Smart Witness CP Series User manual

Vehicle Ca eras
CP Series
www.smartwitness.com
User Manual
CP-S CP-R CP-V CP-VA CP-P

Index
CP-S 960H Analog Vehicle Ca era
CP-R 960H Analog Vehicle Ca era
CP-V 960H Analog Vehicle Ca era
CP-VA 960H Analog Vehicle Ca era with Audio
CP-P 960H Analog Vehicle Ca era
Safet Advice
Please unpack the box carefully and identify that all the parts are
present.
Make sure you use the reco ended power input. Da age caused
to the ca era by incorrect voltage is not covered by the warranty.
Do not atte pt to open the casing to access the ca era. Da age
caused to the ca era by ta pering with the ca era casing is not
covered by the warranty.
What’s in the box (applies to all models)
• Ca era
• S all Screw Tool
..................................................Page 3
..................................................Page 7
..................................................Page 9
...............................Page 12
.................................................Page 15

Introduction
The CP-S is a 960H Analog Camera.
It features a 2.88mm lens and has a viewing angle between 110-120°.
Adjusting the Camera
To adjust the angle of the camera, use the screw tool provided and unscrew the
screws located on the sides of the camera. There are 3 in total.
To unscrew, turn anticlockwise to open the screw from the base.
Then adjust the camera, remove the protective bracket holding it in place.

Adjusting the Camera Continued
Then adjust the camera manually with your hand to your preferred position.
After you have completed your adjustment, replace the protective bracket
Then close the casing of the camera and screw back the screws.

Mounting the camera
To mount the camera, remove the screws from all sides
Drill a hole in the centre of the camera and screw it into
your desired location.
Replace the camera and screw in the screws.

Specification CP-S
Video System PAL
Pick Up Element Colour Sony 1/3” CCD Image Sensor
Image Signal Process Digital Signal Processing System
Lens / Viewing Angle 2.8mm - 96º
Number Of Pixel 960 x 576
Effective Pixels 960 (H)× 576 (V)
esolution Analog 700TVL
Audio No
Power Supply DC 12 ± 1A, Aviator connector to MDV
Power Consumption 5 Watts
Scanning System 2:1 Interlace
Sensitivity 0.01 Lux (I 10m)
S/N atio Max 62 dB
Auto Gain Control Auto
Mirroring Yes
White Balance Auto
Electronic Shutter Auto: 1/50 S to 1/100,000 S (Pal)
Output 1 Vp-p Composite Video Output,
75 OHMS, Aviator connector to MDV
Operating Temperature -10°C ~ +60°C
Dimensions (HxWxD) 89 x 77 x 63mm
Weight 215g
IP ating IP69K

Introduction
The CP-R is a 960H Analog Rear view Mirrored camera.
Adjusting the Camera
To adjust the angle of the dome camera, use the screw tool provided and unscrew
the screws located on the sides of the camera.
To unscrew, turn anticlockwise to open the screw from the base.
Then adjust the camera by moving the lower bracket.

Specification CP-R
Video System PAL
Pick Up Element Colour Sony 1/3” CCD Image Sensor
Image Signal Process Digital Signal Processing System
Lens / Viewing Angle 2.8mm - 96º
Number Of Pixel 960 x 576
Effective Pixels 960 (H)× 576 (V)
esolution Analog 700TVL
Audio No
Power Supply DC 12 ± 1A, Aviator connector to MDV
Power Consumption 5 Watts
Scanning System 2:1 Interlace
Sensitivity 0.01 Lux (I 10m)
S/N atio Max 62 dB
Auto Gain Control Auto
Mirroring Yes
White Balance Auto
Electronic Shutter Auto: 1/50 S to 1/100,000 S (Pal)
Output 1 Vp-p Composite Video Output,
75 OHMS, Aviator connector to MDV
Operating Temperature -10°C ~ +60°C
Dimensions (HxWxD) 89 x 77 x 70mm
Weight 285g
IP ating IP69K

Introduction
The CP-V is a 960H Analog Dome Camera.
It features a 2.88mm lens and has a viewing angle between 90-100°.
Adjusting the Camera
To adjust the angle of the dome camera, use the screw tool provided and unscrew
the screws located on the sides of the camera. There are 3 in total.
To unscrew, turn anticlockwise to open the screw from the base.
Then adjust the camera by turning it to the required position then replace the
bottom bracket.

Mounting the Camera Continued
Get the correct drill bit for the size of the holes which you need to drill.
After drilling, feed through the camera wires into the base, as shown above. Then
screw back the remaining screws.

Specification CP-V
Video ystem PAL
Pick Up Element Colour ony 1/3” CCD Image ensor
Image ignal Process Digital ignal Processing ystem
Lens / Viewing Angle 2.8mm - 96º
Number Of Pixel 960 x 576
Effective Pixels 960 (H)× 576 (V)
Resolution Analog 700TVL
Audio No
Power upply DC 12 ± 1A, Aviator connector to MDVR
Power Consumption 5 Watts
canning ystem 2:1 Interlace
ensitivity 0.01 Lux (IR 10m)
/N Ratio Max 62 dB
Auto Gain Control Auto
Mirroring No
White Balance Auto
Electronic hutter Auto: 1/50 to 1/100,000 (Pal)
Output 1 Vp-p Composite Video Output,
75 OHM , Aviator connector to MDVR
Operating Temperature -10°C ~ +60°C
Dimensions (HxWxD) 82 x 86 x 86mm
Weight 215g
IP Rating IP66

Introduction
The CP-VA is a Internal only 960H Analog Dome Camera with built in audio
It features a 2.88mm lens and has a viewing angle between 90-100°.
Adjusting the Camera
To adjust the angle of the dome camera, use the screw tool provided and unscrew
the screws located on the sides of the camera. There are 3 in total.
To unscrew, turn anticlockwise to open the screw from the base.
Then adjust the camera by turning it to the required position then replace the
bottom bracket.

Mounting the Camera Continued
Get the correct drill bit for the size of the holes which you need to drill.
After drilling, feed through the camera wires into the base, as shown above. Then
screw back the remaining screws.

Specification CP-VA
Video ystem PAL
Pick Up Element Colour ony 1/3” CCD Image ensor
Image ignal Process Digital ignal Processing ystem
Lens / Viewing Angle 2.8mm - 96º
Number Of Pixel 960 x 576
Effective Pixels 960 (H)× 576 (V)
Resolution Analog 700TVL
Audio Built-in
Power upply DC 12 ± 1A, Aviator connector to MDVR
Power Consumption 5 Watts
canning ystem 2:1 Interlace
ensitivity 0.01 Lux (IR 10m)
/N Ratio Max 62 dB
Auto Gain Control Auto
Mirroring No
White Balance Auto
Electronic hutter Auto: 1/50 to 1/100,000 (Pal)
Output 1 Vp-p Composite Video Output,
75 OHM , Aviator connector to MDVR
Operating Temperature -10°C ~ +60°C
Dimensions (HxWxD) 50 x 69 x 69mm
Weight 310g
IP Rating IP66

Introduction
The CP-P is a 960H Analog Internal Dome Camera.
It features a 2.88mm lens and has a viewing angle between 90-100°.
Adjusting the Camera
To adjust the angle of the dome camera, use the screw tool provided and unscrew
the screws located on the sides of the camera. There are 3 in total.
To unscrew, turn anticlockwise to open the screw from the base.
Then adjust the camera, remove the protective bracket holding it in place.

Adjusting the Camera Continued
Then adjust the camera manually with your hand to your preferred position.
After you have completed your adjustment, replace the protective bracket
Then close the casing of the camera and screw back the screws.

Specification CP-P
Video ystem PAL
Pick Up Element Colour ony 1/3” CCD Image ensor
Image ignal Process Digital ignal Processing ystem
Lens / Viewing Angle 2.8mm - 96º
Number Of Pixel 960 x 576
Effective Pixels 960 (H)× 576 (V)
Resolution Analog 700TVL
Audio No
Power upply DC 12 ± 1A, Aviator connector to MDVR
Power Consumption 5 Watts
canning ystem 2:1 Interlace
ensitivity 0.01 Lux (IR 10m)
/N Ratio Max 62 dB
Auto Gain Control Auto
Mirroring No
White Balance Auto
Electronic hutter Auto: 1/50 to 1/100,000 (Pal)
Output 1 Vp-p Composite Video Output,
75 OHM , Aviator connector to MDVR
Operating Temperature -10°C ~ +60°C
Dimensions (HxWxD) 63 x 118 x 118mm
Weight 270g
IP Rating None
