Sonder RAFFLES FG0803140 User manual

H A RD W A RE LI ST
Thank you for choosing this quality product. Be sure to check all packaging materials carefully for small parts that may have
become loose during shipment and place all parts on a non-abrasive surface.
IMPORTANT :These parts can be cumbersome and heavy to some people, therefore the assistance of two or more people is
recommended in order to prevent personal injury and ensure the furniture is not damaged during the assembly Process.
CAREINSTRUCTIONS
1. Dust often using a clean, soft, dry and lint-free
cloth.
2. Blot spills immediately and wipe with a clean,
damp, cloth.
3. We do not recommend the use of chemical
cleansers, abrasives or furniture polish on our
lacquered finish.
IMPORTANT SAFETY INSTRUCTIONS
1. Please read all instructions carefully before
assembling.
2. Keep instructions for future use.
3. Use only vendor supplied hardware to
assemble. Using unauthorized hardware could
jeopardize the structural integrity of the item.
NO.
1
2
3
4
ALLEN HEAD BOLT
FLAT WASHER
D E S C R I P T I O N Q T Y
12 PCS
ALLEN WRENCH 1PC
12 PCS
LOCK WASHER 12 PCS
PART LIST
A [ 1] HEADBOARD
B [ 2] SIDERAILS
C [ 1] FOOTBOARD
D [ 13] BED SLATS
E [ 1] SUPPORT SLAT
F [ 3] SUPPORT LEGS
RAFFLES UK SUPER KING BED
- 6 PANELS, PLATFORM
SO N D ER
L I V I N G
12
/

A SSEM BLY I N ST RU CT I O N
The bed is composed of several
components: The headboard, foot
board, side rails, bed slats and
support slats. Determine the
intended location and ensure there is
enough space to work with and fully
read these instructions before
physically doing the entire assembly.
STEP#1:
Place the headboard upright in the
position you wish the bed to be in
when fully assembled. The
headboard bed fast hardware should
be facing inside, toward the mattress.
Secure the threaded rod (1) to the
fixed nut in the headboard (A) by
simply turning it manually. Raise the
side rail (B) up and place the rod (1)
to align with the bore holes on the
end of the side rails (B). Put the side
rails (B) up against the headboard
(A) so the threaded rods (1) go
through the bore holes. Insert curved
washer (2), lock washer (3) and
place hex nuts (4) on threaded rod
(1) then tighten the hex nuts (4) with
wrench (5) provided, as illustrated in
FIGURE 01.
STEP#2:
Repeat the above procedure with the
other side rail (B) to attach it to the
headboard (A), and then repeat to
connect side rails (B) to the
footboard (C).
STEP#3:
Attach the short support leg (F) to
the slat support (E) by turning it
manually, as illustrated in FIGURE 02.
STEP#4:
On inside face of both headboard (A)
and footboard (C) are pre-installed
metal brackets for the support slat
(E). Set the support slat (E) on the
metal brackets, as illustrated in
FIGURE 03.
STEP#5:
On inside surface of both side rails
(B) are cavities designed to hold the
individual bed slats (D). Set
individual bed slats (D) on both
cavities of the side rails (B) as
illustrated in FIGURE 04.

FIGURE 01
FIGURE 03
E
FIGURE 04
D
D
D
FIGURE 02
E
F
Fig.03
Fig.02
E
F
A
B
B
C
3
2
1
4
22
/
