SNAIGE Fresh INN RF53SM User manual

REFRIGERATOR - FREEZER
Instruction for Use
RF53SM
RF56SM
RF57SM
RF58SM

1
DEAR CUSTOMER!
Some provisions in this user manual are unified for refrigerating products of different types
(for a refrigerator, refrigerator-freezer or freezer). CAREFULLY READ THE INSTRUCTION
MANUAL.
The Manufacturer shall not be held liable for damage arising from the failure to observe
the instructions contained in this manual.
Keep this manual for future reference, or to pass it over to the next user.
General information:
The appliance is a two–compartment refrigerator-freezer combination and is intended to
be used in household and similar applications.
The refrigerator compartment is designed for the brief storage of fresh food. The freezer
compartment is designed for the freezing and long-term storage of food products.
GUIDELINES CONCERNING THE SAFETY OF USE
General safety requirements:
–WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
–WARNING: Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
–WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type recommended by the
manufacturer.
–WARNING: When positioning the appliance, ensure the supply cord is not
trapped or damaged.
–WARNING: Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the appliance.
–WARNING: Disposal of the appliance should be according to national rules.
WARNING: Do not damage the appliance refrigeration system. It contains
the refrigerant gas R600a. If the refrigeration system is damaged:
•Do not use any open flame.
•Avoid sparks-do not turn on any electrical appliances or lighting fixtures.
•Immediately ventilate the room: air the room in which the appliance is placed for a
few minutes (the size of the room for a product containing isobuthane / R600a
must be at least 4 m3) to avoid damage to the cooling system.
C-Pentane is used as blowing agent in the insulation foam and it is a
flammable gas.

2
–This appliance is not designed for the storage of explosive substances such as
aerosol cans with a flammable propellant.
–It is prohibited to store petrol and other flammable liquids near the appliance.
–The appliance should be used only for storing foodstuffs.
Children and vulnerable people safety:
–Do not allow children to play with the appliance or to plug it in or unplug from the
electricity supply socket. Do not allow children to play with the packaging material
from the appliance.
–This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
–Cleaning and user maintenance shall not be made by children without
supervision.
–Children aged from 3 to 8 years are allowed to load and unload refrigerating
appliances.
Requirements for the connection to the mains:
–The appliance should only be connected to an earthed socket installed in
accordance with the regulations. Make sure that the supply voltage corresponds
with the voltage marked on the rating label. This product complies with all binding
CE labelling directives. The earthed electrical socket by which the appliance is
connected to the mains should be in an accessible place. It is a legal requirement
that the appliance is properly earthed. The manufacturer will not be held liable for
any damage or injury which may result from the failure to fulfil this requirement.
–To avoid the exposure to danger, always have faulty cable be replaced only by
the manufacturer, by our customer service or by qualified person and with a cable
of the same type.
–It is forbidden to readjust or modify any parts of the unit. It is crucial not to
damage the capillary tube visible in the compressor recess. The tube may not be
bent, straightened or wound. If the capillary tube is damaged by the user the
guarantee will be void.
–Do not use adapters, multiple sockets and two-wire extension leads. If it is
necessary to use the extension lead, it must be equipped with a protection ring
and a single socket and must have a VDE/GS safety certificate. If an extension
lead is used (with a protection ring and safety certificate), its socket must be
located at a safe distance, away from the sinks, and must not be in a place where
it could be flooded by water or waste water.

3
–The frequency and power of the electricity supply in your house must conform to
the general data parameters of the appliance as it is shown in the product label.
–When positioning the appliance, be careful that the electrical cord isn’t squeezed
in order to avoid its damage. Do not store heavy objects such as cooling devices
or other devices next the appliance in such a way that they could squeeze and
damage the electrical cord. This can cause a short circuit and a fire.
–Make sure that the plug of the electrical cord is not squeezed by the back wall of
the appliance or otherwise damaged. A damaged plug can be the cause of a fire!
CAUTION! If the installed interior lighting or the advertising panel’s light-
emitting diode (LED) lamp for the cooling device is not functioning, contact
the maintenance and repair representative for replacements. Lamps can be
replaced only by the maintenance and repair representative
Do not try repair the appliance on your own. Always contact an authorized
technician. To avoid the exposure to danger, always have faulty cable be
replaced only by the manufacturer, by our customer service or by qualified
person whit a cable of same type.
Requirements for safe use:
–It is forbidden to use a technically damaged appliance.
–If the appliance is unplugged (for cleaning, moving to another place, etc.), it may
be repeatedly switched on after 15 min.
–When performing activities, such as cleaning, maintenance or moving, the
appliance must be completely disconnected from power supply (by pulling the plug
out from the socket). Do not pull on the cord, but hold the body of the plug
instead.
–Do not place any switched on electrical devices on top of the appliance because
this may cause ignition of plastic parts.
–Do not place any dishes with liquids on top of the appliance and do not keep
flowers in vases or other liquid-filled vessels on the appliance.
–Do not climb on or sit on the appliance, do not lean on or hang on the appliance
doors and do not allow children to do this.
–Do not remove or touch items from the freezer compartment if your hands are wet
or damp.
–Do not use water spray and steam to clean the appliance.
The appliance should be transported in the vertical position. The
manufacturer will not be responsible for any damage of the appliance that
results from non-compliance with the instructions for transportation.

4
The manufacturer guarantees reliable operation of the refrigerator when
the relative air humidity not greater than 70 per cent and the ambient
temperature is:
+16 TO +32 DEGREES CELSIUS (Climate class N);
+16 TO +38 DEGREES CELSIUS (Climate class ST);
+16 TO +43 DEGREES CELSIUS (Climate class T).
INSTALLATION AND OPERATING CONDITIONS
Positioning:
•This appliance can be installed in a dry, well ventilated indoor where the ambient
temperature corresponds to the climate class indicated on the rating plate of the
appliance.
Do not install this appliance in areas that are too humid or too colds, such as
the construction appendices, garages or wine cellars. Place the appliance
away from heat sources such as kitchen stove/oven, radiators, or direct
sunlight. The appliance must not touch any pipes for heating, gas or water
supply, or any other electrical devices.
Minimum distances from the heat sources:
- from the electric gas and other ovens - 30 mm,
- from oil or coal fired ovens - 300 mm,
- from built-in ovens - 50 mm
If there is no possibility of ensuring the above- mentioned distances,
provide an appropriate insulation board.
•Do not cover the ventilation holes at the top of the appliances –it
must be a good air circulation around the appliance. There should
be a gap of at least 10 cm between the top of the appliance body
and any furniture that may be above it. If this requirement is not
followed, the appliance consumes more electrical energy and its
compressor may overheat. 
•The appliance must stand on a level surface and must not touch the
wall. If necessary, regulate the height of the appliance by adjusting
the levelling feet: by turning them clockwise –the front of the
appliance rises, by turning them counter clockwise –it comes down.
If the appliance is tilted slightly backward –the doors will close by
themselves.

5
•If the appliance is placed in a corner, a gap must be left between the appliance body and
the wall so that the freezer compartment door can be opened enough to pull out the
frozen product drawer.
With integrated handles With external handles
Preparing for operation:
•It is recommended to prepare the appliance for operation with a helper.
•Remove package. Lift the appliance away from
foamed polystyrene base. Tear off adhesive
tapes. Remove all red-coloured parts from the
shelves (fig. 2.).
NOTE. When you open the freezer compartment
door a little red packing detail will fall out –it is
for transportation purposes only.
•When positioning the appliance in chosen location, it will move more easily into position
if you lift the front a little and incline it backward, allowing it to roll on its casters. When
placing, moving, lifting the appliance, do not hold the door handles, do not
pull the condenser at the rear part of the
refrigerator and do not touch the compressor
unit.
•Take two supports 1from the bag and insert them
into the guides 2at the top back part of the
appliance (see fig). 
•The appliance should not be connected to the mains until all packing and
transport materials aren’t removed. Suitably dispose the packaging material.
First use:
•Before using the appliance for the first time, the interior and all internal accessories
should be washed with lukewarm water and some neutral soap to remove the typical
smell of a brandnew product, then dried thoroughly.
Wait at least 4 hours before connecting the appliance to the power
supply. This is to allow the oil to flow back in the compressor.
•When first starting-up or after a period out of use, before putting the products in the
compartment let the appliance run at least 2 hours.

6
DESCRIPTION OF THE APPLIANCE, BASIC PARTS
The appliance accessories listed below may differ from the accessories of the
appliance you have bought in quantity and in design. This description is adapted for
entire group of two–compartment refrigerator-freezer combinations.
A–refrigerator compartment
B–freezer compartment

1
Temperature controller / thermostat
8
Fast-freeze section
2
Interior lighting on / off button
9
Frozen products section(s)
3
Height-adjustable shelves
10
Door trays
4
Shelf for bottles
12
Egg tray
5
Glass shelf
13
Condenser
6
Fruit and vegetable drawer Fruit&VEGS
14
Thaw water drip tray
7
Section for freezing small products
15
Compressor

7
TEMPERATURE REGULATION
The temperature in the refrigerator compartment is controlled using the thermostat knob 1
by turning it to one side or the other. The temperature indication in digits is shown beside
the thermostat knob 1. The number “0, 2, 3, 4, 5, 6, 7”do not mean a specific
temperatures
The temperature is regulated on a scale of seven digits.
0= Compressor is switched off. WARNING! Electric current is not switched off.
1= highest temperature (lowest cooling)
7= lowest temperature (highest cooling)
The temperature in the refrigerator compartment can vary due to the ambient
temperature, the amount of food, and the frequent opening of the refrigerator door.
If the room is cool, the appliance cools less. The temperature in the appliance may
therefore rise. Use the thermostat wheel to set a lower temperature.
STORAGE AND FREEZING OF FOODSTUFFS
Temperature zones in the refrigerator:
Due to the natural air circulation, there are different temperature zones in the refrigerator
compartment.
1) The upper part of the refrigerator compartment and the door - the warmest area: store
tropical fruits, cans, drinks, eggs, sauces, canned products, butter, jam.
2) The middle part of the refrigerator compartment - cold zone: store cheese, milk, dairy
products, delicacies, yogurt.
3) The lower part of the refrigerator compartment - the coldest area: keep cold snacks,
desserts, meat and fish, cheesecake, fresh pasta, sour cream, pesto / salsa sauce,
home-cooked food, dough, pudding and cream cheese.
4) Fruit and vegetable drawer at the bottom of the refrigerator compartment: Store
vegetables and fruits (except tropical fruits).
To avoid food contamination, follow the instructions below:
•Prolonged opening of the door can significantly increase the temperature in the
compartments of the appliance: only open the door for the time required to place /
remove food.
•Regularly clean surfaces that may come into contact with food and accessible drainage
systems.
•Store fresh meat and fish in suitable containers in the refrigerator so that they do not
come into contact with or drip on other food.
•If the appliance is left empty for a long time, switch it off, defrost, clean, dry and leave
the door open to prevent mold from forming inside the appliance.
Freezing of foodstuffs
The thermostat knob should be set to 7. After 24 hours place fresh food ready for freezing
in one or two rows in the fast-freeze section FAST FREEZE. After a day, transfer the frozen
food from the quick-freeze compartment to the drawer in the storage compartment. After
freezing the products, turn the thermostat knob to the previous position.
DO NOT EXCEED THE MAXIMUM QUANTITY OF FROZEN FOODS IN THE PRODUCT DATA
SHEET (see in the rating label).

8
•Leave a space of at least 3 cm between refrigerated food and the upper partitions.
•Do not put unpackaged food in the freezer compartments.
•IMPORTANT! Do not freeze liquid food in glass containers or bottles. Do not freeze
sparkling drinks.
•Fresh frozen food must not come into contact with food that has already been frozen.
•Do not freeze food that is above ambient temperature.
•Strictly adhere to the expiration date for frozen foods as stated by the manufacturer on
the product packaging.WE RECOMMEND THAT FROZEN FISH AND SAUSAGE SHOULD BE
STORED IN THE FREEZER COMPARTMENT NOT LONGER THAN 6 MONTHS; CHEESE,
POULTRY, PORK, LAMB –NOT MORE THAN 8 MONTHS; BEEF, FRUIT AND VEGETABLES
–NOT LONGER THAN 12 MONTHS.
CAUTION! In the event of accidental defrosting, for example due to a power failure, if the
power has been off for longer than the value shown in the technical characteristics chart
under "rising time", the defrosted food must be consumed quickly or cooked immediately
and then refrozen (after cooling).
DEFROSTING, CLEANING AND CARE
THE REFRIGERATOR COMPARTMENT defrosts automatically. Drops of ice that form on the
back wall of the refrigerator compartment thaw during the time the compressor is not working
and the thaw water runs down the thaw water runoff channel to the tray on top of the
compressor (Fig. 1), where it evaporates.
FREEZER COMPARTMENT should be thawed not less than twice a year or when a layer of
ice thicker than 5 mm forms in it. Do the actions below in the order they are listed:
WARNING! Turn the appliance off and pull the plug out of the electrical socket.
•Remove food from the freezer compartment. The
frozen foodstuffs will not warm up too much while
you are thawing the freezer compartment if you
cover them with a thick cloth and keep them in a
cool place.
•Pull out the melt water gutter, turn it 180Oand
hook it up. After melting, place the dish with a
water gutter (see fig. 4)
•Leave the appliance compartment door open. After
the frost has thawed, dry the surfaces and
accessories dry.
•Remove the melt water gutter, turn it 180º again and replace it. Close the appliance
door. Turn on the appliance.
REGULARLY CLEAN THE APPLIANCE.
Remember that before defrosting the appliance and cleaning the back
part of the appliance body you must disconnect the appliance from the
electrical energy supply socket by pulling the plug out of the electricity
outlet.
•Protect the appliance inner surfaces and plastic parts from fats, acids and sauces. In
case of accidental spills –immediately clean with warm soapy water or dishwashing
detergent. Wipe dry.

9
•Regularly clean the hermetic gaskets of the doors. Wipe dry.
•Regularly clean the thaw water channel space in the refrigerator
with a special cleaner for that purpose (see fig.).
•At least once a year clean dust away from the back part of the
appliance body and the compressor. A soft brush, electrostatic cloth
or vacuum cleaner may be used for cleaning.
•DO NOT use detergents containing abrasive particles, acid, alcohol
or benzene for cleaning the appliance inner and outer surfaces. DO
NOT use for cleaning cloths or sponges that have coarse surfaces
intended for scrubbing.
•If the appliance is to be left switched off for an extended period, leave its doors open.
CHANGING THE OPENING DIRECTION OF THE DOORS
It is recommended that changing the opening direction of the doors should be done with a
helper. You will need two spanners No. 8 and No. 10 and a head screwdriver.
When changing the opening direction of the doors, YOU CAN NOT lay the
refrigerator horizontally!
Warning: Always disconnect the unit from the mains before any maintenance or repair
work is carried out.
Before you start, please note the following:
∙ Always ensure that the correct number of washers is used on all hinge bolts and screws.
∙ So that the doors can close tightly against the frame, take the utmost care that they are
properly aligned during reassembly.

10
1. Remove the four covers C from the housing and inside of the door.
2. Unscrew the hinge bolt on the inside of the door in thearea C/6. Caution: Support
the door.
3. Take off the refrigerator door.
4. Take out the fi xing screws and remove the upper bracket 6. Note the small plastic
plate underneath the bracket.
5. Turn the bracket 6 including the small plastic plate through 180° and replace it on the
other side of the refrigerator, using the two screw holes adjacent to each other.
6. Place the refrigerator door on a soft surface. Remove the hinge support 5 from the
underside of the door and fit the hinge support provided on the opposite side.
7. Take out the covering caps and then remove the hinge support in the middle 4. Note
the small plastic plate underneath the bracket. Caution: Support the door.
8. Take off the freezer door 3.
9. Unscrew the legs 7from the cabinet.
10. Unscrew the lower bracket 2together with the washers on the shaft. Unscrew the
shaft counterclockwise. Turn the bracket 2At an angle of 180 °, screw the shaft into
the bracket on the other side and place the washers on the shaft.
11. Attach the bracket 2on the opposite side of the cabinet. Screw the legs 7into the
cabinet.
12. Take out the sealing plugs 8 from the partition separating the refrigeration and freezer
compartments and replace them in the openings on the opposite side.
13. Take out sealing plugs 9 from the freezer door and replace it in the opening on the
opposite side.
14. Place the freezer door onto the hinge bolt on holding bracket 2. Caution: Support
the door.
15. Turn the holding bracket 4 with its hinge bolt and plastic plate through 180°.
16. Replace the bracket bolt on the opposite side of the freezer door and secure it with the
screws.
17. Replace the covering caps over the screw heads. Place the refrigerator door onto the
hinge bolt on holding bracket 4. Caution: Support the door.
18. Re-insert the hinge bolt of the bracket 6 into the refrigerator door and secure it with
the screws.
19. Fit the four covers C over the bracket and the openings.

11
OPERATION PROBLEMS AND THEIR SOLUTIONS
•The appliance is plugged in to the mains but it does not work. Check that your
house electricity supply installations are in order. Check that the plug is correctly
inserted into the electricity supply socket.
•The noise has become louder. Check that the appliance is standing stable, on a level
place. To make it level, regulate the front feet. Check if the appliance is not touching any
furniture, and that no part of the refrigeration system at the back part of the appliance
body is touching the wall. Pull the appliance away from any furniture or walls. Check
that the cause of increased noise isn’t due to bottles, cans or dishes in the appliance that
might be touching each other.
•Water has appeared at the bottom of the refrigerator compartment. Check
whether a thaw water channel space isn’t blocked. Clean the thaw water channel space
with a cleaner intended for that purpose.
•Water has appeared on the tempered glass shelves. Food items or dishes in the
refrigeration compartment are touching the back wall of the compartment. Do not let
food items or dishes touch the back wall.
•Moisture dripping from under the glass shelves. If you placed many containers
with liquids on the shelf, moisture can condense and drip onto the shelf below. Move
some containers with liquids onto other shelves.
•Water has appeared under the appliance. The thaw water collection tray has
slipped off the compressor. Place the tray on top of the compressor.
•When the appliance door is opened, the rubber sealing gasket pulls out. The
gasket is smeared with sticky foodstuffs (fat, syrup). Clean the sealing gasket and the
groove for it with warm water containing soap or dishwashing detergent and wipe dry.
Put the rubber sealing gasket back into the place
•High temperature in appliance, the compressor operation pauses are short.
Ascertain whether the appliance doors are shutting tightly, whether the door wasn’t kept
open longer than necessary when taking out or putting in foodstuffs or whether a large
amount of warm food was placed in the appliance.
•The top of the appliance has condensation on it. The ambient relative air humidity
is above 70 %. Ventilate the room where the appliance stands and if possible remove
the cause of the humidity.
Remarks on the appliance operating noise. As the appliance operates and goes
through the freezing cycle, various noises will be emitted. This is normal and is not a sign
of any malfunction. As the refrigerant circulates around the refrigeration system, it causes
sounds like murmuring, bubbling, or rustling. Louder sounds like popping or clicking may
be heard for a short time as the refrigerator’s compressor switches on.

12
ENVIRONMENTAL PROTECTION INFORMATION
Important Note:
This appliance is marked according to the European directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste handling of this
product.
The symbol on the product, or on the documents accompanying the product,
indicates that this appliance may not be treated as household waste. Instead it
shall be handed over to the applicable collection point for the recycling of
electrical and electronic equipment.
Disposal must be carried out in accordance with local environmental regulations for waste
disposal. For more detailed information about treatment, recovery and recycling of this
product, please contact your local authority, your household waste disposal service or the
retailer where you purchased the product.
Our packaging are made of environmentally friendly materials, which can be reused:
● The external packaging is made of cardboard/foil
● The FCKW free shape of foamed polystyrene (PS)
● Polyethylene (PE) foils and bags
The refrigerants and foaming agents, which are 100% free of FCKW and FKW have been
used for manufacturing our product. Therefore we are helping to protect the ozone layer
and prevent the increase of greenhouse effects. Also, the innovative technology and
environmentally friendly insulation help in reducing energy consumption.
