Unmanaged Switch SMC-EZ108FDT / SMC-EZ1024FDT
EZ SwitchTM 8 and 24-Port 10/100Mbps Standalone Unmanaged Layer 2 Switches
www.smc.com
The EZ Switch ™ 10/100 provides 8/24 10/100 switching
ports and a slot for an optional fiber uplink. A range of
100Mbps connectors is available, including SC, MTRJ, and
VF-45. It is most ideal for workgroups looking for distance
connection up to 20Km, suitable for environment such as
schools, university campus, and between buildings.
For SMC-EZ108FDT, it also includes a sliding switch in the
rear for VLAN configurations. When turned on, all ports will
automatically be segregated into an individual VLAN. The
uplink will be belong to every VLAN. This is the perfect
solution for workgroups that requires security but at the
same time, still have access to distance servers or back-
bone connection.
FEATURES
Distance connection up to 20Km away with optional
uplink connection
A range of fiber modules to choose from with
SC/ST/VF-45/MT-RJ connectors
High port count for expanding network—max. of 9/17/25 ports
Auto-MDIX ports—no crossover cables required
Rackmountable
No crossover cable required, simply plug and play
Simple VLAN application on the EZ108FDT for easy management
BENEFITS
OVERVIEW
TECHNICAL SPECIFICATIONS SMC-EZ108FDT / SMC-EZ1024FDT
PORTS
• SMC-EZ108FDT:
8 10BASE-T/100BASE-TX RJ-45 ports,
and 1 slot for expansion module with
VLANs
• SMC-EZ1024FDT:
24 Auto-MDIX 10BASE-T/100BASE-TX
RJ-45 ports, 1 slot for expansion module
NETWORK INTERFACE
• 10BASE-T: RJ-45 UTP CAT. 3,4,5
• 100BASE-TX: RJ-45 UTP Cat. 5
• 100BASE-FX: SC/ST connector
• Multimode fiber cable; 62.5/125
or 50/125 microns
• Singlemode fiber cable: 9/125 micron
LEDs
• Power – one
• Speed – one per port
• Link/Activity – one per port
AC INPUT
• 100 to 240V, 50 to 60 Hz
POWER SUPPLY
• Internal, auto-ranging transformer:
100 to 240VAC, 50 to 60 Hz
QUEUE BUFFER
• SMC-EZ108FDT: 1Mb
• SMC-EZ1024FDT: 768K
ADDRESS TABLE
• SMC-EZ108FDT: 2K MAC
address entries
• SMC-EZ1024FDT: 8K
MAC address entries
TEMPERATURE
• Operating: 0 °C to 65 °C
(32 °F to 122 °F)
• Relative humidity: 15 to 95%
@ 40 °C (104 °F), noncondensing
• Storage: : -40 °C to 70 °C
(-40 °F to 158 °F)
• Relative humidity: 90% @ 65 °C
(149 °F), noncondensing
WARRANTY
• Limited Lifetime
DIMENSIONS
• SMC-EZ108FDT
9.81 x 4.55 x 1.44 in / 24.9 x 11.6 x 3.7 cm
• SMC-EZ1024FDT
17.3 x 6.9 x 1.8 in / 44 x 17.5 x 5.6 cm
WEIGHT
• SMC-EZ108FDT 1.89 lbs / .86 kg
• SMC-EZ1024FDT 5.3 lbs / 2.4 kg
HUMIDITY
• Operating: 5% to 95%
POWER CONSUMPTION
• EZ108FDT -13W
• EZ1024FDT – 40W
HEAT DISSIPATION
• EZ108FDT - 137 BTU/hr
• EZ1024FDT - 137 BTU/hr
MAXIMUM CURRENT
• 0.5ARMS max. @110V,
0.20ARMS max. @240V
STANDARDS
• IEEE802.3u Fast Ethernet
COMPLIANCES
• CE Mark
EMISSIONS
EZ108FDT
• FCC Class B
• Industry Canada Class B
• EN55022 (CISPR 22) Class B
• IEC 1000- 4- 2/3/4/6
EZ1024FDT
• FCC Class A
• Industry Canada Class A
• EN55022 (CISPR 22) Class A
• IEC 1000- 4- 2/3/4/6
SAFETY
• CSA/NRTL (CSA22.2.2.950
&UL 1950) En60950 (TUV/GS)
SLIDE-IN MODULES
• 100Base-FX Extender Module
MODEL
• SMC-EZ108FMSC
• SMC-EZ108FMMT
• SMCEZ108FMST
PORTS
• 1- 100Base-FX
NETWORK INTERFACE
• SC/MTRJ/ST connector, 50/125 or
62.5/125 micron multimode fiber cable
LENGTH
• Up to 2Km (1.24 miles)
MODEL
• SMC-EZ108FSMT
• SMC-EZ108FSSC
NETWORK INTERFACE
• MTRJ/SC connector, 9/125 micron
single mode fiber cable
LENGTH
• Up to 20km / 12.43 miles
STANDARDS
• 802.3u Fast Ethernet
