Socket Wireless LAN CF Card 11Mbps User manual

11Mbps Wireless LAN CF
Card
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

Date ofIssue: January.25th, 2002
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

Technical Support
The firmware and driver version of the Wireless LAN CF Card isdisplayed on the utility
About tab. Users could download and upgrade the latest software version from the
supplier’sweb site or refer to the sales contactfor the latest software information. Ifyou
have difficultyresolvingthe problem whileinstallingor usingthe Wireless LAN CFCard,
please contact the supplier for support.
About This Manual
11Mbps Wireless LAN CF Card User Manualisfirstpublished on January,2002. The
manual includes procedures for the setup of the 11Mbps Wireless LANCF Card under
WindowsCE 3.0, PocketPC 2002, Windows XP, Windows 2000, Windows 98, Windows
ME and WindowsNT. Take amoment to read throughthismanualand familiarize
yourself with wireless technology.
Software Information
The software packageworks onlyon the Wireless LANCF Card and Wireless LANPCMCIA
Card, and contains the followingversions of driver andutilityprograms.
For CE Windows System:
Ø Driver -- Version 1.1.0and above
Ø Utility-- Version 1.1.0 and above
For Windows XP/2000/NT/98/ME Systems:
Ø Driver -- Version 4.0.7
Ø Utility-- Version 4.0.7
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

FCC Information
Thisdevice complies with Part15 of the FCC Rules. Operation is subject to the followingtwo
conditions: (1) this device maynot cause harmfulinterference, and (2) this device must accept
anyinterference received; includinginterference thatmaycause undesired operation.
Federal Communications Commission (FCC) Statement
ThisEquipment has been tested and found to complywith the limits for aClass Bdigitaldevice,
pursuant to Part15 of the FCC rules. These limits are designed toprovide reasonableprotection
against harmful interference in aresidential installation. This equipmentgenerates, uses and can
radiate radiofrequencyenergyand, if not installed and used inaccordance withthe instructions,
maycause harmful interference to radiocommunications. However, there is no guarantee that
interference will not occur inaparticular installation. Ifthis equipment does cause harmful
interference to radioor television reception, which can be determined byturningthe equipment
off and on, the user is encouraged to tryto correctthe interference byone or more of the
followingmeasures:
- Reorient or relocate the receivingantenna.
- Increase the separation between the equipmentand receiver.
-Connect the equipment intoan outlet on acircuitdifferent from that towhich the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC RF Radiation Exposure Statement:
1. This Transmitter mustnot be co-located or operatingin conjunction with anyother antenna
or transmitter.
2. This equipmentcomplies with FCC RF radiation exposure limits setforth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of
20 centimeters between the radiator and your body.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

Table of Contents
Chapter 1 About Wireless LAN CF Card............................................1
1-1Featuresand Benefits................................................................................1
1-2Applications..............................................................................................2
1-3Product Kit................................................................................................3
1-4LEDInformation.......................................................................................3
Chapter 2 Install the CF Card for Pocket PC 2002/WinCE3.0..........4
2-1System Requirements.................................................................................4
2-2Before GettingStarted...............................................................................4
2-3Install the SetupUtility.............................................................................7
2-4Install the Wireless LAN CF Card.............................................................9
Chapter 3 Setthe CF Cardunder Pocket PC 2002/WinCE3.0.........10
3-1UsingWireless LAN Utility Under Pocket/HandheldPC........................10
Chapter 4 Install the CF Card for Windows XP/2000/NT/98/ME...18
4-1System Requirements...............................................................................18
4-2Insert the WirelessLAN CFCard...........................................................18
4-3Set up Wireless LAN CF Card for WindowsXP......................................19
4-4Set up Wireless LAN CF Card for Windows2000...................................24
4-5Set up Wireless LAN CF Card for WindowsNT 4.0................................27
4-6Set up Wireless LAN CF Card for Windows98/ME................................30
4-7 Remove the WirelessLAN PC Card........................................................33
Chapter 5 Set the CF Cardunder Windows XP/2000/NT/98/ME...35
5-1Install the WLAN Utility..........................................................................35
5-2Usingthe WLAN Utility...........................................................................37
LimitedWarranty.................................................................................47
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-1-
About Wireless LAN CF Card 1
The 11Mbps IEEE 802.11b Wireless LANCF Card is astandard CFtype interface adapter
integrated withwireless LAN technology.Itprovides you the easiest and fastest waytoaccess
your wireless and wired network. The Wireless LAN CFCard, which utilizes the latest
advancement of PC industry–CompactFlash technology,allows you toinstall and use the card
easier than ever before. 11Mbps data rategives equivalentEthernet speed to access corporate
network or the Internet in awireless environment. When installed, 11Mbps Wireless LAN CF
Card is able to communicate with any802.11 and 802.11b compliantproducts.
1-1 Features and Benefits
1. FullyIEEE 802.11b compatible.
2. Direct Sequence Spread Spectrum (DSSS) technologyprovides robust,
interference-resistant and secure wireless connection.
3. Supports 1, 2, 5.5 and 11 Mbps data rate.
4. Workingrange up to 800 ft. in an open environment.
5. Seamless connectivityto wired Ethernetand PC network LAN’s augments existing
networks quicklyand easily.
6. Greater flexibilityto locate or move networked PCs.
7. Wireless connection without the cost of cabling.
8. Easyto install and user friendly, justPlugand Play.
9. Low power consumption.
10. Supports a varietyof operatingsystems (Pocket PC 2002, WinCE/Win98/ME/NT/2000/XP)
11. 64-bitand 128-bits WEP encryption capable.
12. Provides Window-based Diagnostic Tools, mostnotably, Site Survey, Link QualityTest and
Access Point Browser.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-2-
1-2 Applications
11Mbps Wireless LAN CFCard offers a fast, reliable and cost-effective solution for wireless
clientaccess to the network in applications like these:
1. Remote access to corporate network information
E-mail, file transferringand terminal emulation.
2. Difficult-to-wire environments
Historical or old buildings, asbestos installations, and open area where wiringis difficultto
deploy.
3. Frequently changing environments
Retailers, manufacturers and those who frequentlyrelocate the workplace.
4. Temporary LANs for special projects or peak time
C1. Trade shows, exhibitions and construction sites where atemporarynetwork willbe
practical.
C2. Retailers, airline and shippingcompanies need additionalworkstations duringpeak
period.
C3. Auditors requiringworkgroups atcustomer sites.
5. Access to database for mobile workers
Doctors, nurses, retailers, accessingtheir database while beingmobile inthe hospital, retail
store or office campus.
6. SOHO(Small Office and Home Office) users
SOHO users who need easyand quick installation of a small computer network.
7. High security connection
The secure wireless network can be installedquicklyand provide flexibility.(Please refer
to page14 (under Windows CE) and 40 (under WindowsXP/2000/98/ME/NT) for
encryption configuration.)
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-3-
1-3 Product Kit
11Mbps Wireless LAN CFCard comes with the followingitems. Please go through each item
below.If anylisted item is notincludedor found damaged, please contact your local dealer.
11MbpsWireless LANCFCard
l 11Mbps Wireless LAN CFCard………………….…………………….….….. x1
l Wireless LANCF Card Product CD…………………..…………………….... x1
l 11Mbps Wireless LAN CFCard QIG……….…………..…………………..…x1
l CF/PCMCIA Adapter (Optional)…………………………………………….…x1
1-4 LED Information
The 11Mbps Wireless LANCF Card has one LED indicator. The behavior of the indicator is
described as below:
LINK
Link LED
n Solid Green –Associated with the
Access Point or Ad-Hoc wireless
workstation.
n Blinking Green –Not connecting to
the AccessPoint orPow
er Savemode
enabled.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-4-
2
This chapter describes the instructions that guide you through the proper hardware installation of
your 11Mbps Wireless LANCFCard for Pocket PC 2002 and Windows CE 3.0 operating
system.
2-1 System Requirements
Inorder to use the 11Mbps Wireless LANCF Card, your computer must be equipped with the
following:
Pocket PC (PPC) Handheld PC (HPC)
n Compaq: IPAQ(CPU: StrongARM) ■Sharp:Telios (MIPS R3000)
n HP:Jonada 525 and 548 (CPU: SH3) ■HP: Jornada 720 (StrongARM)
n Casio:All models (MIPS R4000) ■Intel:Pentium/X86 CPU
.....
More to come, check with supplier’s website.
2-2 Before Getting Started
Before installingthe driver and utilityof the Wireless LANCF Card for the Pocket
PC/Handheld PC, you need to first establish a connection between hostPC and PDAdevice with
Microsoft Active Sync. Instructions are as follows:
Install the CFCard for
Pocket PC 2002/WinCE 3.0
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-5-
Step 1: Installthe MicrosoftActive Sync program that camewith your PDA ProductCD.
Follow the on-screen instructions to install the Active Sync on the host computer.
Step 2: Upon completion of installation, establish an ActiveSync connection between the host
computer and the Pocket PC usingaserial cable, aUSB cable, or an infrared link. (Refer to
your PocketPC manual for instructions. A“Get Connected “messagewillpop-up. Click
Next to proceed.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-6-
Step 3: The ActiveSync willstartlookingfor your Pocket PC/Handheld PC to get connected.
Step 4: Once the connection has been made, you will see the “connected”messageshown as
belowfigure.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-7-
2-3 Install the Setup Utility
Step 1: After successfullyforming aconnection between host PC and PDA device with
ActiveSync Program, insert the CD-ROM intothe CD-ROM drive and run the setup utility
(nb825.exe)for Windows CE operatingsystem. The InstallShield Wizard willlaunch
automatically.Click Next to continue.
Step 2: An InstallShield Wizard windowappears. Click Next to proceed.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-8-
Step 3: Click YES when prompted to installthe CompactFlash Card driver and utilityinthe
default application install directory.
Step 4: Follow on-screen instructions to installthe Setup Utility.Click Finish to complete
the installation.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-9-
2-4 Install the Wireless LAN CF Card
Step 1: Insertthe 11Mbps Wireless LAN CF Card into the CF sloton your PDA. The PDA
willauto-detectthe Wireless LANCF Card and automaticallyinstallthe correspondingdriver
and utility.
Step 2: Assignan IPaddress to your Wireless LAN CF Card. You mayeither setthe
Wireless LANCFCard to obtain an IPaddress fromyour DHCP server, or to be assigned with a
fixed IP address.
Step 3: Resetyour PDA.
Upon completion of installation, the Wireless LANCFCard willstart to look for an Access
Point withGreen LED blinking.The Green LED willstaysteadyonce the Wireless LANCF
Card successfullyassociates with an Access Point.To configure the Wireless LAN CFCard
please proceed to the next chapter.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-10-
3
Thischapter gives you assistance withdetailed description of settingthe 11Mbps Wireless LAN
CF Card with the Wireless LANUtilityunder Pocket/Handheld PC.
3-1 Using Wireless LAN Utility Under Pocket/Handheld PC
The 11Mbps Wireless LAN CF Card is a ready-to-use device. Its defaultsettingsperform for a
typical Infrastructure Wireless LAN.Simplyinstall the Wireless LAN CF Card onto your
computer and itis readytouse. Inspecial situations however, you mayadjust configuration
settingsdependingon howyou wouldlike to manageyour wireless network. The Wireless
LAN Utilityprovides you an easyinterface to make configuration changes and perform
user-level diagnostics on your Wireless LAN CF Card.
Step 1: Go to Start --> Settings.Goto the System tab, and click the “
Wireless LAN
Setting”icon.
Set the CF Card under Pocket
PC 2002/Win CE3.0
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-11-
A configuration window appears. The Wireless LANUtilityprovides the 5 followingitems for
you to configure and monitor the 11Mbps Wireless LANCF Card.
Status
The Status tab displays the current status of the Wireless LAN CF Card.
Adapter - Displays the name of the Wireless LANCF Card.
Firmware - Displays the firmware version of your Wireless LAN CF Card.
Domain - The regulated operatingfrequencyper country.
Channel - Displays the current channel that the Wireless LANCF Card is using.
MAC Address - It is a hardware identification number that distinguishes the unit fromothers.
Sync to AP - Displays the ESSID of the Access Point thatthe Wireless LANCF Card associates
with.
BSSID - ShowsMACAddress of the Access Point that the Wireless LAN CFCard associates
with.
Link Quality - Link qualitymonitors the qualityof the data transmission between the Wireless
LAN CF Card and an Access Point.
Signal Level - Thisbar graph displayssignal strength as reported bythe radio, averaged over all
frames that are received fromthe Access Point.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-12-
Configuration
The Configuration tab contains several fields where the currentparameters of the Wireless
LAN CF Card can be viewed and changed. You willsee current configuration information in
terms of ESSID,Network Type, Power SavingMode and TxRate. Upon modification of
parameters for the Wireless LANCF Card, click the Apply button to make the changes take
effect.
ESSID
The ESSID isan unique IDgiven tothe Access Point.Wireless clients associatingtoAccess
Points must have the same ESSID. The defaultvalue Auto Detect means when the Wireless
LAN CF Card startsto work, itwill associatewithanyAccess Pointthat gives the fastest
response. You mayalso enter aspecific ESSID(Access Point) you desire to connectwith. It
is recommended that you specifyan ESSID for your Wireless LANCF Card. This willprevent
your computer from unintentionallyconnectingtoadifferentwireless network. The ESSID
can be set up to 32 characters and is case sensitive.
Network Type
There are3network types for the 11Mbps Wireless LANPC Card tooperate. Ifyou need to
access companynetwork or Internetvia Access Point, select “Infrastructure”.To set up a
group of wireless stations for file and printer sharing,select “Ad-Hoc”or “802.11 Ad-Hoc”
(withoutAccess Point). If Ad-Hoc (without access point) is selected, you need to set wireless
stations with the samechannel.For 802.11 Ad-Hoc,the sameESSID are required to the
wireless stations.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-13-
Power Saving Mode
The Power Saving Mode option is designed to conserve batterylife of you computer. When
the Power SavingMode is activated byselectingthe Enable button, your 11Mbps Wireless
LAN CF Card will go into sleep mode to minimize power consumption.
Note: When power savingmode is enabled, the Access Pointsyou use need to
support power savingas well so that the communication can be established.
TX Rate
The 11Mbps Wireless LAN CF Card provides various data rateoptions for you to select. Data
rates options include Auto, 1Mbps, 2Mbps, 1M/2Mbps, 5.5Mbps,and 11Mbps.Inmost
networkingscenarios, you will see that the factory-set default“
Auto”willprove the most
efficient. This settingwill allow your 11Mbps Wireless LANCF Card to operate atthe
maximumdata rate. When the communications qualitydrops belowacertainlevel,the
Wireless LANCF Card willautomaticallyswitch to alower data rate. Transmission at lower
dataspeed is usuallymore reliable. However, when the communications qualityimproves
again, the Wireless LANCFCard will graduallyincrease the data rateagain, until it has reached
the highest available transmitrate.
Link
Similar to PingCommand, this tool allows you to point-to-pointdata transmission quality
between twostations. Byentering IP address of another station and set the timeout and
packet size, you maycheck whether the communication has been made successfullyor not.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-14-
Security
To preventunauthorized wireless stations fromaccessingdata transmitted over the network, the
11Mbps Wireless LAN CFCard offers highlysecure data encryption, known as WEP (Wired
Equivalent Privacy). Ifyou desire touse WEP encryption to secure your data, please selectthe
Enable check boxand setthe followingvalues.
Ø There are two types of WEPKey Length described as follows:
40 Bit –Requires wireless stations to use dataencryption with 40 Bitalgorithm when
communicatingwith the Access Point also with WEP 40 enabled.
128 Bit –Allowswireless clientstocommunicate with the Access Point with data 128 Bit
encryption algorithm.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

-15-
Ø WEPKey Type offers two methods to set the WEP keys, as described below:
Create Encryption Keys by Using a Passphrase
Step 1. To create encryption keysbyusingapassphrase, pulldown the WEPKey Type
and select Passphrase.
Step 2. Type acharacter string in the Key inthe phrase to generate keys field, then click
OK.As you type, the utilityuses an algorithm to generate 4 keys automatically.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com
