smartheart 19-103 User manual

TALKING
Digital Weight Scale
Model # 19-103
INSTRUCTION MANUAL
ENGLISH AND SPANISH
Please read this instruction manual
completely before operating this device.

2 • ENGLISH
Three (3) AAA
Batteries
Instruction Manual
STOP!
PLEASE ENSURE YOU HAVE ALL OF THE FOLLOWING
COMPONENTS BEFORE USING YOUR WEIGHT SCALE.
This product is specially designed for body weight measurement for persons
who are able to stand on the scale platform for medical purposes. It should
never be used for verication of goods’ weight. Personal weight results should
be discussed with your physician or healthcare professional; this device is not
intended to diagnose, treat or prevent an illness.
INTENTION FOR USE

ENGLISH • 3
Care & Safety Information.....................................................................4
Introduction .........................................................................................5
Product Overview ................................................................................5
Battery Installation................................................................................6
Mode Selection....................................................................................6
Instructions for Use ..............................................................................7
Care and Maintenance.........................................................................8
Device & Label Symbols........................................................................8
Troubleshooting & Error Codes ..............................................................9
FCC Information ................................................................................10
Specications ....................................................................................11
Warranty ..........................................................................................12
Instrucciones en Español ................................................................13-24
INDEX
SmartHeart™
Manufactured for
Veridian Healthcare
1175 Lakeside Drive
Gurnee, IL 60031
Made in China
#93-1462 02/20
©2020 Veridian Healthcare, LLC

4 • ENGLISH
CARE & SAFETY INFORMATION
NOTE: Read all instructions carefully before use. The following basic precautions are needed
when using an electrical product.
CAUTION: Failure to read and observe all precautions could result in personal injury or equip-
ment damage.
SAFETY CAUTIONS AND WARNINGS
• Do not use on slippery oor such as some tiles or laminates
• Do not use with wet feet; feet should be completely dry before use
• Do not use near a cell phone or microwave oven
• Do not drop the scale; take care not to drop items onto the scale; do not jump onto the scale
or while on the scale
• Always stand in the center of the scale; do not stand on the edges or allow feet to hang off
the edge(s)
GENERAL CAUTIONS AND WARNINGS
• Do not use the unit if it has any damaged parts or if the top is cracked
• If any abnormality occurs, discontinue use until the unit has been examined and repaired
• Do not disassemble the unit or attempt to repair it; doing so may result in results error and
will void manufacturer warranty
• Always follow local regulations for proper disposal of the digital scale and batteries
• Do not use this device simultaneously with other diagnostic monitoring equipment
OPERATING CAUTIONS AND WARNINGS
• Operation outside of stated operating temperature may result in measurement error or
device malfunction; operation environment temperature is: 32°F – 104°F (0°C – 40°C);
Humidity: 25%~85%R.H.
• Read and follow the Instructions For Use section of this manual for safe use of this device
STORAGE CAUTIONS AND WARNINGS
• Storage outside of stated storage temperature may result in measurement error or device
malfunction; storage environment temperature is: -4°F – 140°F (-20°C – 60°C); Humidity:
20%~90%R.H.
• Avoid storage near water, moisture or excessive humidity
• Avoid storage in extreme temperatures, direct sunlight, dust or salt air
• Keep out of the reach of infants, children or incapacitated persons
CLEANING CAUTIONS AND WARNINGS
• Never immerse the unit in water to clean as it may damage the unit
• Follow the ‘Cleaning and Maintenance’ portion of this manual for instruction on how to
clean and care for your scale

ENGLISH • 5
Thank you for purchasing a SmartHeart TALKING Digital Weight Scale.
Please read this instruction manual completely before using your unit to ensure
safe and effective use, as well as long life of the product.
INTRODUCTION
PRODUCT OVERVIEW
DETAILS OF THE DIGITAL DISPLAY SCREEN
AND INTERPRETATION OF THE SYMBOLS
ARE INCLUDED THROUGHOUT THIS
MANUAL.
LCD
Display
GLASS
Platform
MODE
Button
BATTERY
Compartment
SENSOR
Feet
Pound
Kilogram

6 • ENGLISH
BATTERY INSTALLATION
This unit includes 3 AAA batteries.
It is necessary to replace the batteries when the display does not turn
on when being activated by stepping on the scale.
The battery compartment is located on the underside of this scale.
1. Depress the clip on the battery compartment cover and remove.
2. Insert or replace 3 AAA batteries into the battery compartment,
following the indicated polarity. Always use new batteries.
3. When batteries are rst installed, device will default to English
audio announcements in Lbs.
4. Replace the battery cover.
5. Dispose of batteries according to local disposal and recycling
regulations.
It is recommended to remove the batteries if the unit will not be used
for an extended period of time.
MODE SELECTION–POUND (LB), KILOGRAM (KG), TALKING
This scale will automatically default to pound (LB) unit
of measure and audible English language.
1. The scale must be ON/Active to change modes.
2. To change the unit of measure mode, press and release the
UNIT button on the back side of the monitor.
3. The display will alternate between ‘lb’ ‘kg’ with and without
audio annoucements.
MODE/
UNIT
Button
• Lbs, English audio ON
• Kg, English audio ON
• Kg, Spanish audio ON
• Lbs, NO audio
• Kg, NO audio
4. When the desired unit of measure is active, release the button. The unit of measure
mode is now set.

ENGLISH • 7
INSTRUCTIONS FOR USE
SENSE-ON Technology—The Talking Digital Scale will automatically turn on when you step
onto the scale. It is not necessary to turn the unit ON/OFF.
FOR BEST RESULTS:
• Weigh yourself before eating
• Weigh yourself at the same time of day;
ideally in the mornings after using the bathroom
• Weigh yourself naked or in minimal clothing
• The Talking Digital Scale should be used on a at, hard surface
• Use on soft surfaces such as carpeting may affect the accuracy of your results
• Remain still; do not hold onto or lean on anything
SIMPLE STEP INSTRUCTIONS:
1. Step onto the scale. Stand still with your feet evenly
planted on the scale surface, which will result in a more
even weight distribution and more accurate results.
2. Stand still and keep full contact with the scale surface.
3. Allow the scale several seconds to calculate the nal
results; you will notice the numbers uctuate multiple
times before the true weight is reached.
4. Take care not to move or shift during measurement.
5. The results will show on the display – lb, kg – with or
without the audio announcement depending upon the
mode selected. The results will display for approximate-
ly 10 seconds.
6. The digital scale will turn off after approximately 10
seconds.

8 • ENGLISH
CARE & MAINTENANCE
Use common sense caution when cleaning an electronic device.
• The scale may be dusted with a soft cloth, or wiped down with a damp cloth.
• Always dry the scale top after cleaning.
• Never get excessively wet or submerge the scale in water.
• Never use propellant, abrasive or other chemicals on the scale.
• Do not disassemble this device; doing so may void the manufacturer’s warranty.
• Follow the Operating and Storage Temperature ranges as indicated in the Specications
section of this manual.
• Follow the indicated weight range capacity; weight in excess of the stated range may
damage the unit.
• It is recommended that the battery be removed if the scale will not be used for an
extended period of time.
These symbols may appear on your device, instructions or packaging and may
vary by make and model.
Read This Manual—All included manuals should be read prior to rst
use
Warning—Symbol indicates a warning, prohibition or mandatory
action that mitigates a risk that is not necessarily obvious to the device
operator
Environment Protection—dispose of this product properly; consult with
your local recycling ordinances for proper recycling and disposal
Keep Dry—This device should be kept dry; never submerge the unit or
cuff. Consult with the Care and Maintenance section of this manual for
information on cleaning your monitor
Symbol Meaning

2012

2012
DEVICE & LABEL SYMBOLS

ENGLISH • 9
TROUBLESHOOTING & ERROR CODES
ERROR
Overload / too much
weight is on the scale. The
unit will shut off.
Low battery
This scale is not suitable for weight in
excess of 199 kg / 438.7 lbs; cease
using this scale.
Replace the batteries with new, unused
batteries.
DESCRIPTION SOLUTION
PROBLEM
Battery is not installed or
installed incorrectly; battery
is depleted.
Batteries are low
Blank LCD display
with the device is
powered on
The scale activates
but shuts off imme-
diately
Install 3 AAA batteries if not already
installed; check the polarity of the batter-
ies; install new battery.
Replace the batteries with new, unused
batteries.
DESCRIPTION SOLUTION

10 • ENGLISH
FCC INFORMATION FCC ID:OU9LS102-H
IMPORTANT INFORMATION REQUIRED BY THE FCC
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference; and (2) this device must accept any interference
received, including interference that may cause undesirable opera-
tion.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equip-
ment generates, uses, and can radiate radio frequency energy, and
if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
CAUTION: Changes or modications not expressly approved by the
party responsible for compliance could void the user’s authority to
operate the equipment.

ENGLISH • 11
Name SmartHeart Talking Digital Weight Scale
Model Number 19-103
Display System Digital display/LCD, 72.5x33.8mm
Scale Dimensions 11-3/4” x 11-3/4” x 9/10” / 300 x 300 x 23.5 mm
Scale Weight 4 lbs. 8 oz/2.04 kg (with batteries)
Measuring Unit Pound (lb) / Kilogram (kg)
Measuring Range 6.6 lb – 438.7 lb / 3 kg – 199 kg
Accuracy 50 kg: ±0.3kg 100 kg: ±0.5 kg
150 kg: ±0.7 kg 200 kg: ±1.1kg
Operating Temperature 32°F – 104°F (0°C – 40°C);
Environment Humidity 25%~85%R.H.
Storage Temperature -4°F – 140°F (-20°C – 60°C);
Environment Humidity 20%~90%R.H.
Power Source 3x AAA Alkaline batteries
Battery Life Approximately 350 measurements
Auto-On Sense-on Technology
Auto-Off After 10 seconds of non-use
Mode of Operation Continuous Operation
Accessories Instruction Manual; Three (3) AAA Battery
Specications are subject to change without notice
SPECIFICATIONS

12 • ENGLISH
ONE-YEAR LIMITED WARRANTY
Congratulations on your purchase of a Weight Scale. Your Weight Scale is covered by the follow-
ing limited warranty commencing upon the date of purchase, and subject to the following terms
and conditions:
The Warrantor warrants that its Weight Scale will be free from defects in materials and work-
manship under normal consumer usage for a period of one year for the original purchaser of the
product.
Periodic maintenance, repair and replacement of parts due to normal wear and tear are excluded
from coverage. Defects or damage that result from: (a) improper operation, storage, misuse or
abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of
the product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy
perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the Weight Scale for commer-
cial purposes or subjecting the Weight Scale to abnormal usage or conditions; or (d) other acts
which are not the fault of the Warrantor, are excluded from coverage. This warranty does not cover
batteries or other power sources that may be provided with, or used with the Weight Scale.
If the Weight Scale fails to conform to this limited warranty, return the Weight Scale postage
prepaid to: Attn: Repair Department, 1175 Lakeside Drive, Gurnee, IL, 60031. When
returning a product, please also include: (i) a copy of your receipt, bill of sale or other compara-
ble proof of purchase; (ii) a written description of the problem; and (iii) your name, address and
telephone number. Carefully package the product to avoid any damage that may occur while in
transit; shipping insurance with returned receipt is recommended. At our option, the Warrantor will
repair or replace the unit found to be defective in materials or workmanship under normal consum-
er usage. The purchaser will be notied of any additional repairs required prior to completing the
repair, and will be responsible for parts charges, if any, and repair charges not covered by this
limited warranty.
EXCEPT AS PROVIDED FOR IN THIS LIMITED WARRANTY, ALL EXPRESS AND IMPLIED WARRAN-
TIES AND CONDITIONS ARE DISCLAIMED, INCLUDING WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE REPAIR
OR REPLACEMENT AS PROVIDED UNDER THIS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY
OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED. IN NO EVENT SHALL THE WARRANTOR BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE
PRODUCT, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES
OF ANY KIND, OR FOR DAMAGES TO, OR LOSS OF, OTHER PROPERTY OR EQUIPMENT OR
PERSONAL INJURIES TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or exclusion of incidental or consequential
damages, or limitation on the length of an implied warranty, so the above limitations or exclusions
may not apply to you. This warranty gives you specic legal rights, and you may also have other
rights that vary from state to state or from one jurisdiction to another.

MANUAL DE INSTRUCCIONES
ESPAÑOL
Lea las instrucciones en su totalidad antes de
utilizar la unidad.
PARLENTE
Balanza Digital
Modelo # 19-103

14 • ESPAÑOL
Tres (3) Una (1)
baterías AAA
Manual de instrucciones
¡ALTO!
ASEGÚRESE DE TENER TODOS LOS COMPONENTES
QUE SE INDICAN A CONTINUACIÓN ANTES
DE UTILIZAR LA BALANZA.
Este producto está especialmente diseñado para la medición de peso
corporal para las personas que son capaces de pararse en la plataforma
de la balanza para los propósitos médicos. Nunca debe utilizarse para
la vericación del peso de las mercancías. Resultados de peso personal
deben discutirse con su médico o profesional sanitario; Este dispositivo no
está diseñado para diagnosticar, tratar o prevenir una enfermedad.
INTENCIÓN DE USO

ESPAÑOL • 15
Información sobre cuidado y seguridad.............................................16
Introducción ...................................................................................17
Generalidades del producto.............................................................17
Colocación de baterías....................................................................18
Selección de modos ........................................................................18
Instrucciones de uso .......................................................................19
Cuidado y mantenimiento ................................................................20
Símbolos del dispositivo y de las etiquetas .........................................20
Detección de problemas y códigos de errores ....................................21
Información de la Comisión Federal de Comunicaciones de los Estados
Unidos ..........................................................................................22
Especicaciones..............................................................................23
Garantía........................................................................................24
ÍNDICE
SmartHeart™
Manufactured for
Veridian Healthcare
1175 Lakeside Drive
Gurnee, IL 60031
Hecho en China
#93-1462 02/20
©2020 Veridian Healthcare, LLC

16 • ESPAÑOL
INFORMACIÓN SOBRE CUIDADO Y SEGURIDAD
NOTA: Lea con atención todas las instrucciones antes del uso. Cuando se usa un producto
eléctrico se deben tener en cuenta las siguientes precauciones básicas.
PRECAUCIÓN: Si no lee ni presta atención a todas las precauciones, puede resultar lesio-
nado(a) o dañar el equipo.
PRECAUCIONES Y ADVERTENCIAS DE SEGURIDAD
• No usar en pisos resbaladizos tales como cerámicos o plasticados.
• No usar con los pies mojados; séquese bien los pies antes de usar la balanza.
• No usar cerca de un teléfono celular u horno a microondas.
• No deje caer la balanza; ponga cuidado para no dejar caer elementos sobre ella; no salte
sobre la balanza ni mientras esté sobre ella.
• Ubíquese en el centro de la balanza; no se pare sobre los bordes ni con los pies fuera de
ellos.
PRECAUCIONES Y ADVERTENCIAS GENERALES
• No use la unidad si alguna de sus partes está dañada o si la parte superior está rota.
• Si se produce alguna anormalidad, interrumpa el uso hasta que la unidad haya sido exam-
inada y reparada.
• No desarme ni intente reparar la unidad, pues podría arrojar resultados erróneos y anulará
la garantía del fabricante.
• Siempre siga las normas locales para desechar la balanza digital y las baterías en la forma
correcta.
• No use este dispositivo con otros equipos de monitoreo de diagnóstico.
PRECAUCIONES Y ADVERTENCIAS PARA SU USO
• Si se usa a temperaturas diferentes a las indicadas, se puede producir un error en la
medición o el mal funcionamiento del dispositivo; la temperatura ambiente operativa es:
32°F - 104 °F (0°C - 40 °C); humedad: 25%~85%R.H. de humedad relativa.
• Lea y siga las instrucciones de uso indicadas en la sección correspondiente de este manual
para garantizar el uso seguro de este dispositivo.
PRECAUCIONES Y ADVERTENCIAS DE ALMACENAMIENTO
• Si la unidad se guarda a temperaturas diferentes a las indicadas, se puede producir un
error en la medición o el mal funcionamiento del dispositivo; la temperatura ambiente de
almacenamiento es: -4°F - 140°F (-20°C - 60°C); humedad: 20%~90%R.H de humedad
relativa.
• Evite guardar el dispositivo cerca de agua, humedad o excesiva humedad ambiental.
• Evite guardar el dispositivo en lugares de temperaturas extremas, exponerlo a la luz solar
directa, al polvo o a un ambiente salino.
• Mantenga alejado del alcance de bebés, niños o personas discapacitadas.
PRECAUCIONES Y ADVERTENCIAS PARA LA LIMPIEZA
• Nunca sumerja la unidad en agua para su limpieza, pues ello podría dañarla.
• Siga las instrucciones de la sección ‘Limpieza y mantenimiento’ de este manual acerca de
cómo limpiar y cuidar la balanza.

ESPAÑOL • 17
Gracias por comprar la Balanza Digital PARLANTE SmartHeart. Lea este man-
ual de instrucciones en su totalidad antes de utilizar la unidad para garan-
tizar un uso seguro y efectivo y una vida útil prolongada del producto.
INTRODUCCIÓN
DESCRIPCIÓN GENERAL DEL PRODUCTO
SE INCLUYEN EN ESTE MANUAL
DETALLES DE LA PANTALLA DIGITAL E
INTERPRETACIÓN DE LOS SÍMBOLOS.
LCD
Pantalla
VIDRIO
Plataforma
MODA
Botón
BATERÍA
Compartimento
SENSOR
Pies
Libras
Kilogramos

18 • ESPAÑOL
COLOCACIÓN DE LA BATERÍA
Esta unidad incluye baterías 3 AAA.
Es necesario cambiar las baterías cuando no se encienda la pantalla
al subirse a la balanza para activarla.
El compartimento de la batería está ubicado en la parte de abajo de
la balanza.
1. Presione la presilla en la cubierta del compartimento de la
batería y quítela.
2. Inserte o reemplace baterías 3 AAA en el compartimento de
la batería, siguiendo la polaridad indicada. Siempre utilice
baterías nuevas.
3. Cuando se instalen baterías por primera vez, el dispositivo
hará los anuncios de audio en inglés y en libras.
4. Coloque nuevamente la tapa de la batería.
5. Deshágase de las baterías de acuerdo con las normas locales
de desecho y reciclado.
Se recomienda retirar las baterías si no usará la unidad durante un
período prolongado.
SELECCIÓN DE MODO–LIBRAS (LB), KILOGRAMOS (KG), PARLANTE
Esta balanza automáticamente utilizará la unidad de
medición libra (LB) y el idioma hablado inglés.
1. La balanza debe estar en ON/Activa para cambiar de
modo.
2. Para cambiar la unidad del modo de medición, presione y
suelte el botón UNIDAD en la parte de atrás del monitor.
3. La pantalla alternará entre ‘lb’ ‘kg’ con o sin anuncios de
audio.
MODA/
UNIDAD
Botón
• Lbs, inglés audio ON (encendido)
• Kg. inglés audio ON (encendido)
• Kg. español audio ON (encendido)
• Lbs, NO (SIN) audio
• Kg, NO (SIN) audio
4. Cuando se encuentre activa la unidad de medición deseada, suelte el botón. Ya se jó
el modo de unidad de medición.
5. Cuando la unidad de medida deseada esté activa, suelte el botón. El modo de unidad
de medida ahora está congurado.

ESPAÑOL • 19
INSTRUCCIONES DE USO
Tecnología SENSORIAL—La Balanza digital Parlante automáticamente se encenderá al
subirse a ella. No es necesario encender la unidad ON/OFF.
PARA OBTENER LOS MEJORES RESULTADOS:
• Pésese antes de comer
• Pésese a la misma hora del día, idealmente en las mañanas después de ir al baño.
• Pésese sin o con poca ropa.
• La Balanza Digital Parlante debe usarse en una supercie plana y dura
• Su uso en supercies suaves, como alfombras, puede afectar la exactitud de los resul-
tados.
• Permanezca quieto, no se apoye sobre nada ni se sostenga
INSTRUCCIONES SIMPLES PASO A PASO:
1. Súbase a la balanza. Quédese quieto con los pies
sobre la supercie de la balanza uniformemente
plantados, lo cual distribuirá mejor el peso y dará
resultados más exactos.
2. Quédese quieto y apoyando todo el pie en la balanza.
3. Al cabo de unos segundos la balanza calculará los re-
sultados nales; observará que los números uctuarán
múltiples veces antes de llegar al peso verdadero.
4. Trate de no moverse ni inclinarse durante la medición.
5. Los resultados aparecerán en la pantalla – lb, kg
– con o sin el anuncio de audio, dependiendo del
modo seleccionado. Los resultados se mostrarán du-
rante aproximadamente 10 segundos.
6. La balanza digital se apagará después de aproxima-
damente 10 segundos

20 • ESPAÑOL
CUIDADO Y MANTENIMIENTO
Use el sentido común cuando efectúe la limpieza del dispositivo electrónico.
• Limpie de polvo la balanza con un paño suave o con un paño húmedo.
• Seque siempre la carcasa de la balanza después de limpiarla.
• Nunca moje excesivamente ni sumerja en agua la balanza.
• Nunca use propelente, abrasivo ni ninguna otra sustancia química para limpiar la
balanza.
• No desarme este dispositivo, pues anulará la garantía del fabricante.
• Observe los rangos de temperatura operativa y de almacenamiento indicados en la
sección Especicaciones de este manual.
• Observe el rango de capacidad indicado; el exceso de peso respecto del rango indica-
do podría dañar la unidad.
• Se recomienda retirar las baterías si no usará la balanza durante un período prolonga-
do.
Estos símbolos pueden aparecer en la balanza, instrucciones o embalaje y pueden
variar según la marca y el modelo.
Lea este manual—Antes de usar la balanza por primera vez se deben leer
todos los manuales que se incluyen
Advertencia—El símbolo indica una advertencia, prohibición u acción
obligatoria que mitiga un riesgo que no es necesariamente obvio para el
operador de la balanza
Protección ambiental—disponga adecuadamente de este producto; consulte
las ordenanzas locales para el adecuado reciclaje y desecho de la unidad
Mantenga seco—Este aparato se debe mantener seco; nunca sumerja la
unidad. Consulte la sección Cuidado y mantenimiento en este manual para
más información sobre la limpieza de su aparato
Símbolo Signicado

2012

2012
SÍMBOLOS DEL DISPOSITIVO Y DE LAS ETIQUETAS
