Smartparts SP15MW User manual

QUICK START………………………………………...…………...…..……………1
DIAGRAM OF THE DIGITAL PICTURE FRAME...………………………………2
KEYPAD BUTTON FUNCTIONS...……..…………………………………………3
REMOTE CONTROL FUNCTIONS………………………………………………..4
DIGITAL PICTURE FRAME NAVIGATION…..……………....…………………...5
OSD MENU FUNCTIONS…………………………………….…………………….6
ADDITIONAL PICTURE FRAME FEATURES.....…..………………………………7
ADDITIONAL FEATURES CONTINUED…...……………....…………………...8
USING THE MINI-USB FOR FILE TRANSFER…..…………………….………9
SAVING AND DELETING FILE FROM INTERNAL MEMORY..…….………10
TECHNICAL SPECIFICATIONS…..…………………………………………....11
FREQUENTLY ASKED QUESTIONS….………………………………………...12
IMPORTANT SAFETY INSTRUCTIONS……………………………………….13
CLEANING THE DIGITAL PICTURE FRAME…………………………………..15
TABLE OF CONTENTS

1
Congratulations on your purchase of a Smartparts, Inc. 15” LCD Digital Picture
Frame.Please read carefully and follow all warnings and instructions in this User's
Manual and those marked on the product before you use the Digital Picture Frame.
Failing to follow warnings can result in personal injury or damage to the Digital
Picture Frame. Please keep this User's Manual in a convenient location for future
reference.
Important: Save the original box and all packing material for future shipping
needs.
Quick Start
1. Plug the AC adapter into the Digital Picture Frame and plug it into a power
outlet.
2. Insert a memory card into one of the slots:
Slot 1 - Secure Digital or MultiMedia Card
Slot 2 - Compact Flash or Micro Drive
Slot 3 - xD-Picture Card
Slot 4 - Memory Stick , Memory Stick PRO , Memory Stick Duo , or Memory
Stick PRO Duo.
Or insert a USB Flash Drive into the USB port.
Note: To view a sample of how the Digital Picture Frame displays digital photos,
simply turn on the frame without inserting a memory card.
3. Push the power button for a few seconds on the back of the Digital Picture
Frame to turn on the frame.
TM TM
TM TM
TM TM TM
TM
TM

Diagram of the Digital Picture Frame
USB Port for USB Flash Drives
Mini USB Port for File Transfer
AC Power Input
xD-Picture Card Slot
TM
Memory Stick ,Memory Stick PRO ,
Memory Stick Duo ,and
Memory Stick PRO Duo Slot
TM
TM
TM
TM
Secure Digital and
Multi Media Card Slot
TM
TM
Compact Flash and
Micro Drive Slot
TM
TM
Keypad
Power Button
Adjustable Stand
Speaker
2

Keypad Button Functions
On Screen Display Functions
Note: To enter the On Screen Display (OSD), press the Menu button at any
time (except when in Slide Show or playing a video). To exit the OSD, simply
press the Exit button.
Button Command
<< Up
Play Select
>> Down
Exit Exit OSD Menu
Menu Enter OSD Menu
Viewing Images Individually
Button Command
<< Go to the Previous Image
Play Start Slide Show
>> Go to the Next Image
Exit Return to Thumbnail View
Menu Enter OSD Menu
Thumbnail View / Select Mode Page / Card Select Page
Button Command
<< Left
Play Select
>> Right
Exit Back to the previous page
Menu Enter OSD Menu
Viewing Video Files
Button Command
<< Go to the Previous Video File
Play Play / Pause Video File
>> Go to the Next Video File
Exit Exit Video
Menu Enter OSD Menu
3

Remote Control Functions
DIGITAL PICTURE FRAME
ON/OFF
4

Digital Picture Frame Navigation
Using the Play and Exit button, you will be able to advance or go back a Menu
Page within the Digital Picture Frame.
The top Menu Page is the “Select Card” Page. To enter this selection, press
the Exit button twice from Thumbnail View.
Select Card Page
SD / MMC
MS / MS Duo
CF / MD
XD
Built-in Memory
Selecting an option that is highlighted will take you to the next page.
Select Mode Page
Photo Selecting “Photo” will allow you to preview your photos through
Thumbnail View.
Slideshow This selection will automatically start Slide Show.
Audio Selecting “Music” will list all music files available for hearing.
Select a file and press the “ENTER” button to hear.
Video Selecting “Video” will list all video files available for viewing.
Select a file and press the “Play” button to view.
Clock Select the “Clock” option to enter the clock setup menu. From here
you can access the Set Date/Time, Auto Power On, Auto Power Off
options to customize the settings.
5

OSD Menu Functions
All function settings for the Digital Picture Frame can be controlled via the
buttons located on side of the Frame. You can access the On Screen Display
(OSD) at any time, except when in Slide Show Mode or playing a video,
by pushing the “Menu” button.
Slide Show Shuffle This function allows images to be displayed in random order and can
be turned on or off
This selection allows video files to automatically repeat themselves
when finished.
This function allows you to save images from the memory card that
have been changed thru the OSD into the internal flash memory
This allows a file to be copied from a memory card into the internal
flash memory.
This allows an image to be deleted from the internal flash memory.
This allows a file to be rotated 90 degrees clock-wise
This allows you to zoom into a picture.
This function allows you to select images to appear more often.
Resets all settings back to default.
Changes the OSD menu language: English, Italian, German, French,
Spanish, Portuguese or Dutch
This function allows you to adjust the brightness of the screen and
adjust the contrast
This function allows you to adjust the color and adjust the tint
Video Repeat
Save Screen
Copy File
Delete File
Rotate
Zoom
Set Favorite
Reset Settings
Language
Brightness/ Contrast
Color/ Tint
6
Slide Show Speed This selection allows you to choose the speed of the Slide Show
Slide Show Effect This selections allows you to choose the transition style of Slide Show
This function allows you to adjust how the image fits on the screen.
"Original" retains the original aspect ratio of the image. "Optimal"
optimizes the image to fit the screen
Image Size
OSD Menu Description and Function of Operation
This function allows you to turn on/off the show clock.Show Clock
This function allows you to turn on/off the slide show plus calendar
feature.
Slideshow+Calendar

Additional Digital Picture Frame Features
Clock
You can display the clock on the screen by turning on the Show Clock feature in
the Setup Menu. The clock will be display on the bottom of the frame.
Auto On/Off
The digital photo frame has the ability to automatically turn on or off at any time
of the day. You can customize your settings by accessing the Auto On/Off setup
menu.
Note: Press Enter to save your settings.
Setting Favorite Pictures
Marking an image as a Favorite allows you to see the image more often during
Slide Show. To do so, in Thumbnail View highlight a picture and enter the OSD
by pressing the Menu button. Select “Set Favorite” and a small check mark will
appear next to the image. To unmark a picture, repeat the same steps.
Note - Favorite pictures will not be saved once the frame has been turned off.
Calendar
This feature transforms the DPF into a calendar. The slide show feature is
available in calendar mode to allow you to display your photos.
Note: To access the clock setup menu, select "setup" under the clock screen
Click "exit" or "setup" to exit the setup menu
7

8
Additional Features - Continued
Slide Show Shuffle
Slide Show Shuffle allows you to display your photos in random order during
Slide Show. You may turn this feature “on” or “off” in the OSD under “Slide
Show Shuffle”.
Rotate and Zoom
At anytime when you are viewing images individually, you can zoom or rotate a
picture. When viewing an image, push the Menu button to display the OSD.
Scroll down to Rotate or Zoom. By pushing the play button you will be able to
rotate or zoom the image. If you press the Next or Previous button, the image
will revert back to its original form. You will not be able to zoom and rotate a
picture at the same time.
You can save changes made to the image into the internal memory if you are
changing a file from an inserted memory card.
Saving Screen to an Image
You can save changes made to an image into the internal memory if you are
changing the file from an inserted memory card. To do so, after you have either
rotated or zoomed to your preference, enter the OSD menu and select Save
Changes. Once you hit select, the changes made to the image will be saved
into the internal flash memory.
Adjusting the Stand
Simply push the button in the back to adjust the angle of the stand. If you wish
to have the unit in portrait orientation, simply remove the four screws, re-adjust
the stand and place the screws back into place.

9
Using the Mini-USB for File Transfer
The Digital Picture Frame comes with 256MB of built-in Flash Memory. Make
sure that the Frame is first turned off before connecting a USB cable from a
computer to the Digital Picture Frame and ensure that the power supply is
plugged into the Digital Picture Frame.
Turn on the Digital Picture Frame. Once the computer has detected the Digital
Picture Frame, you will be able to download compatible image or video files
stored in your computer or delete them from the internal memory of the Digital
Picture Frame.
Disconnecting the Frame from a PC Computer:
1. Click the “Safely Remove Device” icon on the Task Bar located on the
bottom right corner of the computer Desktop.
2. A dialogue box (“Safely Remove Hardware”) will appear.
3. Select USB Mass Storage Device and click “Stop”.
4. On the next dialogue box, click “OK”.
5. On the final dialogue box, click “Close”. Now you can safely remove the
Digital Photo Frame.
The saved images will appear once you have turned off the Frame and turned
it back on.
Note: Attempting to disconnect the Digital Picture Frame without using
the “Safely Remove Device” procedure may cause the files in the internal
memory to be unreadable.

10
Saving to and Deleting an Image from the
Internal Flash Memory
How to save an image into the internal memory from a Memory Card:
Note: The Copy File function only allows compatible image files from the
memory card to be copied onto the internal memory.
1) Make sure that the Digital Picture Frame is turned off.
2) Insert a memory card into the Digital Picture Frame.
3) After turning on the frame, exit the Slide Show and highlight the picture you
would like to save into the internal memory.
4) Press the “Menu” button to enter the OSD. Select “Copy File” to save the
image into the internal memory.
How to delete files from the internal memory:
Note: The Delete File function only allows files in the internal memory to be
deleted.
1) When viewing images from the internal memory, go to Thumbnail View and
highlight the picture you would like to delete.
2) Press the “Menu” button to enter the OSD.
3) Select “Delete File” to delete the image from the internal memory.

11
Technical Specifications
Product: 15” LCD Digital Picture Frame
Input Formats: Secure Digital , Secure Digital High Capacity ,
Multi Media Card , Compact Flash ,Micro Drive ,
xD-Picture Card , Memory Stick ,Memory Stick PRO ,
Memory Stick Duo , Memory Stick PRO Duo and
USB Flash Drives
File Format: JPEG, AVI Motion JPEG, MPEG1, MPEG4, MP3
Features: Individual Picture View and Slide Show
Range of Transitional Styles for Slide Show
Variable Speed for Slide Show
Random Picture Shuffle
Set Favorite Pictures
Copy and Save Functions
Color Adjustment Functions
Show clock
Slideshow+calendar
Auto power on
Auto power off
AVI Motion JPEG Player
MPEG 1 and 4 Video Player
Extendable Stand for Angle Adjustment
Wall-mountable VESA hole pattern (75mm x 75mm)
Internal Memory: 256MB
USB Ports: Mini-USB (for file transfer), USB (for USB Flash Drives)
Power: Input: 100V-240V AC, 50~60HZ
Output: 9V DC, 2A
Weight: 3.5kgs
Dimensions: 416X340X55(mm)
TM TM TM
TM TM
TM TM TM
TM TM

12
Frequently Asked Questions
Q: What other media formats can the Digital Picture Frame support? Why will it
not play all images or movie files?
A: The Digital Picture Frame will support JPEGs and AVI Motion JPEGs taken
from a digital camera. The Digital Picture Frame may not read all images or
video files downloaded from the Internet. Many of the video formats
downloaded from the Internet are not supported as well.
Q: I have a memory card in the Digital Picture Frame, but it's not reading the
card. What should I do?
A: First, make sure that you are using a memory card that is supported by the
Digital Picture Frame. Second, ensure that the memory card is inserted all
the way into the correct slot. Third, press the Menu button until you reach
the Card Select page. If the memory card is properly inserted into the slot,
that memory card icon will be highlighted.
Note: Some digital cameras save images into non-standard formats. Please
refer to your camera's operating manual for specifics.
Q: Why do some pictures load faster than others?
A: Higher resolution pictures load slower. Using a lower resolution when taking
pictures will speed up loading time.
Q: If I have a card inserted into the frame, but I want to run the Slide Show with
pictures in the internal memory, what should I do?
A: Go to the Card Select page and select “Built-in Memory”. Go to Photos and
select an image. Press the Play Button and the unit will go into Slide Show.
Q: How do I rotate portrait photos to display correctly on the frame?
A: Rotate the images by using a computer. Portrait pictures must stand upright
to allow the Digital Picture Frame to detect it as a portrait picture. Pictures
that are EXIF compatible will automatically rotate within the frame.

13
IMPORTANT PRODUCT SAFETY INSTRUCTIONS
Proper Handling of the Digital Picture Frame
Always handle the Digital Picture Frame with care. Avoid touching the LCD
screen. Skin oils are difficult to remove.
Always position the Digital Picture Frame on a stable and level surface. Unstable
surfaces can cause the Digital Picture Frame to topple and fall, resulting in
possible damage or injury.
Avoid exposing the Digital Picture Frame to direct sunlight or high temperatures,
which can damage or shorten its useful life. Do not place it near heat sources
such as radiators, heat registers, or other appliances that generate heat. Orient
the Digital Picture Frames away from direct sunlight to reduce glare.
Avoid exposing the Digital Picture Frame to rain, water, moisture or high
humidity. Do not place it near basins or sinks where it may come in contact with
water.
Never place heavy or sharp objects on the LCD panel, frame, or power cord.
Overloading Outlets
Do not overload electrical power sources when using the Digital Picture Frame.
Overloading wall outlets, circuits, or extension cords can result in overheating,
fire, or electric shock. Use only grounded or polarized outlets.
Power Cord Protection
Minimize wear on the power supply cord. The power supply cord should be
routed away from foot traffic and contact with other objects. Do not route the
power cord under rugs or carpeting. The cord should never be severely bent,
pinched, or twisted. Periodically inspect the power cord and each end of the
cord for wear or damage. Unplug and replace the cord if it is damaged.

14
Ventilation
Slots and openings on the Digital Picture Frame are provided for ventilation
purposes. To ensure reliable operation of the product and to protect it from
overheating, these openings must not be blocked or covered. Keep the Digital
Picture Frame a minimum of four (4) inches away from any wall to assure
sufficient airflow and ventilation. Increased temperatures may cause fire or
device failure.
To assure proper ventilation, do not block the openings by placing the Digital
Picture Frame on a bed, sofa, rug or other similar surface. Do not place it in a
built-in installation, such as a bookcase or enclosed rack, unless proper
ventilation is provided.
Other Notices and Precautions
Caution: Never remove the plastic casing. There are no user serviceable parts
inside. The Digital Picture Frame contains high voltage parts. You may be
seriously injured if you touch them.
Do not attempt repairs yourself. The warranty does not cover repairs or
attempted repairs by anyone not authorized by Smartparts, Inc. Refer all
servicing and repairs to qualified service personnel.
If the Frame begins to emit smoke, an abnormal noise, or a strange odor,
immediately turn it off and unplug the power cord. Contact Smartparts, Inc.
If the Digital Picture Frame will not be used for an extended period of time,
unplug the power cord.

Cleaning the Digital Photo Frame
MAKE SURE THE DIGITAL PHOTO FRAME IS TURNED OFF
NEVER SPRAY OR POUR LIQUID DIRECTLY ONTO THE SCREEN
OR PLASTIC CASING
To Clean the Screen:
1. Wipe the screen with a clean, soft, lint-free cloth. This removes dust
and other particles.
2. If it still is not clean, apply a small amount of non-ammonia, non-alcohol
based glass cleaner on a clean, soft, lint-free cloth to clean the screen.
To Clean the Plastic Casing:
1. Use a soft, dry cloth.
2. If it still is not clean, apply a small amount of non-ammonia, non-alcohol
based, and mild non-abrasive detergent on a clean, soft, lint-free cloth
to clean the surface.
To Clean the Frame:
1. Use a soft, dry cloth.
Warranty and Technical Support
Smartparts, Inc. warrants its products against defects in material and
workmanship for a period of 90 days from the date the product was
purchased. For any warranty claims under this policy, please e-mail
Smartparts Inc. at [e-mail] or call us at
1.800.442.1418.
15

Made In ChinaA15-0215-310
