SMART LightRaise 40wi User manual

LightRaise™ 40wi
interactive projector
User’s guide

Product registration
If you register your SMART product, we’ll notify you of new features and software upgrades.
Register online at smarttech.com/registration.
Keep the following information available in case you need to contact SMARTSupport.
Serial number:
Date of purchase:
FCC warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the manufacturer’s instructions, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
Trademark notice
LightRaise, SMARTNotebook, SMARTInk, SMARTBoard, smarttech, the SMART logo and all SMART taglines are trademarks or registered trademarks of
SMARTTechnologiesULC in the U.S. and/or other countries. Blu-ray is a trademark of the Blue-ray Disc Association. DLP is a registered trademark of Texas Instruments.
Texas Instruments, BrilliantColor and DLP Link are trademarks of Texas Instruments. All third-party product and company names may be trademarks of their respective
owners.
Copyright notice
© 2012 SMARTTechnologiesULC. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated
into any language in any form by any means without the prior written consent of SMARTTechnologiesULC. Information in this manual is subject to change without notice
and does not represent a commitment on the part of SMART.
One or more of the following patents: US6320597; US6326954; US6540366; US6741267; US7151533; US7411575; US7643006; US7757001; US7880720; USD616462;
USD617332; USD643046 and USD649976. Other patents pending.
08/2012

Important information
Read the following warnings carefully. Failure to read the warnings below or to follow the installation
instructions included with your SMART product could result in personal injury or product damage and
may void your warranty.
WARNING
lFailure to follow the installation instructions shipped with your SMART product could result in
personal injury and damage to the product.
lEnsure that any cables extending across the floor to your SMART product are properly
bundled and marked to avoid a trip hazard.
lMake sure an electrical socket is near your SMART product and remains easily accessible
during use.
lTo reduce the risk of fire or electric shock, do not expose the SMART product to rain or
moisture.
lYou must connect the USB cable that came with your SMART product to a computer that
has a USB compliant interface and that bears the USB logo. In addition, the USB source
computer must be compliant with CSA/UL/EN 60950 and bear the CE mark and CSA and/or
UL Mark(s) for CAS/UL 60950. This is for operating safety and to avoid damage to your
SMARTproduct.
lTo attach the wall tether, use the appropriate hardware for your wall type. Failure to do so
could result in injury if the unit detaches from the wall.
lDo not touch or replace the projector lamp (which will be very hot) for at least 30 minutes after
you turn it off. Failure to do so can cause severe burns.
i

Contents
Important information i
Chapter 1: About your interactive projector 1
LightRaise 40wi interactive projector features 1
Optional accessories 3
How your interactive projector works 3
Chapter 2: Installing your interactive projector 5
Choosing a location 5
Routing the cables 8
Installing SMARTNotebook software 9
Chapter 3: Using your interactive projector 11
Using your projector 11
Focusing the image 21
Adjusting the image 22
Projector connection diagram 22
Using your interactive pen 24
Chapter 4: Integrating other devices 27
Video format compatibility 27
Native video format 28
HD and SD signal format compatibility 29
Video system signal compatibility 29
Connecting peripheral sources and outputs 30
Chapter 5: Maintaining your interactive projector 31
Cleaning the projector 32
Replacing the projector lamp module 33
Resetting the lamp hours 36
Chapter 6: Troubleshooting your interactive projector 39
Determining your interactive projector’s status 40
Determining if your interactive projector is connected to your computer 42
Determining your interactive pen’s status 43
Troubleshooting issues with interactive features 44
Resolving image issues 45
Accessing the service menu 48
Resolving projector errors 49
i

Troubleshooting audio issues 51
Locating the serial number 51
Chapter 7: Remotely managing your interactive projector 53
Accessing web page management 53
Home 54
Control panel 54
Control panel II 57
Network settings 57
E-mail alerts 59
Password settings 59
Simple Network Management Protocol (SNMP) 60
Chapter 8: Connecting your room control system to your interactive projector 61
Command inventory 61
Value-based command methods 62
Power state controls 63
Source selection controls 64
General source controls 64
Additional VGA source controls 66
Additional Composite video source controls 66
Audio controls 67
Network controls 70
System controls 70
Appendix A: Hardware environmental compliance 75
Waste Electrical and Electronic Equipment regulations (WEEE directive) 75
Restriction of Certain Hazardous Substances (RoHS directive) 75
Batteries 75
Packaging 76
Covered electronic devices 76
China’s Electronic Information Products regulations 76
Restriction of Certain Chemicals (REACH directive) 76
Index 77
C O N T E N T S
ii

Chapter 1: About your interactive projector
LightRaise 40wi interactive projector features 1
Interactive projector 2
Interactive pen 2
Remote control 2
Pen holder 3
USB charging cable 3
Optional accessories 3
Hardware mounting kit 3
How your interactive projector works 3
This chapter describes the features and components of your LightRaise™ 40wi interactive projector.
LightRaise 40wi interactive projector features
Your LightRaise 40wi interactive projector is a wall-mounted, short-throw projector that transforms
any wall or dry-erase whiteboard into an interactive surface.
You can use the pen as a mouse device to interact with your computer and write in digital ink over
SMARTNotebook™ interactive learning software files.
When the interactive projector projects an image from your computer on a surface, you can do
everything that you can do at your computer—open and close applications, scroll through files, hold
meetings with others, create new documents or edit existing ones, visit websites, play videos and
more—by touching the surface with the interactive pen.
This projector supports video and audio connections from a variety of devices, including DVD/Blu-
ray™ players, VCRs, document cameras and digital cameras, and can project media from these
sources onto the interactive screen.
When you use SMART software with your interactive projector, you can write or draw over the
projected computer image in digital ink, and then save these notes to a .notebook file or directly into
any Ink Aware application.
Chapter 1
1

Interactive projector
The features of your projector include the following:
lWall-mounted, projection engine that uses DLP®
technology by TexasInstruments™, providing
BrilliantColor™ performance and quality Gamma 2.2
correction with Bright Room, Dark Room, sRGB, User
and SMART Presentation modes.
lInteractive features that allow you to use the pen as a mouse device and to write in digital ink
l3D-ready using DLPLink™ technology
lNTSC, NTSC 4.43, PAL, PAL-N, PAL-M and SECAM video system compatibility
lWXGA 1280 × 800 display resolution
lHD-ready, maximum resolution 720p pixel perfect, 1080i supported
l16:10 and 16:9 selectable native aspect ratios with support for 4:5 and 4:3 ratios with scaling
l2900:1 contrast ratio
l102" (259.1 cm) diagonal maximum interactive area size on a blank wall
l0.30:1 throw-ratio
lBuilt-in speaker
lSecure mounting and installation system that includes the following safety features:
oOptional projector padlock ring to prevent removal of the projector from the boom
oA safety tether
oTemplates and instructions for positioning the system safely
Interactive pen
The interactive pen enables you to interact with your computer and write in digital ink. You can
perform a left-click by touching the pen nib to the projection surface. It has a left-click button that
enables you to use the pen from a short distance.
Remote control
The projector remote control enables you to access on-screen projector menus and to change
projector settings.
C H A P T E R 1
About your interactive projector
2

Pen holder
Store your interactive pen in the holder when you’re not using it and when you’re charging it with a
USBcharging cable. The holder is also a convenient place to store the remote control.
USB charging cable
Charge your interactive pen with the included USB charging cable.
Optional accessories
These accessories aren’t included with your projector, but you can order them from your authorized
SMART reseller.
Hardware mounting kit
You can order a hardware mounting kit from your authorized SMART reseller. It contains an
assortment of screws and wall anchors for several different wall types.
How your interactive projector works
Your interactive projector uses optical and radio frequency signals to detect the position of the pen. It
projects patterns that aren’t visible to the eye that the pen detects, and then sends this information to
the projector.This allows the projector to determine the position of the pen as you move it. Touching
the pen to the surface depresses the pen nib, which registers a left-click. If you’re using
SMARTInk™ or SMARTNotebook software, you can write in digital ink.
Your interactive projector has similar features as an interactive whiteboard and allows you and your
audience to interact with content and collaborate with each other. Because the interactive technology
is in the projector and not the board, almost any surface can be an interactive surface.
C H A P T E R 1
About your interactive projector
3
