Sofar HYD 3000-EP User manual

HYD 3000 ~ 6000-EP USER MANUAL
I

HYD 3000 ~ 6000-EP USER MANUAL
I
CONTENT
Preface...................................................................................................................................... IV
1. Basic safety information................................................................................................2
1.1. Safety instructions..................................................................................................2
1.2. Symbols and signs..................................................................................................7
2. Product characteristics................................................................................................10
2.1. Product information............................................................................................10
2.2. Size description.....................................................................................................11
2.3. Function characteristics.....................................................................................11
2.4. Electrical block diagram....................................................................................12
3. Installation........................................................................................................................ 13
3.1. Checking Before Installation............................................................................ 13
3.2. Product Overview................................................................................................. 14
3.3. Tools.......................................................................................................................... 15
3.4. Installation Environment................................................................................... 17
3.5. Determining the Installation Position...........................................................17
3.6. Unpacking the inverter.......................................................................................18
3.7. Installation of the inverter.................................................................................19
4. Electrical Connections................................................................................................. 21
4.1. Wire instructions...................................................................................................22
4.2. Connecting PGND Cables..................................................................................23

HYD 3000 ~ 6000-EP USER MANUAL
II
4.3. PV Connection.......................................................................................................25
4.4. Battery Connection..............................................................................................27
4.5. Load connection................................................................................................... 28
4.6. Grid connection.................................................................................................... 30
4.7. System electrical topology................................................................................32
4.8. External communication interface................................................................ 35
5. Buttons and indicator lights......................................................................................47
5.1. Buttons.....................................................................................................................48
5.2. Alarm lights and status...................................................................................... 48
6. Operation...........................................................................................................................49
6.1. Double Check.........................................................................................................49
6.2. First Time Setup (IMPORTANT!).......................................................................49
6.3. Menu......................................................................................................................... 51
7. Troubleshooting..............................................................................................................70
Maintenance.................................................................................................................. 80
8. DataSheet.......................................................................................................................... 82
9. Quality Assurance.......................................................................................................... 89
Standard warranty period.........................................................................................89
Extended warranty period........................................................................................ 89
Invalid warranty clause.............................................................................................. 90
Statement....................................................................................................................... 91

HYD 3000 ~ 6000-EP USER MANUAL
III
Notice
This manual contains important safety instructions that must be followed
during installation and maintenance of the equipment.
Save these instructions!
This manual must be considered as an integral part of the equipment. The
manual must always accompany the equipment, even when it is transferred
to another user or field.
Copyright Declaration
The copyright of this manual belongs to Shenzhen SOFARSOLAR Co. ,Ltd. Any
corporation or individual should not plagiarize, partially copy or fully copy it
(including software, ect . ), and no reproduction or distribution of it in any
form or by any means. All right reserved.
SOFAR reserves the right of final interpretation. This manual is subject to
change according to user’s or customer’s feedback. Please check our website
at http://www.sofarsolar.com for latest version.
Document Updates
V5. 02023-10-31

HYD 3000 ~ 6000-EP USER MANUAL
IV
Preface
If you have any question or problem when you
read the following information, please contact
Shenzhen SOFARSOLAR Co. , Ltd.
Note
Outline
Please read the product manual carefully before installation,operation or
maintenance. This manual contains important safety instructions and
installation instructions that must be followed during installation and
maintenance of the equipment.
Scope
This product manual describes the installation, electrical connections,
commissioning,maintenance and troubleshooting of HYD 3000/3680/
4000/4600/5000/5500/6000-EP inverters:
HYD 3000-EP HYD 3680-EP HYD 4000-EP
HYD 4600-EP HYD 5000-EP HYD 5500-EP HYD 6000-EP
Keep this manual where it will be accessible at all times.
Target Group
This manual is intended for qualified electrical technical personnel who are
responsible for inverter installation and commissioning in the PV power
system and PV plant operator.

HYD 3000 ~ 6000-EP USER MANUAL
Copyright © Shenzhen SOFARSOLAR Co. , Ltd。
1
Symbols Used
This manual is provides safety operation information and uses the symbol in
order to ensure personal and property security and property security and
use inverter efficiently when operating the inverter.You must understand
these emphasized information to avoid the personal injury and property
loss. Please read the following symbols used in this manual carefully.
Danger indicates a hazardous situation which, if
not avoided, will result in death or serious injury.
Danger
Warning indicates a hazardous situation which, if
not avoided, could result in death or serious injury.
Warning
Caution indicates a hazardous situation which, if
not avoided, could result in minor or moderate
injury.
Caution
Attention indicates potential risks which, if not
avoided, may lead to equipment fault or property
damage.
Attention
Note provides tips that are valuable for the optimal
operation of the product.
Note

HYD 3000 ~ 6000-EP USER MANUAL
2
1. Basic safety information
1.1. Safety instructions
Read and understand the instructions of this manual, and be familiar
with relevant safety symbols in this chapter, then start to install and
troubleshoot the equipment.
According to the national and state requirements, before connecting to
the electrical grid, you must get permission from the local electrical grid
operation can only be performed by qualified electrical engineer.
Please contact the nearest authorized service center if any maintenance
or repair is needed. Contact your distributor for the information of the
nearest authorized service center.Do NOT repair it by yourself, it may
cause injury or property damage.
Before installing and maintaining the equipment, you should turn the
DC switch OFF to cut off the high voltage DC of the PV array.You can
also turn the switch in the PV combiner box OFF to cut off the high
voltage DC. When the battery needs to be installed, please confirm the
positive and negative terminals of the battery and turn OFF the
battery.Otherwise, serious injury may be caused.
Qualified persons
The customer must make sure the operator has the necessary skill and
training to do his/her job. Staff in charge of using and maintaining the
equipment must be skilled,aware and mature for the described tasks
and must have the reliability to correctly interpret what is described in

HYD 3000 ~ 6000-EP USER MANUAL
Copyright © Shenzhen SOFARSOLAR Co. , Ltd。
3
the manual.For safety reason only a qualified electrician, who has
received training and / or has demonstrated skills and knowledge in
construction and in operation of this unit, can install this inverter.
Shenzhen SOFARSOLAR Co. , Ltd.does not take any responsibility for the
property destruction and personal injury because of any incorrect use.
Installation requirements
Please install inverter according to the following section.Fix the inverter
on an appropriate objects with enough load bearing capacity (such as
walls, PV racks etc. ), and ensure that inverter is vertical placed.Choose a
place suitable for installing electrical devices.And assure there is enough
fire exit space, convenient for maintenance.Maintain proper ventilation
to ensure enough air cycle to cool the inverter.
Transport requirements
If you find packing problems that may cause the damage of the inverter,
or find any visible damage, please immediately notice the responsible
transportation company.You can ask solar equipment installation
contractor or Shenzhen SOFARSOLAR Co. Ltd.for help if necessary.
Transport of the equipment, especially by road, must be carried out with
by suitable ways and means for protecting the components (in
particular, the electronic components) from violent shocks, humidity,
vibration, etc.
Labels on the equipment

HYD 3000 ~ 6000-EP USER MANUAL
4
The picture is only for reference,please make the
object as the standard.
Note
Electric connection
Please comply with all the current electrical regulations about accident
prevention in dealing with the solar inverter.
Before the electrical connection, make sure to use
opaque material to cover the PV modules or to
disconnect PV array DC switch. Exposure to the sun, PV
array will produce a dangerous voltage!
Danger
All installation accomplished only by professional
electrical engineer!
Must be trained;

HYD 3000 ~ 6000-EP USER MANUAL
Copyright © Shenzhen SOFARSOLAR Co. , Ltd。
5
Completely read the manual operation and
understand relevant matter.
Warning
Get permission from the local electrical gird
operator, complete all electrical connections by
professional electrical engineer, then connect
inverter to electrical grid.
Attention
It’s forbidden to remove the tamper evident label,
or open the inverter.Otherwise Sofar will not
provide warranty or maintenance!
Note
Operation
Touching the electrical grid or the terminal of the
equipment may lead to electrocution or fire!
Don’t touch the terminal or conductor connected
to the electrical grid.
Pay attention to any instructions or safety
documents related to grid connection.
Danger
Some internal components will be very hot when
inverter is working.Please wear protective gloves!
Attention

HYD 3000 ~ 6000-EP USER MANUAL
6
Maintenance and repair
Before any repair work, turn OFF the AC circuit
breaker between the inverter and electrical grid
first, then turn OFF the DC switch.
After turning OFF the AC circuit breaker and DC
switch, wait for 5 minutes at least before carrying
out any maintenance or repair work.
Danger
Inverter should work again after removing any
faults.If you need any repair work, please contact
with the local authorized service center.
Can’t open the internal components of inverter
without authorized.Shenzhen SOFARSOLAR Co. ,
Ltd.Does not take any responsibility for the losses
from that.
Attention
EMC / noise level of inverter
Electromagnetic compatibility (EMC) refers to that one electrical
equipment functions in a given electromagnetic environment without
any trouble or error, and impose no unacceptable effect upon the
environment.Therefore, EMC represents the quality characters of an
electrical equipment. The inherent noise-immune character: immunity
to internal electrical noise. External noise immunity: immunity to
electromagnetic noise of external system. Noise emission level:
influence of electromagnetic emission upon environment.

HYD 3000 ~ 6000-EP USER MANUAL
Copyright © Shenzhen SOFARSOLAR Co. , Ltd。
7
Electromagnetic radiation from inverter may be
harmful to health!
Please do not continue to stay around the inverter in
less than 20 cm when inverter is working.
Danger
1.2. Symbols and signs
Caution of burn injuries due to hot enclosure!
You can only touch the screen and pressing key of
the inverter while it’s working.
Caution
PV array should be grounded in accordance to the
requirements of the local electrical grid operator!
We suggest that all PV module frames and inverter
are reliably grounded to protect the PV system and
personnel security.
Attention
Ensure input DC voltage < Max.DC voltage . Over
voltage may cause permanent damage to inverter
or other losses, which will not be included in
warranty!
Warning

HYD 3000 ~ 6000-EP USER MANUAL
8
Signs on the inverter
There are some symbols which are related to security on the
inverter.Please read and understand the content of the symbols, and
then start the installation.
This symbol indicates a hazardous situation which could
result in injuries, if not avoided.
There is a residual voltage in the inverter! Before opening
the
equipment, operator should wait for five minutes to
ensure the capacitor is discharged completely.
Caution, risk of electric shock.
Caution hot surface.
Comply with the Conformite Europeenne (CE)
certification.
Grounding point.
Please read this manual before install HYD
3000/3680/4000/4600/5000/5500/6000-EP.
This indicates the degree of protection of the
equipment according to IEC standard 70-1 (EN 60529
June 1997).

HYD 3000 ~ 6000-EP USER MANUAL
Copyright © Shenzhen SOFARSOLAR Co. , Ltd。
9
Positive pole and negative pole of the input voltage (DC).
This side up, HYD 3000/3680/4000/4600/5000/5500/
6000-EP inverter must always be transported, handled
and stored in such a way that the arrows always point
upwards.
RCM (Regulatory Compliance Mark)
The product complies with the requirements of the
applicable Australian standards.

HYD 3000 ~ 6000-EP USER MANUAL
10
2. Product characteristics
2.1. Product information
HYD 3000/3680/4000/4600/5000/5500/6000-EP inverter is a single-
phase photovoltaic energy storage inverter integrating grid-connected
photovoltaic inverter and battery energy storage.
The HYD 3000/3680/4000/4600/5000/5500/6000-EP inverter has a
variety of built-in operating modes to suit the diverse user needs.
The HYD 3000/3680/4000/4600/5000/5500/6000-EP inverter can provide
a complete solution in the period of rising energy costs such as oil and
coal, the energy subsidy of photovoltaic grid-connected system keeps
falling. In the period of continuous power supply and emergency power
supply demand in mountainous areas or base stations without power
grid.
Fig.2-1 HYD 3000/3680/4000/4600/5000/5500/6000-EP inverter system diagram

HYD 3000 ~ 6000-EP USER MANUAL
Copyright © Shenzhen SOFARSOLAR Co. , Ltd。
11
2.2. Size description
①Front view
②left view
③Bracket
Fig.2-2 Size chart
2.3. Function characteristics
The HYD 3000/3680/4000/4600/5000/5500/6000-EP energy storage
inverters allow up to 10% overloading to maximize power output, and
the Uninterruptible Power Supply (UPS) mode can support inductive
loads such as air conditioners or refrigerators with an automatic
switchover time of less than 10 milliseconds.
(1) Dual MPP trackers with 1. 5* DC overload.
(2) Flexible switching between grid-tied mode and energy storage
mode.
(3) Max.battery charge and discharge efficiency 94. 6%.
(4) 1 strings of battery input with maximum 100A charge and
discharge current.
(5) Wide battery voltage range(90-580V).
(6) AC Multi-parallel function, more flexible system solution.

HYD 3000 ~ 6000-EP USER MANUAL
12
(7) Smart monitoring, RS485/WiFi/Bluetooth/GPRS(Optional)
2.4. Electrical block diagram
Fig.2-3 Electrical block diaram

HYD 3000 ~ 6000-EP USER MANUAL
Copyright © Shenzhen SOFARSOLAR Co. , Ltd。
13
3. Installation
Installation notes
3.1. Checking Before Installation
Checking Outer Packing Materials
Packing materials and components may be damaged during
transportation.Therefore, check the outer packing materials before
installing the inverter.Check the outer packing materials for damage,
Do NOT install the HYD 3000/3680/4000/4600/5000
/5500/6000-EP on flammable material.
Do NOT install the HYD 3000/3680/4000/4600/5000
/5500/6000-EP in an area used to store Flammable or
explosive material.
Danger
The enclosure and heat sink are very hot while the
inverter is working, therefore do NOT install the HYD
3000/3680/4000/4600/5000/5500/6000-EP in places
where you might touch them inadvertently.
Caution
Consider the weight of HYD 3000/3680/4000/4600/
5000/5500/6000-EP when transporting and moving
the inverters.
Choose an appropriate mounting position and
surface.
Assign at least two persons to install the inverter.
Attention

HYD 3000 ~ 6000-EP USER MANUAL
14
such as holes and cracks.If any damage is found, do not unpack the HYD
3000/3680/4000/4600/5000/5500/6000-EP and contact the dealer as
soon as possible.You are advised to remove the packing materials
within 24 hours before installing the HYD 3000/3680/4000/4600/5000
/5500/6000 -EP inverter.
Checking Deliverables
After unpacking the inverter, check whether deliverables are intact and
complete.If any damage is found or any component is missing, contact
the dealer.
Please see the packing list for Components and
mechanical parts that should be delivered.
Note
3.2. Product Overview
HYD 3000/3680/4000/4600/5000/5500/6000-EP inverter is 100% strictly
inspected before package and delivery.It is forbidden to put the HYD
3000/3680/4000/4600/5000/5500/6000-EP inverter upside down during
delivery.
Please check the product package and fittings
carefully before installation.
Caution
