Trampoline “S”
Page 1
Installation instructions EN 1176-1
Maintenance instructions EN 1176-1
26.08.11
General
The work described must be carried out by a qualified person.
Due to the heavy weight of the completed trampoline, no further anchorage is necessary.
The trampoline is designed to be used on ground level.
Dimensions
Overall size 1.25 x 1.25 m
Minimum space 3.25 x 3.25 m
Jumping area 0.75 x 0.75 m
Clearance 1.50 m
Max. free drop height: 0.60 m
Age suitability
3 years and older
Number of users
1 person
Composition of the ground
Please refer to DIN EN 1176-1 for ground conditions in the play area.
We recommend a covering with shock-absorbing qualities like grass or synthetic surface. Sand,
bark mulch or wood chips aren’t able, while they can fall into the trampoline and decrease the
play function.
Installation tools
Tools supplied:
4 off Supporting iron rings
1 off Tool to assemble and/or remove jumping mats
List of supplied / Packing units
1 Palett
Figure 1 Trampoline S

Technical Information
Trampoline „S“
Page 2
Assembly
The trampoline is erected after the ground has been
excavated (450 mm deep, size according to number
of trampolines) and an even horizontal surface
created. If there is a bad grown situation (e.g. loamy
soil) we recommend a drainage layer.
Boreholes (sealed with stoppers), which are for the
four supporting iron rings supplied (close boreholes
again!), are located on the sides. One must ensure
that the framework is lying snug and does not wobble.
This can be checked simply by standing on it. The
play level is to be remade by filling in appropriately
Removal and/or assembly of the jumping mat
The trampoline is supplied complete with suspended jumping mat. The jumping mat must only be
removed when damaged or cleaning the trampoline
Using the tool supplied, the springs can be loosened from the suspended net from the top (Figure 3).To
do this, the hock is suspended in the eye of the tension spring which opens from the bottom and slowly
pulled onto the rope which is fastened onto the hook. If the spring extends enough, then the eye, which is
suspended on the jumping mat, falls down automatically.
Figure 2
Figure 3
smb
Seilspielgeräte GmbH Berlin
Handwerkerstraße 7
15366 Hoppegarten
Germany
Phone ++49 (0)3342 5 08 37 20
Fax ++49(0)3342 5 08 37 80

Technical Information
Trampoline „S“
Page 3
How to suspend the jumping mat:
•Tighten the springs
•Suspended the eyes
•Release the springs
Maintenance instructions EN 1176-1
Routine visual inspection
The frequency of this inspection depends on local conditions (high/low usage, vandalism, air
contamination, effects of the weather).
Operational inspection (every 6 months)
•Check toy for general damage or wear and tear.
•Check condition of the jumping mat, spring suspensions and protective panels.
Main inspection
The trampoline framework consists of galvanised sheets, 4 mm thick. In view of this fact, a main
inspection, which then includes checking the framework for corrosion, only needs to be carried out every
two years.
Notice to the type label
The type label is placed in the middle of the side panel. It is fixed there at the inner side. It could be
necessary to remove the jumping mat (see page 2 and 3, removal/assembly of the jumping mat), to
read the type label (producer, model, test number, TÜV-seal).
