Skil 3400 User manual

+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
10" TABLE SAW
Model F012340000
CONSUMER
July 2001
open for tool illustration
F/CPos. Part Number Description {Qty} F/CPos. Part Number Description {Qty}
3400
1 2 610 358 924 Motor Housing 71
2 2 610 909 424 Field 120V 22
3 2 610 905 924 Armature w/Fan 120V AW
4 2 610 912 921 Switch On/Off 15
5 2 610 912 922 Cord 11
6 2 610 358 840 Strain Relief 11
7 2 610 358 842 Cord Clamp 89
8 2 610 912 923 Nameplate 9
13 2 610 015 747 Ball Bearing 60
14 2 610 017 349 Ball Bearing 61
19 2 610 358 841 Screw {2} 89
20 2 610 912 925 Label 9
22 2 610 358 803 Spacer {2} 82
23 2 610 358 801 Washer 65
24 2 610 358 802 Washer {4} 65
25 2 610 304 772 Nut {2} 89
26 2 610 358 804 Rubber Pad 88
27 2 610 905 900 Bracket 9
28 2 610 358 806 Pivot {2} 54
29 2 610 358 807 Push Nut {4} 89
30 2 610 358 800 Guard 91
31 2 610 358 811 Pin 66
32 2 610 358 808 Anti-Kickback Pawl {2} 80
33 2 610 358 809 Spacer {2} 82
34 2 610 912 939 Splitter 9
35 2 610 358 810 Spring 27
36 2 610 358 812 Roll Pin 66
37 2 610 358 813 Push Nut {2} 89
38 2 610 703 214 Screw 89
39 2 610 910 013 Washer {2} 65
40 2 610 912 936 Mounting Block 9
41 2 610 358 819 Screw {2} 89
42 2 610 912 937 Bracket 9
43 2 610 912 938 Clamp Plate 89
44 2 610 912 941 Screw {3} 89
45 2 610 998 580 Set Screw 89
46 2 610 912 926 Rip Fence Handle 74
47 2 610 044 563 Nut 89
48 2 610 358 895 Cam Pin 66
49 2 610 358 896 Pin 66
50 2 610 358 894 Roll Pin 66
51 2 610 910 017 Cam 80
52 2 610 358 890 Lever 64
53 2 610 358 891 Front Clamp 80
54 2 610 358 892 Screw {2} 89
55 2 610 358 898 Screw 89
56 2 610 358 899 Spring 27
57 2 610 913 862 Screw 89
58 2 610 912 927 Pointer 9
59 2 610 912 928 Rip Fence Housing 9
60 2 610 358 888 Rip Fence Body 9
61 2 610 358 887 Rear Sliding Pad 88
62 2 610 358 886 Spring 27
63 2 610 358 885 Clamp 80
64 2 610 358 884 Rod 9
65 2 610 912 929 Miter Guage Handle 63
66 2 610 358 907 Washer 65
67 2 610 358 910 Miter Guage Body 9
68 2 610 358 911 Pin 66
69 2 610 358 913 Sliding Pad 88
70 2 610 358 832 Screw {9} 89
71 2 610 990 539 Screw 89
72 2 610 913 860 Pointer 9
73 2 610 912 930 Guide Bar 9
74 2 610 358 858 Arbor Nut 89
75 2 610 358 857 Outer Flange 91
76 2 610 912 924 Base 9
77 2 610 358 914 Shaft 52
78 2 610 358 915 Key 66
79 2 610 015 361 Ball Bearing 61
80 2 610 358 916 Retaining Ring 89
81 2 610 358 920 Screw & Washer {6} 89
82 2 610 358 917 Bearing Cap 56
83 2 610 358 918 Bearing Housing 73
84 2 610 358 919 Spindle Gear 32
85 2 610 358 922 Needle Bearing 56
86 2 610 908 278 Gear Housing 72
87 2 610 358 926 Screw {2} 89
88 2 610 358 936 Washer {2} 65
89 2 610 358 927 Washer 65
90 2 610 358 928 Screw {3} 89
91 2 610 351 107 Nut {2} 89
92 2 610 358 937 Brush Holder Pad {2} 25
93 2 610 358 935 Rear Motor Cover 70
94 2 610 358 932 Connector 10
95 2 610 909 438 Cable 10
96 2 610 998 567 Strain Relief 11
97 2 610 358 822 Insert 9
98 2 610 358 823 Screw {2} 89
99 2 610 358 824 Nut {2} 89
100 2 610 358 826 Screw {6} 89
101 2 610 358 827 Screw 89
102 2 610 358 828 Screw 89
103 2 610 912 931 Table 88
104 2 610 358 451 Scale 9
105 2 610 358 876 Nut {15} 89
®

106 2 610 358 867 Strap {2} 80
107 2 610 912 935 Rod 5
108 2 610 903 744 Strap {4} 80
109 2 610 905 904 Bracket 9
110 2 610 358 863 Screw 89
111 2 610 358 865 Saddle 9
112 2 610 905 908 Screw {3} 89
113 2 610 358 882 Roll Pin {2} 66
114 2 610 908 268 Screw {2} 89
115 2 610 908 270 Washer {2} 65
116 2 610 908 271 Screw {2} 89
117 2 610 908 269 Support Bracket 62
118 2 610 990 544 Motor Bracket 62
119 2 610 910 044 Screw 89
120 2 610 358 860 Screw {3} 89
121 2 610 908 272 Nut {2} 89
122 2 610 358 861 Screw {2} 89
123 2 610 358 862 Spacer {2} 82
124 2 610 358 869 Retaining Ring 89
125 2 610 901 978 Spacer 82
126 2 610 358 874 Rocker Bar 9
127 2 610 358 877 Nut {2} 89
128 2 610 358 878 Washer 65
129 2 610 358 879 Washer 65
130 2 610 358 868 Pin 66
131 2 610 990 545 Mounting Plate 62
132 2 610 903 733 Spring 27
133 2 610 912 932 Adjustment Wheel 63
134 2 610 912 933 Knob 63
135 2 610 990 547 Screw 89
136 2 610 358 833 Washer {2} 65
137 2 610 990 548 Handle Lock 80
138 2 610 358 844 Screw {3} 89
139 2 610 910 018 Switch Cover 9
140 2 610 358 831 Clamp Plate 89
141 2 610 358 846 Rubber Foot {4} 9
142 2 610 702 414 Screw 89
143 2 610 912 934 Label 9
144 2 610 358 830 Screw {4} 89
145 2 610 306 005 Screw {3} 89
146 2 610 026 248 Lock Washer {3} 89
147 2 610 358 881 Pointer 9
148 2 610 990 549 Deflector Plate 9
149 2 610 994 251 Spacer 82
150 2 610 994 252 Bolt 89
151 2 610 358 902 Rail 9
152 2 610 358 903 End Cap {2} 9
153 2 610 905 909 Screw {4} 89
154 2 610 358 904 Spacer {4} 82
155 2 610 911 896 Nut 89
156 2 610 912 945 Mounting Post 9
157 2 610 998 574 Screw 89
158 2 610 997 243 Nut 89
159 2 610 912 946 Label {2} 9
650 2 610 912 940 Wrench 9
651 2 610 996 880 Wrench 89
753 2 610 080 093 Table Saw Stand 9
w/pos. 753/6 - 753/10
753/6 2 610 016 325 Bolt {24} 89
753/7 2 610 994 262 Nut {28} 89
753/8 2 610 967 194 Bolt {4} 89
753/9 2 610 909 178 Washer {4} 65
753/10 2 610 994 283 Foot {4} 9
754 2 610 080 099 Dust Bag Kit 9
w/pos. 754/2
754/2 2 610 990 516 Dust Bag 9
756 2 610 080 089 Table Extension Kit 9
w/pos. 756/2 - 756/7
756/2 2 610 351 293 Washer {6} 65
756/3 2 610 304 772 Nut {3} 89
756/4 2 610 702 414 Bolt {3} 89
756/5 2 610 905 936 Bolt {3} 89
756/6 2 610 911 906 Lock Washer {3} 65
+ 756/7 2 610 994 273 Scale 9
810 2 610 909 439 Brush & Holder Set 25
830 2 610 912 944 Blade Guard Assembly 92
w/pos. 22 - 37, 142
860 2 610 912 942 Rip Fence Assembly 87
w/pos. 24, 41, 46 - 64
867 2 610 912 943 Miter Guage Assembly 87
w/pos. 65 - 73
N/A Not Available Separately
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
F/CPos. Part Number Description {Qty} F/CPos. Part Number Description {Qty}
S-B Power Tool Company Chicago IL 60646-5999
Service Notes:

136
D
F
K
H
G
94
95
96
4
56
20
139
141
157
156
158
19
7
76
8
144
137
136
25
149
138
70
140
132 133
134
135
E
G
B
C
F
F
116
150 122
145
145
146
147
146
113
131148
130
119
105
118
120
122
123
126 127128
129
123
105
L
125
124
153
152
152
154
151
104
B
C
105
112
110
105
106
106
109
111
107
D
98
103
97
99
99 100
100
101
102
108 105
N
45
44
155
38
40
2439 42
A
43 44
143
65
867
67
71
72
73
69
68
66
70
159

30
28
28
142
23
31
24
27
25
29 33 35
22 29
32
34
33
32
26
22
36
37
830
A
754/2
N/A
754
753/10
753/9
753/8
753/7
753/6
753/7
753
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
753/10 753/10
756/2
756/6
756/3
756/2
756/4
756/5
756
N/A
E
78
79
80
82
83
84
85
77
81
86
74
75
14
114 115
117
121
L
J
K
JH
92
2
3
88 87
13
89
90
91
93
810
810
81
1
650
651
41
24
56
60
860
64
63
54
5352
50 47
51
61
62
49
59
58
48
55
57
46
