SmartWitness DDC-200
Installation Guide
v.1.0
WARNING: SmartWitness installations should be performed by a qualified individual
or installation professional only. Working with a vehicle's power system can be
dangerous to both you and your vehicle. This installation is intended only to be a
guide since vehicle designs and power/input sources can vary significantly from
vehicle to vehicle.
If you need to schedule a professional installation service in the USA for your
SmartWitness device(s), please visit smartwitness.com/request-install and submit the
online form.

www.smartwitness.com
1. Overview:
The SmartWitness DDC-200 is the world’s most advanced fatigue detection and
driver distraction alert camera. The detection is focused on harmful face, eyes,
mouth and head movement. The DDC-200 allows for day and night detection,
with the use of infrared and a customized alarm and alerting system.
Fatigue Detection: Drowsiness, micro-sleep, or yawning
Distraction Detection: Texting, phone calling, or eating/drinking
Features:
Dual-lens design: facial recognition lens plus video recording lens
Recognizes facial patterns and alerts drivers who are fatigued or distracted to help
avoid accidents
12 Infrared LEDs for Night-time Recording
Alarm I/O to trigger recording of the Video Lens on the SmartWitness recorder
(CP2, CP4, CRX)
Transmit fatigue and distraction events in real time when connected to
SmartWitness recorder
Simple installation with Smartphone calibration App
Adjustable sensitivity
Mount on dashboard or windshield

www.smartwitness.com
Package Contents:
2. Installation Steps:
1. Download the DDC App from iOS or Android play store
(or you can use search term “SmartWitness DDC”).
2. Follow the App instructions for device mounting location
and calibration
3. Connect the DDC-200 cables to vehicle power and to the
SmartWitness recording device
4. Power up the device and use the DDC app to connect
to the DDC200 and calibrate it.
5. Ensure the SmartWitness recorder is receiving the DDC-200 camera image.
If this is a new SmartWitness installation, please complete the installation process at
install.smartwitness.com. For installation support please email [e-mail]
or call our technical support at [phone].
DDC200 unit
Mounting Bracket
with 3M pad pre-adhered
Power/GPIO cable
Quick Start Guide
Extra 3M Adhesive
Screws for dashboard
installation (optional)

www.smartwitness.com
3. Wiring Connection
Connect mounting
bracket to notch
on rear of DDC
Connect
Power/GPIO cable
extension here
Connect recording device
here (CP2-LTE can connect
directly. CP4 & CRX require
adaptors.

www.smartwitness.com
4. Windshield or Dash installation
Attach the mounting bracket to the DDC camera slot until it clicks.
IMPORTANT: Make sure the glass is clean and dry before attaching to the windshield,
holding the camera in position for 30 sec. with firm pressure. The glass temperature
should not be too cold or hot. Please install the camera in moderate temperature
(between 50°F ~ 80°). The distance angle from the driver’s face should not exceed 20°
Make sure the status LED is at the bottom of the DDC200.
For Technical Support, please visit support.smartwitness.com
