Snell Advanced Media KudosPro MC1000 User manual

www.s-a-m.com
Operator’s Manual
KudosPro MC1000
Single-channel Motion Compensated Standards Converter
KudosPro MC1000-IQ
Single-channel Motion Compensated Standards Converter with
Two IQ Module Slots
KudosPro MC2000
Dual-channel Motion Compensated Standards Converter
KudosPro MC2000-IQ
Dual-channel Motion Compensated Standards Converter with
Two IQ Module Slots

MC1000/MC1000-IQ/MC2000/MC2000-IQ Information and Notices
Issue 1 Rev 8 Page 2 © 2015 SAM
Information and Notices
About this Manual
This manual contains information for the installation and operation of the KudosPro
MC1000/MC1000-IQ/MC2000/MC2000-IQ unit.
For information on the operation of any IQ modules fitted to the -IQ variants please see the
relevant IQ module user manual(s).
Software Version
Software version: 2.2.A.10
QT Library
KudosPro products use modified Qt Library under GNU LGPL:
http://doc.qt.io/qt-4.8/index.html
The Library, its modifications, and its use are covered by the terms of this license.
Copyright and Disclaimer
Copyright protection claimed includes all forms and matters of copyrightable material and
information now allowed by statutory or judicial law or hereinafter granted, including without
limitation, material generated from the software programs which are displayed on the screen
such as icons, screen display looks etc.
Information in this manual and software are subject to change without notice and does not
represent a commitment on the part of SAM. The software described in this manual is
furnished under a license agreement and can not be reproduced or copied in any manner
without prior agreement with SAM or their authorized agents.
Reproduction or disassembly of embedded computer programs or algorithms prohibited.
No part of this publication can be transmitted or reproduced in any form or by any means,
electronic or mechanical, including photocopy, recording or any information storage and
retrieval system, without permission being granted, in writing, by the publishers or their
authorized agents.
SAM operates a policy of continuous improvement and development. SAM reserves the right
to make changes and improvements to any of the products described in this document
without prior notice.
Contact Details
Customer Support
For details of our Regional Customer Support Offices, please visit the SAM website and
navigate to Support/Contact Support.
www.s-a-m.com/support/contact-support/
Customers with a support contract should call their personalized number, which can be found
in their contract, and be ready to provide their contract number and details.

MC1000/MC1000-IQ/MC2000/MC2000-IQ Safety Information
Issue 1 Rev 8 Page 3 © 2015 SAM
Safety Information
Explanation of Safety Symbols
Erklärung der Sicherheitssymbole
Dieses Symbol weist den Benutzer auf wichtige Informationen
hin, die in der begleitenden Dokumentation enthalten sind.
Dieses Symbol zeigt an, dass gefährliche Spannung vorhanden ist.
Es befinden sich keine vom Benutzer zu wartenden Teile im Geräteinneren.
Dieses Gerät sollte nur von geschultem Personal gewartet werden
· Um das Risiko eines Elektroschocks zu reduzieren, setzen Sie das
Gerät weder Regen noch Feuchtigkeit aus.
· Stellen Sie immer sicher, dass das Gerät ordnungsgemäß geerdet
und verkabelt ist.
· Dieses Equipment muss an eine Netzsteckdose mit Schutzleiter
angeschlossen werden und einen zuverlässig identifizierbaren Nullleiter haben.
· Die Netzsteckdose sollte nahe beim Gerät und einfach zugänglich sein.
Netzanschluss in anderen Ländern als der USA
Das Equipment wird im Normalfall mit einem Netzkabel mit Standard IEC
Anschlussbuchse und einem Standard IEC Anschlussstecker geliefert.
Sollten Sie den angeschweißten Stecker auswechseln müssen, entsorgen
Sie diesen bitte umgehend. Die farbliche Belegung des Netzkabels ist wie folgt:
GRÜN GELB E = Schutzleiter
BLAU N = Nulleiter
BRAUN L = P = Phase
Achtung:Wenn das Gerät zwei Anschlussbuchsen hat, stellen
Sie bitte sicher, dass beide Netzkabel mit der selben Phase in die
Netzsteckdose gesteckt werden.
Sicherheits-Warnhinweise
D
!
!
Die angeführten Service-/Reparatur-Anweisungen sind
ausschließlich von qualifiziertem Service-Personal
auszuführen. Um das Risiko eines lektroschocks zu
reduzieren, führen Sie ausschließlich die im
Benutzerhandbuch eschriebenen Anweisungen aus,
es sei denn, Sie haben die entsprechende Qualifikation.
Wenden Sie sich in allen Service-Fragen an qualifiziertes Personal.
!
ACHTUNG
Gefahr von Elektroschocks.
Abdeckungen nicht entfernen
Keine vom Benutzer zu wartende Teile
Wenden Sie sich ausschließlich
an qualifiziertes Personal
L=
Phase N= Nulleiter N= Nulleiter L= Phase
E=
Schutzleiter E= Schutzleiter
Explicación de los Símbolos de Seguridad
Éste símbolo refiere al usuario información importante contenida
en la literatura incluida.Referirse al manual.
Éste símbolo indica que voltajes peligrosos están presentes en el interior.
No hay elementos accesibles al usuario dentro.
Esta unidad sólo debería ser tratada por personal cualificado.
Las instrucciones de servicio cuando sean dadas, son
sólo para uso de personal cualificado.Para reducir el
riesgo de choque eléctrico no llevar a cabo ninguna
operación de servicio aparte de las contenidas en las
instrucciones de operación, a menos que se esté
cualificado para realizarlas.
Referir todo el trabajo de servicio a personal cualificado.
· Para reducir el riesgo de choque eléctrico, no exponer este equipo
a la lluvia o humedad.
· Siempre asegurarse de que la unidad está propiamente conectada a
tierra y que las conexiones de alimentación están hechas correctamente.
· Este equipo debe ser alimentado desde un sistema de alimentación
con conexión a TIERRA y teniendo una conexión neutra fácilmente
identificable.
·La toma de alimentación para la unidad debe ser cercana y fácilmente
accesible.
Conexión de alimentación en otros países que no sean USA
El equipo es normalmente entregado con un cable de alimentación con un
enchufe hembra estándar IEC en un extremo y con una clavija estándar
IEC en el otro.Si se requiere eliminar la clavija para sustituirla por otra,
disponer dicha clavija de una forma segura.
El código de color a emplear es como sigue:
Advertencia Si la unidad tuviera dos tomas de alimentación, asegurarse
de que ambos cables de alimentación están conectados a la misma fase.
ESP
!
!
Advertencias de Seguridad
LN
E
NL
E
Clavija
Aerea Macho Enchufe Aereo Hembra
VERDE/ AMARILLO conectado a E
(Conductor de protección a Tierra
-Earth en el original-)
AZUL conectado a N (Conductor Neutro -Neutral en el original-)
MARRÓN conectado a L (Conductor Fase -Live en el original-)
RIESGO DE CHOQUE ELECTRICO
NO QUITAR LAS PROTECCIONNES
ELEMENTOS NO ACCESIBLES AL
USUARIO.
SERVICIO SOLAMENTE A PERSONAL
CUALIFICADO

MC1000/MC1000-IQ/MC2000/MC2000-IQ Safety Information
Issue 1 Rev 8 Page 4 © 2015 SAM
Simboli di sicurezza:
Questo simbolo indica l'informazione importante contenuta nei
manuali appartenenti all'apparecchiatura. Consultare il manuale.
Questo simbolo indica che all'interno dell'apparato sono presenti
tensioni pericolose. Non cercare di smontare l'unità.
Per qualsiasi tipo di intervento rivolgersi al personale qualificato.
Le istruzioni relative alla manutenzione sono ad uso
esclusivo del personale qualificato.E' proibito all'utente
eseguire qualsiasi operazione non esplicitamente
consentita nelle istruzioni. Per qualsiasi informazione
rivolgersi al personale qualificato.
· Per prevenire il pericolo di scosse elettriche è necessario non esporre
mai l'apparecchiatura alla pioggia o a qualsiasi tipo di umidità.
· Assicurarsi sempre, che l'unità sia propriamente messa a terra e che
le connessioni elettriche siano eseguite correttamente.
· Questo dispositivo deve essere collegato ad un impianto elettrico
dotato di un sistema di messa a terra efficace.
·La presa di corrente deve essere vicina all'apparecchio
e facilmente accessibile.
Connessione elettrica nei paesi diversi dagli Stati Uniti
L'apparecchiatura normalmente è spedita con cavo pressofuso con la presa
e spina standard IEC. Nel caso della rimozione della spina elettrica,
gettarla via immediatamente osservando tutte le precauzioni del caso.
La leggenda dei cavi è la seguente:
VERDE/GIALLO cavo connesso
ad "E" (terra)
BLU cavo connesso ad "N" (neutro)
MARRONE cavo connesso ad "L" ( fase)
Attenzione! Nel caso in cui l'apparecchio abbia due prese di corrente,
assicurarsi che i cavi non siano collegati a fasi diverse della rete elettrica.
I
!
!
Attenzione:
!
ATTENZIONE
LN
E
NL
E
Presa volante Spina volante
RISCHIO DI SHOCK ELETTRICO
NON CERCARE DI SMONTARE
L'UNITA PER QUALSIASI TIPO DI
INTERVENTO RIVOLGERSI AL
PERSONALE QUALIFICATO
Forklaring på sikkerhedssymboler
Dette symbol gør brugeren opmærksom på vigtig information
i den medfølgende manual.
Dette symbol indikerer farlig spænding inden i apparatet. Ingen bruger
servicerbare dele i apparatet på brugerniveau.
Dette apparat må kun serviceres af faglærte personer..
Serviceinstruktioner er kun til brug for faglærte
servicefolk. For at reducere risikoen for elektrisk
stød må bruger kun udføre anvisninger i
betjeningsmanualen.
Al service skal udføres af faglærte personer.
· For at reducere risikoen for elektrisk stød må apparatet ikke
udsættes for regn eller fugt.
· Sørg altid for at apparatet er korrekt tilsluttet og jordet.
· Dette apparat skal forbindes til en nettilslutning, der yder
BESKYTTENDE JORD og 0 forbindelse skal være tydeligt markeret.
· Stikkontakten, som forsyner apparatet, skal være tæt på apparatet
og let tilgængelig.
Nettilslutning i andre lande end USA
Udstyret leveres normalt med et strømkabel med et standard IEC støbt løst
hunstik i den ene ende og et standard IEC støbt hanstik i den anden ende.
Hvis et af de støbte stik på strømkablet er defekt, skal det straks kasseres på
forsvarlig vis. Farvekoden for lederen er som følger:
GRØN/GUL leder forbundet til J (Jord)
BLÅ leder forbundet til 0
BRUN leder forbundet til F(Fase)
Forsigtig Hvis enheden har to lysnetindgange, skal der sørges for at
begge ledninger tilsluttes lystnetudgange fra den samme fase.
DK
!
!
!
Sikkerhedsadvarsler
!
FORSIGTIG
RISIKO FOR ELEKTRISK STØD
DÆKPLADER MÅ IKKE FJERNES
INGEN BRUGER SERVICERBARE
DELE SERVICE MÅ KUN UDFØRES
AF FAGLÆRTE PERSONER
F0
J
0F
J
Han-stik Hun-stik
Förklaring av Säkerhetssymboler
Denna symbol hänvisar användaren till viktig information som
återfinns i litteraturen som medföljer. Se manualen.
Denna symbol indikerar att livsfarlig spänning finns på insidan.
Det finns inga servicevänliga delar inne i apparaten.
Denna apparat få endast repareras av utbildad personal.
Serviceinstruktioner som anges avser endast kvalificerad
och utbildad servicepersonal.För att minska risken för
elektrisk stöt, utför ingen annan service än den som
återfinns i medföljande driftinstruktionerna, om du ej är
behörig. Överlåt all service till kvalificerad personal.
· För att reducera risken för elektrisk stöt, utsätt inte apparaten för
regn eller fukt.
· Se alltid till att apparaten är ordentligt jordad samt att strömtillförseln
är korrekt utförd.
· Denna apparat måste bli försörjd från ett strömsystem som är försedd
med jordadanslutning samt ha en neutral anslutning som lätt identifierbar.
· Vägguttaget som strömförsörjer apparaten bör finnas i närheten samt
vara lätttillgänglig.
Strömkontakter i länder utanför USA
Apparaten utrustas normalt med en strömkabel med standard IEC gjuten
honkontakt på ena änden samt en standard IEC gjuten hankontakt på den
andra änden. Om man måste avlägsna den gjutna hankontkaten, avyttra
denna kontakt omedelbart på ett säkert sätt. Färgkoden för ledningen är följande:
GRÖN/GUL ledning ansluten till E
(Skyddsjordad ledare)
BLÅ ledning ansluten till N (Neutral ledare)
BRUN ledning ansluten till L (Fas ledare)
Varning! Om enheten har två huvudsakliga elförsörjningar, säkerställ att
båda strömkablarna som är inkopplade i enheten arbetar från samma fas.
S
!
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVERS
NO USER SERVICEABLE PARTS
REFER SERVICING TO QUALIFIED
PERSONNEL ONLY
!
!
Säkerhetsvarningar
LN
E
NL
E
Stickkontakt-Hane Stickkontakt-Hona
Turvamerkkien selitys
Tämä merkki tarkoittaa, että laitteen mukana toimitettu kirjallinen
materiaali sisältää tärkeitä tietoja. Lue käyttöohje.
Tämä merkki ilmoittaa, että laitteen sisällä on vaarallisen voimakas jännite.
Sisäpuolella ei ole mitään osia, joita käyttäjä voisi itse huoltaa.
Huollon saa suorittaa vain alan ammattilainen.
Huolto-ohjeet on tarkoitettu ainoastaan alan
ammattilaisille.Älä suorita laitteelle muita
toimenpiteitä, kuin mitä käyttöohjeissa on
neuvottu, ellet ole asiantuntija.Voit saada sähköiskun.
Jätä kaikki huoltotoimet ammattilaiselle.
· Sähköiskujen välttämiseksi suojaa laite sateelta ja kosteudelta.
· Varmistu, että laite on asianmukaisesti maadoitettu ja että
sähkökytkennät on tehty oikein.
· Laitteelle tehoa syöttävässä järjestelmässä tulee olla
SUOJAMAALIITÄNTÄ ja nollaliitännän on oltava luotettavasti
tunnistettavissa.
· Sähköpistorasian tulee olla laitteen lähellä ja helposti tavoitettavissa.
Sähkökytkentä
Laitteen vakiovarusteena on sähköjohto, jonka toisessa päässä on muottiin
valettu, IEC-standardin mukainen liitäntärasia ja toisessa päässä muottiin
valettu, IEC-standardin mukainen pistoliitin.Jos pistoliitin tarvitsee poistaa,
se tulee hävittää heti turvallisella tavalla.Johtimet kytketään seuraavasti:
KELTA-VIHREÄ suojamaajohdin E-napaan
SININEN nollajohdin N-napaan
RUSKEA vaihejohdin L-napaan
Huom! Jos laitteessa on kaksi verkkojännitteen tuloliitäntää, niiden johdot
on liitettävä verkkopistorasioihin, joissa on sama vaiheistus.
FI
!
!
Turvaohjeita
!
SÄHKÖISKUN VAARA ÄLÄ AVAA
LAITTEEN KANSIA EI SISÄLLÄ
KÄYTTÄJÄLLE HUOLLETTAVIA
OSIA HUOLTO AINOASTAAN
AMMATTILAISEN SUORITTAMANA
VAROITUS
LN
E
NL
E
Pistoliitin Liitäntärasia

MC1000/MC1000-IQ/MC2000/MC2000-IQ Safety Information
Issue 1 Rev 8 Page 5 © 2015 SAM
Símbolos de Segurança
O símbolo triangular adverte para a necessidade de consultar o
manual antes de utilizar o equipamento ou efectuar qualquer ajuste.
Este símbolo indica a presença de voltagens perigosas no interior
do equipamento.As peças ou partes existentes no interior do equipamento
não necessitam de intervenção, manutenção ou manuseamento por parte
do utilizador.Reparações ou outras intervenções devem ser efectuadas
apenas por técnicos devidamente habilitados.
As instruções de manutenção fornecidas são para
utilização de técnicos qualificados. Para reduzir o
risco de choque eléctrico, não devem ser realizadas
intervenções no equipamento não especificadas no
manual de instalações a menos que seja efectuadas
por técnicos habilitados.
· Para reduzir o risco de choque eléctrico, não expor este equipamento
à chuva ou humidade.
· Assegurar que a unidade está sempre devidamente ligada à terra e
que as ligações à alimentação estão correctas.
· O sistema de alimentação do equipamento deve, por razões de
segurança, possuir ligação a terra de protecção e ligação ao
NEUTRO devidamente identificada.
· A tomada de energia à qual a unidade está ligada deve situar-se na
sua proximidade e facilmente acessível.
Ligação da alimentação noutros países que não os EUA
O equipamento é, normalmente, enviado com cabo de alimentação com ficha
IEC fêmea standard num extremo e uma ficha IEC macho standard no extremo
oposto.Se for necessário substituir ou alterar alguma destas fichas, deverá
remove-la e elimina-la imediatamente de maneira segura.
O código de cor para os condutores é o seguinte:
Condutor VERDE/AMARELO ligado a E (Terra)
Condutor AZUL ligado a N (Neutro)
Condutor CASTANHO ligado a L (Vivo).
Atenção: Se a unidade tem duas fontes de alimentação assegurar que os
dois cabos de alimentação estão ligados a tomadas pertencentes à mesma fase.
P
!
!
Avisos de Segurança
LN
E
NL
E
Ficha Livre Tomada Livre
!
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVERS
NO USER SERVICEABLE PARTS
REFER SERVICING TO QUALIFIED
PERSONNEL ONLY

MC1000/MC1000-IQ/MC2000/MC2000-IQ Safety Information
Issue 1 Rev 8 Page 6 © 2015 SAM
Mains Power Supplies
This equipment has two 3-pin IEC power sockets, one for the main power supply unit and one
for the redundant power supply unit.
The power supply is auto switching for input voltages in the ranges of 100 V to 240 V nominal.
No voltage adjustment procedure is required.
Power Cord Supplied
The equipment is shipped with a power cord with a standard molded IEC female plug on one
end and a standard mains plug on the other. If you are required to remove the molded mains
supply plug, dispose of the plug immediately in a safe manner.
The color code for the cord is as follows:
• GREEN/YELLOW lead connected to E (Protective Earth Conductor)
• BROWN lead connected to L (Live Conductor)
• BLUE lead connected to N (Neutral Conductor)
Laser Safety
This product operates with Class 1 laser products.
Ventilation
Although the unit is constructed to meet normal environmental requirements, ensure that
there is a free flow of air at the front, rear, and sides of the unit to dissipate the heat produced
during operation. Installations should be designed to allow for this.
• This equipment has more than one power supply. To reduce the risk of electric
shock, plug each power supply into separate branch circuits employing separate
service grounds.
• Before performing any servicing or maintenance, disconnect and isolate the unit
from the mains input and from any product outputs.
• Do not operate this unit without an earth connection.
Caution: Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
Do not obstruct the ventilation holes on the right-side of the unit. Damage to the equipment
may result.

MC1000/MC1000-IQ/MC2000/MC2000-IQ Safety Information
Issue 1 Rev 8 Page 7 © 2015 SAM
Safety Standards
This equipment conforms to the following standards:
EN60950-1 2006
Safety of Information Technology Equipment
Including Electrical Business Equipment.
UL1419 (3rd Edition) - UL File E193966
Standard for Safety – Professional Video and Audio equipment.
EMC Standards
This equipment conforms to the following standards:
EN 55103-1: 1996 (Environment E4)
Electromagnetic Compatibility, Product family standard for audio, video, audio-visual and
entertainment lighting control apparatus for professional use. Part 1. Emission.
EN 55103-2: 1996 (Environment E2)
Electromagnetic Compatibility, Product family standard for audio, video, audio-visual and
entertainment lighting control apparatus for professional use. Part 2. Immunity.
FCC/CFR 47:Part 15, Class A
Federal Communications Commission Rules Part 15, Subpart B, Class A.
EMC Environment
The product(s) described in this manual conform to the EMC requirements for, and are
intended for use in, the controlled EMC environment (for example, purpose-built broadcasting
or recording studios), and the rural outdoor environment (far away from railways, transmitters,
overhead power lines, etc.) E4.
EMC Performance of Cables and Connectors
SAM products are designed to meet or exceed the requirements of the appropriate European
EMC standards. In order to achieve this performance in real installations it is essential to use
cables and connectors with good EMC characteristics.
All signal connections (including remote control connections) shall be made with screened
cables terminated in connectors having a metal shell. The cable screen shall have a
large-area contact with the metal shell.
Coaxial Cables
Coaxial cables connections (particularly serial digital video connections) shall be made with
high-quality double-screened coaxial cables such as Belden 1694 or BBC type PSF1/2M.
D-type Connectors
D-type connectors shall have metal shells making good RF contact with the cable screen.
Connectors having “dimples” which improve the contact between the plug and socket shells
are recommended.

MC1000/MC1000-IQ/MC2000/MC2000-IQ Contents
Issue 1 Rev 8 Page 8 © 2015 SAM
Contents
Information and Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1. Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.1.1 MC1000-IQ/MC2000-IQ Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.2 Front Panel View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.3 Rear Panel View: MC1000 and MC2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.4 Rear Panel View: MC1000-IQ and MC2000-IQ . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.5 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.6 Block Diagrams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.6.1 MC1000 & MC1000-IQ Video Processing. . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.6.2 MC1000 & MC1000-IQ Audio Processing. . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.6.3 MC2000 & MC2000-IQ Video Processing. . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.6.4 MC2000 & MC2000-IQ Audio Processing. . . . . . . . . . . . . . . . . . . . . . . . . . 17
2. Technical Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.1 Unpacking the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.2 Rack Mounting the Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.3 Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.4 MC1000-IQ/MC2000-IQ Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.4.1 Removing IQ modules/Rears . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4. Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.1 Rear Panel View: MC1000 and MC2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.2 Rear Panel View: MC1000-IQ and MC2000-IQ . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.3 Input and Output Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.3.1 Audio Connection Pin Numbers (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.3.2 Fiber Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.4 Control Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.4.1 GPI Pin Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5. Front Panel Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.1 Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.2 Front Panel Dual Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.3 Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6. Operation Using the Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.1 Turning the Unit On or Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.2 Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.3 Selecting Processing Channels (MC2000/MC2000-IQ only) . . . . . . . . . . . . . . . 29
6.4 Accessing the Main Menu List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.5 Moving Through a Menu List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.6 Selecting Menu Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.7 Adjusting Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.7.1 Adjusting Values with the Control Knob . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.7.2 Adjusting Values with the Alphanumeric Buttons . . . . . . . . . . . . . . . . . . . . 30
6.8 Entering Alphanumeric Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.9 Resetting Menu Options to Preset Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.10 Using Shortcuts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7. System Setup Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.1 System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.2 CVBS (MC1000/MC2000 Only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.2.1 CVBS Decoder A and B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.2.2 CVBS Encoder C and D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

MC1000/MC1000-IQ/MC2000/MC2000-IQ Contents
Issue 1 Rev 8 Page 9 © 2015 SAM
7.2.3 Routing a Processing Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.3 Audio Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.3.1 AES 1–4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.3.2 Analog Group 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.4 Audio Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
7.4.1 AES Input Type (Option, MC1000/MC2000 Only). . . . . . . . . . . . . . . . . . . . 36
7.4.2 Analog In ADC Headroom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
7.4.3 Analog Out DAC Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
7.5 Genlock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.5.1 Source Ch 1 and Ch 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.5.2 Reference Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.5.3 Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.6 Dolby. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7.6.1 Dolby Ch 1 and Ch 2 (Option). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.7 Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
7.7.1 Ethernet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
7.7.2 RollCall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7.8 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.8.1 Lock Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.8.2 Current Channel (MC2000/MC2000-IQ Only). . . . . . . . . . . . . . . . . . . . . . . 42
7.8.3 Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.8.4 Headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.9 Memories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.9.1 Memory Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.9.2 Save Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.9.3 Recall Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.9.4 Reset to Defaults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.9.5 Factory Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.9.6 Memory Name. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
7.10 Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.11 Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.12 Calibration (MC1000/MC2000 Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.12.1 CVBS Decoder/Encoder A–D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.12.2 CVBS Encoder C and D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
8. Channel Operation Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8.1 Home. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8.2 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8.2.1 Input Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8.2.2 Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8.3 Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.3.1 Output Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.3.2 Current Output Standard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.3.3 Blanking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.3.4 Test Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.3.5 Default Output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.3.6 Scrolling Caption Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.3.7 Freeze. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.3.8 Legalization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.3.9 Logo Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.4 Video. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8.4.1 Proc Amp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8.4.2 Enhance – Nonlinear Enhancer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
8.4.3 Enhance – Conversion Aperture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
8.4.4 Noise Reduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
8.5 Convert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
8.5.1 Motion Processing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
8.5.2 Up Conversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
8.5.3 Input Cadence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
8.5.4 Output Cadence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

MC1000/MC1000-IQ/MC2000/MC2000-IQ Contents
Issue 1 Rev 8 Page 10 © 2015 SAM
8.6 ARC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
8.6.1 Sync Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
8.6.2 Signaling Detected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
8.6.3 Sidebar Keying & Output Crop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
8.6.4 Post Scaling Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
8.6.5 Scaler Config – Presets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
8.6.6 Scaler Config – Input Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
8.6.7 Scaler Config – Output Config. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
8.6.8 Input Signaling ARC Conversions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.6.9 Output Signaling Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
8.6.10 Output Signaling Config – Force Mode Config . . . . . . . . . . . . . . . . . . . . . 75
8.7 Audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
8.7.1 Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
8.7.2 Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
8.7.3 Shuffle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
8.8 Timecode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
8.8.1 Source (HD/SD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
8.8.2 Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
8.8.3 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
8.8.4 VITC Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
8.8.5 Output Line (525) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
8.8.6 Output Line (625) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
8.8.7 Output Line Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
8.8.8 Input Trigger Entry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
8.8.9 Output Timecode Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
8.8.10 Timecode Entry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
8.8.11 Timecode Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
8.8.12 On Timecode Loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
8.8.13 Non Drop Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
8.9 Metadata . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
8.9.1 Closed Captions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
8.9.2 Multi-line WST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
8.10 Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
8.10.1 Memory Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
8.10.2 Save Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
8.10.3 Recall Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
8.10.4 Reset to Defaults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
8.10.5 Memory Name. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
8.11 RollCall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
8.12 Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
9. Operation Using the RollCall Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
9.1 Opening the System Setup Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
9.2 Opening the Channel Operation Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
9.3 Navigating Screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
9.4 Unit Status Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
9.5 Using the Web Applet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
10. RollCall Control Panel System Setup Screens . . . . . . . . . . . . . . . . . . . . . . . . . . 93
10.1 Genlock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
10.1.1 Source Ch 1 and Ch 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
10.1.2 Current Reference Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
10.1.3 Channel 1 and Channel 2 Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
10.2 Audio Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
10.2.1 AES Output 1–4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
10.2.2 Analog Output 1–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
10.3 Audio Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
10.3.1 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
10.3.2 Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
10.4 CVBS (MC1000/MC2000 Only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

MC1000/MC1000-IQ/MC2000/MC2000-IQ Contents
Issue 1 Rev 8 Page 11 © 2015 SAM
10.4.1 CVBS Decoder A and B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
10.4.2 CVBS Encoder C and D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
10.4.3 Routing a Processing Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
10.5 Dolby. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
10.5.1 Dolby Ch 1 and Ch 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
10.6 Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
10.6.1 Ethernet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
10.6.2 RollCall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
10.7 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
10.7.1 Current Channel (MC2000/MC2000-IQ Only). . . . . . . . . . . . . . . . . . . . . 105
10.7.2 LCD Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
10.7.3 Headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
10.8 Memories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
10.8.1 Creating and Saving Memories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
10.8.2 Recall Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
10.8.3 Reset to Defaults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
10.8.4 Factory Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
10.9 Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
10.10 Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
10.11 CVBS Calibration (MC1000/MC2000 Only). . . . . . . . . . . . . . . . . . . . . . . . . . 109
10.11.1 CVBS Decoder A and B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
10.11.2 CVBS Encoder C and D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
11. RollCall Control Panel Channel Operation Screens . . . . . . . . . . . . . . . . . . . . . 110
11.1 Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
11.1.1 Input Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
11.2 Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
11.2.1 Output Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
11.2.2 Freeze . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
11.2.3 Legalization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
11.2.4 Test Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
11.2.5 Blanking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
11.2.6 Default Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
11.2.7 Scrolling Caption Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
11.2.8 Logo Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
11.3 Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
11.3.1 Proc Amp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
11.3.2 Nonlinear Enhancer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
11.3.3 Conversion Aperture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
11.3.4 Noise Reduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
11.4 Convert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
11.4.1 Up Conversion. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
11.4.2 Motion Processing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
11.4.3 Input Cadence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
11.4.4 Output Cadence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
11.5 ARC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
11.5.1 Sync Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
11.5.2 Signaling Detected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
11.5.3 Sidebar Keying & Output Crop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
11.5.4 Post Scaling Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
11.5.5 Scaler Config – Presets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
11.5.6 Scaler Config – Input Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
11.5.7 Scaler Config – Output Config. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
11.5.8 Input Signaling ARC Conversions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
11.5.9 Output Signaling Config. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
11.5.10 Output Signaling Config – Force Mode Config . . . . . . . . . . . . . . . . . . . 137
11.6 Audio Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
11.6.1 Input Pairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
11.6.2 Process Pairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
11.7 Audio Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

MC1000/MC1000-IQ/MC2000/MC2000-IQ Contents
Issue 1 Rev 8 Page 12 © 2015 SAM
11.7.1 Gain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
11.7.2 Tone Frequency. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
11.7.3 Dolby E Alignment Offset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
11.7.4 Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
11.8 Audio Shuffle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
11.8.1 Process Pairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
11.8.2 Output Pairs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
11.8.3 Invert Phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
11.8.4 Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
11.9 Timecode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
11.9.1 Source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
11.9.2 Processing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
11.9.3 Embedding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
11.10 Metadata . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
11.10.1 Closed Captions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
11.10.2 Multi-line WST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
11.11 Memories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
11.11.1 Creating and Saving Memories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
11.11.2 Recall Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
11.11.3 Reset to Defaults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
11.12 RollCall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
11.13 Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Appendix A. Conversion Operational Examples. . . . . . . . . . . . . . . . . . . . . . . . . . . 155
A.1 MC1000/MC1000-IQ Frame Rate Conversion . . . . . . . . . . . . . . . . . . . . . . . . . 155
A.2 MC2000/MC2000-IQ Frame Rate Conversion . . . . . . . . . . . . . . . . . . . . . . . . . 156
A.3 MC1000 Frame Rate Conversion – SD Composite Video . . . . . . . . . . . . . . . . 157
A.4 MC2000 Frame Rate Conversion – HD SDI to SD Composite Video. . . . . . . . 158
A.5 Using Decoded Dolby E Audio when Converting Video . . . . . . . . . . . . . . . . . . 159
A.5.1 From the Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
A.5.2 From the RollCall Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
A.6 Transcoding Dolby E Audio when Converting Video . . . . . . . . . . . . . . . . . . . . 160
A.6.1 From the Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
A.6.2 From the RollCall Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Appendix B. Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
B.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
B.2 General Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
B.2.1 Performing a Factory Reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
B.2.2 PSU Fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
B.3 Video Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
B.3.1 Video Quality Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
B.3.2 No Video Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
B.3.3 Front Panel Display is Blank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
B.3.4 Composite Input Problems (MC1000/MC2000 Only) . . . . . . . . . . . . . 164
B.3.5 Hardware or Software Fault?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
B.3.6 Video Troubleshooting Flowchart . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
B.4 Audio Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
B.4.1 SD Embedded Audio Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
B.4.2 Testing Audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
B.5 Timecode Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
B.5.1 Testing Timecode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
B.6 Software Upgrade Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

MC1000/MC1000-IQ/MC2000/MC2000-IQ Introduction
Issue 1 Rev 8 Page 13 © 2015 SAM
1. Introduction
1.1 Description
The KudosPro MC1000/MC1000-IQ/MC2000/MC2000-IQ units are motion compensated
standards converters for a range of applications including:
• International program distribution
• Content re purposing for Internet, TV, and Blu-ray distribution
• International TV and video production
These units are ideal for customers who wish to perform high-quality conversions from one
frame rate to another, such as 50 Hz to 60 Hz.
1.1.1 MC1000-IQ/MC2000-IQ Only
KudosPro units with the IQ suffix can be fitted with up to two IQ modules and rear panels.
When ordered with the KudosPro unit the IQ modules will be factory fitted before shipping.
Any IQ modules fitted are controlled using RollCall and cannot be controlled from the front
panel of the MC1000-IQ/MC2000-IQ unit.
For a full list of compatible IQ modules and rears see the Recommended Modules for
KudosPro-IQ Units Application Note under the “Support” tab at:
http://www.snellgroup.com/products/conversion-and-restoration/conversion/kudospro/
1.2 Front Panel View
The front panel provides a user-friendly interface for complete control of the unit.
For information about front panel features, see page 27. For information about operating the
front panel, see page 29.
1.3 Rear Panel View: MC1000 and MC2000
The rear panel accommodates a CVBS option with AES unbalanced audio and composite
video connections.
1.4 Rear Panel View: MC1000-IQ and MC2000-IQ
The rear panel has space for up to two IQ module rear panels. CVBS and unbalanced AES
inputs and outputs are not supported.

MC1000/MC1000-IQ/MC2000/MC2000-IQ Introduction
Issue 1 Rev 8 Page 14 © 2015 SAM
1.5 Features
• Motion compensated SD/HD/3G frame rate conversion.
• SD/HD/3G up, down, and cross conversion.
• Independent dual-channel conversion (MC2000/MC2000-IQ only).
• Optional Composite input and output (MC1000/MC2000 only).
• Flexible video and audio i/o configuration.
• 16-channel embedded audio processing for each video channel.
• Optional one channel (MC1000/MC1000-IQ) or two channels (MC2000/MC2000-IQ)
of Dolby E decode/transcode.
• Dolby E guard-band alignment.
• Up to two IQ modules can be fitted within the unit (MC1000-IQ/MC2000-IQ only).
• Fiber input and output (option).
• HDMI monitor output.
• Dual PSU as standard.
• Relay bypass on primary SDI inputs.
• Automatic Aspect Ratio Conversion (AFD, VI, L23).
• Powerful picture enhancement tools.
• User-friendly front panel.
• RollCall and web interface remote control.
• Closed caption, teletext subtitle, and timecode handling.
• Insertion of SMPTE ST352 payload identification for psf standards

MC1000/MC1000-IQ/MC2000/MC2000-IQ Introduction
Issue 1 Rev 8 Page 15 © 2015 SAM
1.6 Block Diagrams
1.6.1 MC1000 & MC1000-IQ Video Processing
The MC1000 and MC1000-IQ offer one channel of frame rate or format conversion with a
choice of four SDI inputs and four SDI outputs.
MC1000 only: The CVBS I/O is restricted by design, only CVBS A1 and A2 can be used as
inputs to the MC1000, and only CVBS B1 and B2 can be used as outputs. Other connectors
are present on the rear panel, such as CVBS C1 and C2, and CVBS D1 and D2, but these
cannot be used.
1.6.2 MC1000 & MC1000-IQ Audio Processing
Note:
• The MC1000-IQ unit does not have CVBS inputs or outputs.
• If the optional SFP connectors are fitted as receivers, they will not be available as
transmitters. Likewise, if fitted as transmitters, they will not be available as
receivers.
Not
MC1000-IQ
Not
MC1000-IQ
Note:
The MC1000-IQ unit does not have unbalanced AES inputs or outputs.
Not MC1000-IQ,
Balanced AES
Only
Not MC1000-IQ,
Balanced AES
Only

MC1000/MC1000-IQ/MC2000/MC2000-IQ Introduction
Issue 1 Rev 8 Page 16 © 2015 SAM
1.6.3 MC2000 & MC2000-IQ Video Processing
The MC2000 and MC2000-IQ offer two channels of frame rate or format conversion with a
choice of four SDI inputs and four SDI outputs. SDI outputs A1 and A2 are used for video
processing channel A, and SDI outputs B1 and B2 are used for video processing channel B.
MC2000 only: The CVBS I/O is restricted by design, only CVBS A1, A2, B1, and B2 can be
used as inputs to the MC2000, and only CVBS C1, C2, D1, and D2 can be used as outputs.
Note:
• The MC2000-IQ unit does not have CVBS inputs or outputs.
• If the optional SFP connectors are fitted as receivers, they will not be available as
transmitters. Likewise, if fitted as transmitters, they will not be available as
receivers.
Not
MC2000-IQ
Not
MC2000-IQ Not
MC2000-IQ
Not
MC2000-IQ

MC1000/MC1000-IQ/MC2000/MC2000-IQ Introduction
Issue 1 Rev 8 Page 17 © 2015 SAM
1.6.4 MC2000 & MC2000-IQ Audio Processing
Where two Dolby E options are fitted (MC2000/MC2000-IQ only), the first decode/transcode
path (Decode 1/Encode 1 in the block diagram) is only available as embedded audio on SDI
outputs A1 and A2, and can be routed to any AES or analog audio encoder. The second
decode/transcode path (Decode 2/Encode 2 in the block diagram) is only available as
embedded audio on SDI outputs B1 and B2, and can be routed to any AES or analog audio
encoder.
It is not possible to cross-route the Dolby option outputs. For example, you cannot embed
decoded Dolby D or E audio from the second decode/transcode path (Decode 2/Encode 2 in
the block diagram) to embedded audio on SDI outputs A1 and A2.
Note:
The MC2000-IQ unit does not have unbalanced AES inputs or outputs.
Not MC2000-IQ,
Balanced AES Only
Not MC2000-IQ,
Balanced AES Only

MC1000/MC1000-IQ/MC2000/MC2000-IQ Technical Specification
Issue 1 Rev 8 Page 18 © 2015 SAM
2. Technical Specification
Signal Inputs
Serial digital 4 x 75 Ohm SD/HD/3Gb/s serial digital with embedded audio
Input standards:
3Gb/s HD-SDI, SMPTE425 level A, dual-link level B
1.5 Gbit/s HD-SDI SMPTE292M/SMPTE299M
270 Mbit/s SD-SDI SMPTE259M
Composite Not MC1000-IQ/MC2000-IQ:
PAL, NTSC, NTSC-J, PAL-M, PAL-N, N4.4, SECAM
12-bit ADCs
Analog component YC
Reference 1 x loop-through HDTV Tri-sync/SD Bi-sync (black & burst) SMPTE 240M/274M, with
auto selection dependant on output standard
Audio AES 4 x balanced AES inputs via 25-way D-type
Not MC1000-IQ/MC2000-IQ:
4 x unbalanced AES inputs via 4 x BNC
Audio Analog 4 x stereo analog inputs via 25-way D-type
Signal Outputs
Serial digital 4 x 75 Ohm SD/HD/3Gb/s serial digital with embedded audio
Output standards:
3Gb/s HD-SDI, SMPTE425 level A, dual-link level B
1.5 Gbit/s HD-SDI SMPTE292M/SMPTE299M
270 Mbit/s SD-SDI SMPTE259M
Payload Identification
Codes Insertion of SMPTE ST-352 payload identification codes for psf standards
Composite Not MC1000-IQ/MC2000-IQ:
PAL, NTSC, NTSC-J, PAL-M, PAL-N
12-bit ADCs
Analog component YC
Audio AES 4 x balanced AES outputs via 25-way D-type
Not MC1000-IQ/MC2000-IQ:
4 x unbalanced AES outputs via 4 x BNC
Audio analog 2 x stereo analog outputs via 25-way D-type

MC1000/MC1000-IQ/MC2000/MC2000-IQ Technical Specification
Issue 1 Rev 8 Page 19 © 2015 SAM
Standards
Input standard (auto detect) 525 59i
625 50i
720 23/24/25/29/30/50/59/60p
1080 50/59/60i
1080 23/24/25/29/30p
1080 50/59/60p level A, Dual Link Level B
1080 23/24/25/29psf, with film detection and processing
Output standard 525 59i
625 50i
720 23/24/25/29/30/50/59/60p
1080 50/59/60i
1080 23/24/25/29/30p
1080 50/59/60p level A, Dual Link Level B
1080 23/24/25/29psf, with film detection and processing
Conversion Functions
Modes SD/HD/3Gb/s motion compensated standards conversion
Up, down, and cross conversion
Conversion Linear/motion compensated
Conversion processing Still process: Detects still images and applies an aperture with full (progressive)
vertical frequency response
Enhanced still: Adds field motion detection to still process. Prevents artifacts on
moving repetitive patterns
Aspect ratio conversion
(manual or auto) AFD (SMPTE 2016), VI (RP186), WSS (L23)
SD input format Normal 4:3, Anamorphic 16:9, Letterbox 14:9, Letterbox 16:9
SD output format Normal 4:3, Anamorphic 16:9, Letterbox 14:9, Letterbox 16:9
Auto zoom On/Off
Manual zoom Zoom +/- 20%
Safe area marker Off, 16:9, 4:3
Metadata Closed caption CE608 <> CE708
Timecode conversions
Teletext subtitles WST/RDD8 conversion

MC1000/MC1000-IQ/MC2000/MC2000-IQ Technical Specification
Issue 1 Rev 8 Page 20 © 2015 SAM
Audio Functions
Analog audio Four pairs of analog inputs, individually available to any or all processing channels
Two groups (two pairs) of analog outputs, separately assignable to any processing
channel
Headroom: +24 dBu, balanced connection
AES audio Four AES audio inputs, individually available to any or all processing channels
Four AES audio outputs (48 kHz), separately assignable to any processing channel
AES input is auto-detected as PCM (32 to 96 kHz) or non-PCM (48 kHz locked to
relevant video input)
Embedded audio Each processing channel includes 16-channel embedded audio processing
PCM audio processing includes channel-level gain and delay compensation, as well
as pair level routing with L/R swap and phase invert feature
Non-PCM processing features pair level routing and delay compensation. Dolby E
data is passed with a delay to match the video and with co-timed audio frame drop or
repeat
Dolby E MC1000/MC1000-IQ: Optional single channel Dolby E decode/transcode
MC2000/MC2000-IQ: Optional one or two channels of Dolby E decode/transcode
Throughput delay
Video processing delay
field = 16.7 or 20 ms
frame = 33.3 or 40 ms
With scaling active in same frame rate:
Ref lock / Free run between 3 and 5 fields + ~200 us, Input lock (SDI) 3 fields + 1 ms
With same standard in & out and Sync mode = Enabled:
Ref lock / Free run between ~200us and 1 frame + ~200 us, Input lock (SDI) ~1 ms
Frame rate conversion:
Any lock mode, 110 ms typical
Audio processing delay
(Audio delay = 0 ms)
With scaling active in same frame rate:
Ref lock / Free run 1.5 frames, Input lock 1 frame + 1 ms
With same standard in & out and Sync mode = Enabled:
Ref lock / Free run 0.5 frames, Input lock ~3ms
Frame rate conversion:
Any lock mode, 110 ms typical
