SMA POWER+ Installation guide

3.31.17 R. Raxter
SMA POWER+
INSTALLATION OVERVIEW

SMA Solar Technology AG
POWER+ PARTS LIST
2
SMA POWER+ INSTALLATION OVERVIEW

SMA POWER+ PARTS LIST
3
Additional Gateway
Part # 150-00000-50
Rooftop Communication Kit
Part # ROOFCOMMKIT-P1-US
Shutdown TS4-R-S
Part # 476-00240-00
Optimization TS4-R-O
Part # 471-00252-10
SMA Sunny Boy Inverter
Part # SBx.x-1SP-US-40
TS4-S
TS4-O
TS4 FKT Field Key Tool
Part # 400-94000-10
(only required if you intend
to change a TS4-R cover)

SMA POWER+ ROOFTOP COMMUNICATION KIT
(WHAT’S IN THE BOX)
4
LABELS and GUIDE
GATEWAY CLOUD CONNECT
ADVANCE (CCA)
and ANTENNA
POWER SUPPLY
DIN RAIL, SCREWS, and
ETHERNET CABLE
SCREWDRIVER
INSTALLATION
MANUAL
INSULATING SLEEVE

SMA POWER+ ROOFTOP COMMUNICATION KIT
LABELS NOTE
5
LABELS and GUIDE
This label is NEC 2014 compliant
Do not use this label

SMA POWER+ ROOFTOP COMMUNICATION KIT
LABELS NOTE
6
Image Source: www.HellermanTyton.com
Labels for NEC 2017
compliance will have to be
obtained separately
For more information pertaining to
NEC 2017 labeling requirements
please view the poster listed below
from HellermanTyton

SMA Solar Technology AG
SMA POWER+ INSTALLATION OVERVIEW
INSTALLATION OVERVIEW
3.13.17 R. Raxter

SMA POWER+ CCA INSTALLATION OVERVIEW
8

SMA POWER+ STEPS IN THE INVERTER
9
Install din rail
Attach antenna
Connect CCA to din rail

SMA POWER+ STEPS IN THE INVERTER
10
Connect the output of
the power supply unit
Connect the power
supply line to the power
supply unit
Unplug power
supply terminal
block from the CCA

SMA POWER+ STEPS IN THE INVERTER
11
Plug the power supply
terminal block
into the CCA.
Connect the positive and
negative conductors to the
terminal block
Mount the power supply unit
on the din rail.

SMA POWER+ STEPS IN THE INVERTER
12
Plug one end of the network
cable into the
network port B of the
communication assembly
Plug the other end of the
network cable into the
network port at the bottom
of the CCA

SMA POWER+ STEPS IN THE INVERTER
13
Unplug gateway terminal
block from the CCA.
Connect the conductors to the
terminal point of
the terminal block
Plug the gateway terminal
block into the CCA
Attach the conductor to the
communication assembly
using a zip tie.

SMA POWER+ INSTALLATION OVERVIEW
14
(E)CLOUD CONNECT ADVANCE (CCA)
and ANTENNA
(D) POWER SUPPLY
(C) DIN RAIL
(H) RS485 FROM GATEWAY
(F) 120V AC POWER
(B) 24V DC POWER
CONNECTION

SMA POWER+ STEPS IN THE INVERTER
15
Place the insulating hose
over the AC conductors.
Insert a flat-blade screwdriver into the actuation shaft
(rectangular opening), then insert the connector into the
terminal point (round openings).
Ensure the conductors are plugged into the terminal points
and not the actuation shaft!

SMA POWER+ STEPS CONNECTING
THE TS4-R DEVICE
16
Clip the SMA TS4R-S/O
to the PV Module

SMA POWER+ STEPS CONNECTING
THE TS4-R DEVICE
17
Clip the SMA TS4R-S/O
to the PV Module

SMA POWER+ STEPS CONNECTING
THE TS4-R DEVICE
18
Connect the Module leads to the
SMA TS4R-S/O
–Connect the Female Negative module
lead to the Male input of the SMA
TS4R-S/O
–Connect the Male Positive module lead
to the Female input of the SMA TS4R-
S/O

SMA POWER+ STEPS CONNECTING
THE TS4-R DEVICE
19
Connect the Module leads to the
SMA TS4R-S/O
–Connect the Female Negative module
lead to the Male input of the SMA
TS4R-S/O
–Connect the Male Positive module lead
to the Female input of the SMA TS4R-
S/O

SMA POWER+ STEPS CONNECTING
THE TS4-R DEVICE
20
Then wire in series as normal
