MAKE YOUR HEART RACING AND
YOUR BLOOD BOILING ...

INTRODUCTION 简介
Congratulations on your choice of the SkyRC
Super Rider SR4. This kit is a high performance
RC vehicle with electronic stabilizing system and
adjustable gyro effect control board. Please
carefully follow the instruction manual during
assembly and pay attention to the warnings.
SKYRC Super Rider SR4 is a fully ready-to-run 1/4
dirt motocross. All electronics and other
components are installed in the factory. The users
only need to install the battery, and then it is ready
to run. It is very stable even at very low speed.
What's more, it is also able to do quick brake and
jump in every different terrain and can do the off-
road function in a superior way.
The point users concern most is the stability of the
motocross. This newly-developed Super Rider SR4
features a revolutionary stability technology ESS
(Electronic Stability System). This system consists
of a gyro effect governor and an electronic gyro in
rear wheel which makes the bike super stable
when running. The users can adjust the RPM of
the electronic gyro according to his request. There
are 4 kinds of RPM that can be selected by user,
8000RPM, 10000RPM, 11000RPM and
12000RPM. The beginners can choose 12000RPM
as the gyro effect is strong at this speed and the
motocross will be more stable. When the users are
familiar with the operation, he can choose lower
RPM and the sensitivity of the motocross will be
higher. Besides that, the oil shock absorbers in
both front and rear wheel also make the SR4 much
more stable than others.
Power is everything in motocross, and the SR4
comes with Toro 540 class 3200KV brushless
motor and Leopard 60A ESC V2. The motor and
ESC are all assemble well in the factory and the
users only need to connect a 2S or 3S Lipo battery
to the motocross, it will be ready to run. The
battery case is located at the bottom of the
motocross, it is simple and easy to take off the bolt,
open the case, put the battery into it and lock the
battery case. When the power system works, it will
burn out monster power. Even the motocross fall
down, the monster power can make it stand up by
itself. Users can run it wherever he feels like and
however fast he wants. Up hills and flying over
jumps or traveling on gravel and grass, dirt or
非常感谢您购买由天空创新科技（深圳）有限
公司研发生产的闪电骑士SR4。这是一款高性能的
电动遥控摩托车，配有电子平衡装置及可调节的陀
螺仪控制装置。安装时，请仔细阅读说明书及各项
警告。
闪电骑士SR4是一款1/4的遥控越野摩托车。所
有的电子零件及其他配件在工厂已经安装好。用户
只需装上遥控器及摩托车电池，就可以尽情操控摩
托车了。此款摩托车的稳定性能非常好，即使是低
速运行。在不同的场地，摩托车都能随时刹车跳
跃，在泥泞道路上能发挥出越野性能。
对于大多数用户来说，最关心的问题就是摩托
车的稳定性。这款最新研发的闪电骑士SR4运用了
开创性的ESS电子平衡系统。此系统由陀螺效应控
制板和后轮内的电子陀螺部件构成，可以提供超级
稳定的驾驶感觉。用户可以根据自己的需求，调节
电子陀螺仪的转速，有4种转速可供调节，
8000RPM, 10000RPM, 11000RPM和12000RPM。
初学者可以选择12000的电子陀螺转速，此时陀螺
效应非常强，稳定性好，摩托车可以超低速前进。
当用户熟悉操作后，可选择稍低的电子陀螺仪转
速，此时摩托车的操作灵敏性增强。除此之外，前
轮及后轮的油压减震系统也使闪电骑士SR4比市场
上其他的摩托车稳定。
对于任何一款遥控模型产品，最重要的莫过于
动力。闪电骑士SR4使用540级3200KV的无刷马达
以及豹子二代60A的无刷电子调速器。马达及电子
调速器在工厂已经安装完成并测试完成，用户只需
装上2节或者3节的锂聚合物电池，摩托车就可以奔
跑了。电池的安装非常简单，只需将电池盒上插销
取下，放入电池，再装上插销即可。通电之后，闪
电骑士将爆发出巨大的能量。即使摩托车在运行过
程中倒下了，仍能依靠自身强大的动力站立起来继
续奔跑。用户可以在任何地方以任何速度奔跑。爬
山，飞跃，跳跃，在草坪，灰尘地，甚至很多沙子
的地面，摩托车都能疾驰而过。直行/突转都在掌控
之中。
铝合金车架加上金属链条让闪电骑士SR4越野
摩托车非常的坚固耐用。配置的遥控器为2.4G，用
