SMART-AVI USB2-Mini User manual

USB2-Mini
User Manual
The USB2-Mini extends USB 2.0 up to 150 ft.
from the computer using a single Cat5e/6 Cable
Notice
The information contained in this document is
subject to change without notice. SmartAVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and tness for any particular purpose.
SmartAVI will not be liable for errors contained
herein or for incidental or consequential damages in
connection with the furnishing, performance or use of
this material.
No part of this document may be photocopied,
reproduced or translated into another language
without prior written consent from SmartAVI.
Technical Specications
USB DATA
USB Fixed
Data Rate
480Mbps
USB Version
Compatibility
2.0 and 1.1
USB Connector
Type (TX)
(1) Type B
USB Connector
Type (TX)
(4) Type A
UTP DATA
Signal Type LVDS
Connector Unshielded RJ-45
POWER
External or via USB 5V DC @ 2mA
Connector 2.1mm DC jack
(center+ve)
PHYSICAL
Dimensions 3.375” x 3.375” x 1.5”
Weight 0.14lb
ELECTRICAL
Range over
Cat5e/6
150 ft.

What’s in the box?
Installation and Operation
Connecting the Transmitter
1. Connect the transmitter to the host using the A-B
USB cable (included with the unit).
2. The A side of the connector would go to the com-
puter host and the B side would be connected to
the transmitter.
Connect the receiver to the peripheral device using
the included USB-Hub.
Introduction
Features
SmartAVI’s USB2-Mini extends standard USB
(Universal Serial Bus) 2.0 signals up to 150
feet using a single Cat5e/6 cable. The USB2-
Mini supports all USB 2.0 high-speed devices,
from keyboards to printers, and will operate on
Windows®, Mac and Linux® operating systems.
An integrated four-port hub allows for multiple
devices to be connected to the USB2-Mini at once.
Additional USB hubs can be added, increasing the
amount of devices that can be plugged into the
USB2-Mini.
•
• Supports all USB 2.0 and 1.1 Devices
Transparently
(Flash Drives, Printers, etc.)
• Supports USB 1.1 keyboard and mouse
• Works on Windows, Mac and Linux Operating
Systems
•Integrated Four-Port Hub
•Bus-Powered Local Unit
•Power Adaptor for Remote Unit
•Plug-and-Play Ready
Part No. Description
USB2-Mini-S USB 2.0/1.1 over Cat5e/6 Extender.
Includes: [USB2M-TX, USB2M-RX,
and PS5VD4A]
Note: You must connect the included USB-Hub to the
receiver unit for the system to work properly.
Note:
The receiver provides remote power up to 500
mA to the connected peripherals. This power comes
from the host computer and is passed by the transmitter
to the receiver. In some applications, and external power
supply is required. SmartAVI can provide a power supply
for such cases with the receiver and transmitter units.
