SMC Networks HEF Series User manual

Air-cooled
Peltier-type Chiller
Thermo-con/
Compact Type
150 mm
210 mm
130 mm
Replaceable
Compact
130 mm x 210 mm x 150 mm
HeightWidth Depth
Display/Operation panel
Dustproof filter
Circulating fluid level gauge
86 % reduction (294 s a41 s)
∗Compared with the existing product HECR002
∗Time to change the circulating fluid temperature from 30 °C to 20 °C
(when the circulating fluid IN and OUT are directly connected)
Now only takes about 41 seconds
to lower the temperature by 10 °C
Superior temperature
control
Cooling capacity: 220 W
Low-noise design (at low load):
37 dB
Temperature stability:
±0.1 °C
Set temperature range:
10 °C to 60 °C
HEF Series
CAT.EUS40-76A-UK

Peltier-type Chiller
Thermo-con/Compact Type Air-cooled HEF Series
Actual size 130 mm
Can precisely control the temperature
Precisely control the temperature of the
circulating fluid by using the Peltier device.
Refrigerant-free and environmentally friendly
37 dB (at low load)
This product generates less vibration, dust, and noise due to its lack of
moving parts, such as a compressor.
The noise is kept low by reducing the fan speed in low-load operation.
Customers can reduce the noise by setting the unit to constant fan speed
mode when the noise at high load is concerned.
∗Note that in constant fan speed mode, cooling performance is reduced.
Low-noise design
Noise Level
Sound level Noise level
reference Sound example
20 dB Whisper The sound of leaves touching each
other or the sound of snow falling
30 dB
Very quiet
Suburbs late at night or the sound
of writing with a pencil
40 dB A quiet residential area in the
daytime or in the library
50 dB
Normal
External unit of a home air
conditioner (close distance) or in a
quiet office
60 dB
In a moving car, normal
conversation, or in a department
store
70 dB
Noisy
In a car driving at high speed, in a
noisy office, or the sound of cicadas
(close distance)
80 dB
On a running train, ambulance siren
(close distance), or inside a
pachinko parlor
90 dB Very loud Karaoke bar (in the centre) or the
barking of a dog (close distance)
HEF002 Noise
level range
Refrigerant-free
Fluid contact material:
Stainless steel, Resin, Rubber
(Aluminum and copper material-free)
1

Peltier-type Chiller
Thermo-con/Compact Type Air-cooled HEF Series
210 mm
of a heat source or process fluid
Construction and Principles
Heat dissipation air flow direction
The thermo-con is constructed as shown in Figure 1. The circulating fluid outlet temperature
is controlled precisely by a Peltier element (thermo module) between the heat exchanger
and heat sink which is controlled by supplying DC power supply. The circulating fluid returns
to the tank and is transferred by the pump which is built into the thermo-con, then it goes
through the heat exchangers and temperature sensor and out from the circulating fluid outlet.
The heat dissipation air flow direction is as
shown in Figure 2. Air is taken from the front
of the Thermo-con and discharged from the
rear. Do not cover the inlet and outlet vents.
Integrated with the front panel
grille. Easy to install and remove
Easy to remove dust, cutting
chips, etc., stuck to the filter with
a brush or vacuum cleaner
Dustproof filter set
Dustproof filter
p. 11
Easy maintenance
Easy to clean and replace the
dustproof filter
Air
Air
p. 11
T
2
Peltier device T
(Thermo-module)
Controller
Figure 1
Figure 2
Tan k
Pump
Heat sink
Heat exchanger
Fan
Level switch
Power switch
Power supply
(24 VDC)
Circulating fluid
OUT
Temperature
sensor
Circulating fluid
fill port (Tank lid)
Circulating fluid
IN (Drain)

Cool Diode Laser
Microscope Cooling Plate
Cool Power Device
Cooling Glass Heat Exchanger
Cooling Sample Embedding Machine
Cool Optical Camera
Laser Oscillator
Beam Bumper
Circulation Between Gas Generation Analyzer and Jacketed Vessel
Application Examples
Peltier-type Chiller
Thermo-con/Compact Type Air-cooled HEF Series
C-mount lens
F-mount lens
Microscope
C-mount
TV adapter
Data analyzer
Compatible with digital cameras
∗Open bath type (Can be connected to a water tank, etc., and the
temperature can be directly controlled.)
3

CONTENTS
HEF Series
Thermo-con/Compact Type Air-cooled
HEF Series
Cooling Capacity Calculation............................................................ p. 5
How to Order/Specifications ............................................................. p. 6
Cooling Capacity............................................................................... p. 7
Heating Capacity .............................................................................. p. 7
Pump Capacity (Thermo-con Outlet)................................................ p. 7
Dimensions....................................................................................... p. 8
Operation Display Panel................................................................... p. 9
Alarm ................................................................................................ p. 9
Maintenance ..................................................................................... p. 9
앬Option
High-Pressure Pump Mounted ....................................................... p. 10
앬Optional Accessories
AC Adapter ..................................................................................... p. 11
Power Supply Cable ....................................................................... p. 11
Dustproof Filter ............................................................................... p. 11
Specific Product Precautions............................................................... p. 12
4

Temperature [°C] Density ρ[kg/m3] Specific heat C [J/(kg·K)]
10 1.03 x 1033.93 x 103
20 1.03 x 1033.95 x 103
30 1.02 x 1033.97 x 103
40 1.02 x 1033.98 x 103
50 1.01 x 1034.00 x 103
60 1.01 x 1034.02 x 103
HEF Series
Cooling Capacity Calculation
Q = ΔT x V x 웂x C
h x 60 x 1000
10 x 2 x 1 x 103x 4.2 x 103
15 x 60 x 1000
= 93.3 W
=
Cooling capacity = Considering a safety factor of 20 %,
93.3 W x 1.2 = 112 W
After 15 min,
cool 30 °C down to 20 °C.
Water bath
Example When cooling the object below a certain temperature in certain period of time.
Cooled substance total volume V : 2 L
Cooling time h : 15 min
Cooling temperature difference ΔT : Temperature difference: 10 °C (10 K). Cool from 30 °C (303 K) to 20 °C (293 K).
Circulating fluid : Tap water
Density 웂: 1 x 103kg/m3
Specific heat C: 4.2 x 103J/(kg·K)
∗Refer to the information shown below for the typical physical property values by circulating fluid.
Circulating Fluid Typical Physical Property Values
Ethylene Glycol Solution 20 %
Water
Density 웂: 1 x 103[kg/m3] Specific heat C: 4.2 x 103[J/(kg·K)]
Air-cooled
20 °C V
5

002 220 W
Cooling capacity
AAir-cooled
Radiating method
624 VDC
Power supply
—None
PHigh-pressure pump mounted
Option
—Rc
NNPT thread
Pipe thread
How to Order
Specifications
Cooling method Thermoelectric device (Thermo-module)
Radiating method Forced air cooling
Control method Cooling/Heating automatic shift PID control
Ambient temperature/humidity 10 to 35 °C, 35 to 70 % RH (No condensation)
Circulating fluid system
Circulating fluid Tap water, Ethylene glycol aqueous solution (20 % or less)
Set temperature range 10.0 to 60.0 °C (No condensation)
Cooling capacity 220 W (Tap water)∗1
Heating capacity 500 W (Tap water)∗1
Temperature stability ±0.1 °C∗2
Pump capacity Refer to the performance charts.
Tank capacity Approx. 110 mL
Port size Rc1/4
Fluid contact material Stainless steel, EPDM, NBR, Ceramics, PPE, PPS, Carbon, PP, POM
Electrical system
Power supply 24 VDC ±10 %
Power consumption 12.5 A (Peak current 18 A)
Alarm Refer to “Alarm.”
Communications RS-232C/RS-485
Weight Approx. 3.5 kg
Noise level 37 to 60 dBA
Accessories DC input power supply cable (1 m), Operation Manual
(The 24 VDC power supply should be prepared by the customer.)∗3
Safety standards CE/UKCA marking, UL (NRTL) standards
∗1 Conditions: Set temperature 25 °C, Ambient temperature 25 °C, Circulating fluid flow rate 1 l/min (For options, refer to the performance charts.)
∗2 The indicated values are when there is a stable load without turbulence. It may be out of this range depending on the operating conditions.
∗3 An AC adapter and a power supply cable suitable to this product are available as optional accessories.
For details, refer to the optional accessory (page 11).
Thermo-con/
Compact Type
HEF Series
HEF 002 A 6
Air-cooled
6

Cooling Capacity
Heating Capacity
Circulating fluid: Water, Flow rate: 1 l/min
Circulating fluid: Water, Flow rate: 1 l/min
Circulating fluid: Water, Flow rate: 1 l/min, When constant fan speed mode is selected
Circulating fluid: Water, Flow rate: 1 l/min, When constant fan speed mode is selected
600
500
400
300
200
100
00 1020304050 60 70
800
700
600
500
400
300
200
100
00 1020304050 60 70
600
500
400
300
200
100
00 1020304050 60 70
800
700
600
500
400
300
200
100
00 1020304050 60 70
∗For the high-pressure pump (Option), the cooling capacity decreases by approx. 20 W.
∗For the high-pressure pump (Option), the heating capacity increases by approx. 10 W.
Pump Capacity (Thermo-con Outlet)
Circulating fluid: Water
0.18
0.16
0.14
0.12
0.10
0.08
0.06
0.04
0.02
00 1 1.50.5 2 2.5 3 3.5 4 4.5 5 5.5
7
HEF Series
Circulating fluid temperature [°C]
Circulating fluid temperature [°C]
Circulating fluid flow rate [l/min]
Circulating fluid temperature [°C]
Circulating fluid temperature [°C]
Ambient temperature 25 °C
Ambient temperature 35 °C
Ambient temperature 25 °C
Ambient temperature 35 °C
Ambient temperature 35 °C
Ambient temperature 25 °C
Allowable operating range
High-pressure pump (Option)
Standard pump
Ambient temperature 35 °C
Ambient temperature 25 °C
Cooling capacity [W]Cooling capacity [W]Discharge pressure [MPa] Cooling capacity [W]Cooling capacity [W]

130
43
27
150
115
110
100
89
185
163
148 40
25
110
9020
20
(10)
(20)
Dimensions
Connector
Connector name No. Signal contents Connector type/Part no.
Power
connector
124 VDC +
2
1
J.S.T. Mfg. Co., Ltd.
JFA connector J4000 series
SC02B-J42SK-GHXR
224 VDC −
Alarm,
RUN/STOP,
Communication
connector
1RS-485 BUS +
12345
9876
D-sub 9 pin (socket type)
Holding screw: M2.6
2RS-232C RD
3RS-232C SD
4RUN/STOP signal input
5SG
6
Output cutoff alarm
(open when alarm occurs)
7 Common for output cutoff alarm
8RUN/STOP signal input
9RS-485 BUS −
Power Cable (Accessory)
Connector: J42FSC-02V-KX (J.S.T. Mfg Co., Ltd.-made)
Cable: 16AWG
Wire colour Contents
Brown 24 VDC +
Blue 24 VDC −
(1000)
8
Thermo-con/Compact Type Air-cooled HEF Series
Circulating fluid OUT
Rc1/4
Circulating fluid IN (drain)
Rc1/4
Model no. label
Tank lid
Rubber legs (4 pcs.)
Label
Power connector
Power switch
Alarm, RUN/STOP
Communication
connector
Fluid fill port
Dustproof filter
Display/
Operation panel
Circulating fluid
level gauge
NRTL label
Air Air

Alarm
Operation Display Panel
This product can display eight types of alarm codes and they can be read using serial communication.
In addition, it can relay output as an alarm contact output when an alarm is generated.
RUN/STOP key
For switching the control status (RUN/STOP)
1st line
Displays the current temperature value
[PV]
Displays the alarm code when an alarm
is generated
RUN display
Turns on during control status (RUN status)
2nd line
Displays the setting temperature value
[SV] and each selected input value
왖key (UP key)
Increases set data
ALARM display
Turns on when the unit is alarming
MODE key
For switching the screen
It can be switched between the parameter
screen and operation mode screen when
it is pressed for two seconds.
왔key (DOWN key)
Decreases set data
Maintenance
The maintenance of this unit can only be performed by returning it to be repaired at one of SMC’s sites. As a rule, SMC will not
conduct on-site maintenance.
Alarm
Alarm code Alarm description
Operation
status
Main reason
AL0 Memory error Stop There is an abnormality with the memory data in the controller due to a high level of noise.
AL1 Controller error Stop There is an abnormality with the data in the controller due to a high level of noise.
AL2 Temp. sensor disconnection alarm Stop The temperature sensor has been disconnected or short-circuited.
AL3 Temp. sensor short circuit alarm Stop There is a short-circuit in the temperature sensor.
AL4 Temp. sensor high temp. error alarm Stop The temperature sensor has exceeded the high temperature cutoff setting.
AL5 Temp. sensor low temp. error alarm Stop The temperature sensor has exceeded the low temperature cutoff setting.
AL6 Low fluid level alarm Stop The amount of circulating fluid in the tank has dropped.
AL7 Thermostat alarm Stop The thermostat has activated due to clogging of the heat sink of the filter or product, or failure
of the fan or pump.
9
HEF Series
