Smart Sensor AF110A User manual

Version: SZ110A-1-02
MODEL: AF110A
Human Flu Thermometer
Instruction manual
Introduction
Thank you for choosing AF110A non-contact
Human flu infrared thermometer. AF110A is special
design for measurement Human flu forehead
temperature, provide quick and accurate testing.
Build-in environment temperature compensation and
self-detection, without contact, ear-cap, no more ear
canal cross infection.
How it works
Infrared thermometer measure the surface
temperature of human body. The units optical
,
system sense the object s emitted energy with
different wavelength. It is collected and
,
focus onto a detector. The unit s electronics
system translated the information into a
temperature reading which is displayed on
the unit.
Cautions
Infrared thermometer should be protected for
the following:
--EMF (electro-magnetic fields) from arc welders,
induction heaters.
--Thermal shock (cause by large or abrupt ambient
temperature changes allow 30 minutes for
unit to stabilize before use).
--Do not leave the unit on or near objects of high
temperature.
1. When take measurement, point thermometer
toward the forehead to be measured and hold the
trigger key, the closer distance the more precision
will be obtained..
2. Detection distance: 5 to 10 cm with the
Human flu forehead is more accurate.
1. Open battery door and install 2*AAA battery
properly, when pull the trigger and LCD
display battery power and temperature reading
(as figure 2), the reading will hold for 10 seconds.
LCD display:
A. Data(reading) hold icon
B. Scanning icon
C. Indicator lamp light icon
D. Battery power icon
Quick start instruction
(Figure 1) (Figure 2)
Measurement
trigger
SC AN
Battery door
A
B
C
D
E
F
5 to 10cm
G
3. Not recommended use this unit at direct
sunlight or near a strong wind.
4. When forehead is wetting, please make it dry,
then take measure again.
5. When environment temperature changed,
please keep the unit under this environment
more than 20 minute, then take measure again.
B / S
C / F
5~1 0cm

B/S
C / F
2. Fixed point measurement: Pull the trigger and
aim the thermometer to forehead for measurement
(as figure 3 ).
(Figure 5)(Figure 4)
E. Temperature unit
F. Temperature reading
(Figure 3)
3. Unit diagram description
(1) Measurement trigger: When pulling the
trigger LCD display SCAN icon and temperature
reading , At the same time with HOLD icon. Every
time pulling the trigger obtain a data.
Built-in auto power off in 10 seconds.
(2) Celsius and Fahrenheit selection and down
adjust button.
(3) B/S: body inside / body surface setting button
(4) Back-light On/Off and up adjust button
(5) LCD display(show as figure 2)
(6) Battery door
Repeatablility
Response time 1 s ec
Emissivity
Resolution
0.95 pre-set
0.1℃
Ambient operation range
0 to 40℃ (32 to 104℉)
Relative humidity
10-95% RH non-condensing,
@ up to 30℃(86℉)
Storage temperature
-20 to 60℃ (-4 to 140℉)
without battery
Weight/Dimension
130g; 146 x 80 x 38mm
Power supply
Battery life(alkaline)
12 hours
Specification
Temperature Range
Accuracy
±0.2℃(testing environment
temperature23℃ ±3℃)
4.Operation instruction:
(a)Body inside: 30 to 45℃ (86 ℉ to 113 ℉)
Body surface: 25 to 60℃ (77 ℉ to 140 ℉)
(b)Install 2*1.5V AAA battery correctly,t hen c lose
b attery door, pull the trigger to turn on. LCD display
reading with SCAN icon(every measurement will
takes 1 to 2 seconds), after release the trigger then
the reading will be hold .
(c)Temperature unit selection: In normal status,
the default unit is Celsius, press ℃/℉ button will
turn into
(d) The default setting is back light off, press
button will turn on the back light.
(e) The default measurements is body inside
measurements, Hold down B/S button and then
well switching to body surface measurements.
LCD display , Without it, express body surface
measurements.
(f) The thermometer will auto power off in 20 seconds
without any operations.
(g) Using life: Over hundred thousand times in
normal measurement.
Fahrenheit.
Maintenance
1) Lens cleaning: Blow off lose particles using
clean compressed air. Gently brush remaining
debris away with a moist cotton cloth.
2) Case cleaning: Clean the case with a damp
sponge/cloth and mild soap.
Note:
1) Do not use solvent to clean lens.
2) Do not submerge the unit in water
3) This products is only used for measure
human body's temperature by test the
people's forhead..
(2)
(1)
(4)
(5)
(3)
(6)
G. Body surface measurements icon
Body surface:
25 to 60℃ (77 ℉ to 140 ℉)
Body inside: 30 to 45℃ (86 ℉ to 113 ℉)
when less than 30℃, display“ ”
when over 45℃, display“ ”
2*1.5V AAAbattery
±0.1℃
