SHORELINE 4X4 INSTRUCTIONS
EXTREME SERIES BULLBAR
1. Auto electrical work should be carried out by a competent person. Vehicle
wire colours are listed as a guide only and may vary on some makes and
models.
2. The function of each wire should be checked before any connections are
made.
3. All wires tapped into should be soldered and then insulated with electrical
tape or heat shrink.
4. Grounding/Earth points must always be connected to the factory grounding
points, not to the battery negative terminal. See owner’s manual.
5. Using only a LED test light, test all electrical components of the vehicle before
and after wiring.
This is to ensure everything works correctly.
6. the installation of large or light-coloured antennas or aerials to the
front of a bull bar as this may cause the lane departure system to malfunction.
Only a competent person should perform accessory installations. It is the
responsibility of this person to ensure correct fitment.
• Whilst working on this vehicle, always use appropriate safety equipment.
• Read and understand instructions fully before commencing fitment.
• Check the hardware supplied against the contents list on the following pages.
• Do not use this product for any vehicle make or model other than specified in
these instructions.
• This product and or hardware must not be modified in any way. Do not
remove labels from this product.
• Recording the batch number on the customer’s job card is good practice for
future reference, or complete the information below and file with customer job
card.
Care
• To maintain the finish of the product, wash regularly using a PH neutral car
wash, hose off and
• chamois dry.
• Do not use acidic or alkaline cleaners.
• Plastic components can be maintained with a silicone spray or similar (non-
acidic or alkaline based).
• Ironman 4x4 recovery points are FEA tested during design and destruction
tested during development
• to establish the Working Load Limits (WLL).
• recovery points have been designed as a matching pair, supplied as right and
left sides for vehicle-specific fitment.
• Do not use this recovery point for any other vehicle make or model other than
the one intended.
• Do not alter or modify the recovery point in any way. Doing so may
compromise the strength and integrity of the recovery point.
• It is advised to use an equalising or bridle strap. Failure to do so
correctly can result in recovery point fatigue or bending and void your
warranty.
• Never use a single recovery point combined with a side load pull.
•
Recovery Points are designed for a straight-line pull, by pulling on an angle or
sideways pull may result in a reduction of the WLL.
Shoreline
4
x4
E
xt
reme Se
ri
es Bullbar
X
-1
Fitting instructions for
Holden Colorado 2012 on
Front TOW points only - Rated to 3.75T - NOT
FOR SNATCHING
www.slx4x4.com.au (08) 9444 2946
126 Hector St W - OSBORNE
P
ARK
W
.A. 6017
1. Congratulations on purchasing your very own Shoreline
4x4 Extreme Series Bulbar.
T
o start, clear an ar
ea
a
round the front of your car and unwrap the ba
r
.
2. If you previous had a Xrox
bulbar your front end will
already be half cut. If you
have complete bumper
there is different ways you
can go about cutting your
front bumper.
2.1) If you follow the xrox cut
and remove the lower half you
should be then able to undo
the grille screws at the top of
the grille (under bonnet) and
remove the remaining 1 piece
bumper grille off the car.
3.
It is suggested you remove the front grille off the car inorder to make the final cut shown
below. You will need to remove the 2 barbs either side under the head lights with bolt cutters
or grinder, do not grind near colour coded bullbar
4.Now separate the bar from the bracket.
5.Fit and bolt up the bar using the factory bolts.
Recommended bolts be loosen enough so you can move
the cradle to further help you align the bullbar
6. If you need further adjustment left to right you may need to flatten the bump on the chassis
front member & install the Chassis collar bracket.
.
7.Trim and secure the inner wheel line where applicable
8. Carefully mount the Extreme Series bar it is best to get someone to help you. The bulbar
alignment can be difficult. Its best to have bolts loose enough so two persons can hold the
bar in place while a 3
rd
tightens the bar. If you are installing by your self alignment can be
difficult its suggested you tighten 1 side enough so it can still move under pressure and
wedge foam (or similar) between bar and fender to retain gap when lifting the other side
into place.
9.
Alignment can be difficult on the Colorado RG, Suggest approx. 10-15mm gap between bar
and fender. The body of the car moves independently to the chassis as it sits on rubber/nylon
body blocks. If these are old or worn you can get excessive movement which can result in the
fenders coming into contact with the bullbar. If you want the ‘hard up’ look we suggest pinch
weld in these areas or stick on tabs of rubber, form and furniture floor protectors have been
successfully in creating barrier between the bar & car paints.
10.Solder the fog lights to the factory wiring and test. If you Base model Colorado you
typically don’t have fog lights, you can run separate switch and wiring to LED fogs.
11.Fit the bash plate lining up the holes in the bash plate to
the holes in the bulbar, you may find the mounting bash
plate to the chassis does not line up perfectly this maybe
due to your alignment, in some cases you may need to
elongate or widen the bash plate holes and use larger
washers, if you do this please ensure you seal the cut with
rust paint.
12. The finished result should follow the curve of the
fender, you may wish to paint the inner fender black or
use pinch weld.
NOTE : When you remove RG bumper the alignment of the actual gaurd may change profile due to
potrivot supports being removed, if you find lower section or side profile does not line up enough see
solution end of this document
ALIGNMENT SOLUTION FOR COLORADOS.
SIMPLY SPACE GAURD OUT WITH REQUIRED NUMBER OF
WASHERS
You may wish to purchase 12x12mm Adhesive form available from clark rubber for $7, you need
about 60cm worth, 30cm on each side and you apply It between guard and bulbar for seamless
look
