Snotty Three User manual

Battery Warnings
Battery Operated
Nasal Aspirator
Battery Operated
Nasal Aspirator
aterproof and washable
W
educed noise level
R
arge mucus cup with easy clean-up
L
rgonomic design
E
tands upright
S
sizes of silicone tips
2
attery operated (AA)
B
N
o hidden costs
o ongoing replacement parts reqired
N
MEDICALDEVICE
0120
USER MANUAL SNOTTY THREE
SNOTTY
THREE
1 2
1
2
3
4
Contents
Notes
1 Main Unit
2 Sizes of Silicone Tips
(small and large)
1 Instruction Manual
2 Spare Silicone Rings
Parts Description
Warnings
Before using this aspirator, please read all the instructions in this manual.
Please keep this manual for reference as it contains important information.
1. Do not allow children to play with the aspirator as it is not a toy. Keep the
aspirator out of children’s reach to prevent small parts and accessories from being
swallowed by them accidentally.
3. Always clean the aspirator if the accumulated volume of mucus is over the safe capacity
of the mucus cup (about 4 mL). Always clean and dry thoroughly before and after
each use, please refer to the section of “Clean Instructions.”
4. Do not insert the silicone tip into the nostril too deeply, just to seal the nostril.
5. Do not use it on the baby for a long time, a few seconds in each nostril will be enough.
7. In the case of infection, fever, nasal irritation, or hemorrhage, please stop using the
aspirator and consult your helath professional.
8. This aspirator is restricted for personal use only.
9. The silicone tip is the applied part.
aspirator farther then instructed in this manual.
11. Replace the batteries when the suction power becomes weak during use.
12. Duty cycle：30 seconds ON / 2 minutes OFF.
13. Your product warranty is 12 months on your SNOTTY THEE nasal aspirator but the
expected service life of the device is three years under normal usage.
1. Use alkaline batteries only.
2. Only batteries of the same or equivalent type as recommended should be used.
3. Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.
4. Do not use a mix of used and new batteries.
5. Batteries should be inserted with the correct polarity.
6. Used and exhausted batteries should be removed from the device.
7. Be sure that all contact surfaces are clean before installing batteries.
8. There is a risk of explosion if the batteries are replaced by an
incorrect type.
9. Remove batteries if the device will not be used for a long period
of time; batteries may be removed easily through the hole of
the battery compartment.
Large nose - Silicone Tip
Mucus Cup
Silicone Ring
Lower Cover
Upper Cover
Collar
Button
REF
INTENDED USE : Quickly and gently removes excess mucus
from your child’s nasal cavity
Small nose - Silicone Tip
SL
Guidance and manufacturer’s declaration
SNOTTY THREE electromagnetic emissions.
Emissions Complianc Electromagnetic environment - guidance
RF emissions CISPR 11 Group 1 SNOTTY THREE uses RF energy only for its internal
function. Therefore, its RF emissions are very low and
are not likely to cause any interference in nearby
electronic equipment.
RF emissions CISPR 11 Class B
Harmonic emissions
IEC 61000-3-2
Not
applicable
emissions IEC 61000-3-3
Not
applicable
SNOTTY THREE is suitable for use in all establishments,
including domestic establishments and those directly
connected to the public low-voltage power supply
network that supplies buildings used for domestic
purposes.
How to aspirate your child
Step Comments
One Hydrate your child Always make sure your child is well hydrated
and when the weather is warm.
Two Humidify bedroom, to avoid dry mucus.
Three Use nasal saline spray The saline will loosen up the mucus and enable
better extraction. Spray some saline into child’s
nose 1-2 minutes before aspiration.
Four Aspirate in bath or shower Your SNOTTY THREE is fully waterproof, so why
not take the advantage of the additional vapors
in the shower, bath or even swimmingpool.
Five Consult ALWAYS consult a health professional if you are
uncertain, if your child has undergone any type
of treatment, surgery or is on medication, or the
duration of the illness is too long.
Become a SNOTTY distributor
Your three easy steps to earn extra money
Sign up
Order
Sell
Sign up to become a distributor. You do this via email
we do not require contracts or lengthy legal procedures.
You DO NOT have to have a business or your own ABN,
we will set up an account for you anyhow and allow you to purchase
aspirators from us at wholesale prices.
We will promote you on our web directing local customers to you!
Build your network, sell withing your local community, markets, friends
and relatives, sell on ebay or even via facebook.
Place your order/orders whenever you like, as often or seldom
as required. Order any aspirators you like, we do not have set packages,
* For sales via internet pricing guidelines do apply
** Stock levels and availablity may vary with seasons and customer demand,
as such not all models may be available at all times
3 4
Battery
Battery
TGA Registered
Some basic handy steps how to better aspirate your child.
SNOTTY independent distribution network is thriving, to become a distributor please email us on:
[email protected]
Your chance to increase your income is just an email away!
www.snotty.com.au
2. This aspirator is designed to clean noses; do not use it in mouth or ears.
in or near the nose.

Choose the suitable silicone tip based on the size of
patient’s nostrils.
Be sure to place the silicone tip
securely on the mucus cup.
Gently insert the silicone tip into patient’s nostril.
Do not insert it too deeply, but enough to seal the nose.
Press the button for a few seconds
to collect mucus. Stop pressing the
aspirator and the power will stop.
If the accumulated volume of mucus is near the safe
capacity of the mucus cup (about 4 mL), follow the
cleaning instructions on the next page.
Do not use the aspirator if the extracted mucus level is
near the opening channel (indicated by the arrow).
5 6 7 8
Wash the parts thoroughly with clean water
and soap. Rinse the collar under the tap.
Dry the parts before assemby.
Reassemble all parts as shown below:
*Properly align the positioning
hole on the mucus cup.
Instructions for Use Cleaning Instructions
Operation, Storage & Transportation
Environment Information
Be sure that the upper and lower
cleaning the aspirator.
Bend the mucus cup gently in a downward
direction to remove it from the collar.
Operation Environment
Storage & Transportation
Environment
Temperature: 5°C~40°C
Humidity: 15% ~ 93%
Atmospheric Pressure: 700~1060 hPa
Temperature: -10°C~50°C
Humidity: ≦93%
Atmospheric Pressure: 700~1060 hPa
Remove the silicone tip.
pump of the aspirator in the direction
as shown below in picture 4.
Remove the aspirator from water once the
cleaning is completed. Keep pressing the
button for approximately 30 seconds until
the inner pump is empty and dry.
Change the water and repeat step 1-3
several times if required.
Separate the upper cover
away from the lower cover in a
straight direction. Do not bend
the covers by brute force as
bending will casue damage .
Insert 2 x 1.5V AA alkaline
batteries with the correct
polarity as shown.
Remove batteries
if the device will
not be used for a
long period of
time.
Check to make sure that the
two silicone rings are properly
seated on the grooves. Close
the covers until you hear
a “clicking” sound.
6
7
8
1231
2
3
4
The silicone rings do not have to be removed and washed each time you
use the aspirator, but it is recommended this is done occasionally.
5
4
5
6
7
4
4
5
6
Dry the collar and reassemble the aspirator.
7
Battery
Battery
Battery
Battery
When the accumulated volume of mucus is over the safe capacity of the
mucus cup during use of the device, or if you see mucus dripping out of
the air vent on the back side of the collar, please follow instructions below
Be sure that the upper and lower covers
Have the collar immersed in clean water
as shown. Press the button for 15 seconds
and the inner pump will be cleaned.
Remove the silicone tip and mucus cup.
11
2
3
3
Silicone Tip
LARGE nose
Silicone Tip
SMALL nose
“Click”
“Click”
Positioning
Hole
MEDICAL DEVICE
This device conforms to the provisions of the EC directive MDD (93/42/EEC).
The following standards apply to the design and manufacture of the device:
SNOTTY THREE -20160401-V1
APPLIED STANDARDS:
MANUFACTURER
Perpetus Pty Ltd
ABN 49 142 811 069
T/A SNOTTY
PO Box 111
Labrador QLD 4215
Australia
BATCH CODE
SEE THE LOT LABEL AT THE BOTTOM
OF THE DEVICE
WASTE FROM
ELECTRICAL AND
ELECTRONIC
EQUIPMENT (WEEE)
CONSULT INSTRUCTIONS FOR USE
Type BF applied part
Protection against solid foreign objects
of 12.5mm ø and greater and protection
against vertically falling water drops
when enclosure tilted up to 15˚
INTERNATIONAL DISTRIBUTORS
New Zealand
Ultimax Company Limited
E-mail: [email protected]
Malaysia
Infomedia
E-mail: [email protected]
0120
LOT
IP22
• IEC / EN 60601-1 Medical electrical equipment – Part 1: General requirements for
basic safety and essential performance
• IEC / EN 60601-1-2 Medical electrical equipment – Part 1-2: General requirements
for basic safety and essential performance - Collateral standard: Electromagnetic
compatibility - Requirements and tests
• IEC/EN 60601-1-6 Medical Electrical Equipment – Part 1-6: General Requirements
for Safety - Collateral Standard: Usability
• IEC 60601-1-11 Medical electrical equipment – Part 1-11: General requirements
for basic safety and essential performance – Collateral standard: Requirements
for medical electrical equipment and medical electrical systems used in the
home healthcare environment
• EN ISO 10993-5 Biological evaluation of medical devices – Part 5: Tests for in vitro
cytotoxicity
• EN ISO 10993-10 Biological evaluation of medical devices – Part 10: Tests for
irritation and delayed-typed hypersensitivity
2016
