SolarEdge
SolarEdge
Electricity Meter
Installation Guide
For North America
Version 1.0

Disclaimers
Important Notice
Copyright©SolarEdgeInc.Allrightsreserved.
Nopartofthisdocumentmaybereproduced,storedinaretrievalsystemortransmitted,inanyformor
byanymeans,electronic,mechanical,photographic,magneticorotherwise,withoutthepriorwritten
permissionofSolarEdgeInc.
Thematerialfurnishedinthisdocumentisbelievedtobeaccurateandreliable.However,SolarEdge
assumesnoresponsibilityfortheuseofthismaterial.SolarEdgereservestherighttomakechangestothe
materialatanytimeandwithoutnotice.YoumayrefertotheSolarEdgewebsite
(http://www.solaredge.us)forthemostupdatedversion.
Allcompanyandbrandproductsandservicenamesaretrademarksorregisteredtrademarksoftheir
respectiveholders.
Patentmarkingnotice:seehttp://www.solaredge.us/groups/patent
ThegeneraltermsandconditionsofdeliveryofSolarEdgeshallapply.
Thecontentofthesedocumentsiscontinuallyreviewedandamended,wherenecessary.However,
discrepanciescannotbeexcluded.Noguaranteeismadeforthecompletenessofthesedocuments.
Theimagescontainedinthisdocumentareforillustrativepurposesonlyandmayvarydependingon
productmodels.
FCC Compliance
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuant
topart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmful
interferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequency
energyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmfulinterference
toradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcan
bedeterminedbyturningtheequipmentoffandon,youareencouragedtotrytocorrectthe
interferencebyoneormoreofthefollowingmeasures:
lReorientorrelocatethereceivingantenna.
lIncreasetheseparationbetweentheequipmentandthereceiver.
lConnecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
lConsultthedealeroranexperiencedradio/TVtechnicianforhelp.
Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancemayvoidthe
user’sauthoritytooperatetheequipment.
Disclaimers
SolarEdge-SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
1

Contents
Disclaimers 1
ImportantNotice 1
FCCCompliance 1
Contents 2
HANDLING AND SAFETY INSTRUCTIONS 3
SafetyInformation 3
Chapter 1: Introduction 4
Terminology 4
TheSolarEdgeElectricityMeter 5
MeterConnectionOptions 6
Chapter 2: Meter Installation 7
InstallationGuidelines 7
InstallingandConnectingtheMeter 7
Chapter 3: SolarEdge Device Configuration 12
Appendix A: Troubleshooting Meter Connection 15
CommunicationStatusScreenTroubleshooting 15
DeviceTypeorProtocolareconfiguredincorrectly 15
Numberofdevicesisnotdisplayed 15
MeterStatusScreenTroubleshooting 15
<OK>isnotdisplayed 16
Anerrormessageisdisplayed 16
Total[Wh]valueisnotadvancing 16
MeterStatusLEDs 17
PowerStatusLEDs 17
ModbusCommunicationLEDs 18
Appendix B: Installing Two Meters 19
ConnectingTwoMeters 19
ConfiguringDual-meterConnection 19
VerifyingMeterConnection 20
TroubleshootingDual-meterConnection 21
CommunicationStatusScreenTroubleshooting 21
DeviceTypeorProtocolareconfiguredincorrectly 21
Numberofdevicesislowerthanconfiguredornotdisplayed 21
MeterStatusScreenTroubleshooting 21
Appendix C: Meter Information Displayed in the Monitoring Portal 22
Appendix D: Meter Technical Specifications 23
Appendix E: External Lightning Protection Connection 24

SolarEdge SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
2
Contents

HANDLING AND SAFETY INSTRUCTIONS
Duringinstallation,testingandinspection,adherencetoallthehandlingandsafetyinstructionsis
mandatory.Failure to do so may result in injury or loss of life and damage to the equipment.
Safety Information
Thefollowingsafetysymbolsareusedinthisdocument.Familiarizeyourselfwiththesymbolsandtheir
meaningbeforeinstallingoroperatingthesystem.
WARNING!
Denotes a hazard. It calls attention to a procedure that, if not correctly performed or adhered to, could
result in injury or loss of life. Do not proceed beyond a warning note until the indicated conditions
are fully understood and met.
Dénote un risque: il attire l'attention sur une opération qui, si elle n'est pas faite ou suivi correctement,
pourrait causer des blessures ou un danger de mort. Ne pas dépasser une telle note avant que les
conditions requises soient totallement comprises et accomplies.
CAUTION!
Denotes a hazard. It calls attention to a procedure that, if not correctly performed or adhered to, could
result in damage or destruction of the product. Do not proceed beyond a caution sign until the
indicated conditions are fully understood and met.
Dénote un risque: il attire l'attention sur une opération qui, si elle n'est pas faite ou suivi correctement,
pourrait causer un dommage ou destruction de l'équipement. Ne pas dépasser une telle note avant que
les conditions requises soient totallement comprises et accomplies.
NOTE
Denotes additional information about the current subject.
IMPORTANT SAFETY FEATURE
Denotesinformationaboutsafetyissues.

HANDLING AND SAFETY INSTRUCTIONS
SolarEdge-SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
3

Chapter 1: Introduction
Terminology
Thefollowingtermsareusedinthisdocument:
lExport:Thepowerinjectedtothegrid.
lImport:Thepowerpurchasedfromthegrid.
lExport/ Import meter:Ameterthatisinstalledatthegridconnectionpointandreadsthe
energy/powerexported/importedto/fromthegrid.
lConsumption:Thepowerconsumedbythesite.
lConsumption meter:Ameterthatisinstalledattheloadconsumptionpointandreadsthe
energy/powerconsumedbythesite.
lSelf-consumption:ThePVpowerconsumedbythesiteandnotfedintothegrid.
lProduction:ThePVpowerproducedbythePVsystem.
lProduction meter:Ameterthatisinstalledattheinverteroutputorintheinverter(abuilt-inrevenue
grademeter)andreadstheenergy/powerproducedbythePVsystem.
Figure 1: Terminology
SolarEdge SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
4
Chapter 1: Introduction

The SolarEdge Electricity Meter
TheSolarEdgemeterenablesmeasuringthepowerandenergyofthephotovoltaic(PV)system.
Themeterisusedbytheinverterforthefollowingapplications:
lConsumptionmonitoring
lExportlimitation
lStorEdgeSmartEnergyManagementon-gridapplications
ThemeterisbuiltintoanenclosureandrequirestwoCurrentTransformers(CTs;availablefrom
SolarEdge).
TheSolarEdgeinverterortheControlandCommunicationGateway(CCG)readstheexportedpower
fromameterinstalledatthegridconnectionpointorreadstheconsumptionfromameterinstalledat
theloadconsumptionpoint.
Figure 2: Typical installation with export meter
Figure 3: Typical installation with consumption meter

Chapter 1: Introduction
SolarEdge-SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
5

Meter Connection Options
Inasingleinvertersystem,themeterisconnecteddirectlytotheinverter.Ifyourinverterhasabuilt-in
revenuegrademeter(RGM;theinverterisreferredtoarevenuegradeinverter),youcanconnectan
externalmeteronthesamebusastheRGM(availableformSolarEdge).
Figure 4: Single-inverter connection
Inamultipleinvertersystem,twooptionsareavailable:
lThemeterisconnectedtotheRS485portofoneoftheinverters.Inthiscase,astheinverter'sRS485
portisoccupiedbythemeter,useanRS485ExpansionKit(availablefromSolarEdge)orZigBee
communicationbetweentheinverters.
lThemeterisconnectedtooneoftheRS485portsofaCCG.TheCCG’ssecondRS485portcanbeused
tocreateanRS485busforcommunicationbetweentheinverters.ThisoptionisillustratedinFigure 5.
Figure 5: Multi-inverter connection with CCG and meter
SolarEdge SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
6
Meter Connection Options

Chapter 2: Meter Installation
ThemeterisconnectedtotheinverterusingRS485.
Installation Guidelines
ACwirespecifications:1.3to2.0mmdiameter/16-12AWGstrandedwire,600V,typeTHHN,MTW,or
THWN.
RS485wiringspecifications:
lCabletype:Min.3-wireshieldedtwistedpair(a4-wirecablemaybeused)
lWirecross-sectionarea:0.2-1mm²/24-18AWG(aCAT5cablemaybeused)
NOTE
If using a cable longer than 10 m/33 ft in areas where there is a risk of induced voltage surges by
lightning, it is recommend to use external surge protection devices. For details refer to External
Lightning Protection Connection on page 24. If grounded metal conduit are used for routing the
communication wires, there is no need for a lightning protection device.
lThemeterisconsidered“permanentlyconnectedequipment”andrequiresadisconnectmeans
(circuitbreaker,switch,ordisconnect)andovercurrentprotection(fuseorcircuitbreaker).
lThemeterdraws10-30mA,thereforetheratingofanyswitches,disconnects,fuses,and/orcircuit
breakersisdeterminedbythewiregauge,themainsvoltage,andthecurrentinterruptingrating
required.
lTheswitch,disconnect,orcircuitbreakermustbelocatednearthemeterandbeeasilyoperated.
lUsecircuitbreakersorfusesratedfor20Aorless.
lUsegroupedcircuitbreakerswhenmonitoringmorethanoneline.
lThecircuitbreakersorfusesmustprotectthemainsterminalslabeledL1,L2,andL3.Intherarecases
whereneutralhasovercurrentprotection,theovercurrentprotectiondevicemustinterruptboth
neutralandtheungroundedconductorssimultaneously.
lThecircuitprotection/disconnectsystemmustmeetallnationalandlocalelectricalcodes.
Installing and Connecting the Meter
Mountthemeteronawallorpoleusingthesuppliedbracket.
To mount the meter:
1. Installthebracketwiththesemi-circlesfacingdown,asshownbelow.Verifythatthebracketisfirmly
attachedtothemountingsurface.
Figure 6: Mounting bracket
Chapter 2: Meter Installation
SolarEdge-SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
7

2. Loosenthe4Allenscrewsofthemeterenclosureandremovethecover.
Figure 7: Meter front view without cover
3. Carefullymovetheterminalblockend-stopstothesidesofthemeterandremovetheterminal
blocks.
4. Openoneormoreconduitknockoutsaccordingtotheconduitsusedintheinstallation:Openthe
requiredknockout(s),eachwithtwosizes:¾''and1'',takingcarenottointerferewithanyofthe
internalcomponents.AUnibitdrillmaybeused.
CAUTION!
Use only knockouts located at the bottom, back and sides of the enclosure. Opening the top
knockouts may damage the protection rating of the enclosure.
Figure 8: Meter - rear view
5. Mountthemeter:Attachthemeterenclosurebackbracketstothemountedbracketusingthefour
suppliedscrews.Tightenthescrewswithatorqueof9N*m/6.6lb*ft.
To install the CTs:
1. TurnoffACpowerbeforeclampingoncurrenttransformers.
2. InstalltheCTsaroundtheconductortobemeasured.Split-coreCTscanbeopenedforinstallation
aroundaconductor.AnyloncabletiemaybesecuredaroundtheCTtopreventaccidentalopening.
3. InstalltheCTwiththearrowpointingtothegridforconsumptionorexportmeasurement.

SolarEdge SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
8
Installing and Connecting the Meter

To wire the meter:

Ifyouareconnectingthemetertoarevenuegradeinverter,refertoInstalling Two Metersonpage19.
Refertotheconnectiondiagrambelow:
Figure 9: Meter connections
NOTE
lClamp the CT connected to L1 CT around the wire connected to ØL1.
lClamp the CT connected to L2 CT around the wire connected to ØL2.
1. VerifythatpowerisOFFbeforemakingconnections.
2. Insertagroundingcablethroughtheappropriateconduitandtheknockoutthatwasopenedand
connectitfromPin10ofthe10-pinterminalblocktothegroundingterminal(bus-bar)atthebottom
ofthemeterenclosure.
3. ConnecttheACsidewires(meterinput)usingthe10-pinterminalblock:
a. Insertthewiresthroughtheappropriateconduitandtheknockoutthatwasopened.
b. Loosentheappropriatescrewsonthe10-pinterminalblock.
c. ConnecteachACwiretotheappropriatescrewterminal(pins6,4).Verifythatthelinesmatch
thesymbolsprintedonthemeterfrontlabel.
d. Connectgroundtopin10andneutraltopin8.
e. Tightenthescrewsmakingsurethewiresarefullyinsertedandcannotbepulledouteasily.
f. Insertthe10-pinterminalblockintothesocketonthemetermakingsureitisfullyseatedinthe
meter.
4. ConnecttheCTwirestothe6-pinterminalblock:
a. Insertthewiresthroughtheappropriateconduitandtheknockoutthatwasopened.
b. Connecttheblackandwhitewiresaccordingtothedotsprintedonthelabel:WhitetoL1/L2
white(pins1/3),andblacktoL1/L2black(pins2/4).
c. Insertthe6-pinterminalblockintothesocketonthemetermakingsureitisfullyseatedinthe
meter
5. ConnecttheRS485twistedpaircabletothe4-pinterminalblockofthemeter:
a. Insertthewiresthroughtheappropriateconduitandtheknockoutthatwasopened.
b. ConnectthewirestotheA+andB-terminals,andconnecttheshieldtotheGterminal.
c. Insertthe4-pinterminalblockintothesocketonthemetermakingsureitisfullyseatedinthe
meter
6. Returntheterminalblockend-stopstothesidesofthemeter.
Chapter 2: Meter Installation
SolarEdge-SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
9

To connect the meter to the inverter or CCG:
1. Ifconnectingtoaninverter,removethesealfromoneoftheopeningsincommunicationgland#2at
thebottomoftheinverterandinserttheRS485wiresfromthemeterthroughtheopening.
Figure 10: Communication glands
2. PreparetoconnecttooneoftheavailableRS485portsofthedevice,asshownbelow:
lInverterRS485-1-pulloutthe9-pinRS485connectorlocatedonthecommunicationboard.
Figure 11: Inverter RS485 connector
lInverterRS485Expansionmodule-pulloutthe3-pinconnector
Figure 12: Inverter RS485 Expansion module
lCCG-useoneofthe3-pinconnectorssuppliedwiththeCCG.ConnectittotheRS485-2
connectionontheCCG.
Figure 13: CCG RS485 connector
SolarEdge SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
10
Installing and Connecting the Meter

3. Connectthewiresasshownbelow:
Figure 14: Meter RS485 connections
4. IftheSolarEdgedeviceisattheendoftheRS485bus,terminateasfollows:
lInverter-TerminatebyswitchingaterminationDIP-switchinsidetheinvertertoON(top
position).TheswitchislocatedonthecommunicationboardandismarkedSW7.
lCCG-TerminatebyswitchingtheSW2terminationDIP-switchtoON.
Figure 15: RS485 termination switch
Chapter 2: Meter Installation
SolarEdge-SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
11

Chapter 3: SolarEdge Device Configuration
ThissectiondescribesbasicconfigurationofSolarEdgedevices(inverter/CCG)forusingameter.In
addition,configurationspecifictotheapplicationbeingusedisrequiredinsomecases.Refertothe
followingdocuments:
lExportLimitation-http://www.solaredge.us/files/pdfs/products/export_limitation_application_
note_NA.pdf
lConsumptionandProductionMonitoring-
http://www.solaredge.us/files/pdfs/products/consumption_production_monitoring_application_
note.pdf
lStorEdgeSmartEnergyManagementoff-gridapplications-
http://www.solaredge.us/files/pdfs/storedge_backup_installation_guide_NA.pdf.
ForconfiguringtwoconnectedmetersrefertoInstalling Two Metersonpage19.
To configure the SolarEdge device:
UsethefouruserbuttonstocontroltheLCDpanelmenus:
lEsc:Goestothebeginningofthecurrentlyenteredparameterortothepreviousmenu.
lUp (1)andDown (2):Movesthecursor(>)totherelevantmenuoption.
lEnter (3):Usedtoselectanoption
1. VerifythatthedeviceON/OFFswitchisOFF.
2. TurnONtheACswitchofthemaincircuitboard.
WARNING!
ELECTRICAL SHOCK HAZARD. Do not touch uninsulated wires when the inverter cover is
removed.
RISQUE D’ÉLECTROCUTION, ne touchez pas les fils non isolés lorsque le couvercle de l'onduleur
est retiré.
3. PresstheEnter(3)buttonforatleastfiveseconds.Thefollowingmessageisdisplayed:
Please enter
Password
********
4. Usethethreerightmostbuttons(Up-1,Down-2andEnter-3)totypeinthefollowingdefault
password:12312312.
5. ScrolltotheCommunicationmenuandselectRS485-X Conf(XrepresentstheactualRS485portto
whichtheelectricitymeterisconnected:1orEfortheinverter;1or2orEfortheCCG).Thefollowing
screenisdisplayed:
Device Type <SE>
Protocol <M>
Device ID <1>
Slave Detect <#>
Slave List <#>
SolarEdge SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
12
Chapter 3: SolarEdge Device Configuration

6. SelectDevice Type.thefollowingscreenisdisplayed:
SolarEdge <M>
Non-SE Logger <S>
Revenue Meter <M>
Multi-devices <M>
None
7. SelectRevenue Meter,thefollowingscreenisdisplayed:
Device Type <MTR>
Protocol <WN>
Device ID <1>
CT Rating <0>
Meter Func. <None>
8. Configurethemeterparametersasfollows:
lSelectProtocol è WattNode.
lSelectDevice ID: 2
lSettheCTratingtothevaluethatappearsontheCT:CT Rating è <xxxxA>.Thedefaultis5
Amperes.Ifthedisplayedratingis0oryoucannotchangethevalue,thereisnocommunication
withthemeter.CheckthattheACpowertothemeterison.
lSelectMeter Func. andselectoneofthefunctionalityoptions,accordingtotheinstalledmeter
specificationsandlocation.
Export+Import
Export
Consumption
Production
Import
None
oExport+Import:Themeterisinstalledatthegridconnectionpointandreadspulsesfromboth
directions-exportandimportenergy.
oExport:Themeterisinstalledatthegridconnectionpointandreadstheexportenergy.
oConsumption:Themeterisinstalledattheloadconsumptionpointandreadstheenergy
consumedbythesite.
oProduction:Themeterisinstalledattheinverteroutputandreadstheenergyproducedby
theinverter.
oImport:Themeterisinstalledatthegridconnectionpointandreadstheimportenergy.
oNone:Noreading
TheselectedoptionisdisplayedintheRS485Confscreenas<E+I>,<E>,<Cons>,<Prod>,<I>,
<None>.
9. ExitSetupmode.
NOTE
Calculated meter readings, such as self-consumption, are calculated using the data measured by
the meter and the inverters. Calculated meters are only sent when Energy Manager is enabled
(for details refer to http://www.solaredge.us/files/pdfs/products/export_limitation_application_
note_NA.pdf).

Chapter 3: SolarEdge Device Configuration
SolarEdge-SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
13

To verify meter connection:
1. PresstheEnterbuttonortheLCDexternalbuttonuntiltheCommunicationstatusscreenis
displayedasshownbelow.Thisscreenshowsthenumberofexternaldevicesthatcommunicateon
eachport,thedevicetype,andtheprotocoltowhicheachportwasconfigured.
2. VerifythatthesettingoftherelevantRS485portiscorrectandthattheportiscommunicatingwith
themeter.
Forexample,ifthemeterisconnectedtotheRS485-1port,theCommunicationstatusscreenshould
displaythefollowing:
w w w w w w w Dev Prot ##
RS485-1<MTR><WN>< 1>
RS485-2<---><--><-->
Z i g B e e < - - - > < - - > < - - >
Dev:thetypeofdeviceconfiguredtothisport.MTR indicatesameter.
Prot:thecommunicationprotocol
## = 1:Indicatesthattheconnectiontothemeterissuccessful.
3. PresstheEnterbuttonortheLCDexternalbuttonuntilreachingthemeterstatusscreenshowing
thetotalenergy[Wh].Ifthereismorethanonemeter/function,thereisastatusscreenforeachone.
ThefollowingisanexampleofanExportmeter:
Export Meter
Status: <OK/Error#>
Power[W]: xxxxx.x
Energy[Wh]: XXXXX.X
Status:DisplaysOKifthemeteriscommunicatingwiththeinverter.
<Error message>:Ifaninternalmetererroroccurs,itwillbedisplayedhere.RefertoTroubleshooting
Meter Connectiononthefacingpage.
Total [Wh]:Displaystheaccumulatedlifetimeenergyofthemeter.

IftheSolarEdgedeviceisconnectedtotheSolarEdgeserverthisvaluewillalsobedisplayedinthe
monitoringportal.
To display the meter serial number:
1. EnterSetupmodeandselectInformation.Thefollowingscreenisdisplayed:
Versions
Error Log
Warning log
Hardware IDs
2. SelectHardware IDs.ThefollowingisdisplayedshowingtheIDoftheinverterandanymeter
connectedtoit:
ID 5000FFFF 4E
RGM: 12345678
SolarEdge SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
14
Chapter 3: SolarEdge Device Configuration

Appendix A: Troubleshooting Meter
Connection
SolarEdgerevenuegradeinvertershaveabuiltinRevenueGradeMeter(RGM).Fortroubleshooting
RGMs,refertohttp://www.solaredge.com/files/pdfs/built-in_rgm_troubleshooting.pdf.Thissection
describeshowtotroubleshootmeter-relatedinstallationandperformanceerrors.
Communication Status Screen Troubleshooting
Thecommunicationstatusscreenshoulddisplaythefollowing:
wwwwwwwwDev Prot ##
RS485-1<MTR><WN>< 1>
RS485-2<---><--><-->
Z i g B e e < - - - > < - - > < - - >
Device Type or Protocol are configured incorrectly
IfMTR(meter)isnotdisplayedasthedevicetype(DEV),orWN(WattNode)isnotdisplayedastheProt
(protocol),configurethemeterasfollows.:
1. SelectCommunicationèRS485-x ConfèDevice Typeè Revenue Meter.
2. SelectCommunication è RS485-x Conf è Protocol èWattNode.
3. CheckthattheDeviceIDunderCommunication è RS485-x Conf è Device IDissetto2.
4. SelectRevenue Meter è Meter Func. èExport+Import/Export/Import/Consumption.
Number of devices is not displayed
If<-->isdisplayedunderthe##columnintheCommunicationstatusscreen,themeterisnot
communicatingwiththeinverter.Checkthefollowing:
lThemeterconfigurationisasdescribedabove.
lTherearenolooseconnectionsattheinverterconnectorsandatthemeter,specificallytheRS485
wiring.
lThewiringbetweentheblack4-pinterminalblockonthemeterandtheRS485terminalblockonthe
communicationboardiscorrect,asshowninFigure 9.
lCheckforwaterdamageorsealingproblems:
oInspecttheentireconduitrunforpossiblepointsofwaterpenetration,andfixleaks.
oEnsurethatproperoutdoorratedcomponentsareused.
lUseaVoltmetertomeasurethevoltageonthemeter10-pinterminalblock.TheL1–L2linetoline
voltageshouldbe208-240Vac.
Meter Status Screen Troubleshooting
Production Meter
Status: <OK/Error>
Power[W]: xxxxx.x
Energy[Wh]: xxxxx.x
Appendix A: Troubleshooting Meter Connection
SolarEdge-SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
15

<OK> is not displayed
If<OK>isnotdisplayedintheStatuslineofthestatusscreenshownabove,themeterisnot
communicatingwiththeinverter.Checkthefollowing:
lTherearenolooseconnectionsattheinvertercommunicationboardandatthemeter.
lThewiringbetweentheblack4-pinterminalblockonthemeterandtheRS485terminalblockonthe
communicationboardiscorrect.
lCheckforwaterdamageorsealingproblems:
oInspecttheentireconduitrunforpossiblepointsofwaterpenetration,andfixleaks.
oEnsurethatproperoutdoorratedcomponentsareused.
An error message is displayed
lIfComm. Errorisdisplayedinthemeterstatusscreen,verifyproperconnectionof:
oTheRS485cablesandconnectors
oTheACconnectionofthemeter
lIfError 185 Meter Comm. Errormessageisdisplayed,contactSolarEdgesupport.
Total [Wh] value is not advancing
IftheTotal[Wh]valuedisplaysasteadyvaluealthoughtheinverterisproducingpower,checkthe
following:
lTherearenolooseconnectionsattheinverterconnectorsandatthemeter,specificallytheACwiring
onthemeter10-pinconnector.
lTheCTblackandwhitecablesarecorrectlyconnectedtothe6-pinconnectoronthemeter:
oWhiteCTwireisconnectedtotheL1/L2whitedot.
oBlackCTwireisconnectedtotheL1/L2blackdot.
lTheL1/L2cablepassesthroughtheCTinthecorrectdirection(righttoleft),accordingtothearrow
ontheinsideoftheCT.
Figure 16: Meter Connection diagram
lCheckforwaterdamageorsealingproblems:
oInspecttheentireconduitrunforpossiblepointsofwaterpenetration,andfixleaks.
oEnsurethatproperoutdoorratedcomponentsareused.
SolarEdge SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
16
<OK> is not displayed

Meter Status LEDs
Power Status LEDs
ThethreestatusLEDsonthefrontofthemetercanhelpindicatecorrectmeasurementsandoperation.
lNormaloperationindications:
oAtnormalstartup-whenpowerisfirstapplied,alltheLEDslightupsequentiallyfor1sec.
oThefollowingtabledescribesLEDindicationsduringnormaloperation:
LED
color Function Indication
Red Flashing ON/OFF
Appears only when the meter is connected at the grid connection point (CT
directed towards the grid).
Indicates export power measurement.
Yellow Flashing Communication OK
Green
Flashing ON/OFF
oWhen the meter is connected at the grid connection point it indicates import
power measurement (CT directed towards the grid).
oWhen the meter is connected at the load connection point it indicates
consumption power measurement (CT directed towards the grid).
oWhen the meter is used for production it indicates production power
measurement (CT directed toward the inverter).
ON for >3 sec No current flow (zero current)
lAbnormaloperationindications:
oIfallLEDsareoff–themeterisnotoperating.Performalltroubleshootingstepsstartingwith
checkingthephysicalconnections.
oThefollowingtabledescribesadditionalLEDindicationsthatrequiretroubleshootingandrepair.
LED color Function Indication Troubleshooting
Red
ON for >3 sec. Internal error Contact SolarEdge Support.
Flashing ON/OFF Negative power for the
phase
If the meter is connected at the load
connection point or if the meter is used for
production metering, check for reversed CTs,
swapped CT wires, or CTs not matched with
the lines.
Flashing with green
LED
Voltage is too high for this
model
Disconnect power immediately!
Check the line voltages and the meter ratings.
Flashing with
yellow LED
The line voltage is out of
range (Vac ±20%).
Specifically, the voltage is
too low for the meter to
operate correctly and the
meter reboots repeatedly.
Verify that the voltage on the Vac screw
terminals is within the range of ±20% of the
nominal operating voltages printed in the white
rectangle on the front label.
Yellow
ON for >3sec.
Power line frequency is
below 45 Hz or above
70 Hz.
Check for the presence of high noise, for
example, the meter is too close to an unfiltered
variable frequency drive.
Flashing with red
LED
Voltage is too high for this
model
Disconnect power immediately!
Check the line voltages and the meter ratings.
Appendix A: Troubleshooting Meter Connection
SolarEdge-SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
17

Modbus Communication LEDs
ThecommunicationLEDislocatedattheupperleftcorner.ThefollowingareindicationsoftheLEDlight:
LED
color Function Indication Troubleshooting
Red
Flashing An invalid packet: bad baud rate, bad CRC,
noise, bad parity, etc.
Check that the communication wires
are connected correctly.
ON The address is set to zero: an invalid choice Check that the Device ID is set to 2 in
the RS485 Conf screen.
Flashing with
yellow LED
A possible address conflict (two devices with
the same DIP switch address).
Check that the Device ID is set to 2 in
the RS485 Conf screen.
Yellow Flashing Valid packets addressed to different devices. N/A
Green Flashing A valid packet addressed to this device N/A
SolarEdge SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
18
Modbus Communication LEDs

Appendix B: Installing Two Meters
Thissectiondescribesconnectinganexternalmetertoaninverterequippedwithabuilt-inRevenue
GradeMeter(RGM),whichislocatedintheSafetySwitch.RS485wiringisdaisy-chainedbetweenthetwo
metersandtheinverter.
Connecting Two Meters
1. ConnecttheexternalmetertotheRGMasshowninFigure 17:
a. RoutetheexternalmeterwiresthroughoneoftheSafetySwitchconduits(itisrecommendedto
usetheDCsideconduits).
b. ConnecttheexternalmeterwirestogetherwiththeRGMwirestothesamescrewterminalsof
theRGMRS485terminalblock:
lRemovetheRGMwiresfromtheterminals(notethewirecolorandlocation).
lTwistthewirestogetherandinsertthemintotheterminal.
lSecurelytightentheterminalscrews.
Figure 17: Meters connection to an RGM inverter
2. TerminatetheSolarEdgedeviceasdescribedinInstalling and Connecting the Meteronpage7.
Configuring Dual-meter Connection
Thebuilt-inRGMispre-configuredasaproductionmeteranditssettingsshouldnotbechanged.Verify
thepre-configuredparametersoftheRGMandconfiguretheparametersoftheexternalmeteras
describedbelow.
1. EnterSetupmode,scrolltotheCommunicationmenuandselectCommunication è RS485-x Conf.
Thefollowingscreenisdisplayed:
Device Type <SE>
Protocol <M>
Device ID <1>
Slave Detect <#>
Slave List <#>
Appendix B: Installing Two Meters
SolarEdge-SolarEdge Electricity Meter Installation Guide MAN-01-00270-1.0
19
