Sonoro SO-410 User manual

Operatingmanual
sonoroSTREAM (SO-410)
Smartradio

2©sonoroaudioGmbH2016
sonoroaudioGmbH
Nordkanalallee94
41464Neuss
GERMANY
Telephone:[phone]
Fax:[phone]
Email: [e-mail]
Internet:www.sonoro.de

5
©sonoroaudioGmbH2016
1 Introduction
ThankyouforpurchasingasonoroSTREAM.This operating manualand
thesafetyinstructionsprovidealltheinformationrequiredfortrouble-
free andsafeoperationofthedevice.
Ifyoupass thedeviceontoathirdparty,please providethem with
damagetothedevice.
Theimages inthis operatingmanual areintendedtoillustratethe
actionsnecessarytooperatethedevice.
1.1Contactdata
Address sonoroaudioGmbH,Nordkanalallee94,
41464Neuss,GERMANY
Phone [phone]
Fax [phone]
E-mail [e-mail]
Internet www.sonoro.de

6©sonoroaudioGmbH2016
2 Foryourownsafety
2.1Symbolsinthismanual
Safetyinstructions
Importantinformationfor yoursafetyis highlightedaccordingly.Always
takecaretoobservetheseinstructionsinordertoavoidaccidentsand
damagetothedevice:
WARNING!
Indicatesapotentiallyhazardous situation that mayresultin fatalor
seriousinjury.
CAUTION!
Indicatesapotentiallyhazardous situation that mayresultinminoror
moderateinjury.
NOTICE!
Indicatesapotentiallyhazardous situation that mayresultin material
and environmental damage.
Helpfultipsandrecommendations
i
Highlights information and usefulrecommendations.
2.2Intendeduse
Thedeviceis intendedforpersonal useonly.Itis notintendedfor
commercialuse.Thedeviceis solelyintendedfor thefollowingtasks:
Audioplaybackfrom external devices connectedvia AUXInorUSB
port.
Audioplaybackfrom Bluetooth-enableddevices (e.g.mobile
phones).
Chargingofexternal devicesthatareconnectedvia theUSBport.

7
©sonoroaudioGmbH2016
Anyotheruse is consideredimproperuseandisprohibited.Weassume
noliabilityfordamages resultingfromimproperuse.
2.3Childrenand personswithlimitedcognitiveabilities
Persons(including children)whoarenotable tosafelyoperatethe
lackofexperienceor knowledgeregardingthedevice,shouldnot
responsibleperson.Please keepitsafelyoutoftheirreach.
medical aidimmediately.
Rememberthatpackagingmaterials shouldnotbetoyedwith.Risk
2.4Powersupply
Thedeviceis poweredelectrically,sothereis alwaysariskofelectric
shock.Assuch,payparticularattentiontothefollowinginstructions:
Nevertouchthepowerplugwithwethands.
Whenyouwanttopullthepowerplugfrom thewall outlet,always
pull directlyontheplugitself.Neverpull onthepowercable,as this
coulddamageit.
Ensureunobstructedaccess tothepoweroutletsothatthepower
plugcanbepulledoutimmediatelyincase ofanemergency.
Makesurethatthepowercable is notbent,pinchedorrunover.
Laythepowercable insuchawaythatit isnotatrippinghazardor
withinreachofchildren.
Keepthedeviceawayfrom rain,moistureandanyheatsources.
Onlyoperatethedeviceiftheelectrical voltageindicatedonthe
devicenameplateand thepowerplugmatches thevoltageofyour
poweroutlet.
Incorrectvoltagemayirreparablydamagethedevice.
fromthepowersupplywhenyouwill notbeusing thedevicefor a

8©sonoroaudioGmbH2016
ACoutlet.
2.5Batteries
temperatures.
Donotrubyoureyes.Instead,rinseeyes withplentyofclear
areempty,or ifyoudonotintendtouse thedeviceforalongperiod
product andkeepit awayfrom children.
2.6Transport/shipping
Impropertransport/shippingcanleadtodamagetothedevice’ssurface
orthemedia insideit,thuspreventingitfromworkingproperly.
Personalsafety
Whilstdrivinginavehicle,storethedeviceinsuchawaythatit does
notendangertheoccupants.
Preventingdamagetothedevice
Thefront,edges andcornersofthedeviceareall vulnerable to
Neverplacethedevicefacedown.

9
©sonoroaudioGmbH2016
fortransport.Fill this spacewithpolystyrene.
Protectingthemedia insidethedevice
Toavoiddamagetothemedium insidethedevice,removeit before
transport/shipping.
2.7Ambient conditions
Inordertoensurethatthedevicecanbeoperatedsafely,certain
ambientconditionsmustbeobserved.
Weather,moistureandtemperatures
Protect thedeviceandremotecontrolfrom theweather,moisture
andhigh temperatures.Neveruse thedeviceoutdoors,andnever
placeit inareas withincreasedexposuretosunlight.
liquidsonor nexttothedevice.
Installationlocation
Neveruse thedeviceinareas withhighlevels ofhumidity.Protectit
airinthekitchen.
heatsources,e.g.burningcandles,stovetopsor radiators.
Installationsurface
Placethedeviceonasturdysurfacetopreventseveremechanical
Donotplacethedeviceonsurfaces intowhichit maysink,as this
buildingup insidethedevice.
Ventilation
inordertopreventheatform building up insidethedevice.
walls.
Totransportorshipthedevice,please packit intheenclosed
original packagingforthis purpose.

10 ©sonoroaudioGmbH2016
2.8Operation
Therubberfeetofthedevicemayproducestainsoncertain
surfaces.Use asuitable surface.
wrongpowersupplywill damageyourdevice.
2.9Incaseofdefects
Ifthedevicedevelopsadefect,donotattempttorepairit onyourown.
Ifthepowerplug,adapterorpowercable ofthis deviceis damaged,
theymustbereplacedbythemanufacturerorthemanufacturer’s
customerservicedepartmenttopreventriskofelectricshock.
orotherwise damaged,haveit checkedbyanauthoriseddealer.
Immediatelydisconnect thedevicefrom thepowersupplyand
contact anauthoriseddealeras soonas possible.
2.10 Disposalatendofusefullife
Donotdispose
ofin household
waste
Devices thataremarkedwiththis symbol
(seefigure) shouldnotbedisposedofin
householdwaste.Theymustbereturnedtoa
collectionpointfortherecyclingofelectrical
andelectro-technical devices.Information
regardingthedisposalofoldequipmentcanbeobtainedfromyour
municipality,localwastedisposal company andthestorewhereyou
purchasedthis device.Properdisposalofolddevicesprevents
wastetreatment.Returnthebatteries toamunicipal collectionpointor
havethemdisposedofbyaspecialistcompany.

11
©sonoroaudioGmbH2016
ENVIRONMENT!
Environmentalhazardasa resultof incorrectdisposal!
Incorrectdisposal canbehazardoustotheenvironment.
Enlistauthorised,specialistcompanies todispose ofelectrical
scrapandelectroniccomponents.
Ifindoubt,contact yourlocal municipal authorityorspecialist
disposal companyfor informationonenvironmentallyconscious
disposal.
3 Gettingto knowyour sonoroSTREAM
3.1Scopeofdelivery
InadditiontothesonoroSTREAMitself, thefollowing accessories are
alsoincludes inthescopeofdelivery:
Remotecontrol
Poweradapter(withpowercable)
QuickStartGuide

12 ©sonoroaudioGmbH2016
3.2Controlsand ports
Frontview
ï î í
ì
ë
ê
é
è
ç
1.Display
2.Setupbutton(SETUP)
( )
)
7.Infra-redsensorand ambient
lightsensor(behind thelogo)
)
)

13
©sonoroaudioGmbH2016
Rearand sideviews
ïð ïï
ïîïìïë ïí
10.FM/DABantenna
11.Wi-Fiantenna
12.USBport

14 ©sonoroaudioGmbH2016
Remotecontrol
ïê ïé ïè ïç îð îï
îî
îí
îì
îë
îê
îé
îè
îç
íð
)
)
22.Straphole
)
30.Play/pausebutton( ),
OKbutton
,

15
©sonoroaudioGmbH2016
3.3Technicaldata
Specification
Dimensions
(W×D×H)
148.6×101.45 ×171.1mm
Weight 1.113kg
Display 2.4" TFTcolourdisplay
Frequencyrange
FM
Frequencyrange
DAB/DAB+
Internetradio Morethan25,000stationsworldwide
Stationpresets 10 foreachFM|DAB+|Internetradio
File formats
Max.16 bits,2channels,sample rate48KHz
USBcharging 2.1A
USBplayback Compatibilitysystem:FAT16,FAT32 (not
compatiblewithNTFSorothersystems)
AUX-IN
Streaming Bluetooth|Spotify|DLNA|UPnP
Network
supported
IEEE802.11 a/b/g/n,2.4&5GHzbands
Encryptedkey WEP,WPA,WPA2(PSK),WPS
Multi-room
function
Maximumof5speakersinagroup(4clientand
1server)
ACadapter,power TenPaoPowerIndustrial Co.,Ltd.
2000mA
Battery CR2025(remotecontrol)

16 ©sonoroaudioGmbH2016
3.4Marksofapprovalandcertificates
TheBluetooth®wordmarkandlogosare
registeredtrademarksownedbytheBluetooth
SIG,Inc.andanyuseofsuchmarksbysonoro
audioGmbHisunderlicense.Othertrademarks
andtradenamesarethoseoftheirrespective
owners.
This productincorporatesSpotifysoftwarewhich
www.spotify.com/connect/third-party-licenses
UPnP™is atrademark oftheUPnP™Forum.
3.5DeclarationofConformity
Product:sonoroSTREAM
Model:SO-410
Manufacturer:sonoro audioGmbH
Address:Nordkanalallee 94,41464Neuss,Germany
Weherebydeclarethatonthebasisofits design andconstruction,the
sonoroSTREAMsmartradio meetsthe fundamental requirements of
theEMCDirective2014/30/EU,the LowVoltage Directive2014/35/EU,
theRadio EquipmentDirective2014/53/EU, theEcoDesign Directive
2009/125/EC,andthe Restriction ofthe useofcertain hazardous
substancesinelectrical andelectronicequipmentDirective2011/65/EU,
including anychanges applicable at the timeofthis declaration.

17
©sonoroaudioGmbH2016
4 Gettingstarted
WARNING!
Riskofsuffocation!
Improperhandlingofbatteries mayincreasetheriskofswallowingby
immediately.
NOTICE!
Riskofdamage!
Improperhandlingofthedevicemaycausedamage.
remotecontrol.
Alwaysuse theincludedpoweradapter.
thevoltageofyourpoweroutlet.
4.1Unpackingthedevice
1.Takethedeviceofthepackagingand checkwhetherthedeviceor
theindividualpartsexhibitdamages.Ifthis isthecase,donotuse
thedevice.Shouldyoudetectanydamage,contactyourdealeror
sonoroaudioGmbHcustomersupportimmediately.
2.Checktomakesurethat thedeliveryiscomplete(see chapter
“Scopeofdelivery”).
3.Placethedeviceat asuitable location(see chapter“Ambient
conditions”).
4.Removetheprotectivefilm fromthedisplay.

18 ©sonoroaudioGmbH2016
4.2Connectingthepowersupply
1.InserttheconnectorofthepoweradapterintotheDCpowerinput
onthebackofthedevice.
2.Insertthepowerplugintoawallsocket.
Thedeviceis turnedon.
4.3Insertingthebatteryintheremotecontrol
1.Openthebatterycompartmentcoveronthebackoftheremote
controlbyturningitanticlockwiseusingasmallcoin.
3.Replaceandclosethebatterycompartmentcoverbyturningthe
coverclockwiseusingasmallcoin.
i
Donotblocktheinfra-red sensoron the deviceandthe infra-red
transmitteron the remotecontrol during use.
4.4Usingtheantennas
1.DetachtheFM/DABantennafromthecatchonthebackofthe
device.
2.LiftbothFM/DABantennaandWi-Fiantennaupwards.
3.ExtendtheFM/DABantennaforbetterreception.
4.5Performinginitialsetup
Whenthedeviceispoweredonforthefirsttime,the“Setupwizard”
appearsonthedisplay.Followtheinstructionsbelowtoconfiguresome
basicsettings.
1.Whenthe“Setupwizard”is displayed,press or ontheremote
OKtostartthesetup.

19
©sonoroaudioGmbH2016
2.Youarethenpromptedtoselect:
Language(tobeusedinthedisplay)
Timeformat(12or24-hour),
Sourceofautoupdate(Updatefrom radio,Internetornoupdate).
Dependingontheselectionyouhavemade,followtheinstructions
onthedisplaytofurthersetupdate and time,timezone,daylight
savingorwirelessnetwork.Rotatethenavigationknobonthe
deviceorpressthenavigationbuttonsontheremotecontrolto
makeselectionsand thenpress OKtoconfirm(seechapter“Using
themenus”).
Whenupdate fromInternetis selected,Wi-Ficonnectionmustbe
firstestablished.Whenenteringthekeyofyourwireless network,
rotatethenavigationknobonthedeviceorpress thenavigation
buttonsontheremotecontroltoselectacharacterandthenpress
OKtoconfirm.Todeletethelastentry,select[BKSP].Tocancel
enteringthekey,select[CANCEL]. Toconfirmtheenteredkey,select
[OK].
3.When“Setupwizardcompleted”appears,pressOKtoexitthe
setting.
i
Torun the setup wizardagain,goto [Systemsettings]andthen select
[Setup wizard](Seechapter“Systemsettings”).

20 ©sonoroaudioGmbH2016
5 Basicoperation
Toturnon, Press .
selectedplaybackmode.
Toturnoff(standby
mode),
Press .
Toselectaplayback
mode,
PressMENUonce,then or (orrotatethe
navigationknob)toselectaplaybackmode
andthenpressOKtoconfirm.
Modesequence:FMradio>DABradio>
Internetradio>Spotify>Musicplayer>
Auxiliaryinput>Bluetoothaudio
Tocontrolthe
volume, thevolumeknobonthedevice.
6 Usingthemenus
Therearethreetypesofmenuinthedevice.
e.g.[Manual tune]intheFMmode)
alarms)
Toaccessthe
menus,
PressSETUP.
Contentsofthemenusmaydifferindifferent
playbackmodes.
Toselectanoption
inthemenus,
Rotate thenavigationknobonthedeviceor
pressthenavigationbuttonsontheremote
control.

21
©sonoroaudioGmbH2016
Toconfirma
selectioninthe
menus,
PressOK.
(Onthedevice,pressthenavigationknob)
Togobackonelevel
inthemenu,
Press or .
7 Displayicons
Refertothetable belowforthemeaningsofthedisplayiconswhen
theyshowonthedisplay.
Wi-Ficonnectionisestablished(withsignal strength).
Wi-Ficonnectionisdisconnected.
ABluetoothdeviceisconnected.
Alarm1is activated.
Alarm2is activated.
Theradiostationis inthepresetlist.
FMRDSinformationisreceived.
Radiosignalis beingreceived(withsignal strength).
Repeatallplaybackmodeisactive.
Repeatoneplaybackmodeisactive
Shuffle playbackmodeisactive.
Repeatallandshuffle playbackmodeis active.
Sleeptimeris active.
Stereosoundbroadcastisavailable.
Soundoutputis muted.
AUSBdeviceis connected.
Playbackis paused.

22 ©sonoroaudioGmbH2016
8 FMradiomode
8.1Operation
ToaccesstheFM
radiomode,
PressMENUonce,then or (orrotatethe
navigationknob)toselecttheFMradiomode
andthenpressOKtoconfirm.
Tomanuallytunethe
frequency,
Press or .
Or,select[Manualtune]inthesetupmenu
Toautomatically
tunetothenext
available station,
Pressandhold or .
Tostorearadio
stationinthepreset
list,
Amaximumof10 radiostationscanbe
stored.
1.Pressandhold untilthepresetlistis
shown.
(or rotatethenavigationknob)
toselectapresetstationnumberandthen
pressOKtoconfirm.
Todirectlystorea
radiostationinthe
Tunetoastationandthenpress and holda
inthepresetlist.
Torecallaradio
stationinthepreset
list,
1.Press .
(or rotatethenavigationknob)
toselectaradiostationinthepresetlist
andthenpressOKtoconfirm.
Tobrowse theradio
stationinformation
(ifavailable),
PressINFOrepeatedly.
Tomuteor restore
thesoundoutput,
Press .
