BlackVue DR900S-1CH User manual

ENGLISH
DR900S-1CH
Manual

2BLACKVUE
Table of Contents
Introduction.................................................................5
Important safety information ....................................6
Overview ......................................................................9
In the box.....................................................................................................................9
At a glance.................................................................................................................10
Removing and inserting the dashcam....................................................................................... 12
Installation .................................................................13
Installing the BlackVue dashcam..........................................................................13
Playing and Managing Videos..................................16
Playing and managing video les using your smartphone
(Android/iOS) .......................................................................... 16
Opening video les..................................................................................................16
BLACKVUE WI-FI screen composition...................................................................18
Playing video ............................................................................................................19
Playing back videos.......................................................................................................................19
Identify video les by recording type ........................................................................................ 19
Checking the displayed time & GPS data ..................................................................................21
Real-time streaming video (Live View) ................................................................22
Managing videos .....................................................................................................23
Managing videos in BLACKVUE WI-FI ........................................................................................ 23
Copy to Internal Memory ............................................................................................................................................. 23
Managing videos in INTERNAL MEMORY..................................................................................24
Deleting videos .............................................................................................................................................................. 25
Creating a new folder ................................................................................................................................................... 25
Copying and pasting videos ....................................................................................................................................... 25
Moving videos ............................................................................................................................................................... 26
Renaming a video ......................................................................................................................................................... 26
Uploading, sharing or emailing a video ................................................................................................................... 26
Playing and managing video les using your computer
(Windows/Mac) ....................................................................... 27
Removing the microSD card ..................................................................................27
Opening video les in BlackVue Viewer ..............................................................28
Viewer screen composition....................................................................................29
Windows Viewer .............................................................................................................................29
Mac Viewer ......................................................................................................................................30
Playing video ............................................................................................................31
Playing back videos.......................................................................................................................31
Identify video les by recording type ........................................................................................ 31
Checking the displayed time .......................................................................................................33
Using BlackVue Viewer.................................................................................................................. 33
Exploring the timeline and G-Sensor graph ............................................................................. 34
Zoom options .................................................................................................................................35
Checking the GPS data.................................................................................................................. 36
Managing videos......................................................................................................37
Capturing or printing a still image from video.........................................................................37
Deleting videos ..............................................................................................................................37
For Windows users ......................................................................................................................................................... 37
For Mac users .................................................................................................................................................................. 38
Exporting videos ............................................................................................................................39
For Windows users ......................................................................................................................................................... 39
Copying videos............................................................................................................................... 40
For Windows users ......................................................................................................................................................... 40
For Mac users .................................................................................................................................................................. 41
Tips for optimal performance ..................................42
Formatting the microSD card ................................................ 42
Formatting the card in the BlackVue....................................................................42
Format using BlackVue Viewer (Windows)..........................................................42
Format using BlackVue Viewer (macOS)..............................................................43
Upgrading the rmware......................................................... 45
Upgrading the rmware using an iOS or Android device
(Firmware Over The Air)..........................................................................................45
Upgrading the rmware using a computer (Windows or Mac).......................48
Changing settings .....................................................50
Changing settings using your smartphone (Android/iOS).. 50
Basic settings ............................................................................................................51
Time settings...................................................................................................................................52

DR900S-1CH 3
Video settings................................................................................................................................. 54
Resolution ....................................................................................................................................................................... 54
Video Codec ................................................................................................................................................................... 55
Image quality.................................................................................................................................................................. 55
Enhanced night vision................................................................................................................................................... 55
Brightness........................................................................................................................................................................ 55
Recording settings.........................................................................................................................56
Voice recording............................................................................................................................................................... 56
Date & time display........................................................................................................................................................ 57
Speed unit ...................................................................................................................................................................... 57
Video segment length................................................................................................................................................... 57
Lock event les ............................................................................................................................................................... 57
Front camera rotation ................................................................................................................................................... 57
Sensitivity settings ..................................................................................................58
G-Sensor (Normal mode) / G-Sensor (Parking mode) ............................................................. 59
Motion detection (Parking mode) .............................................................................................. 60
System settings ........................................................................................................61
LED.................................................................................................................................................... 61
Recording status ............................................................................................................................................................ 61
Security (Normal mode)................................................................................................................................................ 61
Security (Parking mode) ............................................................................................................................................... 61
Wi-Fi (Parking mode)..................................................................................................................................................... 61
Proximity Sensor ............................................................................................................................ 62
Voice guidance ...............................................................................................................................62
Impact detected in parking mode.............................................................................................................................. 62
Volume .............................................................................................................................................62
Scheduled Reboot..........................................................................................................................62
Speed alert ......................................................................................................................................62
User text overlay ............................................................................................................................62
Wi-Fi settings ............................................................................................................63
Login credentials............................................................................................................................63
Wi-Fi auto turn on & o.................................................................................................................63
Cloud settings...........................................................................................................64
Enable Cloud service ..................................................................................................................... 64
Cloud service hotspot settings.................................................................................................... 65
Push notication settings.............................................................................................................66
FW Language ............................................................................................................67
Changing settings using your computer (Windows/Mac)... 68
BlackVue Viewer settings........................................................................................69
Select language.............................................................................................................................. 69
Speed unit on map.........................................................................................................................69
Select map service .........................................................................................................................69
Use video accelerator....................................................................................................................69
Firmware settings ....................................................................................................70
Basic settings .................................................................................................................................. 71
Time settings................................................................................................................................................................... 71
Video settings................................................................................................................................................................. 72
Recording settings......................................................................................................................................................... 73
Sensitivity settings ........................................................................................................................ 75
G-Sensor (Normal mode) / G-Sensor (Parking mode) ............................................................................................. 75
Motion detection (Parking mode) .............................................................................................................................. 76
Advanced sensitivity settings for normal and parking mode ............................................................................... 76
System settings .............................................................................................................................. 78
LED.................................................................................................................................................................................... 78
Proximity Sensor ............................................................................................................................................................ 79
Voice guidance ............................................................................................................................................................... 79
Volume ............................................................................................................................................................................. 79
Scheduled Reboot.......................................................................................................................................................... 79
Speed alert ...................................................................................................................................................................... 80
User text overlay ............................................................................................................................................................ 80
Wi-Fi settings ..................................................................................................................................81
Login credentials............................................................................................................................................................ 81
Wi-Fi settings .................................................................................................................................................................. 81
Cloud settings................................................................................................................................. 82
Enable Cloud service ..................................................................................................................................................... 82
Cloud service hotspot settings.................................................................................................................................... 83
Push notication settings............................................................................................................................................. 83
Applying the settings....................................................................................................................83
About the Cloud Service ...........................................84
Connect to BLACKVUE CLOUD (Optional) ............................ 84
Optional accessories .................................................89
Parking mode hardwiring kit (Optional) .............................. 89
Parking mode battery pack (Optional) ................................. 90
ENGLISH

4BLACKVUE
Troubleshooting ........................................................91
Changing / resetting direct Wi-Fi SSID and password ......... 91
On-device Wi-Fi SSID and password reset...........................................................91
Change Wi-Fi SSID and password over the Cloud..............................................92
Change the Wi-Fi password using BlackVue Viewer (Windows or Mac) ........94
Product specications...............................................95
Recording time ..........................................................97
Disposal and recycling information.........................98

DR900S-1CH 5
Introduction
Thank you for purchasing this BlackVue dashcam made by Pittasoft Co., Ltd.
This instruction manual contains information on how to operate your dashcam.
Before using your dashcam, we recommend that you read through this manual to ensure correct usage.
To improve the performance of the product, the contents of this manual are subject to change without prior notice.
Note
yA formatted microSD card is provided with the BlackVue dashcam when you purchase the product. Insert the microSD card in the
dashcam and power it up. The microSD card will be initialized.
ENGLISH

6BLACKVUE
Important safety information
For user safety and to avoid property damage, read through this manual and follow these safety instructions to use the product correctly.
Failure to observe the following directions could result in death or property damage:
DANGER
yDo not disassemble, repair, or modify the product yourself.
Doing so may cause re, electric shock, or malfunction. For internal inspection and repair, contact the service center.
yIf any foreign matter gets inside the product, detach the power cord immediately.
Contact the service center for repair.
yDo not adjust the product while driving.
Doing so may cause an accident. Stop or park your car in a safe place before installing and setting up the product.
yDo not install the product in a location where the product can interfere with the driver's eld of vision.
Doing so may cause an accident.
yDo not use a damaged or modied power cord. Only use the cords provided by the manufacturer.
Damaged or modied power cords may cause an explosion, re, or malfunction.
yDo not operate the product with wet hands.
Doing so may cause electric shock.
yDo not install the product in an environment with high humidity, or combustible gases or liquids.
Doing so may cause an explosion and/or re.

DR900S-1CH 7
Failure to observe the following directions could result in death or serious injury:
WARNING
yDo not leave the product near infants, children, or pets.
There is a risk of them swallowing small components, and/or their saliva may get into the product, causing an explosion due to a short
circuit.
yDo not spray water or wax directly onto the product while cleaning the inside of the car.
Doing so may cause re, electric shock, or malfunction.
yIf smoke or an unusual smell is emitted from the power cord, detach the power cord immediately.
Contact the service center or your distributor.
yKeep the terminals of the power cord clean.
Failure to do so may cause excessive heat and re.
yUse the correct input voltage.
Failure to do so may cause explosion, re, or malfunction.
yPlug in the power cord rmly so that it cannot easily be disconnected.
Failure to do so may cause re.
yDo not cover the product with any material.
Doing so may cause external deformation of the product or re. Use the product and peripherals in a well-ventilated location.
ENGLISH

8BLACKVUE
Failure to observe the following directions could result in injury or property damage:
CAUTION
yDo not spray cleaning products directly onto the product.
Doing so may cause discoloration, cracks, or malfunction.
yIf the product is used outside the optimal temperature range (-20°C – 70°C / -4°F – 158°F), performance can decline or
malfunctions may occur.
yMake sure that the product is installed properly.
If installed incorrectly, vibrations may cause the product to fall, and may cause physical injury.
yWhen entering or exiting a tunnel, when directly facing into bright sunlight, or when recording at night without lighting the
quality of recorded video may deteriorate.
yIf the product is damaged or the power supply is cut due to an accident, video may not be recorded.
yExcessively tinted windshield glass can distort the recorded video or cause recorded video to be indistinct.
yProlonged use of the product can increase the interior temperature and cause burns.
ymicroSD cards are consumables, so replace microSD cards after prolonged use.
microSD cards may not record video correctly after extended use, so check the microSD card's recording capability periodically and
replace as necessary.
yClean the lens regularly.
Foreign material attached to the lens can aect the recording quality.
yDo not remove the microSD card while the microSD card is saving or reading data.
The data can be damaged or malfunctions may occur.
yIt is recommended that you install the software and rmware from the BlackVue downloads page (www.blackvue.com).
yIt is recommended that you remove the power cord if the product (BlackVue dashcam/Parking Mode Hardwiring Kit) is not used
for an extended period of time.

DR900S-1CH 9
Overview
In the box
Check the box for each of the following items before installing the BlackVue dashcam.
BlackVue dashcam microSD card reader microSD Card
Power cord Quick start guide Pry tool
Double-sided
tape for the
Mounting Bracket
Cable clips (5EA)
Note
yThe illustrations in this manual may dier from the product.
yTo improve the performance of the product, the contents of this manual are subject to change without prior notice.
yFor more information about the package components and accessories, visit the BlackVue website (www.blackvue.com).
ENGLISH

10 BLACKVUE
At a glance
The following diagrams explain each part of the BlackVue dashcam.
36 mm
Camera lens
Mounting bracket Front security LED
: Blinks slowly during normal mode and parking mode motion detection standby.
: Blinks quickly when (i) an event is being recorded (impact detected),
(ii) manual recording has started, or (iii) motion is detected in parking mode.
Lock button
55 mm
118.5 mm
GPS LED
: GPS is on
Recording LED
: Blinks orange in normal mode.
: Blinks red when (i) an event is being recorded (impact detected),
or (ii) manual recording has started.
: Blinks green in parking mode when motion is detected.
Speaker

DR900S-1CH 11
Proximity Sensor:
Touch or wave a nger within 20mm of the sensor to turn on/
o audio recording.
Alternatively, it can be set as a manual recording trigger in the
rmware settings.
Wi-Fi/Internet LED
: Direct Wi-Fi is on.
: Blinks when connected to the internet (Cloud connected).
Wi-Fi / Format button:
–Press once to turn on/o Wi-Fi.
–Press and hold for 5 seconds and once voice instructions start, release
the button. Then press once again to reset the Wi-Fi SSID and password
or press and hold for 5seconds to format the microSD card.
CoverDC in
(power connector)
microSD card slot
ENGLISH

12 BLACKVUE
Removing and inserting the dashcam
Serial number label
Connectivity details label:
–Default Wi-Fi SSID
–Default Wi-Fi password
–Cloud code
–QR code
yTo remove the dashcam from its bracket, press the LOCK button and pull the dashcam out of the mounting bracket.
yTo insert the dashcam into its bracket, push the dashcam into the mounting bracket until it "clicks" in.

DR900S-1CH 13
Installation
Installing the BlackVue dashcam
Install the BlackVue dashcam behind the rear view mirror. Remove any foreign matter and clean and dry the windshield before installation.
Warning
yDo not install the product in a location where it can obstruct the driver's eld of vision.
1
Turn o the engine. Open the cover of the microSD card slot, gently push the card into the slot until it locks into place and close the
cover.
ENGLISH

14 BLACKVUE
2Peel o the protective lm from the double-sided tape and attach the dashcam to the windshield behind the rear-view mirror.
3Adjust the angle of the lens by rotating the body of the dashcam. We recommend pointing the lens slightly downwards (≈10° below
horizontal), so as to record video with a 6:4 road to background ratio.
4Plug the power cord into the cigarette lighter socket and the dashcam.
5Use the pry tool to lift the edges of the windshield trim/molding and tuck in the power cord.

DR900S-1CH 15
6Turn on the engine. The BlackVue dashcam will power up and start recording. Video les are stored on the microSD card. When the
microSD card lls up, the newest video les will start to replace the oldest video les (called loop recording) – so you will always
have the most recent video les.
7Turn o the engine. The dashcam will automatically stop recording and power down. To record in parking mode while the engine is
o please install a Power Magic Battery Pack (sold separately) or a Power Magic Pro (sold separately). A Power Magic Pro powers
your dashcam when the engine is o by hardwiring it to the automotive battery. A low voltage power cut-o function and a parking
mode timer protect the automotive battery from discharge.
Note
yUp to 50 event recordings (impact, manual) can be locked from being overwritten. By default, this feature is disabled. You can
enable it from rmware settings and choose to either overwrite them with new event les when the event le storage is full
or lock the 50 event les and save the new event les in loop recording storage. Please note that formatting the microSD card
deletes all the recordings including the locked event les.
yThe recording LED blinks while recording (default setting) and the GPS LED is on when a GPS signal is received. There are 4
recording modes: Normal, Event, Parking and Manual. The dashcam starts recording in normal mode, switches to event mode
when an impact is detected, and switches to parking mode if the vehicle is stationary for 5 minutes. Touching the proximity
sensor turns on/o audio recording or triggers manual recording depending on the rmware settings.
yWhen you run the dashcam for the rst time the rmware is automatically loaded onto the microSD card. After the rmware has
been loaded onto the microSD card you can customize settings using BlackVue Viewer on a computer.
ENGLISH

16 BLACKVUE
Playing and Managing Videos
Playing and managing video les using your smartphone (Android/iOS)
Opening video les
1
Search for the BlackVue app in the Google Play Store or Apple App Store and install it on your smartphone.
2“Pair” your smartphone with the BlackVue dashcam via direct Wi-Fi:
a. Unplug the power cable and remove the front dashcam from its mount. With the label visible, plug in the power cable and wait for
the dashcam to start normal recording. Press the Wi-Fi button once to turn on Wi-Fi.
b. Go to your smartphone's Settings then select Wi-Fi, and make sure Wi-Fi is turned on.

DR900S-1CH 17
c. Choose your BlackVue dashcam from the network list. The dashcam’s default SSID begins with its model number (e.g.
BlackVue****-******).
d. Enter the password and tap join.
* The default Wi-Fi SSID and password are printed on the dashcam's label.
e. Open the BlackVue app and select BLACKVUE WI-FI.
Note
yDirect Wi-Fi lets you directly connect your smartphone to your dashcam via Wi-Fi within a range of 10m.
yThe BlackVue app is available for devices running Android 4.4.2 and higher, or iOS 9.0 and higher.
yYou can change the Wi-Fi SSID and password as described on page 92 and 94.
ENGLISH

18 BLACKVUE
BLACKVUE WI-FI screen composition
Firmware settings
Live View
BlackVue SSID
File type lter buttons
Refresh video list
Copy to Internal Memory
Video le pop-up menu
Video list
Note
yAll images shown are for illustration purposes only. Actual app may dier from images shown.

DR900S-1CH 19
Playing video
Playing back videos
Select the video le you want to play from the video list.
Press the refresh button to refresh the video list.
Note
yThe playback of 4K UHD resolution, 'Highest' image quality and/or H.265 coded videos depends on your device's hardware and
software. Older devices may not support 4K UHD, 'Highest' image quality or H.265 video playback. If you encounter issues please
check your device's video playback capabilities.
Identify video les by recording type
Normal The dashcam records in normal mode by default.
Event
When the dashcam detects an impact while in normal or parking mode, it switches to event mode and
saves an event recording beginning 5 seconds before the event trigger. Exceeding the set speed limit
will also trigger an event recording.
Parking In parking mode the dashcam continuously buers video. When motion is detected in the dashcam's
eld of view, it saves a parking recording beginning 5 seconds before the motion detection.
Manual If proximity sensor is set as a manual recording trigger in the rmware settings, touching or waving a
nger within 20mm of the sensor will turn on manual recording.
Tap the car icon to load the thumbnail of a recording.
ENGLISH

20 BLACKVUE
Recording le names include the date, time, recording type and camera direction.
yRecording type: N: Normal
E: Event
P: Parking mode motion detection
M: Manual
yCamera direction: F: Front camera
yExample le name: 20170104_150838_NF.mp4
Date & time: 4th January 2017, 03:08:38 PM
Recording type: Normal
Camera direction: Front camera
Note
yUse the , , , buttons to lter the video list by recording type (Normal, Event, Parking and Manual). The
lter button displays both E (Event) and I (Impact event while parked) recordings.
yThe dashcam requires a constant power source to record in parking mode. See "Optional accessories" on page 89 for more
information.
