DAB1 Distributed Audio System
DAB1 Remote
DAB1 Keypad
DAB1 Accessories
Volume, source and mute controls for zone
Dedicated tuner control buttons (band,
tuning, preset)
Programmable source control buttons
All zones on (‘Party Mode’) and all zones
off controls
Pre-programmable in-wall keypad.
Extensive macro capability from any button
3 Control levels: Press, Press Twice, Press-
and-Hold
4 Interchangeable hard source buttons.
Buttons can be renamed with labels
included in each DAB 1 keypad box.
Built-in IR receiver (defeatable)
Keypad backlighting
(adjustable/defeatable)
Easily programmable with DAB1 Program
Manager software
Mounts in a single-gang electrical box
Includes white bezel — other colors (black,
almond, ivory) available separately
Overall Dimensions (WxHxD): 2.75" x 4.5" x
1.6" (69.8mm x 114.3mm x 40.6mm)
In Wall Dimensions (WxHxD): 1.75" x 4.1" x
1.6" (44.4mm x 104.1mm x 40.6mm)
6-Zone, 4-source distributed audio and
control system
Can be controlled by up to 6 optional
Sonance keypads (DAB1 or K2), included
DAB1 remote or RS-232 connection
Built-in FM/AM tuner w/12 presets
Extensive macro capability (from keypads,
remote or RS-232 control)
6 built-in 30 watt x 2 power amplifiers
Programmable, common, and zone-specific
IR outputs maximize system control
flexibility
Line-level audio outputs, IR links and sync
connections allow multiple DAB1s to be
bridged into a single system (up to 4
DAB1s for up to 24 zones)
DAB Program Manager programming
software makes it easy to configure even a
sophisticated system
Individual Zones can be set up for Max
volume, default (“turn-on”) volume, paging
volume, bass, treble, and balance
Input level matching keeps all external
sources at same volume level
Specifications:
Tuner: AM/FM Domestic and International
Source Inputs: 4 sources (either internal tuner
and 3 external sources or 4 external sources)
Audio Outputs: 6 speaker level outs, 6 line
level outs (fixed or variable)
Power Output: 30 watts RMS
Amplifier: Class AB, THD 0.05%, 20Hz –
20kHz @ 8 ohms
Expansion: Up to 24 zones (three additional
DAB1 systems) via RCA outputs
Voltage: 110V or 230V (by qualified service
personnel), 2 switched 110 volt outlets on
rear of DAB1
IR Total: 14 outputs - 4 programmable, 4
common, 6 individual zone
Network Connections: RS232 and RS485
Shipping Weight: 42 lbs. (19 kgs)
DAB1
KEYPAD DAB1 KEYPAD DAB1 KEYPAD DAB1 KEYPAD DAB1 KEYPAD DAB1 KEYPAD
K2 Keypad
Programmable in-wall keypad with
touchscreen control
Backlit LCD touchscreen displays relevant
control buttons for selected source
6 Interchangeable hard source buttons
Membrane kit included for re-labeling of
source buttons
Built-in IR receiver and IR output (defeatable).
Speaker relay output w/status input
K2 Program Manager software for easy
programming and configuration
Mounts in a double-gang electrical box
Includes white bezel — other colors (black,
almond, ivory) available separately
Specifications:
One IR output (200mA)
One half-duplex RS-485 port (RJ 45
connection). For use with future RS-485
compatible
products
One power sense input
One relay output
One monitored auxillary input
One keypad sync I/O port for keeping multiple
keypads synched to the same page/source
Fully programmable/configurable using Nav
Program software
Software includes a tool to create a scrollable
list of CD titles or songs. CD titles can also be
manually programmed
Overall Dimensions (WxHxD): 4.5" x 4.5" x
1.83" (114.3mm x 114.3mm x 46.5mm)
In Wall Dimensions (WxHxD): 3.66" x 3.23" x
1.83" (93mm x 82mm x 46.5mm)
Includes programming cable
Includes white faceplate - additional colors
available: black, ivory and almond
K1 Keypad
Programmable In-Wall Keypad
Single gang, shallow depth
Next generation to Navigator Master and
associated components
Easy to use and program
Flexible programming capabilities for use
with a majority of control systems
Easily Programmable via Navigator Manager
Software
Specifications:
Hard Key Buttons: Volume Up/ Down, Channel
Up/Down, 6 interchangeable hard Function
Keys and Power On/Off.
One IR output (200mA)
IR passthrough
One half-duplex RS485 port (RJ 45
connection) for future products. Not active at
this time.
One power sense input
One speaker relay trigger output
One keypad sync I/O port for keeping multiple
keypads synched to the same page/source
Programming Port: 3-pin serial
Color: Decora® White
Fits in single-gang J-Box or P-Ring
Comes with extra membrane buttons for
easy customization
Includes programming cable
Optional wallplate colors: black, almond, ivory
Overall Dimensions (WxHxD): 2.75" x 4.5" x
1.6" (69.8mm x 114.3mm x 40.6mm)
In Wall Dimensions (WxHxD): 1.75" x 4.1" x
1.6" (44.4mm x 104.1mm x 40.6mm)
6 Zone System

DAB1
DISTRIBUTED AUDIO SYSTEM
THE LEADER IN ARCHITECTURAL AUDIO™

DAB1
With the Sonance DAB1 it’s never been easier to enjoy and control music
throughout the home. With the DAB1 you can add any Sonance in-wall keypad
or use the included DAB1 IR remote to listen to and control up to four audio
sources (including the built-in FM/AM tuner) in up to six zones, with independent
control in each zone. With the DAB1’s built-in amplification, just add speakers
and you can bring entertainment to just about anywhere in the home. And
multiple DAB1s can be bridged to provide music in larger homes — up to 24
zones — with the same simplicity of control.
Easy to Program and Configure
The PC-based DAB Program Manager software simplifies configuring even a very
sophisticated whole-house system. The Program Manager software includes an
extremely extensive IR library that lets you build macros with drag-and-drop
convenience. In addition to IR control, DAB1 macros can also contain repeated
commands, time delays, RS-232 commands and commands for the DAB1 itself,
so you have the flexibility to program exactly what the user will need.
Upgradeable firmware lets you add new features to DAB1s in the field as they
become available. In addition to programming macros, the Program Manager software
also makes it simple to set up each zone’s Default (‘turn-on’) Volume and
Maximum Volume, Treble, Bass, Balance and Paging Volume, and to adjust each
source component’s input level so that they all play at the same volume.
Easy to Use
With its extensive macro capability, the DAB1 becomes essentially “invisible” to
the user. The DAB1 can be configured so that a single button touch activates the
audio/video system, dims lights, shuts drapes, lowers a video screen and begins
playing music or a movie. The DAB1 can also provide simple, logical control of
up to four source components. With IR passthrough you can control the DAB1
from the convenience of your listening chair using the included DAB1 remote or
3rd-party remotes.
DAB1 Keypad

•The DAB1 can play and control up to four different audio sources (including a built-in
FM/AM tuner) in up to six zones.
•Can be controlled by up to 6 Sonance keypads (optional), the included remote or an
RS-232 connection.
•Six built-in 30-watts x 2 power amplifiers power speakers without external amplification
Preouts are offered to provide additional power amplification if required.
•Extensive macro capability makes the DAB1 simple and logical to operate.
•DAB Program Manager programming software makes system configuration easy.
