Sonny's Digital Matrix Arch User manual
Digital Matrix Arch
All parts and components MUST be installed by experienced and trained technicians.
The Quick Start is a Summary Overview of the Installation Instructions. For detail instructions and Important Safeguards
and Warnings, the Owner’s Manual MUST be referenced online at SonnysDirect.com under Support Tab.
Checklist
Installation Dimensions
Installation Instructions
1
2
3
QUICK START INSTALL
Work Force
2 Technicians
Installation
1 to 2 Hours
Technical
Support
800-327-8723
Register
Warranty
SonnysDirect.com
Support Tab
Quick Start Digital Matrix Arch Install Manual
__________________________________________________________________________________________________
© 2023 ®. All Rights Reserved. SonnysDirect.com
This document is confidential and proprietary to SONNY’S and cannot be used, disclosed, or published without prior written
consent. Content, prices, and availability subject to change without notice. All brand names, trademarks or registered
trademarks are the property of their respective owners. Sonny’s CarWash Signage by Mr. Foamer, MrFoamer.com
Manual-QS, Digital Matrix Arch Install Part # 10015546-B
Page 1 of 11
Safety Glasses, Gloves, Tape Measure, Sledgehammer,
Hammer Drill with Carbide Bit, Impact Gun with Sockets,
Wrench Set, #2 Phillips Screwdriver,
T20 Torx Screwdriver,
and Anti-Seize NeverSeez®
WARNING: Make sure to follow Local and State Safety
Wear Required Regulations to ensure the safety of all
personnel. Failure to follow Safety Regulations may result
in personal injury, death and/or dismemberment.
Utility Required
Electric Follow Instructions on Equipment Labels
➢100 240 VAC. Water-Proof Power Supply
➢The Customer's Electrician is responsible for all installs.
DANGER: Always Shutoff All Power to the Conveyor & Tunnel
Equipment Before Starting Installs and Repairs.
