Smeg SO4604S4PNR User manual

66 - PRECAUTIONS 91477A485/A
PRECAUTIONS 66
General safety instructions 66
For this appliance 69
Appliance purpose 70
This user manual 70
Manufacturer’s liability 70
Identification plate 70
Disposal 70
Information for European Control Bodies 71
Energy efficiency technical data 71
To save energy 71
Light sources 71
How to read the user manual 71
DESCRIPTION 72
General description 72
Control panel 73
Other parts 73
Accessories 74
Optional accessories (can be purchased separately)
75
Advantages of humidified and steam cooking 75
USE 76
Preliminary operations 76
Using the accessories 76
Display 77
First use 78
Using the oven 79
Using the temperature probe (on some models only)
83
Cooking advice 92
Smart Cooking 97
Multistep cooking 98
History 98
Mini guide to accessories 99
Discover the recipes 99
Information for Supervisory Bodies 99
My recipes 99
Other functions 101
In the event of a blackout 107
Settings 107
CLEANING AND MAINTENANCE 111
Cleaning the appliance 111
Cleaning the door 111
Cleaning the oven cavity 113
Vapor Clean (on some models only) 114
Descaling 115
Cleaning the reservoir and the water circuit manually
117
Reservoir calibration 119
Extraordinary maintenance 120
INSTALLATION 120
Electrical connection 120
Positioning 121
We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• ATTENTION: during use, the
appliance and its accessible
parts become very hot.
Children must be kept away
from the appliance.
• ATTENTION: during use, the
appliance and its accessible
parts become very hot. Never
touch the heating elements
during use.
• Protect your hands by wearing
oven gloves when moving food
inside the oven.
• Never try to put out a fire or
flames with water: turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
• This appliance may be used by
children aged at least 8 and by
people of reduced physical,
sensory or mental capacity, or

PRECAUTIONS - 6791477A485/A
e
lacking in experience in the use
of electrical appliances,
provided that they are
supervised or instructed by
adults who are responsible for
their safety.
• Children must not play with the
appliance.
• Keep children under the age of
8 at a safe distance unless they
are constantly supervised.
• Keep children under the age of
8 away from the appliance
when it is in use.
• Cleaning and maintenance
must not be carried out by
unsupervised children.
• The cooking process must
always be monitored. A short
cooking process must be
continuously surveyed.
• Never leave the appliance
unattended during cooking
operations where fats or oils
could be released, as these
could then heat up and catch
fire. Be very careful.
• Do not pour water directly onto
very hot trays.
• Keep the oven door closed
during cooking.
• If you need to move food or at
the end of cooking, open the
door 5 cm for a few seconds,
let the steam come out, then
open it fully.
• Do not insert pointed metal
objects (cutlery or utensils) into
the slots in the appliance.
• Switch off the appliance
immediately after use.
• DO NOT USE OR STORE
FLAMMABLE MATERIALS
NEAR THE APPLIANCE.
• DO NOT USE AEROSOLS IN
THE VICINITY OF THIS
APPLIANCE WHILST IT IS IN
USE.
• DO NOT MODIFY THIS
APPLIANCE.
• Installation and servicing should
be carried out by qualified
personnel in accordance with
current standards.
• Do not try to repair the
appliance yourself or without
the assistance of a qualified
technician.
• Do not pull the cable to unplug
the appliance.
Risk of damaging the appliance
• Do not use abrasive or
corrosive detergents (e.g.
scouring powders, stain
removers and metallic
sponges), rough or abrasive
materials or sharp metal
scrapers on glass parts as this
could cause scratch the surface
and break the glass. Use
wooden or plastic utensils.
• Do not sit on the appliance.
• Do not use cleaning products
containing chlorine, ammonia
or bleach on parts made of
steel or that have metallic
surface finishes (e.g. anodizing,

68 - PRECAUTIONS 91477A485/A
nickel- or chromium-plating).
• Racks and trays should be
inserted as far as they will go
into the side guides. The
mechanical safety locks that
prevent them from being
removed must face downwards
and towards the back of the
oven cavity.
• Do not use steam jets to clean
the appliance.
• Do not spray any spray product
near the appliance.
• Do not obstruct ventilation
openings and heat dispersal
slots.
• Fire hazard: never leave
objects in the oven cavity.
• DO NOT FOR ANY REASON
USE THE APPLIANCE AS A
SPACE HEATER.
• Do not use plastic cookware or
containers when cooking food.
• Do not place sealed tins or
containers in the oven cavity.
• Remove all trays and racks
which are not required during
cooking.
• Do not cover the bottom of the
oven cavity with aluminium or
tin foil sheets.
• Do not place pans or trays
directly on the bottom of the
oven cavity.
• If necessary, you can use the
tray rack (supplied or sold
separately, depending on the
model) by placing it on the
bottom as a support for
cooking.
• If you wish to use greaseproof
paper, place it so that it will not
interfere with the hot air
circulation inside the oven
cavity.
• Do not use the open door to
rest pans or trays on the internal
glass pane.
• Never use the oven door to
lever the appliance into place
when fitting.
• Avoid exerting too much
pressure on the door when
open.
• Do not use the handle to lift or
move this appliance.
Installation and maintenance
• THIS APPLIANCE MUST NOT
BE INSTALLED IN A BOAT OR
CARAVAN.
• The appliance must not be
installed on a pedestal.
• Position the appliance into the
cabinet cut-out with the help of
a second person.
• To prevent any possible
overheating, the appliance
should not be installed behind
a decoration door or a panel.
• Installation and servicing should
be carried out by qualified

PRECAUTIONS - 6991477A485/A
e
personnel in accordance with
current standards.
• Have the electrical connection
performed by authorised
technical personnel.
• The appliance must be
connected to ground in
compliance with electrical
system safety standards.
• Use cables withstanding a
temperature of at least 90 °C.
• The tightening torque of the
screws of the terminal supply
wires must be 1.5 - 2 Nm.
• If the power cable becomes
damaged, contact technical
support immediately to arrange
for it to be replaced in order to
avoid possible hazards.
• Always use any necessary/
required personal protective
equipment (PPE) before
performing any work on the
appliance (installation,
maintenance, positioning or
movement).
• Before performing any
operation on the appliance,
switch off the power supply.
• Disconnect the appliance after
the installation, through an
accessible plug or switch in
case of fixed connection.
• Fit the power line with an all-
pole circuit breaker with a
contact separation distance
sufficient to provide complete
disconnection in category III
overvoltage conditions,
pursuant to installation
regulations.
• This appliance can be used up
to a maximum altitude of 4,000
metres above sea level.
For this appliance
• Do not rest any weight or sit
on the open door of the
appliance.
• Take care that no objects are
stuck in the doors.
• Do not install/use the
appliance outdoors.
• (on some models only) Only
use the temperature probe
provided or recommended by
the manufacturer.
Temperature probe (if present)
• Do not touch the rod or the tip
of the temperature probe after
use.
• Wear oven gloves when
handling the temperature
probe.
• Take care not to scratch or
damage enamelled or chrome-
plated surfaces with the tip or
the plug of the temperature
probe.
• Do not insert the temperature
probe into openings and slots
on the appliance.
• When the temperature probe is
not in use, make sure that the
protective metal cap is properly
closed.
• Do not pull the cable to remove

70 - PRECAUTIONS 91477A485/A
the temperature probe from the
socket or from the food.
• Make sure that the temperature
probe or its cable do not get
caught in the door.
• Make sure that the temperature
probe or its cable do not come
into contact with heating
elements inside the oven.
• No part of the temperature
probe should be allowed to
come into contact with the walls
of the oven cavity, the heating
elements, the racks or the trays
when they are still hot.
• The probe should not be kept
inside the appliance.
• Do not use the temperature
probe during the pyrolytic
cycle.
Appliance purpose
This appliance is intended for
cooking food in the home
environment. Every other use is
considered inappropriate. It
cannot be used:
• in employee kitchens, shops,
offices and other working
environments.
• in farms/farmhouses.
• by guests in hotels, motels and
residential environments.
• In bed and breakfast
accommodation.
This user manual
• This user manual is an integral part of the
appliance and must therefore be kept in its
entirety and within the user's reach for the
whole working life of the appliance.
• Read this user manual carefully before using
the appliance.
• The explanations in this manual include
images, which describe all that regularly
appears on the display. However, it should
be kept in mind that the appliance may be
equipped with an updated version of the
system, and as such, all that appears on the
display may differ from those in the manual.
Manufacturer’s liability
The manufacturer declines all liability for
damage to persons or property caused by:
• use of the appliance other than that
specified;
• failure to comply with the instructions in the
user manual;
• tampering with any part of the appliance;
• use of non-original spare parts.
Identification plate
The identification plate bears the technical data,
serial number and brand name of the
appliance. Do not remove the identification
plate for any reason.
Disposal
This appliance conforms to the WEEE
European directive (2012/19/EU) and
must be disposed of separately from
other waste at the end of its service life.
The appliance does not contain substances in
quantities sufficient to be considered hazardous
to health and the environment, in accordance
with current European directives.
To dispose of the appliance:
• Cut the power cable and remove it.
• Deliver the appliance to the appropriate
recycling centre for electrical and electronic
equipment waste, or return it to the retailer
when purchasing an equivalent product, on
a one for one basis.
Our appliances are packaged in non-polluting
and recyclable materials.
• Deliver the packing materials to the
Power voltage
Danger of electrocution
• Disconnect the mains power supply.
• Unplug the appliance.

PRECAUTIONS - 7191477A485/A
e
appropriate recycling centre.
Information for European Control
Bodies
Fan forced mode
the ECO function used to define the energy
efficiency class complies with the specifications
of European standard EN 60350-1.
Conventional heating mode
To run the STATIC function, the preheating
phase must be skipped (see section "Preheating
phase" in the USE chapter).
Energy efficiency technical data
Information in accordance with the European
energy labelling and ecodesign regulations is
contained in a separate document
accompanying the product instructions.
These data are present in the "Product
information sheet" that can be downloaded
from the website at the page dedicated to the
product in question.
To save energy
• Only preheat the appliance if the recipe
requires you to do so. The preheating stage
can be disabled for all functions (see
chapter “Preheating”) apart from the PIZZA
(preheating cannot be disabled) and ECO
functions (no preheating stage).
• When using the functions (including the
ECO function), avoid opening the door
during cooking.
• Unless otherwise indicated on the package,
defrost frozen foods before placing them in
the oven.
• When cooking several types of food it is
recommended to cook the foods one after
the other to make the best use of the already
hot oven.
• Use dark metal moulds: They help to absorb
the heat better.
• Remove all trays and racks which are not
required during cooking.
• Stop cooking a few minutes before the time
normally used. Cooking will continue for the
remaining minutes with the heat which has
accumulated inside the oven.
• Reduce any opening of the door to a
minimum to avoid heat dispersal.
• Keep the inside of the oven clean at all
times.
Light sources
• This appliance contains light sources which
cannot be replaced by the user and must
only be replaced by the technical assistance
service.
• This appliance contains light sources of
efficiency class "E".
How to read the user manual
This user manual uses the following reading
conventions:
Plastic packaging
Danger of suffocation
• Do not leave the packaging or any part of it
unattended.
• Do not let children play with the plastic
bags.
Warning/Caution
Information/Advice

72 - DESCRIPTION 91477A485/A
DESCRIPTION
General description
1 Control panel
2 Seal
3 Temperature probe socket (on some models
only)
4 Light bulb
5 Door
6 Fan
7 Loading nozzle
Frame shelf

DESCRIPTION - 7391477A485/A
e
Control panel
1 Function Knob
In Quick Mode, this knob allows you to select
the cooking function.
2 Display
The touchscreen display allows you to interact
with the appliance. Touch the icons to access
the various functions. All the operating
parameters will be shown on the display.
3 Temperature Knob
In Quick Mode, this knob allows you to select
the cooking temperature.
4 ON/OFF key
The ON/OFF button turns the appliance on or
off.
5 Remote control indicator light (on some
models only)
When lit it indicates that the appliance can be
controlled remotely via a smartphone or tablet
(see the “Built-in oven connectivity” user
manual).
SmegConnect (on some models only)
The appliance is equipped with SmegConnect
technology that allows the user to control the
appliance operation via an App on their
smartphone or tablet.
For further information, refer to the supplied
brochure and/or visit the site
www.smeg.com
Other parts
Shelves
The appliance features shelves to position trays
and racks at different heights. The insertion
heights are indicated from the bottom upwards.

74 - DESCRIPTION 91477A485/A
Cooling fan
The fan cools the appliance and comes into
operation during cooking.
The fan causes a steady outflow of air from
above the door which may continue for a short
period of time even after the appliance has
been turned off.
Oven cavity lighting
The appliance’s interior lighting comes on:
• when the door is opened;
• during one function, touch the light symbol
to manually activate or deactivate the
oven cavity light, apart from the and
functions.
Accessories
• Not all accessories are available on some
models.
• The accessories intended to come into
contact with food are made of materials that
comply with the provisions of current
legislation.
• Original supplied and optional accessories
can be requested to Authorised Assistance
Centres. Use only original accessories
supplied by the manufacturer.
• It is recommended to mount the pull-out
slides on the first shelf of the frames. In this
way, it is possible to optimise the space
inside the oven cavity with an intermediate
level between the first and the second shelf.
Perforated tray
Useful for steaming fish and vegetables.
Steel baking tray
Useful when cooking cakes (with cooking times
of less than 25 minutes or without steam), rice,
beans and cereals. It is also essential for
collecting liquids produced by steaming or
defrosting foods contained in the perforated
tray above.
Rack
Used for supporting containers with food during
cooking.
Tray rack
To be placed over the top of the tray; for
cooking foods which may drip.
In order to save energy, the light turns
off after about one minute from the start
of cooking or whenever the door is
opened (this function can be disabled
via the secondary menu).
In this manual, suggestions for the
second or middle shelf refer to the use
of pull-out slides.

DESCRIPTION - 7591477A485/A
e
Deep tray
Useful for collecting fat from foods placed on
the rack above and for cooking pies, pizzas,
baked desserts, biscuits, etc.
Protective cover (on some models only)
Used to cover and protect the temperature
probe socket when the temperature probe is not
in use.
Temperature probe (on some models only)
With the temperature probe, you can cook
according to the temperature measured at the
centre the food.
Optional accessories (can be
purchased separately)
Jug
Useful for containing liquids during filling and
emptying of the reservoir.
PPR2 or STONE(refractory stone)
Ideal accessory for baking bread (pizza,
bread, focaccia...), but you can also use it for
more delicate preparations such as biscuits.
BBQ (teflon-coated barbecue grill pan)
Double-use accessory: the striped side is
recommended for grilling meat (fillets,
hamburgers...), while the smooth surface can be
used for cooking vegetables, fruit, fish...
AIRFRY (oil-free frying grill)
Recommended accessory for air-frying
previously breaded, precooked and/or frozen
food (chips, potato or meat croquettes, small
mozzarella bites...).
Advantages of humidified and steam
cooking
The steam cooking system cooks any type of
food much smoother and faster and finds its
main applications for:
• Braising and stewing
•Cookingsauces
• Cooking au gratin
•Roasting
• Low temperature cooking
• Regenerating
• Multi-mode cooking
Variations in temperature and steam levels allow
the wished gastronomic result to be achieved.

76 - USE 91477A485/A
The addition of steam allows the use of less fat in
favour of a healthier and more genuine cuisine.
It also minimizes the loss of weight and volume
in food while cooking.
Steam cooking is particularly suitable for
cooking meat: in addition to making it very soft,
it maintains it bright and makes it more succulent.
Also recommended for baking leavened and
bread dough. The humidity in fact lets the dough
grow and develop while cooking before
creating the outer crust. The result is a lighter and
more digestible dough, recognizable by thicker
pockets.
(Valid for steam cooking only)
It is also ideal for defrosting food rapidly, for
heating up foods without hardening or drying
them out, and for naturally removing salt from
foodstuffs preserved with salt.
It is not recommended for short cooking times or
for foods that may produce a large amount of
moisture during cooking.
Cooking containers
• You may also use your own containers for
cooking, as long as they are resistant to high
temperatures.
• For steam cooking, the use of metal
containers is recommended. Metal
facilitates better distribution of heat to the
foods.
• It is normal for metal containers to deform
somewhat during high-temperature cooking,
but they will return to their original shape
when they cool down.
• Thick ceramic plates may require more heat
than normal. Longer cooking times may be
necessary.
USE
Preliminary operations
• Remove any protective film from the outside
or inside of the appliance, including
accessories.
• Remove any labels (apart from the technical
data plate) from the accessories and
shelves.
• Remove and wash all the appliance
accessories (see chapter "CLEANING
AND MAINTENANCE").
First heating
1. Set a cooking time of at least one hour (see
paragraph "Using the oven").
2. Heat the empty oven compartment at the
maximum temperature to burn off any
residues left by the manufacturing process.
When heating the appliance
•airtheroom;
•don'tstay.
Using the accessories
Racks and trays
Racks and trays have to be inserted into the side
guides until they come to a complete stop.
• The mechanical safety locks that prevent the
rack from being removed accidentally must
face downwards and towards the back of
the oven cavity.
Tray rack
The tray rack has to be inserted into the tray. In
this way fat can be collected separately from
the food which is being cooked.
See General safety instructions.
Gently insert racks and trays into the
oven until they come to a stop.
Clean the trays before using them for
the first time to remove any residues left
by the manufacturing process.

USE - 7791477A485/A
e
Configuration for steam cooking
If you intend to use the perforated baking tray
for steam cooking, it must be placed on the
desired shelf taking care to place the steel
baking tray on the shelf below. This allows
liquids to be collected separately from the food
which is being cooked.
Display
The parameters and values for the currently
selected function will be indicated on the
display. To use it, simply touch the "virtual" keys
and/or scroll through the values indicated (the
image shows the main menu screen).
Information area
Information regarding the menus and submenus
of the functions in progress in the main area are
indicated in this area.
The following are also present in this area:
• HOME button: touch this button to
return to the main menu;
• The QUICK MODE button (models
with knobs only): touch this button to enter
Quick Mode.
• INFORMATION button: touch this
button to display the following screen:
• current time display.
Main area
The various functions of the appliance can be
set in this area. Touch the buttons and values to
set the required function.
In addition, depending on the screen, dots may
appear at the bottom of this area to indicate that
there are other function pages, which can be
reached by scrolling horizontally.
first page,
second page,
The INFORMATION button is
replaced by the symbol to warn
that the door is open.

78 - USE 91477A485/A
etc...
Lower area
There are various shortcut function buttons in this
area, which vary according to the functions set
in the main area:
MULTISTEP
HISTORY
TIMER
LIGHT BULB
MY RECIPES
SETTINGS
According to the page that is displayed, the
following buttons may also be present:
BACK
CONFIRM
START
REPLAY
STOP
SAVE
DELETE
RAPID PRE-HEATING
PROBE (on some models only)
Connectivity (on some models only)
Connectivity requirements:
• Smartphone or PC tablet with IOS or
Android operating system. The minimum
versions of the operating systems are
available at the following link:
www.smeg.com/smegconnect/
• Wi-Fi network (2.4 GHz band, WPA2
protected) active and available in the
place where the appliance is installed.
• Internet connection.
• Name and password of the home Wi-Fi
network or WPS (Wi-Fi Protected Setup)
mode available.
For further information, please refer to the
"Built-in oven connectivity" manual.
First use
To switch on the appliance:
1. Connect the appliance to the mains power
supply.
The manufacturer’s logo will display for a few
seconds.
The display then shows the current time setting
screen.
To be able to start any cooking function, the
current time must be set.
2. Scroll up and down through the hours and
minutes to set the current time.
3. Touch the CONFIRM button (at the
right in the lower area ) to set the
current time.
Press and hold the HOME button
or the ON-OFF button for a few
seconds to stop cooking immediately at
any time and return to the main menu.
The following instructions are also valid
in the case of a prolonged power
failure.
After the appliance is switched on, you
will need to wait a few seconds before
you can use it.
To change the current time (e.g. due to
daylight saving time) touch the time
shown on the display (in the information
area on the right).

USE - 7991477A485/A
e
The first time you use the appliance, it may be
set to a language other than the one you speak.
It is recommended that you set the required
language at this point.
4. Touch the SETTINGS button on the
display (at the right in the lower area ).
5. Touch the display button .
6. In the Language option (on the left),
scroll through the available languages (on
the right) to select the required language.
7. Touch the CONFIRM button.
Deactivating the display
To deactivate the display manually:
• Press and hold the ON-OFF
button for a few seconds until you hear a
sound.
Reactivating the display
To reactivate the display when it is off:
• Press and hold the ON-OFF
button for a few seconds until you hear a
series of sounds.
The display turns on after a few seconds.
The display shows the main menu when it is
switched on again.
Using the oven
Traditional cooking
1. Touch the time indicated on the display.
2. Touch the COOKING button on the
"main menu" (in the main area ).
3. Touch the TRADITIONAL COOKING
MENU button.
4. Select a combination function (for example
FAN-HEATED ) to enter the relevant
cooking screen.
5. Touch the START button (at the lower
right ) to start pre-heating.
When the current time is visible, after 2
minutes from the last operation by the
user it is displayed with low brightness.
When the " Show the time" mode is
set to Off, if the time display is shown,
the display will switch off automatically
after 2 minutes.
In some cases, the ON-OFF
button does not deactivate the display.
For example, when:
• there is a cooking function in
progress (the button stops the
function);
• the door is open;
• a minute minder timer is active;
• the Showroom and/or
Demo modes are active.
See General safety instructions.
Each time the door is opened, the
function in progress will stop and then
automatically restart when the door is
closed again.

80 - USE 91477A485/A
Preheating stage
Cooking itself is preceded by a preheating
stage, which allows the appliance to heat to the
cooking temperature more quickly.
This stage is indicated by a progressive increase
in the temperature level reached.
After pre-heating, a buzzer will sound and a
message will display to indicate that the food
can be put in the oven.
Cooking phase
1. Open the door
2. Place the dish with the food to be cooked
into the oven cavity.
3. Close the door.
4. Touch the START button to start
cooking.
This stage is indicated by a progressive increase
in the cooking level.
Modifying the cooking temperature
1. Touch the TEMPERATURE button or the
relevant value.
2. Scroll through the values and select the
required cooking temperature.
3. Touch the CONFIRM button (at the
lower right ) to confirm the cooking
temperature that has been selected.
End of cooking
To end cooking at any time:
1. touch the STOP button .
2. Touch the CONFIRM button.
Timed cooking
1. After selecting a function, touch the
COOKING DURATION button or the
relative value.
2. Scroll through the values and select the
required duration.
3. Touch the CONFIRM button to confirm
the selected cooking duration.
Unless otherwise indicated in the
recipe, it is not recommended to place
food in the oven during the preheating
stage.
You can skip the pre-heating phase by
pressing the button related.
The temperature can be modified at
any time during cooking.
Timed cooking is the function which
allows a cooking operation to be
started and then ended after a specific
length of time set by the user.
The hours and minutes can be selected
separately.

USE - 8191477A485/A
e
The expected end of cooking time appears
under the duration.
4. Touch the START button to start timed
cooking.
End of cooking
At the end of cooking, "Function ended"
displays and a buzzer sounds briefly, which can
be deactivated by touching any point of the
display or by opening the door.
• Touch the HOME button to quit the
function.
Programmed cooking
1. After setting timed cooking, touch
PROGRAMMED COOKING button
or the relevant value.
2. Scroll through the values and select the
required end-of-cooking time.
3. Touch the CONFIRM button to confirm
the selected end of cooking time.
End of cooking
At the end of cooking, "Function ended"
displays and a buzzer sounds briefly, which can
be deactivated by touching any point of the
display or by opening the door.
• Touch the HOME button to quit the
function.
List of traditional cooking functions
STATIC
FAN-ASSISTED
THERMALLY-VENTILATED
The duration of the timed cooking
function can be from a minimum of 1
minute to a maximum of 12 hours and
59 minutes.
The minutes required for pre-heating
are already included in the end-of-
cooking time.
The countdown starts after the pre-
heating has ended or if you wish to
avoid pre-heating (touch the relative
button ).
Programmed cooking is the function
which allows a time-controlled cooking
operation to be stopped at an
established time depending on the time
set by the user, after which the
appliance will switch off automatically.
For safety reasons, it is not possible to
set the end of cooking time by itself
without setting the cooking duration.
The hours and minutes can be selected
separately.
Not all functions are available on some
models.
Traditional cooking suitable for the
preparation of one dish at a time. Ideal
for cooking roasts, fatty meats, bread,
pies.
Intense and uniform cooking. Ideal for
biscuits, cakes and multilevel cooking.
The heat is distributed quickly and
evenly. Suitable for all dishes, ideal for
cooking on several levels without mixing
odours and flavours.

82 - USE 91477A485/A
TURBO
GRILL
FAN-ASSISTED GRILL
BASE
THERMALLY-VENTILATED BASE
PIZZA
ECO
Minute minder timer
1. Touch the TIMER button (in the lower
area ) to access the Timer menu.
Up to 2 minute minder Timers can be set:
2. Touch the button of the TIMER -
that you intend to use.
3. Scroll through the values and select the
required duration.
4. Touch the CONFIRM button to confirm
the selected duration.
5. Repeat the procedure for the other Timers
that you intend to use.
6. When finished, touch the CONFIRM
button again to confirm the selected timers.
Allows quick cooking on multiple
shelves without mixing the aromas.
Perfect for large volumes that call for
intense cooking.
It allows to obtain excellent grilling and
grating results. Used at the end of
cooking, it gives a uniform browning to
the dishes.
Allows optimal grilling of even the
thickest meats. Perfect for large cuts of
meat.
The heat only comes from the bottom of
the cavity. Perfect for cakes, pies, tarts
and pizzas.
Allows you to quickly finish cooking
food already cooked on the surface but
not internally. Perfect for any quiches
and any type of food.
Function designed for cooking pizza.
Perfect not just for pizzas, but also for
biscuits and cakes.
This function is particularly suitable for
cooking on a single shelf with low
energy consumption.
It is recommended for all types of food,
excluding those that can create a lot of
humidity (such as vegetables).
To obtain maximum energy savings and
reduce cooking times, it is
recommended to place food in the
oven without preheating.
When using the ECO function, avoid
opening the door during cooking.
In the ECO function cooking times (and
any preheating) are longer and may
depend on the amount of food in the
cooking compartment.
The ECO function is a delicate cooking
function and is recommended for food
withstanding temperatures lower than
210°C; in case of cooking at higher
temperatures, select another function.
This function only activates the buzzer,
without stopping the function in
progress.
The Timer can be set from a minimum of
1 minute to a maximum of 12 hours and
59 minutes.
The DELETE button appears in the
lower area that can be used to
delete a timer if one has been selected.
To cancel the operation, touch the
RETURN button.
The counter must be set to zero in order
to remove the minute minder timer.

USE - 8391477A485/A
e
In the following display, the lit TIMER
button indicates that one or more minute minder
timers have been activated.
7. Wait for the buzzer to indicate that the time
has finished.
Using the temperature probe (on
some models only)
The temperature probe enables you to cook
roasts, loin steaks and other cuts and sizes of
meat with great precision. The probe ensures
that the food is perfectly cooked by monitoring
the core temperature of the food. The core
temperature is measured by a sensor inside the
tip of the probe.
Positioning the probe
1. Place the food on a tray.
2. Insert the tip of the probe into the food
before you place it in the oven.
3. For best results, make sure that the
temperature probe is placed transversely in
the thickest part of the food and for least 3/
4 of its length. Make sure that it does not
touch the tray underneath and that it does
not protrude from the food.
4. The 3 notches on the temperature probe
must be inserted into the food.
Setting cooking parameters when using the
temperature probe
1. Select a cooking function.
2. Touch the TEMPERATURE button or the
relevant value.
3. Scroll through the values and select the
required cooking temperature.
4. Touch the CONFIRM button.
5. Touch the PROBE button in the lower
area .
The display cannot be switched off
using the ON-OFF button when a
timer is active.
See General safety instructions.
In order for the probe to measure the
core temperature of the food precisely,
its tip must not be in contact with bones
or fat.
The recommended minimum
temperature for cooking with the probe
is 120°C, with the exception of slow
temperature cooking.
If the probe does not read the
temperature of the food correctly, 2
error messages will appear on the
display (to acknowledge), after which,
the appliance will automatically carry
out timed cooking.

84 - USE 91477A485/A
6. Scroll through the target temperature values
and select the required temperature.
7. Touch the CONFIRM button to confirm
the selected probe temperature.
A message appears on the display to remind
you to connect the probe to the socket and to
place it in the food.
8. Touch the CONFIRM button.
Cooking
This option automatically sets the ideal
temperature inside the oven cavity according to
the target temperature set by the user.
1. After setting the desired target temperature,
press the button (at the lower right
).
2. Select the temperature difference value.
slow
Sets the smallest difference between the probe
temperature and the temperature of the oven
cavity. This results in a longer cooking time.
Medium
Sets a medium difference between the probe
temperature and oven cavity temperature. This
results in a medium cooking time.
fast
Sets the largest difference between the probe
temperature and the temperature of the oven
cavity. This results in a shorter cooking time.
The temperature range that can be
selected is from a minimum of 20°C to
a maximum of 90°C.
If the temperature of the oven is set too
low, the appliance automatically sets
the minimum temperature necessary in
order to reach the selected target
temperature.
For best results, it is recommended to set
a cooking temperature higher than the
target temperature.
The appliance automatically sets the
cavity temperature to a predefined
temperature (called ) which is
higher than the core temperature
detected by the probe.
When the probe detects one degree
more at the core, the appliance
automatically increases its internal
temperature by one degree.
The appliance offers the possibility to
choose between three different cooking
modes (slow, medium and fast) and to
set any desired core temperature.
A concentrate of technology that
produces tender, juicy, healthy products
of the highest quality.

USE - 8591477A485/A
e
3. Touch the CONFIRM button to confirm
the selected probe temperature.
With preheating:
1. Touch the START button to start pre-
heating.
After pre-heating, a buzzer will sound and a
message will display to indicate that the food
can be put in the oven.
2. Insert the tip of the temperature probe into
the food to be cooked.
3. Open the appliance door.
4. Insert the tray on which the food has been
placed into the appropriate guides.
5. Insert the plug of the temperature probe into
the socket at the side, using the probe to
open the protective cover.
6. Close the door.
7. Touch the START button to start
cooking using the temperature probe.
Without preheating:
1. Touch the PRE-HEATING button to
disable pre-heating.
2. Open the appliance door.
3. Insert the tray on which the food has been
placed into the appropriate guides.
4. Insert the plug of the temperature probe into
the socket at the side, using the probe to
open the protective cover.
5. Close the door.
6. Touch the START button to start
cooking using the temperature probe.
End of cooking parameters with the
temperature probe
Cooking ends when the instantaneous
temperature reaches the target temperature set
by the user.
The heating elements are switched off and the
appliance emits a series of beeps.
1. Open the door.
2. Remove the probe from the food and unplug
it from the socket.
3. Remove the food from the oven.
4. Make sure that the protective cover is
properly closed.
5. Close the door.
Quick Mode (models with knobs only)
1. Turn the Function knob and the
Temperature knob back to position 0.
2. Touch the QUICK MODE button in
the "main menu" (in the information area
at the top left).
It is now possible to use the knobs to operate
the appliance.
Press the button to eliminating the
cooking .
For best results, make sure that the metal
part of the temperature probe is inserted
almost completely into the food at a
right angle, but make sure that it does
not touch the tray underneath.
This mode allows you to set a traditional
cooking function and its temperature
quickly using the knobs.
It is also possible to quickly set the
probe cooking function.
The pre-heating function cannot be
disabled when Quick Mode is being
used.
Cooking can be interrupted at any time
by turning the function knob and the
temperature knob to 0.
