SMC Networks HRS090 Series User manual

(when a load is stable)
Temperature stability ±0.5°C
Indoor use
Cooling capacity 9kW
Max. ambient temperature 45°C
Set temperature range 5°C to 35°C
377 [mm]
1080
970
Water-cooled refrigeration Air-cooled refrigeration
Compatible power
supplies in Europe, Asia,
Oceania, North, Central and
South America
O3-phase 200 V
O3-phase 400 V
Lightweight and Compact
With heating function
Heating method using discharged heat makes a heater unnecessary.
Environmental friendly
as refrigerant
R410A
Convenient functions
Timer operation function/Unit conversion function/Power
failure auto-restart function/Anti-freezing operation function
Page 3
Easy maintenance
Tool-less maintenance of filter
Page 2
Self diagnosis function and check display
41 types of alarm codes
Page 4
Communication function
Equipped with serial communication (RS232C/RS485)
and contact I/Os (2 inputs and 3 outputs) as standard.
Page 4
Weight 136 kg
RoHS
Circulating Fluid Temperature Controller
Thermo-chiller Standard Type
Series HRS090
CAT.ES40-64A
(Only 400 VAC type)

The precision temperature control method by expansion valve and temperature sensor, realized high temperature stability of ±0.5°C and a small-size tank.
Conventional
Multiple air-cooled
condensers are
arranged one
above the other.
Achieved a maximum
reduction in the height
of the product while
expanding the cooling
capacity, by providing
overlapped air-cooled
condensers.
Compact and lightweight 136 kg
Reduced-height double condenser structure
Aluminum air-cooled condenser
Compact tank 18 L
High heat transfer efficiency, Lightweight
Temperature followability control
reduced the tank capacity
required as a buffer.
[mm]
1080
970
377
Circulating fluid circuitRefrigeration circuit
Facility water circuit
WPR
Water regulating valve
Facility water outlet
Facility water inlet
Air release valve for
facility water discharge
Water-cooled
condenser
Expansion valve A
Pressure sensor
(For high-pressure
refrigerant gas)
Pressure sensor
(For low-pressure refrigerant gas)
Level
switch
Circulating
fluid return port
Temperature sensor
(For discharge)
Temperature sensor
(For compressor intake)
Compressor
Pressure sensor
(For discharge)
Temperature sensor
(For return)
Drain port
Circulating fluid
outlet
Temperature sensor
(For compressor discharge)
Heat exchanger
Resin tank
Fluid
level
indicator
User's equipment
(Heat source)
Expansion valve B
E
TS
PS TS
TS
E
PS
PS
TS
Ventilation
Air-cooled
condenser
*This circuit construction of the position of the
parts may be different from actual product.
HRS090-W-l
(Water-cooled refrigeration)
HRS090-A-l
(Air-cooled refrigeration)
¡ The compressor compresses the refrigerant gas, and discharges
the high temperature and high pressure refrigerant gas.
¡ In the case of air-cooled refrigeration, the high temperature and high
pressure refrigerant gas is cooled down by an air-cooled condenser with
the ventilation of the fan, and becomes a liquid. In the case of water-cooled
refrigeration, the refrigerant gas is cooled by a water-cooled condenser
with the facility water in the facility water circuit, and becomes a liquid.
¡ The liquefied high pressure refrigerant gas expands and its temperature
lowers when it passes through expansion valve A and vaporizes by
taking heat from the circulating fluid in the heat exchanger.
¡ The vaporized refrigerant gas is sucked into the compressor
and compressed again.
¡ When heating the circulating fluid, the high pressure and
high temperature refrigerant gas is bypassed into the
evaporator by expansion valve B, to heat the circulating fluid.
¡ The circulating fluid discharged from the pump, is heated or
cooled by the user’s equipment and returns to the thermo-chiller.
¡The circulating fluid is controlled to a set temperature by
the refrigeration circuit, to be discharged to the user’s
equipment side again by the thermo-chiller.
Refrigeration circuit Circulating fluid circuit
For water-cooled refrigeration HRSl-W-l
¡
The water regulating valve opens and closes to keep the
refrigerant gas pressure consistent. The facility water
flow rate is controlled by the water regulating valve.
Facility water circuit
Point
Since the refrigeration circuit is controlled by the signal from
2 temperature sensors (for return and discharge)
, precise
temperature control of the circulating fluid can be
performed. Therefore, there is no necessity of absorbing the
temperature difference in the circulating fluid with a large
tank capacity, and realizes high temperature stability even
with a
small-size tank
. Also, contributes to space-saving.
Point
The combination of precise control of expansion valve A
for cooling, and expansion valve Bfor heating realized
high temperature stability.
1
Circulating Fluid Temperature Controller
Thermo-chiller Standard Type Series HRS090

With heating function
User’s equipment
∗This is just an example diagram.
Current model
Circulating fluid
Compressor
Cool
fluid from refrigerant
Heater
Circulating fluid temperature [°C]
10
0
20
30
40
5
15
25
35
0 5 10 15 20
Temperature increase with heating capacity (Ambient temperature 32°C/50 Hz)
Minute [Time]
25 30
Heating functions are required
to maintain a constant temperature
particularly in the winter when
the ambient temperature is low.
HRS
Circulating fluid
Compressor
Hot discharged
gas from refrigerant
Cool
fluid from refrigerant
Heating method using
discharged heat makes
a heater unnecessary.
An opening with a cap is included
separately from the water inlet.
Opening diameter: ø110
RotationRotation
With unfixed caster
Locking lever
(front wheels only)
∗Remove bracket when moving,
using casters.
Anchor bolt fixing bracket
The angled supply port
facilitates the supply of
circulating fluid.
Tank lid
Filter for circulating fluid fill port
(Optional accessory on page 18)
∗After supplying the circulating
fluid, the tank lid can be closed
with the filter
mounted.
The “large digital display” (7-segment and 4
digits) and “2 row display” provide a clearer view
of the current value (PV) and set value (SV).
Large digital display
Step qPress the key.
Step wAdjust the temperature setting
with the / keys.
Step ePress the key to stop.
Easy operation by these steps
Simple operation Shaped for easy supply of circulating fluid
Easy cleaning
of the tank
Tool-less inspection and cleaning
of air-cooled condenser
Easy check of the
circulating fluid level
wqe
∗It can be removed
with no tools.
Easy to clean dust and cutting
chips etc. stuck to the dustproof
net with a brush or air blow.
Ventilation
Dustproof filter
∗For air-cooled
refrigeration
2
Circulating Fluid Temperature Controller
Thermo-chiller Standard Type Series HRS090

Electric conductivity control set
(With DI filter + Solenoid valve kit for control) (Optional accessory on page 17)
Particle filter set
(Optional accessory on page 17)
Ex. SE.02 “ON timer”
Unit conversion function
Temperature and pressure units can be
changed.
 Timer operation function
Timer for ON and OFF can be set in
units of 0.5 h up to 99.5 h.
Ex.) Can set to stop on Saturday and Sunday
and restart on Monday morning.
Timer The time remaining can be checked.
Power failure auto-restart function
Automatic restart from stoppage due to pow-
er failure etc. is possible without pressing the
key and remote operation.
Anti-freezing operation function
If the temperature approaches freezing point,
e.g. in winter at night, the pump operates au-
tomatically and the heat generated by the
pump warms the circulating fluid, preventing
freezing.
Key-lock function
Can be set in advance to protect the set val-
ues from being changed by pressing keys by
mistake.
Function to output a signal for
completion of preparation
Notifies by communication when the temper-
ature reaches the pre-set temperature range.
 Independent operation of the pump
The pump can be operated independently
while chiller is powered off. You can check
piping leak and remove the air.
Orange
indicator
lights up.
Temperature unit
Pressure unit
Convenient functions (Refer to the Operation Manual for details.)
Globally compatible power supplies
Power supply (24 VDC) available
3
The electric conductivity of the
circulating fluid can be set with
the controller monitor arbitrarily.
Circulating fluid return port
Solenoid valve for control
DI filter
Circulating fluid outlet
Set control range:
5.0 to 45.0 μS/cm
(Europe, Asia, Oceania, Central and South America)
Power supply
Transformers are unnecessary even when used overseas.
Applicable to 200 to 230 VAC, or 380 to 415 VAC
HRS090
Step-down transformer
Unnecessary
380 to 415 VAC
Transformer unnecessary
Current model
Step-down transformer
380 VAC 200 VAC
(Only 400 VAC type)
Removes foreign matter
in the circulating fluid.
Power can be supplied from the terminal block on
the rear side to external switches etc.
Refer to page 7.
Flow switch
Circulating Fluid Temperature Controller
Thermo-chiller Standard Type Series HRS090

Communication function
PC
HRS
Output 1
Output 2
Output 3
HRS
· Output setting example
Output 1: Temperature rise
Output 2: Pressure rise
Output 3: Operation status (start, stop, etc.)
Power for flow switch (24 VDC) can
be supplied from thermo-chiller.
The alarm and status generated in the product
are assigned to 3 output signals based on their
contents, and can be output.
Ex. 1 Ex. 2 Ex. 3
Remote signal I/O through
serial communication
The remote operation is enabled (to start and
stop) through serial communication.
One of the contact inputs is used for remote opera-
tion and the other is used for a flow switch to moni-
tor the flow, and their warning outputs are taken in.
Alarm and operation status
(start, stop, etc.) signal output
Remote operation signal input
¡Circulating fluid
temperature setting
¡Start and stop
¡Circulating fluid discharge
temperature
¡Circulating fluid discharge pressure
¡Run and stop status
¡Alarm information
¡Various setting information
¡Preparation completion status
Remote
operation
switch Input 2Input 1 To the user’s
equipment
HRS
The serial communication (RS232C/RS485) and contact I/Os (2 inputs and 3 outputs) are equipped as standard.
Communication with the user’s equipment and system construction are possible, depending on the application.
A 24 VDC output can be also provided, and is available for a flow switch (SMC’s PF2W etc.).
Flow switch
Low flow switch flow signal
Self diagnosis function and check display
PV
SV
Flashing
Flashing
Lights up
Alarm code
Accumulated
time
Displayed item
PV PV
For details, refer to page 13.
Display of individual alarm codes
Operation is monitored all the time by the integrated sensor.
Should any error occur, the self diagnosis result is displayed by the applicable alarm code.
This makes it easier to identify the cause of the alarm.
Can be used before requesting service.
Changeable alarm set values
Setting item Set value
Circulating fluid discharge temperature rise
Circulating fluid discharge temperature drop
Circulating fluid discharge pressure rise
Circulating fluid discharge pressure drop
5 to 55°C
1 to 34°C
0.05 to 0.6 MPa
0.05 to 0.6 MPa
Ex.
AL01 “Low level in tank”
Alarm codes notify of checking times.
Notifies when to check the pump and fan motor.
Helpful for facility maintenance.
Ex. AL28 “Pump maintenance”
Check display
The internal temperature, pressure and
operating time of the product are displayed.
Ex. drv. “Accumulated operating time”
Displayed item
Circulating fluid outlet temperature
Circulating fluid return temperature
Circulating fluid flow rate ∗1
Compressor gas temperature
Circulating fluid outlet pressure
Compressor gas discharge pressure
Compressor gas return pressure
Accumulated operating time
Accumulated operating time of pump
Accumulated operating time of fan
∗2
Accumulated operating time of compressor
Accumulated operation time of dustproof filter
∗2
∗1 This is not measurement value.
Use it for reference.
∗2 These are displayed only for
air-cooled refrigeration.
∗The fan motor is not used in water-cooled refrigeration.
4
Circulating Fluid Temperature Controller
Thermo-chiller Standard Type Series HRS090

Light sensing part
X-ray tube
Cooling water
Workpiece
X-ray (digital) instrument
Temperature control of X-ray tube and
X-ray light sensing part
Injection molding Atomizing device
(food and cosmetics)
Temperature control of sample and
device
Crushing machine
Cooling of the jacket
Packaging line
(sealing of film and paper package)
Cooling of workpieces for bonding
MRI
Arc welding machine
Cooling of the torch
Resistance welding machine
(spot welding)
Cooling of the welding
head electrodes,
transformers and
transistors
(thyristors)
High frequency induction
heating equipment
Cooling of the heating coils, high
frequency power source and around
inverters
High frequency
inverter Heating coil
Laser beam machine/
Laser welding machine
Cooling of the laser oscillation part and
power source
Printing machine
Temperature control of the roller
Cleaning machine
Temperature control of cleaning solution
Applications
Circulating Fluid Temperature Controller
Thermo-chiller Standard Type Series HRS090
5

Global Supply Network
SMC has a comprehensive network in the global market.
We now have a presence of more than 400 branch offices and distributors in 78
countries world wide such as Asia, Oceania, North/Central/South America, and
Europe. With this global network, we are able to provide a global supply of our
substantial range of products with the best service. We also provide full support
to local factories, foreign manufacturing companies and Japanese companies in
each country.
Series
Temperature
stability
[°C]
Set temperature
range
[°C]
Cooling capacity [kW]
Environment
International
standards
1.2 1.8 2.4 3 5 6 9 10 15 20 25 28
HRSE
Basic type ±2.0 10 to 30 VVV Indoor
use (Only 230 VAC type)
HRS
Standard type ±0.1 5 to 40 VVVVVV Indoor
use
(Only 60 Hz)
HRS090
Standard type ±0.5 5 to 35 VIndoor
use (400 V as standard)
HRS100/150
Standard type ±1.0 5 to 35 V V
Outdoor
installation
IPX4 (400 V as standard)
HRSH090
Inverter type ±0.1 5 to 40 VIndoor
use
(400 V as standard,
200 V as an option)
(Only 200 V as an option)
HRSH
Inverter type ±0.1 5 to 35 VVVVV
Outdoor
installation
IPX4
(400 V as standard,
200 V as an option)
(Only 200 V as an option)
Lots of variations are available in response to the users’ requirements.
SMC Thermo-chiller Variations
6
Circulating Fluid Temperature Controller
Thermo-chiller Standard Type Series HRS090

Pressure Switch: Monitors pressure of the circulating fluid.
2-Color Display
High-Precision Digital Pressure Switch ISE80
Pressure Sensor for General Fluids PSE56
Pressure Sensor Controller PSE200,300
Refer to the WEB catalog or the Best Pneumatics No. 6 for details.
3-Color Display Digital Flow Switch for Water PF3W 3-Color Display
Electromagnetic Type Digital Flow Switch LFE
Digital Flow Switch for
Deionized Water and Chemical Liquids PF2D
4-Channel Flow Monitor PF2200
Flow Switch: Monitors flow rate and temperature of the circulating fluid.
Refer to the WEB catalog or the Best Pneumatics No. 6 for details.
Integrated flow adjustment valve
and temperature sensor
Terminal block
Bypass valve
Power supply (24 VDC) available
User's
equipment
Circulating Fluid Line
Circulating
fluid outlet
Valve
Pressure Switch Fittings and Tubing
Y-strainer
Flow Switch
Circulating fluid
return port
User's
equipment
Pressure Switch Flow Switch
Facility water
outlet
Facility water
inlet
Facility Water Line (Water-cooled)
Terminal block
Power supply (24 VDC) available
Manage pressure and flow rate: digital display
makes these aspects “visible”
PVC Piping
S Coupler KK
Series
T
TU
TH
TD
TL
TLM
Material
Nylon
Polyurethane
FEP (Fluoropolymer)
Modified PTFE
(Soft fluoropolymer)
Super PFA
PFA
Tubing T
Stainless Steel 316
One-touch Fittings KQG2
Stainless Steel 316 Insert Fittings KFG2 Fluoropolymer Fittings LQ
S Coupler/Stainless Steel
(Stainless Steel 304) KKA
Metal One-touch Fittings KQB2
Fittings and Tubing
Refer to the WEB catalog or the Best Pneumatics No. 6 for details.
Circulating Fluid/Facility Water Line Equipment
7
Circulating Fluid Temperature Controller
Thermo-chiller Standard Type Series HRS090

CONTENTS
Series HRS090 Standard Type
How to Order/Specifications
�������������������������������� Page 9
������������������������������ Page 10
Cooling Capacity�������������������������������������������������� Page 11
Pump Capacity ���������������������������������������������������� Page 11
Dimensions ���������������������������������������������������������� Page 12
Operation Display Panel �������������������������������������� Page 13
List of Function ���������������������������������������������������� Page 13
Alarm ������������������������������������������������������������������� Page 13
Communication Function ������������������������������������� Page 14
POptions
With Earth Leakage Breaker ������������������������������� Page 15
With Automatic Fluid Fill Function����������������������� Page 15
Applicable to Deionized Water Piping ����������������� Page 15
Air-cooled 200 V/400 V
Water-cooled 200 V/400 V
POptional Accessories
qPiping Conversion Fitting �������������������������������� Page 16
wBypass Piping Set������������������������������������������� Page 16
eElectric Conductivity Control Set��������������������� Page 17
rParticle Filter Set��������������������������������������������� Page 17
tFilter for Circulating Fluid Fill Port������������������� Page 18
y
Drain Pan Set (With Water Leakage Sensor) ��� Page 18
PCooling Capacity Calculation
Required Cooling Capacity Calculation��������������� Page 19
Precautions on Cooling Capacity Calculation ����� Page 20
Circulating Fluid Typical Physical Property Values ��� Page 20
Specific Product Precautions����������������������������������� Page 21
Thermo-chiller Series HRS090
8A

RoHS
Power supply
20
3-phase 200 VAC (50 Hz)
3-phase 200 to 230 VAC (60 Hz)
40
3-phase 380 to 415 VAC (50/60 Hz)
Option
Nil None
BNote) With earth leakage breaker
J
With automatic fluid fill function
M
Applicable to deionized water piping
OWhen multiple options are combined,
indicate symbols in alphabetical order.
Note) 200 V type only.
400 V type is provided with an earth leakage breaker as standard.
A090HRS
(Only 400 VAC type)
20
How to Order
Specifications
Model HRS090-Al-20-lHRS090-Al-40-l
Cooling method Air-cooled refrigeration
Refrigerant R410A (HFC)
Control method PID control
Ambient temperature∗1°C5 to 45
Circulating fluid system
Circulating fluid∗2Tap water, 15% ethylene glycol aqueous solution, Deionized water
Set temperature range∗1°C5 to 35
Cooling capacity 50/60 Hz∗3kW 8.0/9.0
Heating capacity 50/60 Hz∗4kW 1.7/2.2
Temperature stability∗5°C±0.5
Pump
capacity
Rated flow 50/60 Hz (Outlet)∗6L/min 29/45
Maximum flow rate 50/60 Hz L/min 55/68
Maximum pump head m 50
Minimum operating flow rate 50/60 Hz∗7L/min 29/45
Tank capacity L 18
Circulating fluid outlet, circulating fluid return port Rc1 (Symbol F: G1, Symbol N: NPT1)
Tank drain port Rc1/4 (Symbol F: G1/4, Symbol N: NPT1/4)
Fluid contact material Stainless steel, Copper (Heat exchanger brazing), Brass, Bronze, PTFE,
FKM, EPDM, PVC, NBR, POM, PE, PP, Carbon, Ceramic
Electrical system
Power supply
3-phase 200 VAC (50 Hz), 3-phase 200 to 230 VAC (60 Hz)
Allowable voltage range ±10% (No continuous voltage fluctuation)
3-phase 380 to 415 VAC (50/60 Hz)
Allowable voltage range ±10% (No continuous voltage fluctuation)
Applicable earth leakage
breaker (Standard)
Rated current A 30 20
Sensitivity of leak current mA 30
Rated operating current 50/60 Hz∗5A16/18 8.4/9.1
Rated power consumption 50/60 Hz∗5kW (kVA) 4.3/5.4 (5.5/6.0) 4.4/5.6 (5.8/6.3)
Noise level (Front 1 m/Height 1 m)∗5dB (A) 73 75
Accessories
Alarm code list stickers 2 pcs. (English 1 pc./Japanese 1 pc.),
Operation Manual (for installation/operation) 2 pcs. (English 1 pc./Japanese 1 pc.),
Y-strainer (40 meshes) 25A, Barrel nipple 25A,
Anchor bolt fixing brackets 2 pcs. (including four M10 bolts)∗8
Weight (dry state) kg Approx. 136
∗1 Use a 15% ethylene glycol aqueous solution if operating in a place where the ambient temperature and/or circulating fluid temperature is 10°C or less.
∗2 Use fluid in condition below as the circulating fluid.
Tap water: Standard of The Japan Refrigeration And Air Conditioning Industry Association (JRA GL-02-1994)
15% ethylene glycol aqueous solution: diluted by tap water in condition above without any additives such as antiseptics.
Deionized water: Electric conductivity 1 mS/cm or higher (Electric resistivity 1 MW·cm or lower)
∗3 qAmbient temperature: 32°C, wCirculating fluid: Tap water, eCirculating fluid temperature: 20°C, rCirculating fluid flow rate: Rated flow, tPower supply: 200/400
VAC
∗4 qAmbient temperature: 32°C, wCirculating fluid: Tap water, eCirculating fluid flow rate: Rated flow, rPower supply: 200/400 VAC
∗5 qAmbient temperature: 32°C, wCirculating fluid: Tap water, eCirculating fluid temperature: 20°C, rLoad: Same as the cooling capacity, tCirculating fluid flow
rate: Rated flow, yPower supply: 200/400 VAC, uPiping length: Shortest
∗6 When circulating fluid outlet port pressure = 0.5 MPa.
∗7 Fluid flow rate to maintain the cooling capacity and to keep the circulating fluid discharge pressure to 0.5 MPa or less. If the actual flow rate is lower than this, install a bypass piping.
∗8 The anchor bolt fixing brackets (including four M10 bolts) are used for fixing to wooden skids when packaging the thermo-chiller. No anchor bolt is included.
Pipe thread type
Nil Rc
FG (with Rc-G conversion fitting)
NNPT (with Rc-NPT conversion fitting)
Cooling method
A
Air-cooled refrigeration
Cooling capacity
090
9 kW
Thermo-chiller
Air-cooled 200 V/400 V Type
Standard Type
Series HRS090
9

W090HRS
Power supply
20
3-phase 200 VAC (50 Hz)
3-phase 200 to 230 VAC (60 Hz)
40
3-phase 380 to 415 VAC (50/60 Hz)
Option
Nil None
BNote) With earth leakage breaker
J
With automatic fluid fill function
M
Applicable to deionized water piping
OWhen multiple options are combined,
indicate symbols in alphabetical order.
Note) 200 V type only.
400 V type is provided with an earth leakage breaker as standard.
RoHS
(Only 400 VAC type)
20
How to Order
Specifications
Model HRS090-Wl-20-lHRS090-Wl-40-l
Cooling method Water-cooled refrigeration
Refrigerant R410A (HFC)
Control method PID control
Ambient temperature∗1°C5 to 45
Circulating fluid system
Circulating fluid∗2Tap water, 15% ethylene glycol aqueous solution, Deionized water
Set temperature range∗1°C5 to 35
Cooling capacity 50/60 Hz∗3kW 9.0/10.5
Heating capacity 50/60 Hz∗4kW 1.7/2.2
Temperature stability∗5°C±0.5
Pump
capacity
Rated flow 50/60 Hz (Outlet)∗6L/min 29/45
Maximum flow rate 50/60 Hz L/min 55/68
Maximum pump head m 50
Minimum operating flow rate 50/60 Hz∗7L/min 29/45
Tank capacity L 18
Circulating fluid outlet, circulating fluid return port Rc1 (Symbol F: G1, Symbol N: NPT1)
Tank drain port Rc1/4 (Symbol F: G1/4, Symbol N: NPT1/4)
Fluid contact material Stainless steel, Copper (Heat exchanger brazing), Brass, Bronze, PTFE,
FKM, EPDM, PVC, NBR, POM, PE, PP, Carbon, Ceramic
Facility water system
Temperature range °C5 to 40
Pressure range MPa 0.3 to 0.5
Required flow 50/60 Hz L/min 25/25
Facility water pressure differential MPa 0.3 or more
Facility water inlet/outlet Rc1/2 (Symbol F: G1/2, Symbol N: NPT1/2)
Fluid contact material Stainless steel, Copper (Heat exchanger brazing), Bronze, Brass
PTFE, NBR, EPDM
Electrical system
Power supply
3-phase 200 VAC (50 Hz), 3-phase 200 to 230 VAC (60 Hz)
Allowable voltage range ±10% (No continuous voltage fluctuation)
3-phase 380 to 415 VAC (50/60 Hz)
Allowable voltage range ±10% (No continuous voltage fluctuation)
Applicable earth
leakage breaker∗8
Rated current A 30 20
Sensitivity of leak current mA 30
Rated operating current 50/60 Hz∗5A13/14 6.4/6.7
Rated power consumption 50/60 Hz∗5kW (kVA) 3.3/4.2 (4.4/4.9) 3.4/4.2 (4.4/4.7)
Noise level (Front 1 m/Height 1 m)∗5dB (A) 65
Accessories
Alarm code list stickers 2 pcs. (English 1 pc./Japanese 1 pc.),
Operation Manual (for installation/operation) 2 pcs. (English 1 pc./Japanese 1 pc.),
Y-strainer (40 meshes) 25A, Barrel nipple 25A,
Anchor bolt fixing brackets 2 pcs. (including four M10 bolts)∗9
Weight (dry state) kg Approx. 124
∗1 Use a 15% ethylene glycol aqueous solution if operating in a place where the ambient temperature and/or circulating fluid temperature is 10°C or less. Also, when
there is a possibility of the facility water being frozen, make sure to discharge all the facility water from the facility water circuit.
∗2
Use fluid in condition below as the circulating fluid. Also, when there is a possibility of the facility water being frozen, make sure to discharge all the facility water from the facility water circuit.
Tap water: Standard of The Japan Refrigeration And Air Conditioning Industry Association (JRA GL-02-1994)
15% ethylene glycol aqueous solution: diluted by tap water in condition above without any additives such as antiseptics.
Deionized water: Electric conductivity 1 mS/cm or higher (Electric resistivity 1 MW·cm or lower)
∗3
qFacility water temperature: 32°C, wCirculating fluid: Tap water, eCirculating fluid temperature: 20°C, rCirculating fluid flow rate: Rated flow, tPower supply: 200/400 VAC
∗4 qFacility water temperature: 32°C, wCirculating fluid: Tap water, eCirculating fluid flow rate: Rated flow, rPower supply: 200/400 VAC
∗5 qFacility water temperature: 32°C, wCirculating fluid: Tap water, eCirculating fluid temperature: 20°C, rLoad: Same as the cooling capacity, tCirculating fluid
flow rate: Rated flow, yPower supply: 200/400 VAC, uPiping length: Shortest
∗6 When circulating fluid outlet port pressure = 0.5 MPa.
∗7
Fluid flow rate to maintain the cooling capacity and to keep the circulating fluid discharge pressure to 0.5 MPa or less. If the actual flow rate is lower than this, install a bypass piping.
∗8 To be prepared by user. A specified earth leakage breaker is installed for option B [With earth leakage breaker].
∗9
The anchor bolt fixing brackets (including four M10 bolts) are used for fixing to wooden skids when packaging the thermo-chiller. No anchor bolt is included.
Thermo-chiller
Water-cooled 200 V/400 V Type
Standard Type
Series HRS090
Pipe thread type
Nil Rc
FG (with Rc-G conversion fitting)
N
NPT (with Rc-NPT conversion fitting)
Cooling method
W
Water-cooled refrigeration
Cooling capacity
090 9 kW
10

0
2
4
6
8
10
12
5 10 15 20 25 30 35
Circulating fluid temperature [°C]
Cooling capacity [kW]
Ambient temperature 32°C
Ambient temperature 40°C
Ambient temperature 45°C
0
2
4
6
8
10
12
5 10 15 20 25 30 35
Circulating fluid temperature [°C]
Cooling capacity [kW]
Ambient temperature 32°C
Ambient temperature 40°C
Ambient temperature 45°C
0
2
4
6
8
10
12
Cooling capacity [kW]
5 10 15 20 25 30 35
Circulating fluid temperature [°C]
Facility water temperature 40°C
Facility water temperature 32°C
0
2
4
6
8
10
12
14
5 10 15 20 25 30 35
Circulating fluid temperature [°C]
Cooling capacity [kW]
Facility water temperature 32°C
Facility water temperature 40°C
Circulating fluid flow rate [L/min]
Circulating fluid pressure [MPa]
0
10
20
30
40
50
0
0.1
0.2
0.3
0.4
0.5
0 10 20 30 40 50 60 70
Pump head [m]
Circulating fluid
return port
Usable range
(50 Hz)
Usable range
(60 Hz)
Circulating
fluid
outlet
(50 Hz)
Circulating
fluid
outlet
(60 Hz)
Cooling Capacity
Pump Capacity
HRS090-A-20/40 (50 Hz) HRS090-A-20/40 (60 Hz)
HRS090-A-20/40
HRS090-W-20/40
HRS090-W-20/40 (50 Hz) HRS090-W-20/40 (60 Hz)
11
Series HRS090 Standard Type

208
354
597
Option B Note 2)
[With earth leakage breaker]
Circulating fluid fill port lid
Operation display panel
∗Mount it by yourself on the circulating fluid return port.
View A
Anchor bolt fixing position
Ventilation air outlet
Ventilation air inlet
Barrel nipple 25A
Y-strainer
(40 mesh) 25A
Circulating fluid return port Rc1
377
Fluid level indicator
1080
970
Handle
(Same for the
opposite side)
Note 1)
Dustproof filter
Caster (unfixed) with locking lever
M10 bolt (Accessory)
Serial communication (RS-485/RS-232C) connector
D-sub female receptacle
Signal cable entry (Hole 40)
(Grommet with membrane)
Drain port Rc1/4
(Valve stopper)
655
375
173
Circulating fluid outlet
Rc1
Circulating fluid return port
Rc1
Handle
Power terminal
Power cable entry (Hole 40)
(Grommet with membrane)
325
285
Caster (unfixed)
Anchor bolt fixing bracket (Accessory)
1015 (Dimension of anchor bolt fixing bracket)
(970) (Thermo-chiller dimension)
4 x ø15
28
173102
(377)
(Thermo-chiller dimension)
153
Flow direction
Barrel nipple (25A)
(Accessory)
Y-strainer
(Accessory)
Facility water outlet
Rc1/2
Facility water inlet
Rc1/2
Accessory: Y-strainer mounting view For water-cooled type
Contact input/output
communication connector
A
Note 1) The water-cooled type is not equipped with a dustproof filter.
Note 2) 400 V type is provided with an earth leakage breaker “-B” as standard.
Dimensions
HRS090-m-20/40
12
Thermo-chiller Standard Type Series HRS090

q
we
t
r
y
u
i
o
!0 !1 !2 !3 !4!5 !6
Operation Display Panel
The basic operation of this unit is controlled through the
operation display panel on the front of the product.
Alarm
This unit has alarms as standard, and displays each of them by its alarm code on the PV screen with the [ALARM] lamp ([LOW LEVEL] lamp) lit up on the
operation display panel. The alarm can be read out through communication.
Code Alarm message
AL01 Low level in tank
AL02 High circulating fluid discharge temp.
AL03 Circulating fluid discharge temp. rise
AL04 Circulating fluid discharge temp. drop
AL05 High circulating fluid return temp.
AL06 High circulating fluid discharge pressure
AL07 Abnormal pump operation
AL08 Circulating fluid discharge pressure rise
AL09 Circulating fluid discharge pressure drop
AL10 High compressor intake temp.
AL11 Low compressor intake temp.
AL12 Low super heat temp.
AL13 High compressor discharge pressure
AL15
Refrigeration circuit pressure (high pressure side) drop
AL16 Refrigeration circuit pressure (low pressure side) rise
Code Alarm message
AL17 Refrigeration circuit pressure (low pressure side) drop
AL18 Compressor running failure
AL19 Communication error
AL20 Memory error
AL21 DC line fuse cut
AL22
Circulating fluid discharge temp. sensor failure
AL23 Circulating fluid return temp. sensor failure
AL24 Compressor intake temp. sensor failure
AL25
Circulating fluid discharge pressure sensor failure
AL26 Compressor discharge pressure sensor failure
AL27 Compressor intake pressure sensor failure
AL28 Pump maintenance
AL29 Fan maintenance
AL30 Compressor maintenance
AL31 Contact input 1 signal detection
For details, refer to the Operation Manual. Please download it via our website, http://www.smcworld.com
Code Alarm message
AL32 Contact input 2 signal detection
AL37
Compressor discharge temp. sensor failure
AL38 Compressor discharge temp. rise
AL40 Dustproof filter maintenance Note)
AL41 Power stoppage
AL42 Compressor waiting
AL43 Fan failure Note)
AL45 Compressor over current
AL47 Pump over current
AL50 Incorrect phase error
AL51 Phase board over current
Note) Does not occur on the product of water-cooled refrigeration type.
*For details, read the Operation Manual.
No. Description Function
q
Digital display
(7 segment,
4 digits)
PV
Displays the circulating fluid current discharge temperature
and pressure and alarm codes and other menu items (codes).
SV
Displays the circulating fluid discharge temperature
and the set values of other menus.
w
[°C] [°F] lamp
Equipped with a unit conversion function. Displays the
unit of displayed temperature (default setting: °C).
e[MPa] [PSI]
lamp
Equipped with a unit conversion function. Displays the
unit of displayed pressure (default setting: MPa).
r[REMOTE]
lamp
Enables remote operation (start and stop) by
communication. Lights up during remote operation.
t[RUN]
lamp
Lights up when the product is started, and goes off when
it is stopped. Flashes during stand-by for stop or anti-
freezing function, or independent operation of the pump.
y
[ALARM] lamp Flashes with buzzer when alarm occurs.
u[
] lamp Lights up when the surface of the fluid level indicator falls below the L level.
i[
] lamp
Equipped with a timer for start and stop. Lights up
when this function is operated.
o[
] lamp
Equipped with a power failure auto-restart function, which
restarts the product automatically after stopped due to a
power failure. Lights up when this function is operated.
!0
[RUN/STOP] key Makes the product start or stop.
!1 [MENU] key
Shifts the main menu (display screen of circulating fluid discharge temperature
and pressure) and other menus (for monitoring and entry of set values).
!2 [SEL] key Changes the item in menu and enters the set value.
!3 [] key Decreases the set value.
!4 [] key Increases the set value.
!5 [PUMP] key
Press the [MENU] and [RUN/STOP] keys simultaneously. The pump starts
running independently to make the product ready for start-up (release the air).
!6 [RESET] key
Press the [] and [] keys simultaneously. The alarm
buzzer is stopped and the [ALARM] lamp is reset.
No. Function Outline
1 Main display
Displays the current and set temperature of the
circulating fluid, discharge pressure of the circulating
fluid. Changes the circulating fluid set temperature.
2 Alarm display menu Indicates alarm number when an alarm occurs.
3Inspection
monitor menu
Product temperature, pressure and accumulated
operating time can be checked as daily inspection.
Use these for daily inspection.
4 Key-lock Keys can be locked so that set values cannot be
changed by operator error.
5
Timer for operation
start/stop
Timer is used to set the operation start/stop.
6
Signal for the
completion of
preparation
A signal is output when the circulating fluid
temperature reaches the set temperature, when
using contact input/output and serial communication.
7 Offset function
Use this function when there is a temperature offset between the
discharge temperature of the thermo-chiller and user’s equipment.
8Reset after
power failure
Start operation automatically after the power supply
is turned on.
9Key click
sound setting Operation panel key sound can be set on/off.
10 Changing
temp. unit
Temperature unit can be changed.
Centigrade (°C) ⇔Fahrenheit (°F)
11 Changing
pressure unit
Pressure unit can be changed.
MPa ⇔PSI
12 Data reset Functions can be reset to the default settings
(settings when shipped from the factory).
13 Accumulation
time reset
Reset function when the pump, the fan or the compressor
is replaced. Reset the accumulated time here.
14 Anti-freezing
function
Circulating fluid is protected from freezing during winter
or at night. Set beforehand if there is a risk of freezing.
15
Warming-up
function
When circulating fluid temperature rising time at starting
needs shortening during winter or at night, set beforehand.
16 Alarm buzzer
sound setting Alarm sound can be set to on/off.
17 Alarm
customizing
Operation during alarm condition and threshold
values can be changed depending on the alarm type.
18 Communication
This function is used for contact input/output or
serial communication.
List of Function
13
Series HRS090 Standard Type

Item Specifications
Connector type D-sub 9-pin, Female connector
Protocol Modicon Modbus compliant/Simple communication protocol
Standards EIA standard RS-485 EIA standard RS-232C
Circuit diagram
*The terminal resistance of RS-485 (120 W) can be switched by the operation display panel. For details, refer to the Operation Manual for communication.
Do not connect other than in the way shown above, as it can result in failure.
Contact Input/Output
Item Specifications
Connector type M3 terminal block
Input signal
Insulation method Photocoupler
Rated input voltage 24 VDC
Operating voltage range 21.6 to 26.4 VDC
Rated input current 5 mA TYP
Input impedance 4.7 kW
Contact output
signal
Rated load voltage 48 VAC or less/30 VDC or less
Maximum load current 500 mA AC/DC (resistance load)
Minimum load current 5 VDC 10 mA
Output voltage 24 VDC ±10% 500 mA MAX (No inductive load)
Circuit diagram
*The pin numbers and output signals can be set by user. For details, refer to the Operation Manual for communication.
To the thermo-chiller User’s equipment side
24 VDC
Contact output signal 1
Contact input signal 2
Contact output signal 3
Contact output signal 2
24 VCOM
Contact input signal 1
4.7 kΩ
4.7 kΩ
1 kΩ
1 kΩ
Alarm status signal output
Run/stop signal input
Operation status signal output
Remote status signal output
—
Signal description Default setting
0
8
1
9
2
10
3
11
4
12
13
14
15
7
5
624 VDC output
(500 mA MAX)
24 VCOM output
Internal circuit
1
9
Internal
circuit
To the thermo-chiller
SD+
SG
SD−
5
User’s equipment side
2
3
5
To the thermo-chiller User’s equipment side
RD
SD
SG
Internal
circuit
Serial Communication
The serial communication (RS-485/RS-232C) enables the following items to be written and read out.
For details, refer to the Operation Manual for communication.
Please download the Operation Manual via our website, http://www.smcworld.com
Writing
Run/Stop
Circulating fluid temperature
setting (SV)
Readout
Circulating fluid present temperature
Circulating fluid discharge pressure
Status information
Alarm occurrence information
Communication Function
14
Thermo-chiller Standard Type Series HRS090

Earth leakage breaker
Overflow port
(Rc3/4)
Automatic
fluid fill port
(Rc3/8)
Option symbol
With Automatic Fluid Fill Function
J
Applicable to Deionized Water Piping
Option symbol
M
*400 V type is equipped as standard.
HRS090 J
By installing this at the automatic fluid fill port, the circulating fluid can
be automatically supplied to the product using a built-in solenoid valve
for filling fluid while the circulating fluid is decreasing.
Applicable model HRS090-ll-l-J
Fluid fill method Built-in solenoid valve for automatic fluid filling
Fluid fill pressure [MPa] 0.2 to 0.5
Feed water temperature [°C] 5 to 40
With automatic fluid fill function
Contact material of the circulating fluid circuit is made from
non-copper materials.
M
Applicable to
deionized water piping
*No change in external dimensions.
Applicable model HRS090-ll-l-M
Contact material
for circulating fluid
Stainless steel (including heat exchanger brazing), SiC, Carbon,
PP, PE, POM, FKM, NBR, EPDM, PVC, PTFE
HRS090
Series HRS090
Options
Option symbol
With Earth Leakage Breaker
B
HRS090 20 B
A leakage breaker is built in to automatically stop the supply power when it has
short-circuit, over current or electrical leakage. (For models with power supply
specification ‘-40’, it is not necessary to select this option because an earth
leakage breaker is equipped as standard.)
Applicable model Rated current [A] Sensitivity of
leak current [mA]
Short circuit
display method
HRS090-ll-20-B 30 30 Mechanical
button
With earth leakage breaker
Note) Select the option when ordering
the thermo-chiller because the
option cannot be added after pur-
chasing the unit.
15

rt
req
rt
rw
To circulating
fluid return port
To circulating
fluid outlet
y
u
When option J (With automatic fluid fill function) is included,
use the following part numbers.
· Automatic fluid fill port Rc3/8 RNPT3/8 or G3/8
· Overflow port Rc3/4 RNPT3/4 or G3/4
∗ The conversion fittings for circulating fluid outlet/return port, drain port, facility water inlet/outlet (for water-cooled refrigeration) are also included.
Part no. Contents Applicable model
HRS-EP020
NPT thread conversion fitting set
HRS090-A-20/40-J
HRS-EP021
G thread conversion fitting set
Part no. Contents Applicable model
HRS-EP024
NPT thread conversion fitting set
HRS090-W-20/40-J
HRS-EP025
G thread conversion fitting set
2 pcs./set
1 pc.
Conversion fitting
for circulating fluid
Material: Stainless steel
Conversion fitting
for drain outlet
Material: Stainless steel
Conversion fitting
for facility water
Material: Stainless steel
2 pcs./set
2 pcs./set
1 pc.
Conversion fitting
for circulating fluid
Material: Stainless steel
Conversion fitting
for drain outlet
Material: Stainless steel
qPiping Conversion Fitting
This is a fitting to change the port from Rc to G or NPT.
· Circulating fluid outlet, Circulating fluid return port Rc1 →NPT1 or G1
· Drain port Rc1/4 →NPT1/4 or G1/4
(It is not necessary to purchase this when pipe thread type F or N is selected in “How to Order” since it is included in the product.)
Part no. Contents Applicable model
HRS-EP018
NPT thread conversion fitting set HRS090-A-20/40
HRS-EP019 G thread conversion fitting set
Series HRS090
Optional Accessories
wBypass Piping Set
When the circulating fluid goes below the minimum operating flow rate (as shown below), cooling capacity will be reduced and the temperature
stability will be badly affected. Use the bypass piping set to ensure a circulating fluid flow rate of the minimum operating flow rate or more.
Part no. Applicable model
Minimum operating flow rate
(50/60 Hz) [L/min]
HRS-BP005 HRS090-ll-20/40 29/45
Parts List
No. Description
qHose (I.D.: 15 mm, Length: 700 mm)
wOutlet piping assembly (With globe valve)
eReturn piping assembly
rBarrel nipple (Size: 1 inch) (2 pcs.)
tUnion (Size: 1 inch) (2 pcs.)
ySealant tape
uOperation Manual
Part no. Contents Applicable model
HRS-EP022
NPT thread conversion fitting set
HRS090-W-20/40
HRS-EP023 G thread conversion fitting set
16
A

Circulating fluid
return port
Circulating
fluid outlet To circulating
fluid outlet
To mounting
thread hole
To circulating fluid
return port
e
o
o
i
r
!0q
w
u
y
t
Rc1
NPT1
NPT1
Rc1
t
r
w
q
e
e
(314)
(Flying-out size)
(263)
(Height to the bottom of
the resin filter vessel)
rParticle Filter Set
Removes foreign matter in the circulating fluid. This set cannot be directly connected to the thermo-chiller. Install it in the user’s
piping system. Refer to the Operation Manual for details.
Parts List
No. Description Material Q'ty Note
qBody PC, PP 1—
wElement PP 1—
eExtension piece
Stainless
steel
2Conversion from NPT
to Rc
rHandle —1 When -H is selected
tSealant tape PTFE 1—
Fluid Tap water
Max. operating pressure 0.65 MPa
Operating temperature range 5 to 35°C
Nominal filtration accuracy 5 μm
Installation environment Indoors
HRS PF005 H
HRS PF006
Symbol Accessory
Nil None
HWith handle
Particle Filter Set
Replacement Element
Accessory
(343)
(256)
Parts List
No. Description
qDI filter vessel (resin)
wMounting bracket
eDI filter inlet tube
rDI filter outlet tube
tTapping screw (4 pcs.)
yMounting screw (4 pcs.)
uDI control piping assembly
iDI sensor assembly
oNipple (2 pcs.)
!0 DI filter cartridge
(Part no.: HRS-DF001)
eElectric Conductivity Control Set
The set indicates and controls the electric conductivity of the circulating fluid. Refer to the Operation Manual for details.
Part no. Applicable model
HRS-DI007 HRS090-ll-20/40
Measurement range of electric conductivity 2.0 to 48.0 μS/cm
Set range of electric conductivity target 5.0 to 45.0 μS/cm
Set range of electric conductivity hysteresis 2.0 to 10.0 μS/cm
Operating temperature range
(Circulating fluid temperature) 5 to 60°C
Power consumption 400 mA or less
17
Series HRS090

Tank lid
Filter for circulating fluid fill port
∗After supplying the circulating fluid,
the tank lid can be closed with the filter mounted.
Circulating fluid fill port
q
w
tre
 Filter for circulating fluid fill port
HRS-PF007
Material Stainless steel 304,
Stainless steel 316
Mesh size 200
tFilter for Circulating Fluid Fill Port
Prevents foreign matter from entering the tank when supplying the circulating fluid. Can be used just by fitting into the circulating
fluid fill port.
yDrain Pan Set (With Water Leakage Sensor)
Drain pan for the thermo-chiller. Liquid leakage from the thermo-chiller can be detected by mounting the attached water leakage
sensor. Align the drain pan with the hole in the bottom of the thermo-chiller for installation.
Parts List
No. Description
qDrain pan
wWater leakage sensor
eExtension cable
rBinding band (4 pcs.)
tCable fixture (4 pcs.)
Part no. Applicable model
HRS-WL003 HRS090-mm-20/40
18
Optional Accessories Series HRS090
A

Required Cooling Capacity Calculation
Example 1: When the heat generation amount in the user’s equipment is known.
The heat generation amount can be determined based on the power consumption or output
of the heat generating area — i.e. the area requiring cooling — within the user’s equipment.*
qDerive the heat generation amount from the power consumption.
Power consumption P: 7 [kW]
Q = P = 7 [kW]
Cooling capacity = Considering a safety factor of 20%, 7 [kW] x 1.2 =
wDerive the heat generation amount from the power
supply output.
Power supply output VI: 8.8 [kVA]
Q = P = V x I x Power factor
In this example, using a power factor of 0.85:
= 8.8 [kVA] x 0.85 = 7.5 [kW]
Cooling capacity = Considering a safety factor of 20%,
7.5 [kW] x 1.2 =
*The above examples calculate the heat generation amount based on the power consumption.
The actual heat generation amount may differ due to the structure of the user’s equipment.
Be sure to check it carefully.
Example 2: When the heat generation amount in the user’s equipment is not known.
Obtain the temperature difference between inlet and outlet by circulating the circulating fluid inside the user’s equipment.
Heat generation amount by user’s equipment Q : Unknown [W] ([J/s])
Circulating fluid : Tap water*
Circulating fluid mass flow rate qm : (= ρx qv ÷60) [kg/s]
Circulating fluid density ρ: 1 [kg/L]
Circulating fluid (volume) flow rate qv : 35 [L/min]
Circulating fluid specific heat C : 4.186 x 103[J/(kg·K)]
Circulating fluid outlet temperature T1: 293 [K] (20 [°C])
Circulating fluid return temperature T2 : 296 [K] (23 [°C])
Circulating fluid temperature difference iT : 3 [K] (= T2– T1)
Conversion factor: minutes to seconds (SI units) : 60 [s/min]
* Refer to page 11 for the typical physical property value of tap water or other circulating fluids.
Q = qm x C x (T2 –T1)
= =
= 7325 [J/s] ≈7325 [W] = 7.3 [kW]
Cooling capacity = Considering a safety factor of 20%,
7.3 [kW] x 1.2 =
8.4 [kW]
9.0 [kW]
ρx qv x C x iT
60
1 x 35 x 4.186 x 103x 3.0
60
8.8 [kW]
Thermo-chiller
User’s
equipment
∆T = T2–T1
Q: Heat generation
amount
T1: Outlet
temperature
T2: Return
temperature
qv: Circulating
fluid flow
rate
Series HRS090
Cooling Capacity Calculation
eDerive the heat generation amount from the output.
Output (shaft power etc.) W: 13 [kW]
Q = P =
In this example, using an efficiency of 0.7:
= = 7.3 [kW]
Cooling capacity = Considering a safety factor of 20%,
7.3 [kW] x 1.2 =
W
Efficiency
5.1
0.7
8.8 [kW]
HRS090-A
Q: Heat generation
amount
User’s
equipment
I: Current
Power consumption
V: Power supply
voltage
P
Example of conventional measurement units (Reference)
Heat generation amount by user’s equipment Q : Unknown [cal/h] →[W]
Circulating fluid : Tap water*
Circulating fluid weight flow rate qm
: (= ρx qv x 60) [kgf/h]
Circulating fluid weight volume ratio  : 1 [kgf/L]
Circulating fluid (volume) flow rate qv : 35 [L/min]
Circulating fluid specific heat C
: 1.0 x 103[cal/(kgf·°C)]
Circulating fluid outlet temperature T1 : 20 [°C]
Circulating fluid return temperature T2 : 23 [°C]
Circulating fluid temperature difference iT : 3 [°C] (= T2– T1)
Conversion factor: hours to minutes : 60 [min/h]
Conversion factor: kcal/h to kW : 860 [(cal/h)/W]
Q =
=
=
≈7325 [W] = 7.3 [kW]
Cooling capacity = Considering a safety factor of 20%,
7.3 [kW] x 1.2 =
qmx C x (T2– T1)
860
x qvx 60 x C x iT
860
1 x 35 x 60 x 1.0 x 103x 3.0
860
8.8 [kW]
19
