Instruction Manual
Lock-Up Valve
Series IL201/211/220
The intended use of these Lock-Up Valves is to control the air in the
secondary pressurized air system. Depending on the signal pressure the
types 201 and 211 are locking the air and the type 220 is relieving the air.
Validated according to ISO 13849.
1 Safety Instructions
These safety instructions are intended to prevent hazardous situations
and/or equipment damage. These instructions indicate the level of potential
hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for safety and must be followed in addition to
International Standards (ISO/IEC)*1), and other safety regulations.
*1) ISO 4414: Pneumatic fluid power - - General rules relating to systems.
ISO 4413: Hydraulic fluid power - - General rules relating to systems.
IEC 60204-1: Safety of machinery - -Electrical equipment of machines.
(Part 1: General requirements)
ISO 10218-1: Manipulating industrial robots -Safety.etc.
This manual contains essential information for the protection of users and
others from possible injury and/or equipment damage.
Read this manual before using the product, to ensure correct handling,
and read the manuals of related apparatus before use.
Keep this manual in a safe place for future reference.
To ensure safety of personnel and equipment the safety instructions in
this manual must be observed, along with other relevant safety
practices.
Caution
Caution indicates a hazard with a low level of risk
which, if not avoided, could result in minor or
moderate injury.
Warning
Warning indicates a hazard with a medium level
of risk which, if not avoided, could result in death
or serious injury.
Danger
Danger indicates a hazard with a high level of risk
which, if not avoided, will result in death or serious
injury.
Warning
The compatibility of the product is the responsibility of the person
who designs the equipment or decides its specifications.
Since the product specified here is used under various operating
conditions, its compatibility with specific equipment must be decided by
the person who designs the equipment or decides its specifications
based on necessary analysis and test results. The expected
performance and safety assurance of the equipment will be
the responsibility of the person who has determined its compatibility with
the product. This person should also continuously review all
specifications of the product referring to its latest catalogue information,
1 Safety Instructions - continued
with a view to giving due consideration to any possibility of equipment
failure when configuring the equipment.
Only personnel with appropriate training should operate machinery
and equipment.
The product specified here may become unsafe if handled incorrectly.
The assembly, operation and maintenance of machines or equipment
including our products must be performed by an operator who is
appropriately trained and experienced.
Do not service or attempt to remove product and
machinery/equipment until safety is confirmed.
1) The inspection and maintenance of machinery/equipment should only
be performed after measures to prevent falling or runaway of the driven
objects have been confirmed.
2) When the product is to be removed, confirm that the safety measures
as mentioned above are implemented and the power from any
appropriate source is cut, and read and understand the specific product
precautions of all relevant products carefully.
3) Before machinery/equipment is restarted, take measures to prevent
unexpected operation and malfunction.
Contact SMC beforehand and take special consideration of safety
measures if the product is to be used in any of the following
conditions.
1) Conditions and environments outside of the given specifications, or
use outdoors or in a place exposed to direct sunlight.
2) Installation on equipment in conjunction with atomic energy, railways,
air navigation, space, shipping, vehicles, military, medical treatment,
combustions and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press
applications, safety equipment or other applications unsuitable for the
standard specification described in the product catalogue.
3) An application which could have negative effects on people, property
or animals requiring special safety analysis outside the scope of ISO
13849 described in this document.
4) Use in an interlock circuit, which requires the provision of double
interlock for possible failure by using a mechanical protective function,
and periodical checks to confirm proper operation.
Always ensure compliance with relevant safety laws and standards.
All electrical work must be carried out in a safe manner by a qualified
person in compliance with applicable national regulations.
Caution
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in
manufacturing industries.
If considering using the product in other industries, consult SMC
beforehand and exchange specifications or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
2 Specifications
2.1 Standard Specifications
Model
IL201
IL211
IL220
Action
Single action
Double acting
3 port
Signal pressure
Max.1.0 MPa Note 1)
Set pressure range
0.14 to 0.7 MPa Note 1)
Shut-off pneumatic
circuit pressure
Max.0.7 MPa
Ambient and fluid
temperature
-5 to +60 °C
Port size
Rc1/4
Differential
0.01 MPa Note 2)
Type of fluid
Air
Fluid quality
Oil-free filtered to 5μm air
Min. operating
frequency
1 cycle / 30 days
Flow rate Cv
0.9
0.9
1.1
2 Specifications - continued
Standards
Complies with the basic and well-tried safety
principles of ISO 13849-2:2012
B10
8,000 cycle Note 3)
B10d
16,000 cycle Note 3)
Weight
0.45 kg
0.64 kg
0.7 kg
Table 1
Notes:
Note 1) Provide a differential pressure of 0.1 MPa or more between the
signal pressure and set pressure.
If the differential pressure is small, the internal part is worn out due
to the structure of this product and the bleed amount from the
exhaust port increases, which may affect the characteristics.
Note 2) Pressure difference between lock activated and lock released.
Note 3) Under SMC test conditions. The B10 figure is estimated from SMC
life tests. The B10d figure is derived from B10 using the assumption
in EN ISO 13849-1:2008 Annex C. Contact SMC for details.
2.2 Principle of Operation
The signal air pressure enters the upper diaphragm chamber (1) to
generate a force. When this force is larger than the force generated by
compressing the adjusting spring (3), the upper diaphragm (2) is pushed
up, the exhaust port (4) is closed, and the signal air pressure enters the
lower diaphragm chamber (5) and acts the lower diaphragm (6). This
pushes down the piston (7) to open the valve. IL201 and IL211 enter the
status, in which the flow path between IN and OUT is opened. IL220 enters
the status, in which the flow path between IN1 and OUT is opened. If the
signal air pressure drops to a level below the set pressure for some reason,
the upper diaphragm (2) is pushed down, the pressure inside the lower
diaphragm (6) is exhausted from the exhaust port (4), and the valve (8) is
closed by the force of the spring (9). At this time, IN and OUT are shut
down in IL201 and IL211. In IL220, IN1 and OUT are shut down, and the
flow path between IN2 and OUT is opened. The set pressure is adjusted
with the adjusting screw (10).
Figure 1
Figure 2
2 Specifications - continued
Figure 3
Caution
Special products might have specifications different from those shown in
this section. Contact SMC for specific drawings. These drawings will give
the appropriate specification details and compliance with the safety
principles of ISO 13849, if applicable.
3 Installation
3.1 Installation Warning
Do not install the product unless the safety instructions have been read
and understood.
3.2 Environment Warning
Do not use in an environment where corrosive gases, chemicals, salt
water or steam are present.
Do not use in an explosive atmosphere.
Do not expose to direct sunlight. Use a suitable protective cover.
Do not install in a location subject to vibration or impact. Check the
product specifications.
Do not mount in a location exposed to radiant heat.
3.3 Piping Caution
Before piping make sure to clean up chips, cutting oil, dust etc.
When installing piping or fittings, ensure sealant material does not enter
inside the port. When using seal tape, leave 1.5 to 2 threads exposed on
the end of the pipe/fitting.
Tighten fittings to the specified tightening torque.
3 Installation –continued
3.4 Lubrication Caution
SMC products have been lubricated for life at manufacture, and do not
require lubrication in service.
If a lubricant is used in the system, use turbine oil Class 1 (no additive),
ISO VG32. Once lubricant is used in the system, lubrication must be
continued because the original lubricant applied during manufacturing
will be washed away.
4 Settings
Warning
Since connected equipment will operate when the manual override is
activated, confirm that conditions are safe prior to activation.
Adjusting screw
Adjusting spring
Exhaust port
Upper diaphragm
Upper diaphragm chamber
Lower diaphragm chamber
Lower diaphragm
Piston
Valve
Spring
Spring
Valve
Adjusting screw
Adjusting spring
Exhaust port
Upper diaphragm
Upper diaphragm chamber
Lower diaphragm chamber
Lower diaphragm
Piston
Adjusting screw
Adjusting spring
Exhaust port
Upper diaphragm
Upper diaphragm chamber
Lower diaphragm chamber
Lower diaphragm
Piston
Valve
Spring
IL201 IL211 IL220
ORIGINAL INSTRUCTIONS

IL02-SM00004EN
Page 2 of 3
5 How to Order
6 Outline Dimensions (mm)
6.1 IL201
6 Outline Dimensions (mm) - continued
6.2 IL211
6 Outline Dimensions (mm) - continued
6.3 IL220
7 Maintenance
7.1 General Maintenance Caution
Not following proper maintenance procedures could cause the product to
malfunction and lead to equipment damage.
If handled improperly, compressed air can be dangerous. Maintenance
of pneumatic systems should be performed only by qualified personnel.
Before performing maintenance, turn off the power supply and be sure to
cut off the supply pressure. Confirm that the air is released to
atmosphere.
After installation and maintenance, apply operating pressure and power
to the equipment and perform appropriate functional and leakage tests to
make sure the equipment is installed correctly.
If any electrical connections are disturbed during maintenance, ensure
they are reconnected correctly and safety checks are carried out as
required to ensure continued compliance with applicable national
regulations.
Do not make any modification to the product.
Do not disassemble the product, unless required by installation or
maintenance instructions.
8 Limitations of Use
8.1 Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and
Disclaimer” and “Compliance Requirements”. Read and accept
them before using the product.
Limited warranty and Disclaimer
1) The warranty period of the product is 1 year in service or 1.5 years
after the product is delivered, whichever is first(1). Also, the product may
have specified durability, running distance or replacement parts. Please
consult your nearest sales branch.
2) For any failure or damage reported within the warranty period which is
clearly our responsibility, a replacement product or necessary parts will
be provided.
This limited warranty applies only to our product independently, and not
to any other damage incurred due to the failure of the product.
3) Prior to using SMC products, please read and understand the
warranty terms and disclaimers noted in the specified catalogue for the
particular products.
8 Limitations of Use - continued
(1)Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted for a year after it
is delivered. Also, even within the warranty period, the wear of a product
due to the use of the vacuum pad or failure due to the deterioration of
rubber material are not covered by the limited warranty.
Compliance Requirements
1) The use of SMC products with production equipment for the
manufacture of weapons of mass destruction (WMD) or any other
weapon is strictly prohibited.
2) The exports of SMC products or technology from one country to
another are governed by the relevant security laws and regulations of
the countries involved in the transaction. Prior to the shipment of a SMC
product to another country, assure that all local rules governing that
export are known and followed.
Caution
SMC products are not intended for use as instruments for legal
metrology.
Measurement instruments that SMC manufactures or sells have not
been qualified by type approval tests relevant to the metrology
(measurement) laws of each country.
Therefore, SMC products cannot be used for business or certification
ordained by the metrology (measurement) laws of each country.
Warning
Any use in an ISO 13849 system must be within the specified limit and
application condition. The user is responsible for the specification, design,
implementation, validation and maintenance of the safety
system(SRP/CS)
IL
201
–
02
–
Action
201
Single acting
211
Double acting
220
3 Port
Thread type
Nil
Rc
N
NPT*
F
G*
*Semi-standard
Port size
02
1/4
Accessories
Nil
None
B
With bracket
Suffix
Nil
Standard
T
High temperature (-5 to +100 °C)
L
Low temperature (-30 to +60 °C)
S
External parts copper-free
ST
External parts copper-free/
High temperature (-5 to +100 °C)
SL
External parts copper-free/
Low temperature (-30 to +60 °C)

IL02-SM00004EN
Page 3 of 3
9 Contacts
AUSTRIA
SMC Pneumatik GmbH,Girakstrasse 8, AT-2100
Korneuburg, Austria
BELGIUM
SMC Pneumatics N.V. ⁄ S.A. Nijverheidsstraat 20, B-2160
Wommelgem, Belgium
BULGARIA
SMC Industrial Automation Bulgaria EOOD, Business
Park Sofia, Building 8-6th floor, BG-1715 Sofia, Bulgaria
CROATIA
SMC IndustrijskaAutomatikad.o.o. ZagrebačkaAvenija
104,10 000 Zagreb
CZECH REP.
SMC Industrial Automation CZ s.r.o. Hudcova 78a, CZ-
61200 Brno, Czech Republic
DENMARK
SMC Pneumatik A ⁄ S,Egeskovvej 1, DK-8700 Horsens,
Denmark
ESTONIA
SMC Pneumatics Estonia Oü,Laki 12, EE-10621 Tallinn,
Estonia
FINLAND
SMC Pneumatics Finland Oy, PL72, Tiistinniityntie 4, SF-
02031 Espoo, Finland
FRANCE
SMC Pneumatique SA.1, Boulevard de Strasbourg, Parc
Gustave Eiffel, Bussy Saint Georges, F-77607 Marne La
ValleeCedex 3, France
GERMANY
SMC Pneumatik GmbH, Boschring 13-15, 63329
Egelsbach, Germany
GREECE
SMC Italia Hellas Branch, Anagenniseos 7-9-P.C. 14342
N.Philadelphia, Athens, Greece
HUNGARY
SMC Hungary IpariAutomatizálásiKft.Torbágy u. 19, HU-
2045 Törökbálint, Hungary
IRELAND
SMC Pneumatics (Ireland) Ltd.2002 Citywest Business
Campus, Naas Road, Saggart, Co. Dublin, Ireland
ITALY
SMC Italia S.p.A.Via Garibaldi 62, I-20061Carugate,
(Milano), Italy
LATVIA
SMC Pneumatics Latvia SIA, Dzelzavas str. 120g, Riga,
LV-1021, Latvia
LITHUANIA
UAB “SMC Pneumatics”, Oslo g. 1, LT-04123 Vilnius,
Lithuania
NETHERLANDS
SMC Pneumatics B.V.De Ruyterkade 120, NL-1011 AB
Amsterdam, the Netherlands
NORWAY
SMC Pneumatics Norway AS, Vollsveien 13 C,
GranfosNæringspark, N-1366 Lysaker, Norway
POLAND
SMC Industrial Automation, Polska Sp z o.o.
02-826 Warszawa, ul. Poloneza 89
PORTUGAL
SMC España S.A. Zuazobidea 14, 01015 Vitoria, Spain
ROMANIA
SMC Romania S.r.l. StrFrunzei 29, Sector 2, Bucharest,
Romania
RUSSIA
SMC Pneumatik LLC. Business centre, building 3, 15
Kondratjevskij prospect, St.Petersburg, Russia, 195197
SLOVAKIA
SMC PriemyselnáAutomatizáciaSpols.r.o. Fantranská
1223, Teplickanadvahom, 01301, Slovakia
SLOVENIA
SMC IndustrijskaAvtomatikad.o.o. Mirnskacesta 7, SLO-
8210 Trebnje, Slovenia
SPAIN
SMC España S.A. Zuazobidea 14, 01015 Vitoria, Spain
SWEDEN
SMC Pneumatics Sweden AB,Ekhagsvägen 29-31, SE-
141 71 Segeltorp, Sweden
SWITZERLAND
SMC Pneumatik AG,Dorfstrasse 7, Postfach, 8484
Weisslingen, Switzerland
TURKEY
SMC PnömatikSanayiTicaretveServis A.Ş.
GülbaharCaddesi, Aydın Plaza, No: 9 ⁄ 4 Güneşli –
34212 , Istanbul
UK
SMC Pneumatics (U.K.) Ltd. Vincent Avenue, Crownhill,
Milton Keynes, Buckinghamshire MK8 0AN, United
Kingdom
URL :
http// www.smcworld.com (Global) http// www.smceu.com (Europe)
'SMC Corporation, Akihabara UDX15F, 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101
0021
Specifications are subject to change without prior notice from the manufacturer.
© 2016 SMC Corporation All Rights Reserved.
Template DKP50047-F-085D
