SNAIGE FR27SM User manual

0
Refrigerator with a freezer compartment
FR27SM
FR26SM
FR25SM
FR24SM
Instructions for Use

1
DEAR CUSTOMER,
Some provisions in this user manual are unified for refrigerating products of
different types (for a refrigerator, refrigerator-freezer or freezer). CAREFULLY
READ THE INSTRUCTION MANUAL.
The Manufacturer shall not be held liable for damage arising from the failure to
observe the instructions contained in this manual.
Keep this manual for future reference, or to pass it over to the next user.
General information:
Refrigerating appliance - a household refrigerator with a freezer compartment at
the top, intended for household use. The refrigerator compartment is for short-
term storage of fresh food. The freezer compartment is designed for the freezing
and long-term storage of food products.
GUIDELINES CONCERNING THE SAFETY OF USE
General safety requirements:
–WARNING: Keep ventilation openings, in the appliance enclosure or in the built-
in structure, clear of obstruction.
–WARNING: Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
–WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type recommended by the
manufacturer.
–WARNING: When positioning the appliance, ensure the supply cord is not
trapped or damaged.
–WARNING: Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the appliance.
–WARNING: Disposal of the appliance should be according to national rules.
WARNING: Do not damage the appliance refrigeration system. It contains
the refrigerant gas R600a. If the refrigeration system is damaged:
•Do not use any open flame.
•Avoid sparks-do not turn on any electrical appliances or lighting fixtures.
•Immediately ventilate the room: air the room in which the appliance is placed for
a few minutes (the size of the room for a product containing isobuthane / R600a
must be at least 4 m3) to avoid damage to the cooling system.
C-Pentane is used as blowing agent in theinsulation foam and it is a
flammable gas.

2
Children and vulnerable people safety:
–Do not allow children to play with the appliance or to plug it in or unplug from the
electricity supply socket. Do not allow children to play with the packaging material
from the appliance.
–This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
–Cleaning and user maintenance shall not be made by children without
supervision.
–Children aged from 3 to 8 years are allowed to load and unload refrigerating
appliances.
Requirements for the connection to the mains:
–The appliance should only be connected to an earthed socket installed in
accordance with the regulations. Make sure that the supply voltage corresponds
with the voltage marked on the rating label. This product complies with all binding
CE labelling directives. The earthed electrical socket by which the appliance is
connected to the mains should be in an accessible place. It is a legal requirement
that the appliance is properly earthed. The manufacturer will not be held liable for
any damage or injury which may result from the failure to fulfil this requirement.
–To avoid the exposure to danger, always have faulty cable be replaced only by
the manufacturer, by our customer service or by qualified person and with a
cable of the same type.
–It is forbidden to readjust or modify any parts of the unit. It is crucial not to
damage the capillary tube visible in the compressor recess. The tube may not be
bent, straightened or wound. If the capillary tube is damaged by the user the
guarantee will be void.
–Do not use adapters, multiple sockets and two-wire extension leads. If it is
necessary to use the extension lead, it must be equipped with a protection ring
and a single socket and must have a VDE/GS safety certificate.
–If an extension lead is used (with a protection ring and safety certificate), its
socket must be located at a safe distance, away from the sinks, and must not be
in a place where it could be flooded by water or waste water.
–When positioning the appliance, be careful that the electrical cord isn’t squeezed
in order to avoid its damage. Do not store heavy objects such as cooling
devices, furniture or other domestic devices next the appliance in such a way that
they could squeeze and damage the electrical cord. This can cause a short
circuit and a fire.

3
–Make sure that the plug of the electrical cord is not squeezed by the back wall of
the appliance or otherwise damaged. A damaged plug can be the cause of a
fire!
Do not try repair the appliance on your own. Always contact an authorized
technician. To avoid the exposure to danger, always have faulty cable be
replaced only by the manufacturer, by our customer service or by qualified
person whit a cable of same type.
Requirements for safe use:
–Pull the plug out from the mains socket before each maintenance activity. Do not
pull on the cord, but hold the body of the plug instead.
–If the appliance is unplugged (for cleaning, moving to another place, etc.), it may
be repeatedly switched on after 15 min.
–The mains cable must stay below the level of the mains plug.
–It is forbidden to use a technically damaged appliance.
–Do not place any switched on electrical devices on top of the appliance because
this may cause ignition of plastic parts.
–Do not place any dishes with liquids on top of the appliance and do not keep
flowers in vases or other liquid-filled vessels on the appliance.
–Do not place heavy objects on the top of the appliance.
–Do not remove or touch items from the freezer compartment if your hands are
wet or damp.
–Do not use water spray and steam to clean the appliance.
The appliance should be transported in the vertical position. The
manufacturer will not be responsible for any damage of the appliance that
results from non-compliance with the instructions for transportation.
The manufacturer guarantees reliable operation of the refrigerator when
the relative air humidity not greater than 70 per cent and the ambient
temperature is: +16 TO +32 °C - Climate class N;
+16 TO +38 °C - Climate class ST;
+16 TO +43 °C - Climate class T.

4
INSTALLATION AND OPERATING CONDITIONS OF THE
APPLIANCE
Positioning:
•This appliance can be installed in a dry, well ventilated indoor where the ambient
temperature corresponds to the climate class indicated on the rating plate of the
appliance.
Do not install this appliance in areas that are too humid or too colds, such as
the construction appendices, garages or wine cellars. Place the appliance
away from heat sources such as kitchen stove/oven, radiators, or direct
sunlight. The appliance must not touch any pipes for heating, gas or water
supply, or any other electrical devices.
Minimum distances from the heat sources:
- from the electric gas and other ovens - 30 mm,
- from oil or coal fired ovens - 300 mm,
- from built-in ovens - 50 mm
If there is no possibility of ensuring the above- mentioned distances, provide an
appropriate insulation board.
•Do not cover the ventilation holes at the top of the appliances –it
must be a good air circulation around the appliance. There should
be a gap of at least 10 cm between the top of the appliance body
and any furniture that may be above it. If this requirement is not
followed, the appliance consumes
more electrical energy and its
compressor may overheat. 
•The appliance must stand on a level
surface and must not touch the
wall. If necessary, regulate the
height of the appliance by adjusting
the levelling feet: by turning them
clockwise –the front of the appliance rises, by turning
them counter clockwise –it comes down. If the
appliance is tilted slightly backward –the doors will close
by themselves.
•If you are positioning the refrigerator in a corner, leave
a gap of at least 1 cm between the wall and the body of
the appliance so that the refrigerator door opens enough
to enable the fruit and vegetable tray to be pulled out.
•Preparing for operation:
•It is recommended to prepare the appliance for operation with a helper.
•Remove package. Lift the appliance away from foamed polystyrene base. Tear off
adhesive tapes. Remove all red-coloured parts from the shelves and coloured adhesive
tapes from the door trays
•When placing, moving, lifting the appliance, do not hold the door handles, do
not pull the condenser at the rear part of the refrigerator and do not touch
the compressor unit.

5
•Take two supports 1from the bag and insert them into the
guides 2at the top back part of the appliance.
The appliance should not be connected to the mains
until all packing and transport materials aren’t
removed. Suitably dispose the packaging material.
First use:
•Before using the appliance for the first time, the interior and all internal accessories
should be washed with lukewarm water and some neutral soap to remove the typical
smell of a brandnew product, then dried thoroughly.
Wait at least 4 hours before connecting the appliance to the
power supply. This is to allow the oil to flow back in the compressor. If
this is not done, the appliance compressor may fail.
•When first starting-up or after a period out of use, before putting the products in the
compartment let the appliance run at least 2 hours.
DESCRIPTION OF THE APPLIANCE, BASIC PARTS (fig.1)
The appliance accessories listed below may differ from the accessories of the
appliance you have bought in quantity and in design. This description is adapted
for entire group of refrigerators.
A–refrigerator compartment B–freezer compartment
1
Interior light block
6
Door trays
2
Thermostat knob
8
Wire shelf
3
Adjustable height shelves
9
Condenser
4
Glass shelf
10
Compressor
5
Drawer for vegetables and fruits
11
Thaw water drip tray

6
TEMPERATURE REGULATION
The temperature in the refrigerator compartment is controlled using the thermostat knob
2(fig. 1) by turning it to one side or the other. The temperature indication in digits is
shown beside the thermostat knob 2.
The temperature is regulated on a scale of seven digits.
0= Compressor is switched off. WARNING! Electric current is not switched off.
1= highest temperature (lowest cooling)
7= lowest temperature (highest cooling)
The temperature in the refrigerator compartment can vary due to the ambient
temperature, the amount of food, and the frequent opening of the refrigerator
door.
If the room is cool, the appliance cools less. The temperature in the appliance may
therefore rise. Use the thermostat wheel to set a lower temperature.
FOOD STORAGE
Temperature zones in the refrigerator:
Due to the natural air circulation, there are different temperature zones in the refrigerator
compartment.
1) The upper part of the refrigerator compartment and the door - the warmest area: store
tropical fruits, cans, drinks, eggs, sauces, canned products, butter, jam.
2) The middle part of the refrigerator compartment - cold zone: store cheese, milk, dairy
products, delicacies, yogurt.
3) The lower part of the refrigerator compartment - the coldest area: keep cold snacks,
desserts, meat and fish, cheesecake, fresh pasta, sour cream, pesto / salsa sauce, home-
cooked food, dough, pudding and cream cheese.
4) Fruit and vegetable drawer at the bottom of the refrigerator compartment: Store
vegetables and fruits (except tropical fruits).
To avoid food contamination, follow the instructions below:
• Prolonged opening of the door can significantly increase the temperature in the
compartments of the appliance: only open the door for the time required to place /
remove food.
• Regularly clean surfaces that may come into contact with food and accessible drainage
systems.
• Store fresh meat and fish in suitable containers in the refrigerator so that they do not
come into contact with or drip on other food.
• If the appliance is left empty for a long time, switch it off, defrost, clean, dry and leave
the door open to prevent mold from forming inside the appliance.
Freezing of foodstuff:
Food to be frozen should first be allowed to cool off to room temperature and then should
be placed in one row at the bottom of the freezer compartment.
The thermostat knob should be set to 7. Fresh foodstuffs prepared for freezing and
cooled to room temperature should be placed in one layer at the bottom of the freezer.
After 24 hours, move the frozen foodstuffs onto the wire shelf 8(see illustration 1). When
the products are frozen, the thermostat wheel should be set at its earlier position.

7
•DO NOT EXCEED THE MAXIMUM QUANTITY OF FROZEN PRODUCTS INDICATED IN THE
Product data sheet (Product Fiche).
•Do not put unpackaged food in the freezer compartments.
•Do not freeze liquid foodstuffs in glass vessels or bottles. Do not freeze
carbonated beverages.
•Fresh frozen food must not come into contact with food that has already been frozen.
•Do not freeze food that is above ambient temperature.
•Strictly adhere to the expiration date for frozen foods as stated by the manufacturer on
the product packaging.
WE RECOMMEND THAT FROZEN FISH AND SAUSAGE SHOULD BE STORED IN THE
FREEZER COMPARTMENT NOT LONGER THAN 6 MONTHS; CHEESE, POULTRY,
PORK, LAMB –NOT MORE THAN 8 MONTHS; BEEF, FRUIT AND VEGETABLES –
NOT LONGER THAN 12 MONTHS.
DEFROSTING, CLEANING AND CARE
THE REFRIGERATOR COMPARTMENT DEFROSTS AUTOMATICALLY. Drops of ice that form
on the back wall of the refrigerator compartment thaw during the time the compressor is
not working and the thaw water runs down the thaw water runoff channel to the tray on
top of the compressor (Fig. 1), where it evaporates.
FREEZER COMPARTMENT should be thawed not less than twice a year or when a layer of
ice thicker than 5 mm forms in it. Do the actions below in the order they are listed:
WARNING! Turn the appliance off and pull the plug out of the electrical socket.
•Remove foodstuffs from freezer compartment.
•Leave freezer compartment door partly open. When the ice melts, clean and wipe dry
the surfaces and fixtures of the refrigerator and freezer compartments.
•Close the appliance door. Plug in and turn on the appliance.
REGULARLY CLEAN THE APPLIANCE.
Remember that before defrosting the appliance and cleaning the back
part of the appliance body you must disconnect the appliance from the
electrical energy supply socket by pulling the plug out of the electricity
outlet.
•Protect the appliance inner surfaces and plastic parts from fats, acids
and sauces. In case of accidental spills –immediately clean with warm
soapy water or dishwashing detergent. Wipe dry.
•Regularly clean the hermetic gaskets of the doors. Wipe dry.
•Regularly clean the thaw water channel space in the refrigerator with
a special cleaner for that purpose (see fig.).
•At least once a year clean dust away from the back part of the
appliance body and the compressor. A soft brush, electrostatic cloth or
vacuum cleaner may be used for cleaning.
•DO NOT use detergents containing abrasive particles, acid, alcohol or benzene for
cleaning the appliance inner and outer surfaces. DO NOT use for cleaning cloths or
sponges that have coarse surfaces intended for scrubbing.
•If the appliance is to be left switched off for an extended period, leave its doors open.

8
CHANGING THE INTERIOR LIGHT BULB
When changing the interior light bulb (fig. 6), do the
actions below in the order they are listed:
1. Unplug the appliance from the mains by
pulling the plug out of the electricity
supply socket.
2. Push the interior light bulb lid 4retainer 5with a
flat screwdriver and with your other hand pull it
toward yourself.
3. When you have changed the light bulb, replace
the lid and push —the lid will snap into position.
4. Plug the appliance into the electricity supply
socket.
OPERATION PROBLEMS AND
THEIR SOLUTIONS (TROUBLESHOOTING). What if…
•The appliance is plugged in to the mains but it does not work and. Check that
your house electricity supply installations are in order. Check that the plug is correctly
inserted into the electricity supply socket.
•The noise has become louder. Check that the appliance is standing stable on a level
place. To make it level, regulate the front feet. Check if the appliance is not touching
any furniture and that no part of the refrigeration system at the back part of the
appliance body is touching the wall. Pull the appliance away from any furniture or walls.
Check that the cause of increased noise isn’t due to bottles, cans or dishes in the
appliance that might be touching each other.
•Water has appeared at the bottom of the refrigerator compartment. Check
whether a thaw water channel space isn’t blocked. Clean the thaw water channel space
with a cleaner intended for that purpose.
•Water has appeared on the tempered glass shelves. Food items or dishes in the
refrigerator compartment are touching the back wall of the compartment. Do not let
food items or dishes touch the back wall.
•Moisture dripping from under the glass shelves. If you placed many containers
with liquids on the shelf, moisture can condense and drip onto the shelf below. Move
some containers with liquids onto other shelves.
•Water has appeared under the appliance. The thaw water collection tray has
slipped off the compressor. Place the tray on top of the compressor.
•When the appliance door is opened, the rubber sealing gasket pulls out. The
gasket is smeared with sticky foodstuffs (fat, syrup). Clean the sealing gasket and the
groove for it with warm water containing soap or dishwashing detergent and wipe dry.
Put the rubber sealing gasket back into the place.
•High temperature in appliance, the compressor operation pauses are short.
Ascertain whether the appliance doors are shutting tightly, whether the door wasn’t kept
open longer than necessary when taking out or putting in foodstuffs or whether a large
amount of warm food was placed in the appliance.
•The top of the appliance has condensation on it. The ambient relative air humidity
is above 70 %. Ventilate the room where the appliance stands and if possible remove
the cause of the humidity.

9
R em a r ks o n th e a pp l i an c e o pe r a ti n g n oi s e . As the appliance
operates and goes through the freezing cycle, various noises will be emitted. This
is normal and is not a sign of any malfunction.
•As the refrigerant circulates around the refrigeration system, it causes sounds like
murmuring, bubbling, or rustling. Louder sounds like popping or clicking may be heard
for a short time as the refrigerator’s compressor switches on.
ENVIRONMENTAL PROTECTION INFORMATION
This appliance is marked according to the European directive 2002/96/EC on
Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is
disposed of correctly, you will help prevent potential negative consequences for
the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product.
This symbol indicates that once the appliance is no longer needed, it cannot be disposed
together with other miscellaneous municipal waste. Disposal must be carried out in
accordance with local environmental regulations for waste disposal. For more detailed
information about treatment, recovery and recycling of this product, please contact your
local authority, your household waste disposal service or the retailer where you purchased
the product.
If you decided to scrap the appliance, make it impossible to use in order to prevent
possible misadventure. Pull out the electric plug from the electricity supply socket and
then cut off the cord. Tear off the gasket. Break the door lock if any.
Do not dismantle the appliance yourself. Pass it on to recycling companies.

10

11
NGBFRSN-4
