SMC Networks EX250-SEN1 User manual

Reduced wiring system
EX250 - SEN1
Instruction Manual
EtherNet/IP™ Compatible SI Unit
URL http://www.smcworld.com
Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.
EtherNet/IP™ is a trademark used under licence by ODVA.
The descriptions of products shown in this document may be used by the other companies as their trademarks.
©2006 SMC Corporation All Rights Reserved

Contents
Thank you for purchasing the SMC reduced wiring system EX250 series.
Please read this instruction manual carefully and understand the contents before
use so that you can operate this unit safely and correctly.
Please keep this manual handy for future reference.
OPERATOR
This instruction manual has been written for those who have knowledge of
machines and equipments that use reduced wiring system as well as the
sufficient knowledge to assemble, operate, and maintain such devices.
Before performing assembly, operation and/or maintenance, please read
this manual carefully and understand the contents.
To facilitate recycling, this
manual is printed using
biodegradable soy ink, which
can easily be de-inked.
This manual is printed in the
"non-water system", which does
not output toxic liquid waste.
SAFETY ..........................................................................................................2
Product Summary............................................................................................5
SI Unit
Model Indication Method...............................................................................6
Part Names...................................................................................................6
Dimensions ...................................................................................................7
Mounting/Installation.....................................................................................7
Specifications..............................................................................................10
Wiring..........................................................................................................12
Display/Setting............................................................................................15
Input Block
Model Indication Method.............................................................................18
Part Names.................................................................................................18
Dimensions .................................................................................................19
Mounting/Installation...................................................................................19
Specifications..............................................................................................19
Wiring..........................................................................................................20
Display/Setting............................................................................................22
EX9 Series Output Block/Power Block
Model Indication Method.............................................................................23
Part Names.................................................................................................24
Dimensions .................................................................................................25
Mounting/Installation...................................................................................25
Specifications..............................................................................................25
Wiring .........................................................................................................26
Display ........................................................................................................30
Option............................................................................................................31
Troubleshooting.............................................................................................33

2 3
SAFETY
The body of unit and this manual contain the essential information for the protection of
users and others from possible injury and property damage and to ensure correct
handling.
Please check that you fully understand the definitions of the following messages
( symbols ) before going on to read the body of this manual, and always follow the
instructions.
Please also read the instruction manuals etc. of related machines and equipments and
understand the contents before use.
IMPORTANT MESSAGES
Indicates a potentially hazardous situation that could result in
death or severe injury if you do not follow instructions.
Read this manual and follow its instructions. Signal words such as WARNING,
CAUTION and NOTE will be followed by important safety information that must be
carefully reviewed.
Indicates a potentially hazardous situation that, if not avoided,
may result in minor injury or moderate injury.
Gives you helpful information.
NOTE
Do not disassemble,
modify ( including modification of printed circuit board ) or repair.
Otherwise injury or failure can result.
Do not operate beyond specification range.
Otherwise fire, malfunction or damage to the reduced wiring system can result.
Confirm the specifications before operation.
Do not operate in atmosphere of flammable/explosive/corrosive gas.
Otherwise fire, explosion or corrosion can result.
This reduced wiring system is not explosion-proof type.
For use in interlock circuit:
Provide double interlock system by adding different type of protection
( such as mechanical protection ).
Check that the interlock circuit is working normally.
Otherwise accident caused by malfunction can result.
Before performing maintenance:
Turn off power supply.
Stop air supply, exhaust compressed air in piping, and confirm the release
to atmosphere.
Otherwise injury can result.
Conduct proper functional inspection after completing maintenance.
In the case of abnormality such as unit does not work normally, stop the operation.
Otherwise safety cannot be assured due to unintended malfunction.
Provide grounding to improve safety and noise resistance of reduced wiring
system.
Provide grounding as close to the unit as possible to shorten distance for grounding.
1. UL508-compatible limited voltage/current circuit
A circuit using the secondary coil of an insulating transformer that meets following conditions
as power source.
Maximum voltage ( at no load ):30Vrms ( 42.4Vpeak ) or below
Maximum current: ( 1 ) 8A or less ( including when short-circuited )
( 2 ) When limited by the circuit protector ( such as fuse )
having the following rating.
2. UL1310-compatible Class 2 power supply unit or circuit of max. 30Vrms ( 42.4Vpeak ) or less
using a UL1585-compatible Class 2 transformer as power source. ( Class 2 circuit )
Handling precautions
Use the following UL-recognized DC power supply to combine with.
No-Load Voltage ( Vpeak ) Max. Current Rating ( A )
0 to 20 [V] 5.0
Above 20 [V] to 30 [V] 100/peak voltage

4 5
Product Summary
Power supply for Output Block (for high wattage load)
24VDC
Connecting to bus at upper level
(EtherNet/IP)
Power supply for output/input and control
24VDC
Solenoid valve
Output Block
(for high wattage load)
Power Block
Output Block
(for low wattage load)
SI Unit applicable to
EtherNet/IP
Input Block
End Plate
This system realizes reduced wiring between the input and output equipment by con-
necting to EtherNet/IP. EtherNet/IP and the input and output equipment communicates
through the SI Unit.
Up to 32 Inputs can be connected to the SI Unit using Input Blocks.
Up to 32 Outputs Note) from combined EX9 Output Blocks and Valve manifolds can be
connected to the SI Unit.
Note) The maximum output point is 24 when the Power Block is connected.
SAFETY ( continued )
Follow the instructions given below when handling your reduced wiring system.
Otherwise a damage or failure to cause a malfunction can result.
Operate the reduced wiring system at the specified voltage.
Reserve space for maintenance.
Do not remove any name plate or label.
Do not drop, hit or apply an excessive shock to the unit.
Follow the specified tightening torque.
Do not apply any excessive force to cables by repeated bending, tensioning or placing a
heavy object on the cables.
Connect wires and cables correctly.
Do not perform any wiring work while the power is on.
Do not use the reduced wiring system on the same wiring route as the power line or high
voltage line.
Confirm the insulation of wiring.
Perform the power supply wiring by dividing into two lines ---- one is for power supply for output
and the other is for power supply for input and controlling.
Take sufficient measures against noise such as noise filter when incorporating the reduced
wiring system into a machine or equipment.
Mount a Waterproof Cap on each unused M12 connector for input/output.
Take sufficient shielding measures when operating the product in any of the following places.
( 1 ) A place where noise due to static electricity etc. is generated
( 2 ) A place of high electric field strength
( 3 ) A place where exposure to radioactivity is possible
( 4 ) A place near power cable
Do not operate the product in a place where there is a source of surge.
Use a surge absorbing element built-in type to directly drive the load that generates surge
voltage such as solenoid valve.
Prevent any foreign matter such as remnant of wires from getting inside the product when
opening the station number switch protective cover.
Install the reduced wiring system in a place free from vibration and impact.
Operate the product in the specified ambient temperature range.
Do not use in a place to be affected by the radiant heat from a surrounding heat source.
Set the DIP switch by using a sharp-pointed watchmakers screwdriver etc.
Perform the maintenance regularly.
Conduct an appropriate functional inspection after completing the maintenance.
Do not use chemicals such as benzin and thinner to clean the product.
System configuration general

6 7
SI Unit Model Indication Method
Tie-rod (2 pcs.)
Accessory
Note1 : For wiring method, refer to subsection "Wiring" (page 12) in this manual.
Note2 : For display and setting method, refer to subsection "Display/Setting" (page 15) in this manual.
Dimensions ( unit : mm )
BUSBUS
PWRPWR
SOLSOL NSNS PWRPWR
SETTINGSSETTINGS
11
00
MSMS
----------
64.459.8
63
78.9
No.
Part names Application
1Communication
connector Connect with EtherNet/IP line. Note1)
2Power supply connector Supplies power to the solenoid valve, the Output Block, SI
Unit and the Input Block.Note1)
3Input Block connector Connects the Input Block.
4Output Block connector Connects the solenoid valve, Output Block and etc.
5Display LED display shows the SI Unit status.Note2)
6Switch protective cover Display the power supply status and communication
status with PLC. Note2)
7Ground terminal Used for grounding.
8MAC address A unique MAC address of 12 hexadecimal number digits to
each SI Unit.
Tie-rod : 2 pcs.
Tie-rod : 2 pcs.
Tie-rod : 2 pcs.
EX250 series Input Block
End Plate (Input Block side)
SI Unit
EX9 series Output Block or
Power Block
Solenoid valve or
End Plate R (Output Block side)
M3 x 18 : 2 pcs.
(Hexagon socket head cap screw
(with spring washer))
Mounting/Installation
How to assemble / disassemble units.
NOTE
Hold the SI Unit and the Input / Output Block in order to have no clearance between them
while tightening the bolt.
Be sure to tighten bolt by specified tightening torque. (Tightening torque : 0.6N m)
SI Unit body
Part Names
EX250 SEN1
Communication protocol
EN1 EtherNet/IP

8 9
Mounting/Installation (continued )
Layout of the Input Block
Position the Input Block on the left side of the SI Unit.
Layout of the EX9 series Output Block / Power Block
Position the Output Block / Power Block on the right side of the SI Unit and between
the SI Unit and solenoid valve or End Plate R (on the Output Block side).
1) Output Block for high wattage load
The Output Block for high wattage load cannot be used independently.
Be sure to combine with the Power Block for use.
2) Position of Output Block for high wattage load
The Output Block for high wattage load cannot be mounted at the place nearer to
the SI Unit than the Power Block. However, that place is acceptable if the Power
Block is located between SI Unit and the Output Block for high wattage load.
3) Output Block for low wattage load
The Output Block for low wattage load cannot be mounted at the right side of the
Power Block. Mount to the place nearer to the SI Unit than the Power Block.
Position of End Plate
Be sure to connect the End Plate (on the Input Block side) at the left end of the
manifold.
When the valve is not connected, be sure to connect the End Plate R (on the
Output Block side) at the right end of the manifold.
Installation example Dimensions with solenoid valves unconnected [Unit: mm]
1 2 3 4 5 6 7 8 9 10
L114 135 156 177 198 219 240 261 282 303
Lm
[mm]
* Each dimension shows the unit without solenoid valves connected and with an End Plate
R (on the Output Block side) connected. Standard settings of L dimensions are with 10
or less m blocks. Ask SMC sales for the setting with over 10 blocks mounted.
Refer to the individual specifications for the dimensions when the solenoid valves are
connected.
Wiring (power supply, communication, input/output) and piping are all in one direction.
Space for wiring and piping is required in that direction.
SI Unit For high
wattage load
EX9-OEP1 SI Unit Power
Block
EX9-PE1
For high
wattage load
EX9-OEP1
SI Unit
For high
wattage load
EX9-OEP1
For high
wattage load
EX9-OEP1
For high
wattage load
EX9-OEP1
Power
Block
EX9-PE1
Power
Block
EX9-PE1
For high
wattage load
EX9-OEP1
Power
Block
EX9-PE1
SI Unit
POWER
PWR
PWRPWR
SI Unit SI Unit
For low
wattage load
EX9-OET1
For low
wattage load
EX9-OET1
Power
Block
EX9-PE1
For low wattage load
EX9-OET1
0
0
1
1
EX250
EX250
SOL
SOL
NS
NS
PWR
PWR
SETTINGS
SETTINGS
1
1
0
0
MS
MS
0
0
1
1
0
0
1
1
66
L = 21 x m + 93
* The number of Input Blocks + The number of Output Blocks + The number of Power Blocks : m
The number of
Input Blocks The number of Output Blocks
Mounting hole for 4-M4
Thickness : 13.2

10 11
Specifications
Sensor
input area
1 0
I/O mapping
Offset
(word) Input data
MSB LSB MSB LSB
15 8 70
0
1
Input area mapping
15 14
L : Fixed to Low
Item Status Condition
SP Solenoid power supply status 0No supply voltage
1Supply voltage OK
DI Status of sensor power supply 0Short circuit
1Normal
Diagnostics (Status input area)
2LLLL LLLLLLLLLL
Status input area
SP DI
8 7
13 12 11 10 926 5 4 3 17 16
31 30 24 23
29 28 27 26 25 1822 21 20 19
1 0
Offset
(word) Output data
MSB LSB MSB LSB
15 8 70
0
1
Output area mapping
15 14 8 7
13 12 11 10 9 26 5 4 3 17 16
31 30 24 23
29 28 27 26 25 1822 21 20 19
Basic specifications
Rated voltage 24VDC
Range of power
supply voltage Power supply for input and control : 24VDC 10%
Power supply for output : 24VDC+10%/-5%
Rated current Power supply for input and control : Max. 1.1A
Inside SI Unit : 0.1A
Input device :1A
Power supply for output : Max. 2A
Number of input/
output points Input point : Max. 32/Output point : Max. 32 *
Higher-level bus
()
Protocol Ethernet (IEEE802.3)
Media 100BASE-TX
Communication
speed 10M/100Mbps (Automatic selection or manual setting)
Max. segment length 100m (328ft)
Max. transceiver number 2 (per segment)
Communication
method Full duplex/Half duplex (automatic selection or manual
setting)
Fieldbus protocol EtherNet/IP™ Release1.0
I/O message Input : Data length 6 byte, Instance 100.
Output : Data length 4 byte, Instance 150.
Port No. 44818 (0xAF12)
IP address setting range 192.168.0.1to192.168.0.14 (Setting by an internal switch)
Or optional setting by the DHCP server
Device information Vendor ID : 7 (SMC Corp.)
Product type : 12 (communication adapter)
Product code : 107
Output type PNP output (-COM.)
* The maximum output point is 24 when the Power Block is connected.

12 13
Wiring
43
21
1
34
2
M12
1
2+Rx 3
- Tx 4
- Rx
1
2
3
4
5
6
7
8
Shield
RJ45
6.7
47.3 452000
Model No. : EX9-AC020EN-PSRJ
+Tx
Wiring diagram
Cable core wire external color
Terminal No.
Pin assignment of
plug connector Pin assignment of plug connector
White/Orange
Orange
White/Green
Green 8
7
6
5
4
3
2
1
Connect the Power Supply Cable to the power supply connector of SI Unit.
When selecting the power supply, refer to "Handling precautions" (page 3) in this manual.
M3 Earth terminal
2
43
5
1
Socket connector pin layout
Model No. : EX500-AP -S
M12
14.9
4834
18
6
30 5
50
Communication wiring
Connect the Ethernet Communication Cable to the communication connector of SI Unit.
Cable connection
Aligning the key groove with the communication connector
(4-pin, socket) of SI Unit, plug the Ethernet Communication
Cable (plug).
Tighten the lock nut on cable side by turning it
clockwise by hand.
Confirm that the connector portion does not move.
Pin layout and connection diagram of Ethernet Communication Cable
Core wire
Sheath color
Cable specifications
AWG 26
Blue green
Power supply wiring
Cable connection
Aligning the key groove with the
power supply connector (plug) of
SI Unit, plug the Power Supply Cable
(socket).
Tighten the lock nut on cable side by
turning it clockwise by hand.
Confirm that the connector portion
does not move.
Pin layout and connection diagram of power supply connector cable for (unit : mm)
Pin No.
5
4
3
2
1Cable color: Signal name Brown : 24VDC +10%/-5% (for solenoid valves/output)
White : 0V (for solenoid valves/output)
Blue : 24VDC 10% (for input and control)
Black :0V (for input and control)
Grey : Earth
NOTE
Ground the Earth terminal with the ground resistance at 100 ohm or less. Make the pin No.5 of
the power supply connector ungrounded, and ground at one point.

14 15
Wiring ( continued )
24VDC
24VDC
Brown : 24VDC (for solenoid valves/output)
White : 0V (for solenoid valves/output)
Grey : Earth
Blue : 24VDC (for input and control)
Black : 0V (for input and control)
Cable Part No. :EX500-AP -S
24VDC
Brown : 24VDC (for solenoid valves/output)
White : 0V (for solenoid valves/output)
Grey : Earth
Blue : 24VDC (for input and control)
Black :0V (for input and control)
Cable Part No. :EX500-AP -S
Power supply
connector
Power supply
connector
1
34
5
2
1
34
5
2
SOLSOL NSNS PWRPWR
SETTINGSETTINGSS
11
00
MSMS
SI
Display/Setting
Connecting one or two power supplies to SI Unit.
Both single power supply and two power supply systems can be adopted, however, the
wiring shall be made separately (for solenoid valves/output and for input and control) for
either system.
A. Two power supplies
B. Single power supply
Settings for display
Display Contents
SOL OFF The power supply for solenoids is insufficient
Green light ON The power supply for solenoids is normal
PWR OFF The power supply for input and control is insufficient
Green light ON The power supply for input and control is normal
MS
OFF The power supply for control is OFF
Green light ON Operating normally
Green flashing Setting error (Device has not been configured)
Red flashing Recoverable internal error
Red light ON Unrecoverable internal error
NS
OFF The power supply for control is OFF or IP address not set
Green flashing EtherNet/IP-level communication not established
Green light ON Multiple EtherNet/IP-level communications established
Red flashing Multiple EtherNet/IP-level communications time out
Red light ON IP address duplicated

16 17
12345678
ON
1
0
IP address
192.168.0.X
1
0
1
0
1
0
1
2
0
0
1
1
1
1
3
0
0
0
0
1
1
4
0
0
0
0
1
1
Remote control *1
X
3
2
1
14
DHCP mode *2
SW1
Communication
setting
CLEAR/HOLD
Manual set up of
IP address *3
SW1
5
0
1
1
1
1
1
6
-
-
0
1
-
-
7
-
-
-
-
0
1
SW1 Item
Communication
setting
Communication
speed
Communication
method
Contents
AUTO : The communication setting is automatically
selected.
MANUAL : The communication setting follows
the setting result by the switch No. 6 and 7.
Communicated at 10Mbps
Communicated at 100Mbps
Communicated at half duplex
Communicated at full duplex
SW1
8
0
1
Contents
The output signal is cleared when the communication error occurs.
The output signal is held when the communication error occurs.
Display/Setting ( continued )
*1 : Remote control (SW1 Dip Switches 1 to 4 off)
SMC's EX250 SI Unit will respond to the following Rockwell Automation BOOTP/DHCP
Server commands.
Enable DHCP
Selecting this function will enable the EX250 SI Unit to retrieve its boot information from
the BOOTP/DHCP Server. If DHCP is enabled the EX250 SI Unit will retrieve its boot
information during the next power up.
Disable BOOTP/DHCP
Selecting this function will disable the EX250 to retrieve its boot information from the
BOOTP/DHCP Server, and causes the EX250 to retain its current configuration during
the next power up.
*2 : DHCP Mode (SW1 Dip Switches 1 to 4 on)
The IP address is acquired via DHCP Server. The IP address is not saved and lost if the
power to the EX250 unit is cycled.
*3 : Hardware Addressing
The IP address range is 192.168.0.1-192.168.0.14.
Default settings
At the time of factory shipment, the product is in "Remote Control Mode" and set to
"Enable DHCP".
Switch setting
Open the switch protective cover and set the switches with a
sharp-pointed watchmakers screwdriver etc.
NOTE
1. Be sure to turn off the power before setting the switches.
2. Be sure to set these switches before use.
3. After setting the switch, close the switch protective cover and tighten the screws
with the proper tightening torque. (Tightening torque : 0.6N m)
NOTE
If the stored IP address of an EX250 is not known, please go to the "DHCP Mode" section.
