Soleus Air KFH-12/KFH-12-1 User manual

Wall Mounted Mini Split
Air Conditioner
OWNER’S MANUAL
Models: KFI-09/KFI-09-1, KFH-12/KFH-12-1
Please read this owner’s
Manual carefully before
operating the unit.

TABLE OF CONTENTS
OPERATION AND MAINTENANCE……………………………..……………………………..1-13
The instruction before use …………………………………………………………………..………1
Name and function of each part……………………………………………………………………...3
Name and function-Remote control…………………………………………………….…..……….4
Operation guide……………………………………………………………………………...………6
How to insert batteries………………………………………………………………………………6
The best operating methods…………………………………………………………………………7
User notices……………………………………………………………….……………...………….8
Care and maintenance…………………………………………………..……………………………9
Trouble shooting……………………………………………………….……………………..…….10
Technical Specifications Sheet..……………………………………………………………………13
INSTALLATION…………………………………………………………………………………14-23
Installation dimension diagram…………………………………………………….……………….14
Installation location…………………………………………………………………………………15
Installation…………………………………………………………………………………………..16
Test operation and check after installation…………………………………………...……………..23
WARRANTY…………………………………………………………………………………………24

Technical Specification Sheet
Model KFI-09/KFI-09-1 KFH-12/KFH-12-1
Power supply Ph-V-
Hz 1, 115V~, 60Hz 1, 208/230V~, 60Hz
Capacity Btu/h 9000 12000
Input W 800 960
Rated current A 6.96 4.62/4.17
Cooling
SEER Btu/w.h 13.1 13.1
Moisture Removal Pts/h 4.2 4.2
Max. input consumption W 900 1100
Max. Fuse size A 15 15
Min. circuit ampacity A 15 15
Model 2P14S126B1Y 2P15S236A1H
Type rotor rotor
Brand Panasonic Panasonic
Capacity Btu/h 9165 10140
Input W 855 930
Rated current(RLA) A 7.5 4.1
Locked rotor Amp(LRA) A 49 26
Thermal protector MRA98694 MRA99027
Capacitor uF 40 30
Compressor
Refrigerant oil ml 270 350
Input W 20 20
Capacitor uF 4 1
Speed(hi/mi/lo) r/min 1300/1200/1100 1550/1450/1350
Indoor air flow (Hi/Mi/Lo) CFM 353 482
Indoor noise level (Hi/Mi/Lo) dB(A) 45 47
Dimension (W*H*D) inch 35 3/4x11 3/8x7 5/8 35 3/4x11 3/8x7 5/8
Packing (W*H*D) inch 41 5/8x14 3/8x 12 1/2 41 5/8x14 3/8x 12 1/2
Net/Gross weight lb 26.5/33 26.5/33
Indoor unit
stack height 6 6
Input W 48 48
Capacitor uF 10 2
Speed r/min 885 920
Dimension(W*H*D) inch 33 3/8x 12 5/8x21 1/4 33 3/8x 12 5/8x21 1/4
Packing (W*H*D) inch 24 5/8x14 1/8x23 1/4 24 5/8x14 1/8x23 1/4
Net/Gross weight Lb 88/99 88/99
Outdoor unit
stack height 4 4
Outdoor noise level (Hi/Mi/Lo) dB(A) 55 55
Refrigerant type R22 oz 35.3 44.1
Refrigerant Charging Scale oz/ft 0.21 0.42
Design pressure (Discharge side) Psig 362.5 362.5
Design pressure (Suction side) Psig 145 145
Liquid side inch 1/4 1/4
Gas side inch 1/2 1/2
Max. refrigerant pipe length ft 32.8 32.8
Refrigerant piping
Max. difference in level ft 16.4 16.4
Thermostat type electronic electronic
Operation temp range F 61-86 61-86
Ambient temp F 50-118.4 50-118.4
-13-
