Soleus Air HCB-P08-B User manual

8,000 BTU Portable Air Conditioner
Operating Instructions
V021014
Model No.: HCB-P08-B
Reference Number: BPB08
3092402

2
Thank you for choosing a Soleus Air Portable Air Conditioner. This owner’s manual will provide
you with valuable information necessary for the proper care and maintenance of your new product.
Please take a few moments to thoroughly read the instructions and familiarize yourself with all the
operational aspects of your new Soleus Air Portable Air Conditioner.
For your own records, please attach a copy of your sales receipt to this manual. Also, write the
store name/location, date purchased, and serial number below:
Store Name: ____________________________________________________
Location: ______________________________________________________
Date Purchased: _________________________________________________
Serial Number (located on back of unit): ______________________________
IMPORTANT INSTRUCTIONS
Before installing and using your portable air conditioner, please read this owner’s manual carefully. Store this
manual in a safe place for future reference.
1) Always place the unit on a level surface.
2) Never use or store gasoline or other flammable vapor or liquid near this unit unless instructed by this manual.
3) Maintain at least 10 inches (25 cm) clearance space around this unit. Do not block or cover air inlet or outlet
grilles.
4) The unit must be connected to a correctly grounded power supply.
5) Do not start or stop the unit by inserting or pulling out the power plug.
6) Do not use an adapter plug or extension cord.
7) Do not use the unit in the immediate surroundings of a bath, a shower or a swimming pool.
8) Do not insert anything into the air outlet. Do not obstruct air inlet or outlet grills unless instructed by this
manual.
9) Do not let children play near this unit.
10) Always inspect the cord for signs of damage before use. If the power cord is damaged, it must be replaced by
the manufacturer or a qualified service technician.
11) When cleaning the unit, always turn the unit off and unplug the power cord.

3
SPECIFICATIONS
 The cooling capacity is measured at an ambient temperature of DB 86 °F, WB 78 °F.
 Noise level is measured at a distance of 3.28 ft away from the front of the unit, when the unit is in cooling mode.
 Power consumption is measured when the fan runs at the highest speed setting.
 These specifications are for reference only. For actual data, please refer to the rating label on the back of the unit.
 If the environment temperature is higher than the max operating temperature or lower than the minimum operat-
ing temperature, the air conditioner may not work properly.
PACKAGE CONTENTS
MODEL NUMBER HCB-P08-B
REFERENCE NUMBER BPB08
COOLING CAPACITY 8,000 BTU/H
DEHUMIDIFYING CAPACITY 38 pts per Day
COOLING POWER USAGE 760 Watts, 6.7 Amps
AIR FLOW VOLUME 200 CFM
POWER SOURCE 115 V / 60 HZ
SOUND PRESSURE LEVEL 46 dB(A)
PRODUCT WEIGHT 50 Lbs
OPERATING
TEMPERATURE 60.8℉-107.6℉
11.75” W × 13.75” D × 31” H
PRODUCT DIMENSIONS
REFRIGERANT R-410A
Portable Air Conditioner (1)
Exhaust Hose (1)
Hose Adapter (1)
Window Kit Adapter (1)
Window Kit Adapter Extension (1)
Remote Control (1)
AAA Batteries (2)
Window Kit - 3 Sliding Panels (1 single hose panel, 2 extension panels)
Owner’s Manual (1)

4
LCDI POWER CORD AND PLUG
This air conditioner is equipped with an LCDI (Leakage Current Detection and Interruption) power cord
and plug as required by US National Electric Code 440.65. This cord consists of a length of shielded flexi-
ble cord with no termination on the load side and a LCDI attachment plug on the line side.
The LCDI power cord and plug will remove the supply source via electrical disconnect (circuit trip) if the
nominal current leakage between the cord shield and either load conductor exceeds a predetermined value.
The cord will remain de-energized until the devise has been manually reset. This is intended to reduce the
risk of a fire in the power cord or combustible materials nearby. The cord shields are not grounded and they
must be considered a shock hazards if exposed. The cord shield must not be connected to ground or to
any exposed metal.
The test and reset buttons on the LCDI Plug are used to check if the plug is functioning properly. To test:
1. Plug power cord into wall outlet. The LED light will turn on.
2. Press TEST Button, circuit should trip, cutting power to the air conditioner. When this occurs,
3. Press RESET button to restore power to the machine. Once power is restored, the LED light
will turn on again.
If test button is pressed and unit can still be turned on, current leakage has been detected. Do not use the
air conditioner or attempt to reset the LCDI Plug. Contact Soleus Home Comfort for troubleshooting
recommendations.
WARNING:
1. DO NOT press the TEST button while the air conditioner is operating.
2. The TEST and RESET buttons should not be used as “ON” and “OFF” switches.
3. The cord and plug are not intended to offer protection to externally connected loads or supply circuits.
4. The cord and plug are intended for indoor use only.
LED LIGHT
the LED light will turn off.
Note: Your unit's power cord and plug may differ from the one shown.

5
PRODUCT DIAGRAM
Casters
Louvers
Remote Control
Signal Receptor
Control Panel (on top)
Filter Compartment
Remote Control
Evaporator Air Intake
Condenser Air Outlet
Condenser Air Intake
Drain PortDrain Hole
Rubber Plug

6
PARTS & ASSEMBLY
PARTS
EXHAUST HOSE
WINDOW KIT
ASSEMBLY & INSTALLATION
INSTALLATION
When the unit is operating as an air conditioner or dehumidifier, the unit draws in fresh outdoor air and exhausts hot
air out of the room to complete the air exchange. When the unit is operating in fan mode no outdoor air exchange
takes place. The window kit and exhaust hose do not need to be installed when the unit is used as a fan.
NOTE: The supplied window kit can be installed in sliding windows and sliding glass doors up to 7 ft. long
(approximate length).
MOUNTING THE EXHAUST HOSE
 Choose a suitable location, near a grounded electrical outlet and suitable window or door. Remove
packaging and locate components.
 Extend both ends of the exhaust hose approximately 6 inches.
 Screw the window kit adapter onto one end of the exhaust hose counter-clockwise. Screw the hose
adapter onto the other end of the exhaust hose counter-clockwise.
 Slide the hose adapter of the exhaust hose down arrow over the discharge opening on the back of the
unit.
 Open the window or door and adjust the length of window kit to fit the opening. Then make the kit
fixed.
 Attach the window kit adapter of the exhaust hose to the window kit.

WINDOW KIT INSTALLATION
Installation of the Venting Kit
FOR SINGLE HOSE PORTABLE AIR CONDITIONERS
The venting kit must be installed in order for the unit to
work correctly in the air conditioning mode. The venting
kit should not be used while the unit is heating or
fanning.
The window kit has been designed to fit into most
vertical and horizontal window openings. The window kit
can also be used in a sliding door.
1. Choose a suitable location, near a grounded
electrical outlet and a suitable window or door.
Remove packaging and locate components. (Figure
A)
2. Slide the exhaust connector over the discharge
opening on the back of the unit. (Figure B)
3. Connect the exhaust hose to the exhaust connector,
aligning the fitted grove.(Figure C)
4. Open the window or door and adjust the length of
the window kit to fit the opening. (Figure D) If
necessary, mark the kit and cut one end down to
properly fit the opening. (Figure E&F)
5. Attach the window kit adapter to the window kit.
(Figure G)
6. Place the window kit back into the window and
attach the exhaust hose to the window kit adapter.
(Figures H & I) Close the window tightly. (Figure J)
Your portable Air Conditioner is now ready to cool!
NOTE: When using the venting system, keep the exhaust
hose as straight as possible. The exhaust hose can be
shortened, but it is not recommended to increase the
length of the exhaust hose. Do not use an extension
cord with your portable air conditioner.
Optional Window Kit Adapter Extension (Included)
The Window Kit Adapter Extension is an optional part
that can be used on window sizes that require a longer
connection between the window and the exhaust hose.
NOTE: The Portable Air Conditioner above may differ from the unit described in this manual. The above directions and
images show general directions for Soleus Air hose portable air conditioners.
7

8
WINDOW KIT ASSEMBLY
1.Parts:
A) 2 Track Screws
B) 2 Wing Nuts
C1 & C2) 2 Hose Panels, one Exhaust Hose Openings
D) 1 Sliding Track Panel
2. Assembly:
First, take the Track Screws (A) and screw one
into each of the small holes found on the Hose
Panels (C1 & C2).
3. Next, take the Wing Nuts (B) and tighten them
around each of the Track Screws (A). Do not tighten
the Wing Nuts (B) all the way; make sure they are
somewhat loose.
4. Now, place the Sliding Track Panel (D)
over the Track Screw (A) on Hose Panel (C1).
5. Next, take the other Hose Panel (C2) and connect
it to Hose Panel (C1) by placing the Sliding Track
Panel (D) over the Track Screw (A) on Hose Panel
(C2).
6. The Hose Panels (C1 &C2) should now be
connected using the Sliding Track Panel (D).
7. To complete the assembly, tighten the wing Nuts
(B) installed earlier. The finished Window Kit
should resemble the image seen below.

9
OPERATING INSTRUCTIONS
CONTROL PANEL BUTTONS
1) Power On and Off - Press the POWER button once to manually turn the unit on. Press the POWER
button once more to turn the unit off.
2) Mode Selection - Press the MODE Button repeatedly to cycle between the different modes: Air
Conditioner, Dehumidifier, Fan only mode. Each press of the MODE button will light up a different
icon on the control panel. The exhaust hose and window kit must be installed when the unit is in Air
Conditioner, Dehumidifier mode. When using the unit as a fan, it is not necessary to keep the exhaust
hose and window kit connected to the unit.
3) Temperature - Select the desired temperature by pressing either - or + key when using the unit in
cooling mode. The temperature indicator flashes to display the desired temperature setting. After the
temperature is set, the unit will display this temperature setting until it is changed by the user. The tem-
perature indicator display shows temperature in Celsius or Fahrenheit. Press the - and + simultane-
ously to change between Celsius and Fahrenheit .
4) Bucket Full - when the unit can not evaporate the collected moisture fast enough. The excess water
will collect in a backup water tank located inside the unit. The bucket full icon will light up if this
occurs.
5) Louver Direction - This unit has 4-way directional louvers. Use the louver guides manually to direct
air where cooling or fanning is needed most.
POWER BUTTON
MODE BUTTON
TEMPERATURE AND TIMER
INDICATOR
BUCKET FULL
TIMER/TEMP DECREASE TIMER/TEMP INCREASE
AIR CONDITIONER MODE DEHUMIDIFIER MODE
FAN MODE
CONTROL PANEL, DISPLAY, & OPERATING INSTRUCTIONS
CONTROL PANEL

10
REMOTE CONTROL
TIMER ON
TIMER OFF
LCD DISPLAY
POWER BUTTON
MINUTE SELECTER
SLEEP BUTTON
HOUR SELECTER
TEMP SETTING
MODE BUTTON
FAN SPEED
OPERATING THE UNIT USING THE REMOTE CONTROL
* Remote Colors may differ from the
image above.
