SMART-AVI HFX Series User manual

4K HDMI Extender
over Fiber Optic Cables
EXTEND UNCOMPRESSED
HDMI SIGNALS
UP TO 1,000 FEET
OVER MULTIMODE
FIBER OPTIC CABLING,
WITH RESOLUTIONS
UP TO 4K ULTRA HD
Quick Start Guide
VIDEO
Format HDMI 1.4 and HDCP compliant
HDTV Resolutions 480p, 720p, 1080i,
1080p/60Hz/48bit, 4Kx2K/30Hz
TV Resolution 480i
Refresh Rate Up to 130Hz
Wavelength 850 nm
Bit Error Rate
Performance 1.00E-12
Input Interface (TX) HDMI Type A 19-pin Female TMDS
Output Interface (RX) HDMI Type A 19-pin Female TMDS
Input Cable Length Up to 40 ft
Output Cable Length Up to 40 ft
Format Dolby TrueHD, DTS-HD MA
Input Interface HDMI (Integrated)
Output Interface HDMI (Integrated)
Laser Output Power
Class 1;
EN 60825-1 2007;
EN 60825-2 A2 2010
OTHER
Power External
100-240 VAC/5VDC2A @10W
Dimensions 5” W x 1.125” H x 4.125” D
Weight 1 lbs.
Approvals UL, CE, ROHS Compliant
Operating Temp. 32-131°F (0-55 °C)
Storage Temp. -4-185 °F (-20-85 °C)
Humidity Up to 95%
NOTICE
The information contained in this document is
subject to change without notice. SmartAVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and tness for particular purpose.
SmartAVI will not be liable for errors contained
herein or for incidental or consequential damages in
connection with the furnishing, performance or use of
this material.
No part of this document may be photocopied,
reproduced, or translated into another language
without prior written consent from SmartAVI
Technologies, Inc.
800.AVI.2131, 702.800.0005
2455 W Cheyenne Ave, Suite 112
North Las Vegas, NV 89032
SmartAVI.com
TECHNICAL SPECIFICATION
HFX
WHAT’S IN THE BOX
PART NO. Q-TY DESCRIPTION
HFX-TX 1 HDMI 2K/4K Multimode
Fiber Transmitter
HFX-RX 1 HDMI 2K/4K Multimode
Fiber Receiver
PS5VD2A-WLLMNT 2 PS5VD2A Power Supply
Quick Start Guide 1

ABOUT SFX
For reliable, uninterrupted and long-distance HDMI
extension, the HFX-Pro provides the best solution with its
ber optic extension capabilities. Users can bridge large
gaps that they ordinarily could not with this compact device.
The HFX includes the transmitter and receiver, for complete
point-to-point signal extension, with no need for any other
hardware or software.
The HFX delivers uncompressed HDMI signals up to 1,000
feet (300 meters). Supported resolutions go up to 4K Ultra
HD (@30Hz), and 3D HD video is also supported. As with
all HDMI connections, high-quality digital audio is also
transmitted via the extender.
Fiber optic signal extension is the newest and best way to
break the distance barriers that plague traditional HDMI
connections.
By providing additional distance from the input device to
the screen, users can handle their HD viewing needs in
a number of important environments. This is useful for
separating equipment and computers from the place where
users are viewing content, which includes environments
like medical ofces, recording studios, nancial centers and
much more. Furthermore, ber optic cables are resistant to
electromagnetic and radio frequency interference, creating
a stable and reliable connection.
FEATURES
• Supports HDMI 1.4a
• HDCP Compliant
• Extends HDMI signals up to 1,000 feet
at 10.3 Gbps with OM3 multimode ber optic cabling
• Supports resolutions up to 4K Ultra HD (@30Hz)
• Hot Pluggable
• EMI/RFI Resistant
1. Power off all devices including the HDMI source and display.
2. Connect an HDMI cable from the HDMI source to the HDMI port on the HFX-TX (transmitter).
3. Connect the HFX-TX to the HFX-RX (receiver) using a multimode duplex ber optic cable (up to 1,000 ft.) with LC type
connectors on both ends.
4. Connect an HDMI cable from the HDMI port on the HFX-RX to the HDMI Display.
5. Power on the HFX transmitter and receiver by plugging in their power adapters (5VDC2A).
6. Power on the HDMI source and the display.
HFX-TX FRONT HFX-RX FRONT
HFX-TX BACK HFX-RX BACK
HARDWARE INSTALLATION
