Smart Witness KP2 User manual

DISTRACTION DETECTED
KP2
PRO
INSTALLATION
GUIDE
Version 4.0
Last updated 4/06/2022

2SMARTWITNESS KP2 PRO INSTALLATION GUIDE
TABLE OF CONTENTS
Please follow along with this guide for details on
proper device installation and calibration.
HOW TO CALIBRATE YOUR G-SENSOR...................................10
HOW TO CONFIGURE KP2 SETTINGS...................................... 11
COMPLETE YOUR INSTALLATION/SUPPORT ......................... 12
Not an Installer?............................................................................... 12
LED & BUZZER SPECIFICATIONS............................................... 13
TECHNICAL SPECIFICATIONS....................................................14
PACKAGE CONTENTS....................................................................3
KP2 FEATURE REFERENCE............................................................4
HOW TO INSTALL YOUR KP2.......................................................6
Prepare Your KP2...............................................................................6
Attach Your Camera to the Windshield ........................................ 7
Connect the KP2 to Your Vehicle’s Power Source.....................8
HOW TO TEST YOUR INSTALLATION .........................................9
EVENT TRIGGER
KP2
PRO INSTALLATION GUIDE

3SMARTWITNESS KP2 PRO INSTALLATION GUIDE
PACKAGE
CONTENTS
KP2 Vehicle
Recorder
Double-Sided 3M™Tape
(One Adhered to Bracket, One Extra Pc.)
*64GB SD Card (Pre-Installed)
*128GB SD Available
Upon Request
Square Adhesive
Cable Clips (x5)
Alcohol Prep Pad (x2)Nano SIM Card (Pre-Installed)
Power Cable 1 From Bracket
Removable Wedge Block
(Driver-Facing Camera Ordered Separately) Torx®Wrench
Power Cable 2
(3-Wire Type)

4SMARTWITNESS KP2 PRO INSTALLATION GUIDE
KP2
FEATURE REFERENCE
Windshield Bracket
Lens Angle Lock
Unscrew the right-side bracket.
Remove the KP2 from the
bracket to adjust camera angle
or insert/remove SIM/SD card.
Applied screws for design
purpose only.
FRONT
SIDE
Camera Lens

5SMARTWITNESS KP2 PRO INSTALLATION GUIDE
KP2
FEATURE REFERENCE
SIDE COVER OPEN
BACK
Nano SIM Slot (4FF)
Release Tab
Micro SD Card Slot
Memory SD Card Slot
2nd Camera
(Model: KP2-DFC)
Ecall/Panic Button
LED Types:
Warning LED (RED)
Record LED (BLUE)
Network LED (GREEN)
Bluetooth Pairing Button

6SMARTWITNESS KP2 PRO INSTALLATION GUIDE
Prepare Your KP2
DISCLAIMER
The KP2 installation featured in this guide is designed for professional installation. SmartWitness assumes
installers possess knowledge of current, generally accepted industry installation standards and practices.
The process outlined in this document accounts for driver positioning on the left side of the vehicle.
Please adjust the installation accordingly if you’re working with driver positioning on the vehicle’s right side.
1. Use the Torx®wrench provided in the package contents to open the side cover of
the device. You’ll notice that both the microSD and SIM cards come pre-installed.
See Diagram A.
2. Keep the side panel open. It allows you to remove the KP2 from its mount and
adjust the driver- and road-facing cameras. Prep the cameras for adjustments.
• Loosen the KP2’s top screw (for the road-facing lens) with the Torx wrench.
• The driver-facing camera has a release tab next to the lens.
Note: You must order the KP2’s driver-facing camera as a separate accessory.
White-label KP2s are exceptions.
3. Go to your vehicle, and hold your KP2 where you’ll mount the bracket. Your
KP2 placement should reduce the windshield’s blind-spot footprint, with the
road-facing camera within the top 2" of the wiper path. The device should
reside close to the center of the windshield. See Diagram B.
Note: The driver-facing lens needs complete visibility of the driver,
without any physical or visual obstructions. Ensure your vehicle’s sun visor
doesn’t complicate camera visibility.
4. While holding the KP2 in place, rotate each camera until they’re
at the desired angle.
5. Remove the protective decals from each lens.
6. Use the Torx wrench to tighten the top screw on the KP2 and lock
the road-facing camera’s position.
Once you’ve secured the road-facing camera, please go on to Attach Your Camera to the Windshield.
HOW TO INSTALL
YOUR KP2
Diagram B
Diagram A

7SMARTWITNESS KP2 PRO INSTALLATION GUIDE
Attach Your Camera to the Windshield
Your vehicle’s windshield temperature shouldn’t be too hot or cold. SmartWitness recommends installing your
KP2 in moderate temperatures (50°F~80°F).
If in severe cold weather, use the vehicle defrosters to warm and dry out the windshield.
Ensure your windshield is dry and has no chips or cracks before installation. If the windshield is compromised,
device application may cause chips or cracks to spread.
1. Clean the windshield with your alcohol wipe. See Diagram C. Allow time to dry.
2. Remove any film left over from the solution.
3. Remove the plastic from the tape on the mounting bracket.
4. When attaching the KP2 to the windshield, position the bracket so it’s flush
with the windshield.
Note: When installing the KP2 in a truck, FMCSA mandates that the device’s
camera is in the top 2" of the windshield wiper sweep.
5. Apply your KP2 to the windshield, and maintain pressure for at least 30 seconds.
6. After mounting your KP2, use the Torx®wrench to re-secure the device’s side
cover. This locks both camera positions in place.
7. Go outside the vehicle, and check whether 80%–90% of the tape’s surface area connects with the glass.
Momentarily apply pressure where the camera doesn’t connect to the glass (if necessary).
Once the device is correctly attached to the windshield, continue
to Connect the KP2 to Your Vehicle’s Power Source.
Diagram C
HOW TO INSTALL
YOUR KP2

8SMARTWITNESS KP2 PRO INSTALLATION GUIDE
Connect the KP2 to Your Vehicle’s Power Source
If you are not a professional technician, click here to request installation from an approved SmartWitness
installer. By continuing this process without a certified installer, you accept the ramifications of tampering
with your vehicle’s power source.
1. Turn o your vehicle.
2. Take your main power cable, and place it where it’ll reside alongside the vehicle’s
headliner and A-pillar. This shows you where to route the cable and how much
slack to leave to connect the adapter cable to the vehicle’s power source.
3. Clean the space where the cable clips will reside with an alcohol wipe.
Allow time to dry.
4. Once the windshield is dry, attach clips where you’ll place the cable.
Ensure the clips are evenly spaced, around 6" apart. Keep the opening
of the clips face up, and ensure the cable remains taut.
5. Slide the power cable from the bracket into the clips. Your cable
should look like Diagram D.
6. Route the power cable around the side and behind interior panels
or weather stripping to secure it. See Diagram E. The cable should
fall near the vehicle’s fuse box/power source.
7. Attach the KP2 main power cable to one of the compatible power
adapter options. Let’s use the bare 3-wire connection adapter provided
in the box for this walk-through. See Diagram F.
Note: SmartWitness provides optional power adapter accessories separately.
8. Identify each connection wire on the 3-wire adapter: black, white and red.
Note: Ensure your 3-wire connection has fuses attached to the
red and white wires within 4" of the power source. This is a
requirement that protects both your device and your vehicle.
9. Connect each wire to its associated power source.
• Black – ground or battery (-)
• White – true ignition or ACC
• Red – power or battery (+)
Go to How to Test Your Installation to ensure you’ve properly
applied power to your device.
Diagram D
Diagram E
Diagram F
HOW TO INSTALL
YOUR KP2

9SMARTWITNESS KP2 PRO INSTALLATION GUIDE
HOW TO TEST YOUR
INSTALLATION
After installing the KP2 in your vehicle, test whether it is operational.
1. Turn on your vehicle. Your camera should power on.
2. You’ll see a Red/Blue/Green light sequence during your camera’s
boot-up process (see LED Reference Table).
3. After your camera completes the boot-up process, check for
a solid Blue light. This indicates proper operation and recording.
4. Check for a Green light that remains on, indicating connectivity.
5. Watch for a Blue light. After 5 minutes, if both the Green and Blue lights
don’t remain on, an error has occurred. See Diagram G.
TROUBLESHOOTING ERROR SCENARIOS
If your KP2 has:
• Solid Red, Blue and Green lights, then a camera isn’t receiving
a video signal. Check your camera’s connection.
• A solid Blue light, but the Green light is blinking or is o,
then clean and correctly reinsert your SIM card.
- If the Green light still blinks, this is a configuration or server issue
that requires SmartWitness support.
• A Red blinking light, then there is an SD card error or corruption. Contact your local distributor or
SmartWitness support to repair or replace your SD card.
• A solid Red light, then your device isn’t receiving enough voltage or amperage. Check the output of your
power source or your ground (black wire) connection.
If your KP2 install is operational, please move on to How to Calibrate Your G-Sensor.
Diagram G

10SMARTWITNESS KP2 PRO INSTALLATION GUIDE
HOW TO CALIBRATE
YOUR G-SENSOR
Park your vehicle on a flat surface for calibration.
After your camera boots up, press the G-sensor calibration button. This is the small Red button
to the right of the e-call/panic button.
You’ll hear a beep, and the KP2 LED light will blink briefly to indicate that the G-sensor calibration has registered.
You’ve completed the first steps of your KP2 installation. To adjust your settings, continue to
How to Configure KP2 Settings.

11SMARTWITNESS KP2 PRO INSTALLATION GUIDE
To finalize your installation and onboard your device, scan the
QR code. Download and open the app. Scan your device’s
IMEI label, and follow the walk-through featured below.
HOW TO CONFIGURE
KP2 SETTINGS
Access KP2 Installation App
7. After you’ve made changes
and activated the appropriate
features, click Confirm to save
your configuration.
5. Choose preferences for in-cabin
alerts, an alert’s volume level or
activation of dierent ADAS and
DSM events.
8. On the home screen, you’ll
see a success message validating
your saved configuration.
6. If you’re unaware of a
setting’s function, click the
info icon to learn more.
1. Ensure the IMEI code in the
app matches your device’s IMEI.
If there isn’t a match, click No and
contact SmartWitness support.
If there’s a match, click Yes
to continue.
4. If you adjust either camera, click
Refresh Images to update road- and
driver-facing camera images.
Use the arrows to adjust your
vehicle’s “Horizon” and “Hood” lines.
Ensure your “Hood” line is in the
bottom one-fourth of your image.
Scroll down and click Next to save
the “Horizon” and “Hood” lines.
2. Read the instructions to
understand more about your
vehicle’s “Horizon” and “Hood” lines.
Click Show Me How for a brief
video walk-through of the device
attachment process.
3. Select your KP2 camera
configuration.
Choose the driver’s side of the
vehicle (from the perspective of
the front of the vehicle).
Click Next to set your vehicle’s
“Horizon” and “Hood” lines.
Congratulations. You’ve configured your device settings.

12SMARTWITNESS KP2 PRO INSTALLATION GUIDE
You’ve finished your KP2 installation and device calibration. Your KP2 is ready to go.
If you have any complications during the installation process or have any questions,
please contact our support team at [email protected] or call us.
North America, South America, APAC
[phone]
EMEA
[phone]
NOT AN INSTALLER?
Once you complete the training (about a 30-minute webinar), SmartWitness will provide you with login
credentials for the SmartOPS portal.
To schedule training, please complete the online form here.
COMPLETE YOUR
INSTALLATION/SUPPORT

13SMARTWITNESS KP2 PRO INSTALLATION GUIDE
LED & BUZZER
SPECIFICATIONS
Status/Step
LED
SOUND
Warning Record Communication
Red Blue Green
Startup &
Power O
Booting Step 1 On O O -
Booting Step 2 On On and O O -
Booting Step 3 On On On and O -
Booting Finished On On On -
Power O O Fast Simultaneous On and O Beep No. 2
Power O Finished O O O -
Record Continuous Record Recording - On - -
Event Record Standby - On - -
Recording - Fast On and O - -
Dual Record Continuous Recording - On - -
Event Recording - Fast On and O - -
No Record No Recording - O - -
Communication 4G LTE Network Device Ready - - On -
Communication - - On -
Function SD Format O Sequence On and O Continuously
Beep No. 2
G-Sensor Calibration - - - Beep No. 2
FW Upgrade - Double Sequence On and O -
Warning System Warning SD Card Full Fast On and O O - Beep No. 3
Video Loss On - - -
Error Record Error SD Error,
No SD, Write Fail Slow On and O O - Beep No. 3
Communication
Error
4G LTE Network
Device Error,
SIM Error
- -
O
-Data Network
Connection Error Slow On and O
DMS
Communication Error Slow On and O
Event Trigger G-Sensor, Panic Button, Alarm-In - - - Beep No. 1
Over Speed - - - Beep No. 4
(2 Times)
ADAS PCW, FCW, HMW - - - Warning Beep
or Voice
DSM DSW, DFW, DPUW, DDW - - - Warning Beep
or Voice

14SMARTWITNESS KP2 PRO INSTALLATION GUIDE
TECHNICAL
SPECIFICATIONS
NAME VALUE
Image Sensor 2 Megapixel CMOS Sensor
Angle of View
Main, Road-Facing Camera (Forward-Facing):
140° (115°(H), 60°(V))
2nd Camera (Optional, Driver-Facing):
130° (104°(H) x 56°(V))
Wireless
LTE CAT6 (KP2-NA): B2/B4/B5/B7/B12/B13/
B14/B17/B25/B26/B41/B66/B71
LTE CAT6 (KP2-GB): B1/B2/B3/B4/B5/B7/B8/
B20/B28/B38/B40/B41
3G (KP2-GB): B1/B2/B4/B5/B8
Wi-Fi: 2.4/5GHz, 802.11 a/b/g/n/ac
Bluetooth: 4.2 BLE
Connectivity 4G/LTE (CAT6)
Max Data Rate UL: 50Mbps, DL: 300Mbps
Video Resolution
Main Camera: 1080p (1920 x 1080), 720p
(1280 x 720)
2nd Camera: 1080p (1920 x 1080), 720p
(1280 x 720)
Recording Speed 60FPS (30FPS per Channel)
Recording Mode Continuous, Event, Dual Mode
Memory 16GB eMMC + 2GB LPDDR3, MicroSD Card
Support up to 256GB (FAT32)
GPS/GNSS Internal GPS/GLONASS/BeiDou
G-Sensor Internal 3-Axis G-Sensor
NAME VALUE
Gyro 3 Axis (X, Y, Z), Output Rate: 100Hz
Time GPS Time Sync + Built-In Real-Time
Clock (RTC)
Speaker
Audible Alerts for Events and Audio for
ADAS and DSM. Natural Language or
Beep Sounds (Selectable)
Audio Internal Microphone
Serial RS232 RX/TX
LED 3 (Red, Blue, Green LED)
Supercapacitor Enables Recording of Last File
and Safe Shutdown
PC Software MSM8953, Octa-Core ARM Cortex-A53
Power Input Input Voltage: DC 12V/24V, 1.5A
Delayed Power
Shutdown
Supports Delayed Power Shutdown
and Automated Wake-Up Feature
(Selectable Intervals)
Power
Consumption 4W (6W With ADAS and DSM Enabled)
Size/Weight 126 x 82 x 64 mm/232.4g (Including 2nd
Camera, Excluding Power Cable)
Operational Temp. -10°C~55°C
Storage Temp. -20°C~70°C
Certification/
Regulatory
FCC, CE, E-Mark, UKCA, RoHS, IC, PTCRB,
RCM, AT&T, Verizon and FirstNet
Warranty 2-Year Standard

© 2022 SmartWitness. All Rights Reserved. smw3016-NA_0422
