SMART-AVI SMTCP-2 User manual

© Copyright 2010 Smart-AVI, All Rights Reserved
SMTCP-2
www.smartavi.com / Twitter: smartavi
User Manual
2840 N. Naomi Ave.
Burbank, California 91504
Phone: [phone]
Facsimile: [phone]
Smart Audio Video Innovation
Whats in the box?
The product package should contain the following
Description Qty
SMTCP Device 1
AC Power Adaptor (Varies by region) 1
RS232 to RS422 converter 1
Serial Male to Male crossed cable 1
Notice:
The information contained in this document is subject to change without notice.
Smart-AVI makes no warranty of any kind with regard to this material, including but not
limited to, implied warranties merchantability and fitness for any particular purpose.
Smart-AVI will not be liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance or use of this material.
No part of this document maybe photocopied, reproduced or translated into any other
language without prior written consent from Smart-AVI.
Control any SmartAVI, DVR 4x4, DVR 8x8 or AV 8x8
using Ethernet
Figure 6 Figure 7
The user only has two seconds to press a any button to gain access to the following
menu: (Figure 7)
m_smtcp-2_27Jan10

Introduction
Operation
Configuration Access
Instructions
Connecting the SMTCP-2, Hardware Installation
(see diagram below) to connect any SmartAVI switch use
RS232 cable DB9F.
With the SMTCP-2 you can now control the DVR4x4 and DVR 8x8
RS232
Cable
DB9F
NETWORK
5VDC
When changing input output, press update to send the command to the matrix. *It is
strongly suggested that you change your login and password at this time.
Figure 3 Figure 4
Figure 5
1. Connect to SMTCP by typing http://192.168.2.1 in the address eld of your browser,
then click Enter. (Figure 1)
Figure 1, accessing via browser, type address. http://.....
2. A login window will open. ( Figure 2)
Figure 2, rst time access will require to “Enter” admin and pw.
3. For security reasons, the SMTCP has its own user name and password. When
prompted, enter Adminstrator for the SMTCP user name and admin for the SMTCP
password.
4. After accessing the browser, the user will be able to select these 4 functions;
 t*OQVU0VUQVU4FMFDUUPTXJUDIUPEJòFSFOUQPSUJOUIFSPVUFS
 t5$1*14FUUJOHTUPDIPPTFBOPUIFSJQBEESFTT
 t"ENJO1BTTXPSEDIBOHFZPVSQBTTXPSE
 t-PHPVU
To access the conguration menu the user should perform the following steps:
1. Before powering the SMTCP, make sure that there is a RS-232 cable connecting the
PC and SMTCP.
2. Now the user must open HyperTerminal, or a similar program. This is usually
found in Start Menu >Accessories> Communications.
3. Once HyperTerminal is open, Make sure you have the correct port selected. This is
usually COM1. When you are done select OK.
4. Now make sure bit per second is 9600 and that you have NONE selected for ow
control.
5. Apply power to the SMTCP. You will see the following screen: (Figure 6)
