SmokerStore Taifun GT one User manual

1
Taifun
G
T one
®
Instructions
Please read the following instructions carefully before using the product and keep them for future needs.
1. Usage and storage instructions
Do not expose the product to humid environments or extreme temperatures, it could be damaged. If water enters
by accident, stop the operation to prevent a short circuit. Do not use our product more often or for a longer
period than traditional cigarettes. Keep the product out of the reach of children, adolescents and pets.
2. Contraindications
When using li uids with and without nicotine: Please note the warnings and instructions for use of the li uid
products and do not mix them with other substances. Do not use the product if you have a known problem with
nicotine or other li uid ingredients. In case of nausea, dizziness or rash, discontinue use and consult a medic
immediately. The electronic cigarette is not for smoking cessation.
3. Warnings
Delivery to and use by children and adolescents under the age of 18 is prohibited. The product is not
recommended for non-smokers.
This product is not suitable for pregnant women, women who are breastfeeding, people with cardiovascular and
respiratory diseases, alcoholics and epileptics. Do not use the product if you have lung disease (such as
asthma, COPD, bronchitis, pneumonia). The released vapor may cause an asthma attack, shortness of breath
and coughing fits in the case of a previously damaged lung. If complaints occur, please seek medical attention
immediately. Do not use our product if you have a known problem (allergies, intolerances, etc.) with nicotine or
other ingredients of our product.
When using nicotine-containing li uids: nicotine-containing products are not suitable for people who, for medical
reasons, should abstain from nicotine products. If the li uid is swallowed, contact the emergency number. You
can also contact the poison emergency service in your area.
4. Information on possible adverse ealt effects
- none known, see the instructions of the li uid.
5. Information on addictive effects
If you use products containing nicotine, the following warning is displayed on the packaging of the li uids: "This
product contains nicotine: a substance that is highly addictive.
6. Information on toxicological data
Overheating the li uid (over 240 ° C) in the electronic cigarette may cause toxicological substances. Please use
the electronic cigarette according to the manufacturer's recommendation and operating instructions. The use of
this product is at your own risk.
7. Contact
If you need additional information or if you have uestions about the products and their use, please contact our
local shops or visit our website: www.smokerstore.de
Manufacturer:
SmokerStore GmbH,
Eisenwerkstraße 26,
58332 Schwelm, Deutschland
Email: [e-mail]
Tel.: [phone]
Fax: [phone]
PDF Instructions on website

2
Taifun
G
T one
®
1. PRODUCT DESCRIPTION
SCOPE OF DELIVERY
1x Taifun® GT one
1x Drip Tip
1x Spare Parts Bag
1x Allen Key 1,5 mm
1x Allen Key 0, mm
1x Manual
SPECIFICATIONS
Dimensions: 50,0 mm x 23,0 mm
56,5 mm x 23,0 mm
Weight: ~ 6 ,0 g
Thread: 510 Capacity: 2 ml/4 ml
Material: Stainless Steel (1.4301) / PEEK / PSU / NBR O-Rings
2. SAFETY INSTRUCTIONS
• Do not expose the device to extreme temperatures; Avoid exposure to direct sunlight and high humidity.
• Do not use the device in an environment that is enriched with flammable gases, vapors or dusts; There is a
danger of explosion!
• Do not drop, throw, or apply excessive force to the device to prevent damage; Do not use the device if you
detect damage.
• Refill the li uid early to prevent dry hit.
• The device heats up during use; give it time to cool down again.
• Change the cotton, if you change the flavour.
• Clean the device regularly, as condensate and dirt may settle.
• Make sure that the mod that you use with the device is capable of performance; use of mods without
protection is not recommended.
3. MANUFACTURER RECOMMENDATIONS
• Adjust the power of your mod to an appropriate level, depending on the used coil.
4. STORAGE INSTRUCTIONS
• If you don’t use the device for an extended period of time, close the airflow control or empty the tank, remove
the cotton and clean the device.
• Keep the device out of the reach of children and pets.
• Ensure that the device is firmly and securely in place.
• Store the device clean and dry; avoid high humidity.
• Do not store the device under extreme temperatures; avoid exposure to direct sunlight.
5. DISPOSAL NOTICE
• The packaging must be disposed of in an environmentally friendly manner.
• Products marked with the crossed out bin, do not belong in the trash. These products can be disposed of free
of charge in your local trade or at community collection points. Check with your local council, town hall or local
waste management company.
AUTHENTICITY VALIDATION
You can check the authenticity of your Taifun product at www.taifun-c eck.com.
You can find the verification code and the serial number on your device: 12345678911-1234 (verification code - serial number)

3
Taifun
G
T one
®
6. PRODUCT OVERVIEW
COMPONENT OVERVIEW
1x Base 1x Isolator PEEK 1x Positive Pole Screw M3x8 mm 1x Screw M2x4 mm
1x Isolator Black 1x Grub Screw M2x3 mm (for
closing the external air supply
)
1x O-Ring NBR 50 17x1,5 mm 1x O-Ring NBR 70 11x1 mm
1x Tank Section TopCap/Bell 1x Tank Section Tankshield 1x Tank Section PSU Tank 1x O-Ring NBR 50 17x1,5 mm
1x O-Ring NBR 50 15x1 mm 1x Positive Pole 1x Screw M2x4 mm 1 x O-Ring NBR 70 8x1 mm
1x Air Pin 1x O-Ring NBR 70 2x1 mm 1x Drip Tip 2x O-Ring NBR 50 5x1,5 mm
IMPORTANT
The device is delivered fully assembled. All O-Rings and isolators are already installed correctly. This list is only for illustration and
possible assembly after cleaning the individual parts.
A
B
C
D
E
F
G
H
J
L
I
M
N
O
P
K
Q
R
S
T
!

4
Taifun
G
T one
®
7. START UP
ATTACHING THE COIL
IMPORTANT
Only use coils made of suitable wires. The authorized retailer offers a wide range of different coils and can assist you in selecting the
right one.
First, the screws D and O are slightly unscrewed. The ends of the coil are positioned under the screws.
Then bend the wire ends and retighten the screws D
and O again. This fixes the coil in place.
With a winding aid, the coil can still be
aligned somewhat.
Cut off the exceeding ends of the wire. The coil should now be centered over the air hole.
WARNING
Use an ohm meter to check the resistance of the coil/device before using it. Don’t use the device, if a short circuit is de-tected. This
could lead to battery damage. Check if there is a contact between the coil ends and the surrounding parts.
!
!

5
Taifun
G
T one
®
INSERT COTTON
Cut a suitable cotton strip to size.
Carefully guide it through the coil.
The ends of the cotton are trimmed and positioned
in front of the side openings for li uid flow.
FILLING THE TANK
To fill the device, it must first be turned upside down.
Now carefully unscrew the tank section from the base,
so that no remaining li uid is spilled.
Hold the tank at a slight angle at the beginning. Carefully fill the
li uid into the tank along the edge. During filling, slightly raise the
tank again so that you can see the filling level. Stop filling as soon as
the li uid level reaches the top edge of the bell.
Now screw the base back on.
WARNING
• Make sure to fill the li uid at the edge of the tank next to the bell. No li uid should get into the air opening of the bell.
• Always make sure that the tank is sufficiently filled to avoid dry vaporization.
• Make sure that no li uid gets on your skin, otherwise wash these areas thoroughly.
!

6
Taifun
G
T one
®
REGULATION OF AIR SUPPLY
The true control of the air supply takes place inside the device. In the base there is an Air Pin with an inner diameter of 1.2 mm. Optionally, other Air Pin variants
with diameters of 0.8 mm, 1.0 mm, 1.5 mm and 1.8 mm are available. When inserting the Air Pin, make sure to insert it with the bottom side facing down.
From left to right:
0.8 mm / 1.0 mm / 1.2 mm (standard) / 1.5 mm / 1.8 mm
Air Pin used correctly Air Pin used incorrectly
For the external air supply, there are two air holes in the base, one of them can optionally be closed with a grub screw. This grub screw can be inserted with the 0.9
mm Allen key if necessary. Depending on your own draw techni ue and the amount of nicotine in the li uid, the insertion of the grub screw can increase the
noticeable throat hit. However, it should be noted that the air supply is primarily limited by the inserted air pin inside the vaporizer. The left hole has an air inlet with
a diameter of 2.2 mm. The right hole has an air inlet with a diameter of 1.6 mm.
IMPORTANT
The outer set screw is not used to regulate the air volume in the sense of an airflow control. For a smooth vapor experience you leave
both channels open and regulate the draw resistance via the inner Air Pin.
INSERT / REMOVE AIR PIN
We recommend using tweezers to insert or remove/replace the air pin. Make sure that the Air Pin is always inserted with the bottom side facing down.
!
Top side
Bottom side

7
Taifun
G
T one
®
8. CLEANING
Do not use cleaning agents as they could harm the O-Rings.
Before assembling, check the completeness and positioning of the O-Rings to prevent leakage of li uid.
• Disassemble the device into its components.
• Clean the components (not the cotton) with warm water or in an ultrasonic bath.
• Completely dry the components before reassembling the device.
9. MAINTANANCE
• Wait until the device has completely cooled down before disassembling, to prevent burns.
• Make sure that there is no power supply by unscrewing the device from the mod or by switching off the mod.
ASSEMBLING DEVICE
• The device is usually delivered fully assembled, the following instructions are for the assembly after cleaning.
• Moistening the sealing rings with li uid makes the assembly easier.
• Please use only suitable tools for assembly.
The positive pole [N] is plugged into the positive pole isolator [B]
The isolator [E] is inserted into the base [A] from below.
Now the positive pole [N] with the isolator [B]
is pushed into the base [A].
Then push the positive pole screw [C] from below through
the base [A] and fix the positive pole [N].
The grub screw [F] is screwed into the base [A] from the side.
(optional)
A suitable air pin [Q] is inserted into the positive pole [N].
(optional)
P
G
R
H

8
Taifun
G
T one
®
The screws [D,O] for fixing the coil are screwed into the base [A]. The tank shield [J] is slid over the PSU tank [K].
The bell [I] is screwed to the PSU tank [K]. The Drip Tip [S] is placed on the Top Cap [I].
Base [A] and tank [K] are screwed together. Done!
REPLACING THE PSU TANK
If the PSU Tank is damaged or broken, it must be replaced.
• Only use original spare parts, which can be obtained directly from www.smokerstore.de or from authorized
dealers.
• Before replacing the PSU Tank, the atomizer must be completely emptied.
REPLACING SEALING RINGS
Sealing rings are used to seal the device.
• If you notice li uid or moisture leaking out of the device, the cause may be brittle seal rings that need to be
replaced.
• Moistening the sealing rings with li uid makes the assembly easier.
A comprehensive guide can be downloaded online at www.smokerstore.de as a PDF. See also QR code on page 1
of this manual.
If you have further uestions about attaching a coil and the individual settings of the device, please contact your
SmokerStore dealer or the SmokerStore service.
L
T
M
