SMC Networks IDF190D-3-W Series User manual

IDX-OM-Y002
PRODUCT NAME
Refrigerated Air Dryer
MODEL / Series
IDF190D-3-(C,M,R)W
IDF240D-3-(C,M,R)W
Please read this manual prior of using the air dryer.
Keep the manual readily available for reference.
This manual is intended to explain the installation and operation of the product.
Only those who have thorough understanding of the fundamental operating
procedure or have basic knowledge and skills of handling industrial products are
qualified to perform installation and operation.
2
4
0

Foreword
Thank you for purchasing SMC’s refrigerated type air dryer (hereinafter referred to as the “product”).
For safety and long life of the product, be sure to read this Operation Manual (hereinafter referred to as the
“manual”) and clearly understand the contents.
For safe operation of SMC THERMODRYER, thoroughly read and follow the safety instructions, as well
as regulations stated within ISO 44141& JIS B 83702.
1) ISO4414: Pneumatic fluid power - Recommendations for the application of equipment to
transmission and control systems.
2) JIS B8370: General rules for pneumatic equipment
This manual is intended to explain the installation and operation of the product. Only people who
understand the basic operation of the product through this manual or who install and operate industrial
machinery and have basic knowledge and ability to handle such equipment, are allowed to work on the
product.
This manual and other documents attached to the product do not constitute a contract, and will not
affect any existing agreements or commitments.
It is strictly prohibited to copy this manual entirely or partially for the use by a third party without prior
permission from SMC.
NOTE: The contents of this operation manual are subject to
change without prior notice.

IDX-OM-Y002
Contents
IDF190D/240D Series
Contents
Chapter 1 Safety................................................................................1-1
1.1 Before Using the Air Dryer...................................................................................... 1-1
1.1.1 Danger, Warning and Caution in This Manual..................................................................... 1-1
1.2 Hazard Classifications & Position of Hazard warning Labels.............................. 1-2
1.2.1 Hazard of Electricity ............................................................................................................ 1-2
1.2.2 Hazard of Hot Surface......................................................................................................... 1-2
1.2.3 Hazard of Compressed Air Circuit....................................................................................... 1-2
1.2.4 Cautions for usage .............................................................................................................. 1-3
1.2.5 Cautions for refrigerant........................................................................................................ 1-3
1.3 Waste Disposal........................................................................................................ 1-5
1.4 Limited Warranty and Disclaimer/ Compliance Requirements............................. 1-6
Chapter 2 Name and Function of Parts............................................2-1
2.1 Name and Function of Parts................................................................................... 2-1
Chapter 3 Transportation and installation.......................................3-1
3.1 Transportation......................................................................................................... 3-1
3.2 Installation............................................................................................................... 3-2
3.2.1 Environment ........................................................................................................................ 3-2
3.2.2 Installation ........................................................................................................................... 3-2
3.2.3 Air piping.............................................................................................................................. 3-3
3.2.4 Replacement of auto drain.................................................................................................. 3-4
3.2.5 Electrical wiring ................................................................................................................... 3-4
3.2.5.1. Wiring of the power supply cable ........................................................................................ 3-4
3.2.5.2. Wiring of signal cable (operation / error / remote operation)............................................... 3-5
3.2.6 Cooling water piping............................................................................................................ 3-6
3.3 Cautions about Reinstallation................................................................................ 3-7
Chapter 4 Operation/ Shutdown.......................................................4-1
4.1 Check points before operation............................................................................... 4-1
4.2 Operation................................................................................................................. 4-1
4.3 Stop.......................................................................................................................... 4-2
4.4 Cautions for re-start................................................................................................ 4-2
4.5 Check points before restart.................................................................................... 4-2
4.6 Cautions when the product is shut down for an extended period of time .......... 4-2
4.7 Signal output ........................................................................................................... 4-2
Chapter 5 Checks, Maintenance and Adjustment ...........................5-1
5.1 Daily inspection....................................................................................................... 5-1
5.2 Regular maintenance.............................................................................................. 5-2
5.2.1 Maintenance for water-cooled condenser........................................................................... 5-2
5.2.2 Auto Drain Maintenance...................................................................................................... 5-6
5.3 Adjustment .............................................................................................................. 5-8
5.3.1 Capacity Control Valve........................................................................................................ 5-8
5.3.2 Sight glass (for IDF240D-3-W only).................................................................................. 5-8

IDX-OM-Y002
Contents
IDF190D/240D Series
Chapter 6 Troubleshooting............................................................... 6-1
6.1 Troubleshooting.......................................................................................................6-1
6.2 Reset the Thermal relay and High Pressure Switch..............................................6-3
Chapter 7 Documents ....................................................................... 7-1
7.1 Specifications ..........................................................................................................7-1
7.2 Refrigerant and GWP...............................................................................................7-2
7.3 Dimensions ..............................................................................................................7-3
7.4 Electrical circuit diagram ........................................................................................7-4
7.5 Air and refrigerant circuits and functions..............................................................7-6
Chapter 8 Option C............................................................................ 8-1
8.1 Specifications ..........................................................................................................8-1
8.2 Precautions for installation and handling..............................................................8-1
Chapter 9 Option M ........................................................................... 9-1
9.1 Safety instructions for use......................................................................................9-1
9.2 Specifications ..........................................................................................................9-2
9.3 Installation of Motor type Auto Drain......................................................................9-3
9.4 Electrical circuit diagram ........................................................................................9-3
Chapter 10 Option R.......................................................................... 10-1
10.1 Safety instructions for use....................................................................................10-1
10.2 Specifications ........................................................................................................10-1
10.3 Connection of power supply.................................................................................10-2
10.4 Handling Precautions of the Earth Leakage Breaker ..........................................10-2
10.5 Electrical circuit diagram ......................................................................................10-2
Chapter 11 Inspection record............................................................11-1
11.1 Inspection record...................................................................................................11-1

IDX-OM-Y002
Chapter 1 Safety
IDF190D/240D Series 1.1 Before Using the Air Dryer
1-1
Chapter 1 Safety
1.1 Before Using the Air Dryer
This chapter is intended to specifically describe the safety related issues for handling the product.
Read this before handling the product.
This product is for dehumidification of compressed air. We, as the manufacturer, cannot take any
responsibility if used for any other purpose.
The product operates with high voltage and has some parts that get hot or rotates during operation. If
a component needs to be replaced or repaired, contact a specialized vendor for parts and service.
All personnel who work with or around the product should read and understand the safety related
information in this manual carefully before starting work.
This service manual is not a general safety manual.
People who handle this product or work around it need to take training to understand the inherent risks
and master safety measures.
The safety manager is responsible for strictly observing safety standards, but responsibility in respect
to safety standards during daily work resides with each individual operator and maintenance
personnel.
Operators and maintenance representatives should take the safety of all personnel in the work
environment into account.
It is necessary to think of the safety of working place and work environment for each task.
If the product is subjected to a short power outage (including voltage sag), it may take a long time to
resume normal operation or be unable to restart normally due to the protective equipment triggered
after the power is recovered. Should this happen, turn the product off using the switch with lightand
reset the protection circuits referring to 6.2 - Reset the Thermal relay and High Pressure Switch. It is
possible that the product starts suddenly after the power is recovered. Turn off the switch with light
when removing the cover panel.
This manual must be kept available to operators whenever necessary.
1.1.1 Danger, Warning and Caution in This Manual
The instructions given in this manual aim to ensure that the product is operate in a safe and correct way.
These instructions are grouped into three categories, “Danger, “”Warning”, and “Caution”, which indicate
the level of hazard, damage and also the degree of emergency. Read these statements carefully and
thoroughly understand them and location of the instruction before operating or performing maintenance
on the unit. “DANGER”, “WARNING” and “CAUTION” signs are in order according to severity
(DANGER> WARNING> CAUTION). The meanings of these signs are as follows.
Before using the product, be sure to read and understand all the
important actions highlighted in this manual.
"WARNING": Hazard that may cause serious personal injury or death during operation,
maintenance or inspection due to the negligence of required procedure or warning to avoid
the danger.
WARNING
“DANGER": Hazard that will cause serious personal injury or death during operation,
maintenance or inspection due to incorrect handling or negligence of compliance to avoid
the danger.
DANGER
"CAUTION": Hazard that Will cause minor personal injury or damage to the device or
equipment during operation, maintenance or inspection due to the negligence of required
procedure or warning to avoid the danger.
CAUTION

IDX-OM-Y002
Chapter 1 Safety
1.2 Hazard Classifications & Position of Hazard warning Labels IDF190D/240D Series
1-2
1.2 Hazard Classifications & Position of Hazard
warning Labels
To ensure the safety of the operators, potential hazards are classified and marked with warning labels.
Confirm the potential hazards and positions of the labels before operation.
1.2.1 Hazard of Electricity
1.2.2 Hazard of Hot Surface
1.2.3 Hazard of Compressed Air Circuit
- Transportation, installation, and maintenance involve risks and should only be carried out by
people who have sufficient knowledge and experience about the product and its accessories.
- If there is abnormality, take actions below according to the operation manual.
- Read carefully the Chapter 6 Troubleshooting before taking actions.
- Do not start the product in any trouble. If failure occurs, immediately stop the product, and
contact maintenance personnel or a qualified person.
The product has surfaces that can reach high temperatures during operation. What is more,
there is also the danger of burn injury due to remaining heat after the power supply is cut.
Therefore, wait until the temperature of hot parts become 50oC and below.
WARNING
Before replacing or cleaning parts, be sure to bleed compressed air remaining inside of the
product until the gauge indicates “0”. If there is no relief to the pressure, high pressure can
propel objects at high velocity when unscrewing parts and cause injury.
WARNING
WARNING
Inside of this product, there is a power-supplying section with high voltage separated by the
cover panel. Do not operate the product without the cover panel.
WARNING

IDX-OM-Y002
Chapter 1 Safety
IDF190D/240D Series 1.2 Hazard Classifications & Position of Hazard warning Labels
1-3
1.2.4 Cautions for usage
1.2.5 Cautions for refrigerant
Read with caution and pay attention to the notations on the caution labels.
- Do not remove or rub the caution labels.
- Ensure that the warning labels are placed in the correct position.
WARNING
2
4
0
Front
- The product uses hydro fluorocarbon type refrigerant (HFC).
- This product is a Class 1 specified products of the Act on Rational Use and Proper
Management of Fluorocarbon in Japan.
It is strictly forbidden to emit Fluorocarbon to the atmosphere. Before you repair this
product, you should collect the refrigerant with “Refrigerant collector.”Then, ask a
destruction agency to dispose of collected refrigerant. Only personnel with required
knowledge and experience about the equipment and incidental device should perform the
collection of the refrigerant.
- Only maintenance personnel or qualified personnel are allowed to open the cover panels
of the product.
- The type and quantity of HFC are mentioned on the Chapter 7.1 Specifications.
CAUTION

IDX-OM-Y002
Chapter 1 Safety
1.2 Hazard Classifications & Position of Hazard warning Labels IDF190D/240D Series
1-4
2
4
0
Front

IDX-OM-Y002
Chapter 1 Safety
IDF190D/240D Series 1.3 Waste Disposal
1-5
1.3 Waste Disposal
When you dispose of the product, you should collect the refrigerant and the refrigerant oil enclosed in
the refrigerant circuit.
- The product uses hydro fluorocarbon type refrigerant (HFC).
- This product is a Class 1 specified products of the Act on Rational Use and Proper
Management of Fluorocarbon in Japan.
It is strictly forbidden to emit Fluorocarbon to the atmosphere. Before you repair this
product, you should collect the refrigerant with “Refrigerant collector.”Then, ask a
destruction agency to dispose of collected refrigerant. Only personnel with required
knowledge and experience about the equipment and incidental device should perform the
collection of the refrigerant.
- Only maintenance personnel or qualified personnel are allowed to open the cover panels of
the product.
- The type and quantity of HFC can be found on the product label.
CAUTION
- Dispose of the refrigerant and refrigerant oil according to the bylaw or regulation of local
government.
- Only personnel with required knowledge and experience about the product and incidental
device should perform the collection of the refrigerant.
- Only maintenance personnel or qualified personnel are allowed to open the cover panels
of the product.
- If there is something not clear, please contact our service office.
CAUTION

IDX-OM-Y002
Chapter 1 Safety
1.4 Limited Warranty and Disclaimer/ Compliance Requirements IDF190D/240D Series
1-6
1.4 Limited Warranty and Disclaimer/ Compliance
Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
Requirements”.
Read and accept them before using the product.
Limited Warranty and Disclaimer
1. The warranty period of the product is 1 year in service or within 1.5 years after the product
is delivered. Also, the product may have specified durability, running distance or
replacement parts. Please consult your nearest sales branch.
2. For any failure or damage reported within the warranty period for which we are
responsible, a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other
damage incurred due to the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms and
disclaimers noted in the specified catalog for the particular products.
Compliance Requirements
1. The use of SMC products with production equipment for the manufacture of weapons of
mass destruction(WMD) or any other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are governed by
the relevant security laws and regulation of the countries involved in the transaction. Prior
to the shipment of a SMC product to another country, assure that all local rules governing
that export are known and followed.
CAUTION
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing
industries.
If the product is being considered for use in other industries, consult SMC beforehand and
exchange specifications or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
CAUTION
SMC products are not intended for use as instruments for legal metrology.
Measurement instruments that SMC manufactures of sells have not been qualified by type
approval tests relevant to the metrology (measurement) laws of each country. Therefore, SMC
products cannot be used for business or certification ordained by the metrology (measurement)
laws of each country.

IDX-OM-Y002
Chapter 2 Name and Function of Parts
IDF190D/240D Series 2.1 Name and Function of Parts
2-1
Chapter 2 Name and Function of Parts
2.1 Name and Function of Parts
Front panel
Remove the front panel
of the product. Connect
the power supply cable
through the rubber
grommet.
Auto drain
Check the auto drain is
working properly at least once
a day.
2
4
0
Mini front display
The lamp is continuously on
during normal operation.
Start and stop the operation.
Side ventilation grille
Radiates the heat generated
in the unit. Do not block the
grille by the wall.
Front panel mounting screw
Provided on both sides.
Front
ミニフロント表示部詳細
停止スイッチ(黒)
運転スイッチ(白)
本体/遠隔切換スイッチ(黄)
運転ランプ(緑)
蒸発温度計
異常ランプ(赤)
空気圧力計
Main unit / remote
selector switch (yellow)
Evaporation
thermometer
Operation LED
(green)
Start switch (white)
Stop switch (black)
Air Pressure
gauge
Error indicator
(red)
Enlarged view of the Mini-front display
Grommet with
membrane
Power cable
cable entry
Compressed air
outlet (OUT)
Terminal block
Compressed air
inlet (IN)
Left side panel
Drain plug
Cooling water outlet
Condensing
pressure
gauge
・
・
・
Cooling water inlet

IDX-OM-Y002
Chapter 2 Name and Function of Parts
2.1 Name and Function of Parts IDF190D/240D Series
2-2

IDX-OM-Y002
Chapter 3 Transportation and installation
IDF190D/240D Series 3.1 Transportation
3-1
Chapter 3 Transportation and
installation
3.1 Transportation
Follow the instructions below when transporting the product.
For moving the product, lift it with care so that the product is not laid down on its side or dropped.
Do not transport the product lying down on its side, or the product will be damaged.
Do not suspend the product.
- Use the product in an appropriate manner, and pay attention to safety, particularly
physical safety of operators, during the installation, operation, maintenance and checks of
the product.
- When the product is used for a critical facility or equipment, prepare a spare product or
alternative machine in case of failure or stoppage of the product due to the operation of
the protective equipment.
WARNING
This product is heavy. Follow above cautions to avoid risk during transportation.
This product weighs more than 450kg, only move the product using a forklift. Moving by
forklift should be done by personnel who have the applicable licenses.
WARNING
Tranportation, installation, and maintenance including dangerous work must be done by
personnel who have require knowledge and experience about the product and system.
CAUTION

IDX-OM-Y002
Chapter 3 Transportation and installation
3.2 Installation IDF190D/240D Series
3-2
3.2 Installation
3.2.1 Environment
The product must not be operated or stored in the following conditions. Potential malfunction or damage
to the product may occur if these instructions are disregarded.
Place where the product is exposed to rain or wind. Humid place (more than 85% of relative
humidity).
Avoid locations where water, water vapor, salt water, or oil may splash on the product.
Avoid locations where dust or other particles are present.
Avoid locations where flammable or explosive gases are present.
Avoid locations where corrosive gases, solvents or combustible gases present.
Avoid locations which receive direct sunlight or radiated heat.
Avoid locations where the ambient temperature exceeds the limits as mentioned below.
During operation: 2 to 45oC
During storage: 0 to 50oC (when there is no drain water inside of the piping)
Avoid locations where temperature substantially changes.
Avoid locations where strong magnetic noise occurs. (Avoid locations where strong electric field,
strong magnetic fields, or surge voltage occur).
Avoid locations where static electricity occurs or conditions which make the product discharge static
electricity.
Avoid locations where high frequencies occur.
Avoid locations where damage is likely to occur due to lightening.
Avoid installation on machines used for transporting, such as vehicles, ships, etc.
Avoid locations at altitudes of 2000 meters or higher.
Avoid locations where strong impacts or vibrations occur.
Avoid locations where a massive force strong enough to deform the product is applied or the weight
from a heavy object is applied.
Avoid locations with insufficient space for maintenance.
Necessary maintenance space
Front face: 1.0 m
Rear: 1.0 m
Top: 1.0 m
Right side: 1.0 m
Left side: 1.0 m
Avoid locations where the ventilation grille is obstructed.
Avoid locations where the air dryer will draw in high-temperature air discharged from an air
compressor or other dryer.
Avoid pneumatic circuits where rapid pressure fluctuations or flow speed changes are generated.
3.2.2 Installation
The product should be installed on a vibration-free, stable, horizontal flat surface.
Refer to the 7.3 Dimensions of the Chapter 7.
We recommend the anchor bolt sets.
Do not use or store the product in conditions of compressed air or an environment
containing substances below. Otherwise, malfunction or parts damage may occur.
- Corrosive gas, organic solvents or chemicals.
WARNING

IDX-OM-Y002
Chapter 3 Transportation and installation
IDF190D/240D Series 3.2 Installation
3-3
3.2.3 Air piping
Connect compressed air inlet and outlet using a JIS10K flange specified in Chapter 7- 7.1
Specifications
It is recommended to install a main line filter in the air inlet piping. Main line filter prevents the auto
drain from malfunctioning by stopping rust and particles.
Be careful not to let the vibration of the air compressor transmit.
When the pressure of the air source fluctuates a lot, install an air tank.
Before piping, flush the inside of piping to eliminate foreign matter such as particles, seal tape or
liquid gasket. Entry of the foreign matter may cause cooling failure or drain discharge failure.
Use pipes and fittings that have enough endurance against the operating pressure and temperature.
And connect it firmly to prevent air leakage.
Provide bypass-piping to make it possible to do maintenance without stopping the air compressor.
If rapid pressure fluctuation or flow change occurs, install a filter on the dryer outlet to prevent drain
from splashing.
Flange
Compressed air inlet (IN)
By-pass valve
Compressed air outlet (OUT)
Flange
Downstream side valve
By-pass piping
Upstream side valve

IDX-OM-Y002
Chapter 3 Transportation and installation
3.2 Installation IDF190D/240D Series
3-4
3.2.4 Replacement of auto drain
Mount the nipple to the auto drain (included in the same package). Then connect it to the drain inlet of the dryer.
Connect the drain piping to the auto drain outlet. The drain piping should have an internal diameter of 8mm or
more and be 5m or less in length. Make sure that it does not go upwards and it is not bent. The outlet end of the
tube is released to atmosphere, and lets the drain flow through the tube.
Ensure that the ball valve is opened. Refer to 7.3 Dimensions of the Chapter 7.
Using the pressure of the compressed air, the drain will be discharged periodically. Fix the outlet end
of the tube so as not to swing during discharge.
3.2.5 Electrical wiring
3.2.5.1. Wiring of the power supply cable
Remove the front panel of the product and connect the power cable to the terminal block.
Install the earth leakage breaker on the power supply side. It needs to be prepared by the user.
Allowable power supply fluctuation:
3 phase 200 VAC +/-10% (50Hz); 3 phase 200 VAC to 220V +/-10% (60Hz)
Power supply cable specification
Prepare the power supply cables below.
Power supply cable: 10AWG (5.5mm2or greater), cable O.D. Approx. 16mm, 4 cores (including the
ground)
Approx. 1.5m of cable is necessary for wiring in the product.
All electrical work must be carried out in a safe manner by a qualified person in compliance
with applicable national regulations.
- Be sure to shut off the user’s power supply. Wiring with the product energized is strictly
prohibited.
- Ensure a stable power supply with no surge.
- Install the correct electric earth leakage breaker of the specified leakage capacity and load
capacity referring to 7.1 Specifications to prevent electric shock and burning of the
compressor motor.
- Use a power supply suitable for the specifications of the product.
3 phase power supply type cannot be operated by single phase power supply.
- Be sure to connect the ground connection.
- Never connect the ground to water line, gas pipe or lightning conductor.
- Do not plug too many leads into a single socket. That causes exothermic heat or fire.
- Do not modify the internal electrical wiring of the product.
- For use in Europe, install a breaker compliant with applicable IEC standards to the power
supply of the product.
WARNING
- During drain work, follow the procedure that you define to keep the safety of worker. (ex.
Put on protective glass, apron, and gloves).
- In case that oil gets mixed in the wasted water that is discharged from the auto drain, the
waste liquid treatment is necessary. Handle it following the bylaw or regulation of local
government.
WARNING

IDX-OM-Y002
Chapter 3 Transportation and installation
IDF190D/240D Series 3.2 Installation
3-5
Power supply cable length
Power cable length for the product shall be less than 30m.
Power supply
Connect the power cable and grounding cable to the terminal block.
Wiring procedure
1) Remove the front panel.
2)Introduce the cable through the grommet with membrane to connect to the terminal block. (refer to
the label on the terminal block)
Do not touch any equipment other than the terminal block during wiring. (Refer to the layout of the
terminal box).
3) Loosen the M4 screw of the terminal block using a screwdriver. Attach the round crimp terminal
(R5.5-4) attached to the power cable and tighten it to the terminal block with the previously loosened
screw.【Tightening torque:1.0N･m】
4) Mount the front panel back.
3.2.5.2. Wiring of signal cable (operation / error / remote operation)
Remove the front panel of the product and connect the signal cable to the terminal block.
Signal cable specification
Prepare the following signal cables:
Signal cable: 20AWG (0.5mm2or greater), cable O.D. Approx. 9mm, 6 cores
Approx. 1.5m of cable is necessary for wiring in the product.
Signal cable length
Signal cable length shall be less than 30m.
Signal cable Connection
Connect the signal cable to the terminal block.
Wiring procedure
1) Remove the front panel.
2) Introduce the cable through the grommet with membrane to connect to the terminal block. (refer to
the label on the terminal block)
Do not touch any equipment other than the terminal block during wiring. (Refer to the layout of the
terminal box)
3) Loosen the M4 screw of the terminal block using a screwdriver. Attach the round crimp terminal
(R1.25-4) attached to the signal cable and tighten it to the terminal block with the previously
loosened screw. (Tightening torque: 1.0 N･m)
Terminal width ：9.9mm
アース
お客様接続側
異常
信号
運転
信 号
242365 2221
電源 遠隔
運転
PEL3L2L1
端子台の配置図
Remote
operation
Ground
(to be connected to the user's equipment)
RUN
signal
Power
supply
Error
signal

IDX-OM-Y002
Chapter 3 Transportation and installation
3.2 Installation IDF190D/240D Series
3-6
4) Mount the front panel back.
[Remote control]
Voltage of AC200V is present on the terminal block. The black switch (stop) must be turned on while
wiring. When wiring, shut off the supply breaker.
1) Connect the external switch terminals to the terminal blocks No.5 and No.6.
Use a single pole type (non-voltage) external switch for remote operation.
2) To enable remote operation, the yellow switch (main unit /remote selector switch) must be turned ON.
Then, for remote operation, the product is turned on/off using the external switch.
3.2.6 Cooling water piping
Strainer (60 mesh or finer) is recommended on the inlet of the cooling water.
When the strainer is not used, impurities in the cooling water may adhere the water cooling condenser,
decreasing the cooling performance.
Do not remove the water release plug other than during maintenance or repair.
When there is a possibility of freezing or the dryer is not used for a long period of time, discharge the water in the
piping from the water release plug.
Control the cooling water quality and amount. (Refer to the Chapter 5.2.1 Maintenance for water-cooled
condenser for details.)

IDX-OM-Y002
Chapter 3 Transportation and installation
IDF190D/240D Series 3.3 Cautions about Reinstallation
3-7
3.3 Cautions about Reinstallation
If you move the product and reinstall it into another place after some operations (including trial running),
all installation instructions in chapter 3 should be followed as well as the following instructions.
Disassembly of the power cable
Cut off the power source before you disassemble the power cable.
Removal of air piping
Remove the seal tape completely after detaching the piping. Remaining tape could cause imperfect
cooling or failure by entering into the product.
Procedure to release residual compressed air
1) Even while the dryer is removed, only when compressed air is needed, open the bypass piping valve.
2) Close the compressed air inlet and outlet valve.
3) Ensure that the ball valve of the auto drain is opened.
4) Open the bleed valve of the auto drain. When compressed air stops coming out, press the flush
button to confirm that there is no compressed air left inside. Refer to the figure shown below
Flush button
Bleed valve
Hexagon nut
Only someone who has enough knowledge about the equipment and incidental devices
should reinstall it in another place.
CAUTION
- All electrical work must be carried out in a safe manner by a qualified person in compliance
with applicable national regulations.
- Cut off the power supply for safety before the wiring. Wiring with the product energized is
strictly prohibited.
WARNING
- All electrical work must be carried out in a safe manner by a qualified person in compliance
with applicable national regulations.
- Separate the compressed air source from the product for safety before removing the
piping.
- Do not remove any piping when there is remaining compressed air pressure inside of it.
WARNING
Open
Close

IDX-OM-Y002
Chapter 3 Transportation and installation
3.3 Cautions about Reinstallation IDF190D/240D Series
3-8
