SONBEST SS1060I User manual

SS1060I Us e r Ma nual http://www.sonbus.com/
Sha nghaiSonbest IndustrialCo., Ltd Page1
SS1060I
I2C Illumination BH1750 Sensor
User Manual
File Version: V22.10.31
SS1060I using the standard I2C Interface,easy access to PLC，DCS and other instruments or
systems for monitoring illuminance state quantities.The internal use of high-precision sensing core and
related devices to ensure high reliability and excellent long-term stability,can be customized
RS232,RS485,CAN,4-20mA,DC0~5V\10V,ZIGBEE,Lora,WIFI,GPRSand other output methods.
Technical Parameters

SS1060I Us e r Ma nual http://www.sonbus.com/
Sha nghaiSonbest Industrial Co., Ltd Page2
Technical parameter
Parameter value
Brand
SONBEST
Illuminance measuring range
0~65535Lux
Illuminance allow deviation
±7%
Repeatability test
±5%
Illuminance detection chip
Import digital
Wavelength range
380nm~730nm
Communication Interface
I2C
Power
DC3~5.5V
Running temperature
-30~85℃
Working humidity
5%RH~90%RH
Wiringinstructions
Any incorrect wiring can cause irreversible damage to the product. Please carefully wire the cable as
follows in the case of power failure, and then connect the cable to confirm the correctness and then use it
again.
ID
Core color
Identification
Note
1
Red
VDD
Power V+
2
Green
GND
Power V-
3
Yellow
Sck
Sck
4
Blue
Dat
Data
In the case of broken wires, wire the wires as shown in the figure. If the product itself has no leads, the
core color is for reference.
Disclaimer
This document provides all information about the product, does not grant any license to intellectual
property, does not express or imply, and prohibits any other means of granting any intellectual property
rights, such as the statement of sales terms and conditions of this product, other issues. No liability is
assumed. Furthermore, our company makes no warranties, express or implied, regarding the sale and use
of this product, including the suitability for the specific use of the product, the marketability or the
infringement liability for any patent, copyright or other intellectual property rights, etc. Product
specifications and product descriptions may be modified at any time without notice.
