INSTALLATION INSTRUCTIONS FOR EAF-350 SERIES ELECTRONIC,
BATTERY-POWERED, SENSOR-ACTIVATED LAVATORY FAUCETS
Code No: 0816654
Rev. 3 (04/15)
Faucet Variations
-ISM Integral Spout Temperature Mixer
Limited Warranty
Unless otherwise noted, Sloan Valve Company warrants its products, manufactured and sold for commercial or industrial uses, to be free from defects of material
and workmanship for a period of three (3) years (one (1) year for SF faucets, special nish and PWT electronics and 30 days on PWT software) from the date of
rst purchase. During this period, Sloan Valve Company will, at its option, repair, replace, or refund the purchase price of any produce which fails to confom with
this warranty under normal use and service. This shall be the sole and exclusive remedy under this warranty. Products must be returned to Sloan Valve Company,
at customer’s cost. No claims will be be allowed for labor, transportation or other costs. This warranty extends only to persons or organizations that purchase
Sloan Valve Company’s products directly from Sloan Valve Company for purpose of resale. This warranty does not cover the life of batteries.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. IN NO EVENT IS SLOAN VALVE COMPANY RESPONSIBLE FOR ANY
CONSEQUENTIAL DAMAGES OF ANY MEASURE WHATSOEVER.
PRIOR TO INSTALLATION
Prior to installing the Sloan OPTIMA Plus® EAF-350 Series faucets, install the
items listed below. Also, refer to rough-in illustrations.
• Lavatory/sink
• Drain line
• Hot/Cold water supply lines or pre-tempered water supply line
IMPORTANT:
• ALL PLUMBING SHOULD BE INSTALLED IN ACCORDANCE WITH APPLICABLE
CODES AND REGULATIONS.
• FLUSH ALL WATER LINES PRIOR TO MAKING CONNECTIONS.
• KEEP THREAD SEALANT OUT OF YOUR WATERWAY TO PREVENT
COMPONENT PART DAMAGE! DO NOT USE ANY SEALANT ON
COMPRESSION FITTINGS.
Trim Plates
When the EAF faucet is installed on a sink that has three (3) hole punchings,
a trim plate should be used. Trim plates must be specified and ordered
separately.
ETF-312-A Trim Plate for 4” (102 mm) Centerset Sink
ETF-510-A Trim Plate for 8” (203 mm) Centerset Sink
Tools Required for Installation
• 13mm open wrench or nut driver for faucet retainer nut
• 3/4” open end wrench for female end of ex hose

2
FAUCET ROUGH-IN
Install faucet with o-ring into the center hole in deck or lavatory –
1-5/16” (33 mm) minimum hole required.
NOTE: if installing the faucet on a three (3) hole sink, a trim plate should
be installed at this time.
Remove nut, faucet
retainer and gasket.
DO NOT remove the
o-ring from base of
faucet.
DO NOT remove sensor
label until step.4
AB
1 - INSTALL FAUCET
EAF-350
1.5 gpm (5.6 Lpm) Max. Flow or
0.5 gpm (1.9 Lpm) Max. Flow
Faucets with Single Line Water Supply
EAF-350-ISM
1.5 gpm (5.6 Lpm) Max. Flow or
0.5 gpm (1.9 Lpm) Max. Flow
Faucets with Hot/Cold Water Supply 4-3/64”
103 mm
4-3/64”
103 mm
5-5/32”
131 mm
1-5/16” 33.5 mm
Min. Hole Required
Spout
O-ring
13” 330 mm
Long Flex Hose
If a connection to separate hot and cold
water supplies is desired, then a
Bak-Chek
® tee tting or BDM or BDT
(not supplied) must be used prior to
connecting to the faucet.
Tempered
Supply
Nut
Retainer
Gasket 1 ¾”
45 mm
Max. Deck
Thickness
1-5/16” 33.5 mm
Min. Hole Required
Spout
O-ring
13” 330 mm
Long Flex
Hoses
Hot
Supply
Nut
Retainer
Gasket 1 ¾”
45 mm
Max. Deck
Thickness
Mixing Lever
(Can be set and
removed)
Cold
Supply
1-5/16”
33.5 mm
13-49/64”
350 mm
9/16”
UNEF
Max.
1-49/64”
45 mm
5-5/32”
131 mm
2-1/8”
54 mm
Front View
O-RING –
DO NOT REMOVE
FAUCET
GASKET
FAUCET
RETAINER NUT
R
e
m
o
v
e
b
e
f
o
r
e
u
s
e
FAUCET
CENTER HOLE IN
DECK OR LAVATORY
O-RING
R
e
m
o
v
e
b
e
f
o
r
e
u
s
e
Front View
Side View

3
2 - SLIDE GASKET OVER FLEX HOSE(S) AND SECURE
FLEX
HOSE(S)
O-RING
FAUCET
GASKET
FAUCET
RETAINER NUT
R
e
m
o
v
e
b
e
f
o
r
e
u
s
e
3 - INSTALL STRAINER AND FLEX HOSE ONTO SUPPLY STOP. OPEN SUPPLY STOPS.
Install strainer and
ex hose(s) onto
supply stop.
Open supply stop(s).
Tighten the ex hose(s)
(with strainer in place)
securely to the supply
stop(s).
A C
B
Supply Stop
Gasket
Strainer/
Filter
Flex Hose
3/8” Compression Connector
IMPORTANT: Flush dirt, debris, and sediment from supply line(s) before connecting flex hose(s).
Note:
If water ows immediately after turning water stop to open position, then proceed to step 4 (leave water
running; there is a ‘water off’ signal when faucet is rst activated).

4
4 - REMOVE LABEL FROM SENSOR
Remove Label from Sensor Window.
Adjust lever to set
temperature.
Activate Faucet by holding installation instructions approximately 1-1/2”
(38 mm) in front of the sensor window until red light appears, then
remove instruction sheet. Faucet will run for four (4) seconds and the
range will automatically adjust to its environment. Wait ten (10) seconds
after water shuts off before using faucet.
Activate Faucet and check for leaks. If faucet does not function, refer to
the Troubleshooting section of this instruction manual.
Optional – To x
temperature, set lever to
the desired position, then
remove lever and plug
hole with cap.
A
A
A
B
B
5 - ACTIVATE FAUCET
6 - SET AND FIX TEMPERATURE
R
e
m
o
v
e
b
e
f
o
r
e
u
s
e
Sensor Label

5
Close supply stop(s).
Loosen screw with hex
wrench and remove
cap.
Move battery retainer
tab away from battery.
Remove old battery.
Dispose of properly.
Wait 15 seconds before
installing new battery.
Open supply stop(s).
Replace cover and
tighten screw with
hex wrench.
Wait ten (10) seconds
before using faucet.
Insert a new 6V type CR-P2 lithium battery.
The RED LED will ash for one (1) minute.
Reinstall battery cover. If LED doesn’t
ash or if it just lights up, remove and
then reinsert the battery. If water ows
continuously after inserting the new battery
and opening the supply stops, wait 15
seconds, remove and then reinsert the
battery.
A
B
C
F
E
G
D
7 - BATTERY REPLACEMENT
SETTINGS
Note: Replace battery when RED LED indicator ashes each time faucet is in
use or when faucet stops functioning.
IR-Click Feature
The IR-Click is a detector located in the sensor window
of the faucet spout that allows the user to place the
faucet into the following function modes: Continuous Run,
Temporary Off and Auto Set Range Adjustment.
To use the IR-Click, cover bottom half of sensor with nger,
wait 2 seconds for Green light, then remove nger. When
in programming mode, each touch of IR-Click will produce
a quick Green ash.
10 Sec.
Function Press Button LED Signal
Temporary OFF
(2 min)
1. 1 time for 2 seconds
2. 2 times (double push)
1. LED Green (1)
2. LED Red pulsating ashes
reset: 1 time or will reset
automatically after 2 mins
Continuous Run
2 min default setup
(adjustable from 1-20 min)
1. 1 time for 2 seconds
2. 1 time for 3-5 seconds
1. LED Green (1)
2. Water ows after releasing
reset: 1 time or will reset
automatically after 2 mins
Auto Set Range
Adjustment
Details Shown in Next
Section
1. 1 time for 2 seconds
2. 2 times (double touch)
3. 1 time for 4 seconds then
hold till requested range is
reached
4. Release
1. LED Green (1)
2. LED Red blinks
3. LED Red (1-8)
4. LED Green (1)

6
4Sec.
SENSOR RANGE ADJUSTMENT
12/24 LINE PURGE FEATURE
This feature will operate the faucet every 12 or 24 hours since last use, or if not
used, to prevent stagnant water conditions.
Default purge duration is two minutes.
Consult factory regarding other timing options.
Steps to activate purge line feature:
1. Activate IR: cover lower part of sensor window with a white card/paper until
LED ashes GREEN to conrm program mode is active.
2. Cover lower part of sensor window once more with a white card/paper
for approximately 24 seconds (ignore LED indications during this period).
Release when requested program is reached. (See LED indications to right.)
FACTORY SETTING IS APPROPRIATE FOR THE MAJORITY OF APPLICATIONS AND SHOULD NOT REQUIRE RESETTING UNLESS UNDER EXTREME SITUATIONS.
A
C
B
C
D
IR activation (see page 5). To enter programming mode place
nger on IR-Click (covering bottom half of sensor) 1 time for
2 seconds and remove, GREEN light will come on. Then, place
nger 2 times then remove. Light on sensor should blink RED
to indicate programming mode.
Wait until
LED ashes
GREEN
ACover IR-Click (bottom half of sensor) until
LED ashes RED 4 times - hold IR-Click until
LED ashes 1 to 8 times from minimum to
maximum range. See diagram below. Release
when requested range is reached.
B
D
1x 2 Sec.
10 Sec.
Deactivate...1x
Activate 12HR...2x
Activate 24HR
Activate 48HR
...3x
...4x
touch
(bottom half)
1x
2x
3x
4x
5x
7x
8x
6x = factory setting
SENSOR RANGE ADJUSTMENT DIAGRAM

7
HOT LIMIT STOP ADJUSTMENT
OPERATION
CARE AND CLEANING
DO NOT USE abrasive or chemical cleaners (including chlorine bleach) to clean
faucets that may dull the luster and attack the chrome or special decorative
nishes. Use ONLY mild soap and water, then wipe dry with clean cloth or towel.
While cleaning the bathroom tile, protect the faucet from any splattering of
cleaner. Acids and cleaning uids will discolor or remove chrome plating.
As the user’s hands enter the beam’s effective range, the beam is reected
back into the sensor receiver and activates the solenoid valve allowing water
to ow from the faucet. Water will ow until the hands are removed or until the
faucet reaches its automatic time out setting.
A C
D
TROUBLESHOOTING GUIDE
1. Problem Faucet does not function.
Cause Adhesive packaging label afxed over sensor eye.
Solution Remove adhesive label from sensor eye.
Cause Permanent Off Activated shown by RED ashing LED.
Solution Touch button on sensor window for 2 seconds, RED ashing
LED will stop and conrmed with GREEN LED.
2. Problem Faucet delivers water in an uncontrolled manner.
Cause Faucet is defective.
Solution Contact Sloan Technical Support (see below).
3. Problem Faucet does not deliver any water with hands in sensor
range.
Indicator Solenoid valve produces an audible “click.”
Cause Water supply stop(s) closed.
Solution Open water supply stop(s).
Cause Water supply stop strainer(s) clogged.
Solution Turn off water at supply stop(s). Remove, clean and reinstall
water supply stop strainer(s). Replace strainer(s), if required.
Turn on water at supply stop(s).
Indicator Solenoid valve does not produces an audible “click.”
Cause Battery low.
Solution Replace battery (refer to battery replacement).
Solution Contact Sloan Technical Support (see below)
4. Problem
After removing label water does not flow.
Use this installation guide as a target by placing it in front of the
sensor (approx. 1-1/2” away) until water begins owing, then
remove installation instruction from sensor.
Water will stop owing, wait 10 seconds before using faucet.
5. Problem Faucet delivers only a slow flow or dribble when sensor
is activated.
Cause Water supply stop(s) are partially closed.
Solution Completely open water supply stop(s).
Cause Water supply stop strainer(s) clogged.
Solution Turn off water at supply stop(s). Remove, clean and reinstall
water supply stop strainer(s). Replace strainer(s), if required.
Turn on water at supply stop(s).
Cause Spray head is clogged.
Solution Remove, clean, and reinstall spray head. Replace spray head, if
required.
Cause Faucet is defective.
Solution Contact Sloan Technical Support (see below).
6. Problem Faucet does not stop delivering water or continues to
drip after user is no longer detected.
Cause Faucet is defective.
Solution Contact Sloan Technical Support (see below).
7. Problem LED indicator blinks RED when faucet is in use.
Cause Battery low.
Solution Replace battery (refer to battery replacement)
8. Problem The water temperature is too hot or too cold on a faucet
connected to hot and cold supply lines.
Cause Supply stops are not adjusted properly.
Solution Adjust supply stops.
Cause For models with integral mixing valve – Mixing valve is set
improperly for the water temperature desired.
Solution Rotate mixing valve handle clockwise to decrease water
temperature or counterclockwise to increase water
temperature.
When assistance is required, please contact Sloan Technical Support at:
1-888-SLOAN-14 (1-888-756-2614)
Close supply stop(s).
BLoosen screw
with hex wrench
and remove cap.
• Adjust temperature to desired limit
• Adjust screw to meet limit setting
Replace cover
and tighten screw
with hex wrench.
EOpen
supply stop(s).
Wait ten (10) seconds
before using faucet.
10 Sec.
F

© 2015 SLOAN VALVE COMPANY Code No.0816654 – Rev. 3 (04/15)
REPAIR PARTS LIST
2
4A
5A
6
78
9
1
10
11
12
13
14
4B
5B
3
Item Part Description
No. No.
1 EAF-60 Cover
2 EAF-61 Cover Clip – Battery Support
3 EFX-1015-A Battery Replacement Kit (with 2.5 mm hex key)
4A EAF-22 1.5 gpm (5.6 Lpm) AER Spray Head
4B EAF-63 0.5 gpm (1.9 Lpm) AER Spray Head
5A EAF-1021-A Electronic Sensor (15 Second Shut-off) with Fixing Clip Kit (0.5 gpm only)
5B EAF-1018-A Electronic Sensor (7 Second Shut-off) with Fixing Clip Kit (1.5 gpm only)
6 EAF-1019-A Mixer Handle Assembly and Cartridge Kit
7 EAF-2 Solenoid Valve Cartridge (IQ Faucet)
8 EAF-1020-A Integral Side Mixer Handle Kit
9 EAF-8 Back Check (2 required for ISM models)
10 EAF-1 Faucet Mounting Kit
11 EAF-1008 13” (330 mm) Flexible Supply Hose (2 required for ISM models)
12 EAF-9 Filter (2 required for ISM models)
When assistance is required, please contact Sloan Technical Support at:
1-888-SLOAN-14 (1-888-756-2614)
Sloan
10500 Seymour Avenue
Franklin Park, IL 60131
P: 847-671-4300 / 800-9-VALVE-9
F: 847-671-4380 / 800-447-8329
customer.ser[email protected]
www.sloanvalve.com
