SMS TAKEDO-3VF User manual

TAKEDO®-3VF
V20
INSTRUCTION MANUAL
1 15-04-2013
REL. DATE T.M. Check and Approval
www.sms.bo.it

PAGE INTENTIONALLY LEFT BLANK

TAKEDO - 3VF V20 USER MANUAL Release 1 date 15-04-2013
3
1 – INTRODUCTION
TAKEDO-3VF V20 is a new type of drive with built-in EMC filter, responding to the European Directives
2004/108/EC (EMC) and 2006/95/EC (Low Voltage Equipment).
The inverter can operate only in open loop condition.
This manual provides you with the essential information about the connections in the control panel and the
inverter operation (use of the keypad, parameter and fault message list).
Complete Information for the application can be found in the original INSTALLATION MANUAL from VACON
(inverter series Vacon 20 Cold Plate) available on the site www.it.vacon.com.
2 – SAFETY WARNINGS AND CAUTIONS
For everything related to the warnings about personal safety and prevention of accidental damage to any
product or equipment connected to it, refer to Chapter “SAFETY” of the original INSTALLATION MANUAL
from VACON (inverter series Vacon 20 Cold Plate) available on the site www.it.vacon.com, where you can
also find the “Declaration of Conformity”.
Read this manual carefully and in its entirety before powering up the equipment.
With regard to the specific application on lifts, please consider carefully the following points:
1- The leakage current from the inverter to earth is greater than 30mA, and accordingly, the power
circuit must incorporate a residual current device with I
d
no less than 300mA, type B or type A.
Regulations require that the connection to earth are made with cable of not less than 10 mm² section. If
the residual current device should trip closing the main power switch, do not perform this
operation repeatedly because this could lead to permanent damage to the inverter drive. Check
that the residual current device is rated at least 300mA.
2- To avoid damaging the inverter in case of prolonged stoppages with no power supply, before
restarting the drive proceed as follows:
- If the inverter has been idle for several months, connect it to the power supply for at least 1
hour in such a way as to recharge the bus capacitors.
- If the inverter has been idle for more than one year, supply it for 1 hour with a level of voltage
50% lower than the nominal input voltage, and then supply it with the nominal input voltage for
1 hour.
3- It is advisable to balance the system at 50%. If balanced at 40%, the UP current under full load will be
greater, and it could be necessary to select a drive with a higher specification than the normally needed
ones.

TAKEDO - 3VF V20 USER MANUAL Release 1 date 15-04-2013
4
3 – CONNECTING THE POWER CIRCUIT
L1;L2;L3 A.C. Power Input Connect the three phases of the power supply to this three
terminals, in any order.
U;V;W Inverter output Connect the three output phases to the contactors, then to the
motor
DC+;BR External Braking Resistor Connect the external braking resistor
Earth Connect to the building earth system
With regard to the cable dimensioning and the terminal position, please refer to the Chapter “POWER
CABLING” of the original INSTALLATION MANUAL from VACON (inverter series Vacon 20 Cold Plate)
available on the site www.it.vacon.com.
INVERTER V20 400 VOLT (380 – 480V)
BRAKING RESISTOR
RATED
CURRENT
(A)
MAXIMUM
CURRENT
(A)
CODE
DIMENSIONS
WxHxD
(mm)
FUSES
gG/gL
(A)
SUPPLIED BY SMS
(Ω
ΩΩ
Ω) - (W)
MINIMUM VALUE
RECOMMENDED (Ω
ΩΩ
Ω)
DIMENSIONS
WxDxH (mm)
9 18
302.V6.V20CP0009-4
175x275x140
20
65 Ω – 500W
(004.16.W0065)
50
200x35x30
12 24
302.V6.V20CP0012-4
175x275x140
20
65 Ω – 500W
(004.16.W0065)
50
200x35x30
16 32
302.V6.V20CP0016-4
175x275x140
25
N°2 33 Ω - 500 W
series connected
(004.16.W0033 x 2)
50
200x35x30
TABLE 1 – Current, fuses and braking resistors – mains voltage 380 – 480V
INVERTER V20 230 VOLT (208 – 240V)
BRAKING RESISTOR
RATED
CURRENT
(A)
MAXIMUM
CURRENT
(A)
CODE
DIMENSIONS
WxHxD
(mm)
FUSES
gG/gL
(A)
SUPPLIED BY SMS
(Ω
ΩΩ
Ω) - (W)
MINIMUM VALUE
RECOMMENDED (Ω
ΩΩ
Ω)
DIMENSIONS
WxDxH (mm)
11 22
302.V6.V20CP0011-2
175x275x140
20
33 Ω - 500 W
(004.16.W0033)
25
200x35x30
12,5 25
302.V6.V20CP0012-2
175x275x140
20
33 Ω - 500 W
(004.16.W0033)
25
200x35x30
17,5 35
302.V6.V20CP0017-2
175x275x140
25
33 Ω - 500 W
(004.16.W0033)
25
200x35x30
TABLE 2 – Current, fuses and braking resistors – mains voltage 208 – 240V

4 – CONTROL CIRCUITS
Number
Meaning
1 Control Terminals A-20
2 STO Terminals
3 Relay Terminals
4 Option Board Terminals
5 STO Jumpers
6 DIP Switches:
SW1 in position 0, the common of the digital inputs (8-10 e 14-16)
is connected to the ground (default position);
in position 1, the common above is isolated from ground.
SW2 AI1 analogue input operating mode;
SW3 AI1 analogue input operating mode;
in position 0, the selected analogue input works in current mode;
in position 1, the analog input works in voltage mode (default position);
the voltage range is 0…10V and the current range is 0/4…20mA.
SW4 used for bus termination, related to the RS485 connection;
in position 0, the termination resistance is connected;
in position 1is not connected (default position).
7 Status Led:
“PWR” Orange the drive is supplied by mains
“RUN” Green the drive is running
“FLT” Red the drive is in fault
“RDY” Orange the drive is ready and no fault is present
it starts blinking when a warning is active
8 HMI connector (RJ45 keypad connector)
9 Braking Resistor Terminals
10 Supply Voltage connector for fan
11 Control Terminals A-20 Remote Connector
12 HMI Remote connector (Keypad connector)
