SMART-AVI HKM-04 User manual

© Copyright 2011 Smart-AVI, All Rights Reserved
NOTICE
The information contained in this document
is subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for any particular purpose.
Smart-AVI will not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance or use of this material.
No part of this document may be photocopied, reproduced or
translated into another language without prior written consent
from Smart-AVI.
For more information, visit www.smartavi.com.
SmartAVI, Inc. / Twitter: smartavi
11651 Vanowen St. North Hollywood, CA 91605
Tel: [phone] Fax: [phone]
http://www.SmartAVI.com
Control 4 Computers, PC or Mac on
one Display with USB Keyboard and
Mouse, and Stereo Audio
www.smartavi.com
Installation
Manual
Technical Specications
What’s in the Box?
PART NO. QTY DESCRIPTION
HKM-04 1 4X1 KVM HDMI, USB, Audio
Power Supply 1 PS5VDC4A
AUDIO
Frequency Response 20 Hz to 20 KHz
Impedance 600 ohm
Nominal Level 0-1.0 V
Common Mode Rejection at 60dB
Input Interface (4) 3.5 mm Stereo Audio
Output Interface (1) 3.5 mm Stereo Audio
USB
Signaling USB 1.1 and 1.0
Input Interface (4) USB Type B
Output Interface (2) USB Type A
CONTROL
Front Panel Tact Switch
OTHER
Power External 100-240 VAC/5VDC4A @20W
Dimensions 6.625”W x 1.875”H x 2.875”D
Weight 1 lbs.
Approvals UL, CE, ROHS Compliant
Operating Temp. 32-131°F (0-55 °C)
Storage Temp. -4-185 °F (-20-85 °C)
Humidity Up to 95%
HKM-04
4-Port HDMI KVM with USB
Keyboard and Mouse,
and Stereo Audio
Rack Mountable Option
Our SmartRack is the perfect solution to allow
virtually all SmartAVI devices to be custom mounted
in a standard 19” server rack. The SmartRack is fully
adjustable and can secure/organize several devices.
VIDEO
Format HDMI 1.3b [Deep Color, xvYcc color space supported]
DVI Compliance Single-link DVI-D 1.1
HDCP Compliance 1.0/1.1
Video Bandwidth Single-link 340MHz [10.2Gbps]
Resolution 480i,480p,720i,720p,1080i,1080p
Input Interface (4) HDMI[7.1ch audio & video]
Output Interface (1) HDMI[7.1ch audio & video]
Connector Type A[19-pin female]
Maximum Distance 25 ft.

Mac
HKM-04
PC
Introduction
The HKM-04 is a cross-platform HDMI switch capable
of sharing one HDMI Monitor between four computers,
PC or Mac. View four computers with HDMI on a single
screen, saving money and desktop space.
Features
• Compatible with Mac, PC, Linux and Sun
• Supports High Denition HDMI
• Supports USB keyboard and mouse
• Balanced stereo audio output
• Front panel tactile switch with LED indicator
• Supports Auto-scan mode for simple
discovery
Applications
• Home Theater Integration
• Digital Signage Deployment
• Information Kiosks/Displays
• Film/Recording Studios
In the medical or industrial eld, where it may not be
practical (or safe) to have one or more CPUs in the
general vicinity, SmartAVI’s HDMI Switch Series is the
perfect solution, allowing for either PC or Mac signals
to be extended from computer to the display.
Another practical use for one of our HDMI Switch would
be for media recording studios, where soundproong
and space issues come into play. Using a HDMI Switch
eliminates the inherent “hum” of a powered CPU and
gives you the freedom of using your keyboard, mouse
and monitor without having to nd room for the
computer itself in the same workspace.
Product - Installation Diagram
Installation
1. Turn o all computers and the display.
2. Connect the HDMI extension cables, USB cables, and audio cables (not included) to the computers and to the
“IN” ports on the HKM-04.
3. Connect the display to the“OUT” HDMI connector on the HKM-04.
4. Connect USB mouse and keyboard to the“OUT” USB connector on the HKM-04.
5. Connect speakers to the “OUT” audio connector on the HKM-04.
6. Connect the power cord and power-on the HKM-04.
7. Power on the computers, speakers and the display.
8. Use the front panel buttons to select the desired input port.
Switching Between Ports
Front Panel Control
To switch ports using the front panel, press the Select button to
cycle through the available ports. The selected port number will be
indicated by the LED display. HKM-04 Front
HKM-04 Rear
IR Control (optional)
To switch ports using an infrared remote control (optional accessory),
use the IR remote to cycle through the available ports.
