Ubiquiti airMAX Bullet Titanium BM2-Ti User manual

Zero-Variable Outdoor Radio
Models: BM2-Ti, BM5-Ti

Introduction
Thank you for purchasing the Ubiquiti Networks™airMAX™
Bullet™Titanium. This Quick Start Guide is designed to guide
you through the installation of the radio. This Quick Start
Guide also includes the warranty terms and is for use with the

model BM5-Ti.
Package Contents
Bullet Titanium N-Type Right
Angle Adapter
Zero-VariableOutdoor Radio
Models:BM2-Ti, BM5-Ti
PoE Adapter
(24V, 1A)
Power Cord Quick Start Guide
Products may be different from pictures and are subject to change without notice.
TERMS OF USE: Ubiquiti radio devices must be professionally installed. Shielded Ethernet
cable and earth grounding must be used as conditions of product warranty. TOUGHCable is
designed for outdoor installations. It is the customer’s responsibility to follow local country
regulations, including operation within legal frequency channels, output power, and Dynamic
Frequency Selection (DFS) requirements.

Hardware Overview
N-Type
Connector
Bullet Titanium
Radio
Rubber Washer
Cable Gland Body
Compression Nut
Ethernet Port
Compression Seal

Hardware Installation
1. Unscrew the Cable Gland Body and detach it from the Bullet
Titanium Radio.
2. Unscrew the Compression Nut and remove the Compression
Seal from the Cable Gland Body.

3. Slide the Compression Nut over the Ethernet cable with
the threaded end facing the RJ-45 connector. Slip the
Compression Seal around the cable.
4. Feed the Ethernet cable through the Cable Gland Body and
seat the Compression Seal into the Cable Gland Body.
5. Connect the Ethernet cable to the port located on the
bottom of the Bullet Titanium Radio.

6. Securely screw the Cable Gland Body into the Bullet
Titanium Radio so that the Rubber Washer seals the bottom
of the radio.
7. Tightly screw on the Compression Nut. Ensure the
Compression Seal is securely compressed and tightly sealed
around the cable.

8. Connect the Bullet Titanium to the N-Type connector of
the antenna.
Note: The Bullet Titanium should be mounted
vertically to reduce stress on the N-Type Connector.
The N-Type Right Angle Adapter may be used as
needed.

Connecting Power over Ethernet
1. Connect the other end of the Ethernet cable from the
Bullet Titanium to the Ethernet port labeled POE on the
PoE Adapter.
2. Connect an Ethernet cable from your LAN to the Ethernet
port labeled LAN on the PoE Adapter.
3. Connect the power cord to the power port on the PoE
Adapter. Connect the other end of the power cord to a
power outlet.

Accessing the airOS Utility
1. Make sure that your host machine is connected to the LAN
that is connected to the Bullet Titanium.
2. Configure the Ethernet adapter on your host system with a
static IP address on the 192.168.1.x subnet.
3. Launch your web browser. Type https://192.168.1.20 in
the address field and press enter (PC) or return (Mac).
4. The login screen will appear. Enter ubnt in the Username
and Password fields. Select your Country and Language.
You must agree to the Terms of Use to use the product.
Click Login.
Note: U.S. product versions are locked to the U.S. Country
Code to ensure compliance with FCC regulations.
The airOS Configuration Interface will appear, allowing you to
customize your settings as needed.
For additional details on the airOS Configuration Interface,
refer to the User Guide available at
documentation.ubnt.com/airmax

Installer Compliance Responsibility
Devices must be professionally installed and it is the
professional installer’s responsibility to make sure the device is
operated within local country regulatory requirements.
Since Ubiquiti Networks equipment can be paired with a
variety of antennas and cables, the Antenna Gain, Cable Loss,
and Output Power fields are provided to the professional
installer to assist in meeting regulatory requirements.
