est en marche.
g. Éteignez la scie (OFF) et retirez la fiche de la prise de courant
avant d’installer ou de retirer un accessoire.
h. La porte d’accès doit être fermée pendant l’opération.
i. Le levier de tension à relâchement rapide doit être dans la
position abaissée avant que la scie ne soit mise en marche.
11. LA SÉCURITÉ AVANT TOUT
LA SÉCURITÉ EST UNE COMBINAISON
DE BON SENS DE L’OPÉRATEUR ET DE VIVACITÉ D’ESPRIT À
TOUT MOMENT PENDANT QUE LA SCIE EST EN TRAIN DE
FONCTIONNER.
Il faut toujours rester vigilant, même si, au bout d’un certain
temps, le fait d’avoir utilisé souvent votre scie à chantourner
risque de vous faire croire qu’il n’existe aucun danger. Souvenez-
vous toujours qu’une seconde d’inattention est suffisante pour
causer une blessure grave.
L’utilisation de n’importe quel outil
électrique peut causer la projection de
corps étrangers dans les yeux, ce qui
risquerait de causer des lésions graves
aux yeux. Portez toujours des lunettes de
sécurité conformes à la norme ANSI Z87.1
avant de commencer à vous servir d’un outil électrique.
Certaines poussières créées par des
opérations de ponçage, de sciage, de
rectification, de perçage et d’autres activités de construction
avec des outils électriques contiennent des produits chimiques
qui sont connus comme causant des cancers, des malforma-
tions congénitales et d’autres problèmes affectant la repro-
duction. Voici quelques exemples de tels produits chimiques :
• Le plomb de peintures à base de plomb,
•La silice cristalline de briques et de ciment, ainsi que d’autres
produits de maçonnerie, et
•L’arsenic et le chrome de bois d’œuvre ayant subi un traitement
chimique.
Votre risque résultant de telles expositions est variable, selon la
fréquence de votre exposition. Pour réduire votre exposition à de
tels produits chimiques : travaillez dans un endroit bien ventilé et
en portant un matériel de sécurité agréé, comme un masque
antipoussières qui est conçu spécialement pour filtrer les
particules microscopiques.
AVERTISSEMENT
!
PRENEZ NOTE DES AVERTISSEMENTS ET CONSIGNES DE SÉCURITÉ FIGURANT
SUR LE BÂTI DE LA SCIE À CHANTOURNER ET TENEZ-EN COMPTE :
AVERTISSEMENT
!
Fabriquée en Chine
AVERTISSEMENT
Pour réduire le risque de blessures, l’utilisateur doit lire le mode d’emploi. Portez des dispositifs
de protection des yeux et de protection respiratoire. Débranchez la scie avant d’en changer la lame,
d’effectuer un réglage, de la déplacer ou de la ranger. Assujettissez solidement l’outil à une plate-forme ou à un établi stable.
Apprenez comment éteindre l’outil rapidement en cas d'urgence. Les dents de la scie doivent être orientées vers le bas ; maintenez
une tension de lame appropriée et ajustez la hauteur du pied tombant. Attendez que la lame se soit complètement arrêtée pour retirer
des matériaux coincés ou coupés. N’exposez pas à la pluie et n’utilisez pas dans des endroits humides. Mise à la terre requise.
Scie à chantourner de 16 po (406 mm) F012333500
120 V – 60 Hz 1,2 A no500 – 1 700 tr/mn
SM 2610957121 05-08 6/5/08 7:35 AM Page 20
