Sony Ericsson P910a User manual

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
Working Instruction, Mechanical
Applicable for P910a, P910c, and P910i
Contents
1General.............................................................................................................................2
2Disassembly .....................................................................................................................2
3Reassembly ......................................................................................................................9
4Replacement of Mechanical Parts ...............................................................................19
4.1 Front Cover......................................................................................................19
4.2 Front Speaker, Speaker Holder, and Speaker Cloth ........................................21
4.3 RF Port Cover..................................................................................................23
4.4 Battery Cover .................................................................................................. 23
4.5 Display.............................................................................................................23
4.6 Flip Assembly..................................................................................................24
4.7 Flip Hinge Cover .............................................................................................24
4.8 Camera Module ...............................................................................................24
4.9 Back Cover ...................................................................................................... 26
4.10 Internet Key.....................................................................................................39
4.11 Camera Key.....................................................................................................39
4.12 Power On/Off Key...........................................................................................39
4.13 Camera Gasket ................................................................................................ 40
4.14 Vibrator ...........................................................................................................41
4.15 Rear Speaker, Holder, and Cloth.....................................................................41
4.16 Audio Jack and Audio Jack Cover ..................................................................41
4.17 Microphone Assembly and Microphone Cloth ...............................................41
4.18 Jog Dial............................................................................................................43
4.19 Antenna Assembly ..........................................................................................46
4.20 Memory Stick Cover ....................................................................................... 50
4.21 Camera Window Assembly.............................................................................50
4.22 Camera/Internet Key Switch ...........................................................................51
4.23 Stylus Holder...................................................................................................55
4.24 Water Indicator Label......................................................................................60
4.25 Label Replacement ..........................................................................................61
5Revision History............................................................................................................62

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
2(62)
1 General
When handling this product take care to keep all surfaces clean of dirt, dust, debris, and hand
grease. Use appropriate ESD precautions when working on this product. The use of finger cots or
gloves, an ESD mat, and an ESD wrist strap are required at minimum.
2 Disassembly
Tools:
• Torque screwdriver • Orange stick
• JCIS No. 0 bit • Nylon pointer
• Style 2A ESD-safe tweezers (Blunt Tip) • Front opening tool
NOTE! Whenever the phrase “pry tool” is used, a nylon pointer, an orange stick, or a front
opening tool may be used, depending on the user’s preference.
Step-by-Step Instructions
1. Locate the grip location on the battery cover that
is just below the camera window.
2. Remove the battery cover by pressing down on
grip location and simultaneously sliding battery
door towards the bottom of the phone (away
from the camera) until a 4 to 5 MM gap forms
between the bottom of camera window and top
of the battery cover. The battery cover can then
be lifted away from the phone.
3. Remove the battery by placing your hand over
the battery cavity and orienting the phone so that
the battery cavity is in a downward position.
The battery should drop into your hand.
NOTE! Do not tap the phone against a hard
surface in an attempt to get the battery
out. Damage to the phone may result!

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
3(62)
Step-by-Step Instructions
NOTE! Be careful not to scratch or scar the
phone or the flip hinge cover when
removing the flip hinge cover.
4. With the flip in the closed position, slide the flat
end of a pry tool under one of the accessible
corners of the flip hinge cover and rotate the pry
tool away from the system connector. The hinge
cover should start to separate from the phone
along the edge adjacent to the system connector.
5. Once you have got the separation of the flip
hinge cover started, work the pry tool along the
flip hinge cover’s separating edge to finish
releasing it from the phone.
6. Once the edge of the flip hinge cover is released
from the phone, lift the hinge cover’s free edge
up and out away from the phone as shown. The
flip hinge cover should easily slide out from
between the flip and the front cover when lifted
in the manner shown.
7. Using a torque driver with a JCIS No. 0 bit,
remove the two M1.4 x 3.5MM screws holding
the flip assembly.
NOTE! Do not reuse the screws that hold the
flip assembly in place.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
4(62)
Step-by-Step Instructions
8. Support the hinge joint by placing your finger on
the black portion of the hinge.
9. Then rotate the flip so that it forms a 90º angle
with the rest of the phone.
10. Remove your finger from the black portion of
the hinge and rotate the flip away from the
phone. While rotating the flip, it should come
free from the phone.
11. Orient the phone so that the side of the phone
with the camera is towards you and the end of
the phone with the system connector is the
bottom of the phone.
12. Insert the pointed end of the nylon pointer into
small hole in the RF port cover and rotate the
nylon pointer down towards the outer edge of the
phone. The RF port cover should lift from it
cavity.
13. Using a pair of tweezers, press inward on side of
the left side screw cover that is accessible from
the RF port opening. While applying inward
pressure on the left side screw cover, pry the
cover upward way from the phone.
14. Once the left side screw cover is loose, remove it
from the phone.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
5(62)
Step-by-Step Instructions
15. Using the pair of tweezers, press the tip of one of
the tweezers’ arms down into the notch in the
right side screw cover and pry the cover up out
of its cavity.
16. Once the sides of the right side screw cover are
accessible, lift it from the phone using the
tweezers.
NOTE! If the disassembly procedure is only
being preformed for the purpose of
removing the front cover, the following
two steps can be skipped. Otherwise the
following two steps need to be
preformed before removing the front
cover.
17. If present, remove the memory stick.
18. If present, remove the SIM card.
19. Remove the four screws from the back cover
using a torque driver with a JCIS No. 0 bit.
NOTE! The two screws near the system
connector cannot be reused. The two
screws near the camera window are self-
tapping screws and can be reused.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
6(62)
Step-by-Step Instructions
20. Starting at the end of the phone that contains the
system connector, work a pry tool in the seam
between the front and back covers and gently
twist the pry tool to separate the covers.
21. Once the separation of the front and back covers
is started at the bottom of the phone, move to
one of the seams that run along each side of the
phone where the front and back covers come
together. Using the flat end of a pry tool, gently
twist the pry tool to separate the front and back
covers. As the seam opens up, switch from side
to side working the seam open by sliding the pry
tool down the seam and twisting. Continue
doing this back and forth along each side until
the seams are opened up on each side just passed
where the top of the display is located.
22. Remove the front cover by lifting up and rotating
it away from the end of the phone with the
system connector.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
7(62)
Step-by-Step Instructions
NOTE! The display is connected to the non-
accessible side of the circuit board.
Therefore the circuit board has to be
removed from the back cover before the
display can be disconnected from the
circuit board.
NOTE! Be careful not to damage the display or
its flex film while trying the remove
the circuit board from the back cover.
23. Lay a scrap front cover, external side up,
adjacent to the side of the back cover that the
camera key is located on and rotate the display
so that it is laying on top of the scrap front cover.
24. Remove the two screws from the shielding can
using a torque driver with a JCIS No. 0 bit.
25. Then lift the shield can away from the circuit
board.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
8(62)
Step-by-Step Instructions
26. There are 5 latches that hold the circuit board in
the back cover. To release the circuit board,
gently pry between the circuit board and the
back cover in the 4 locations indicated in the
order specified.
NOTE! Only pry as much as is needed to
release the latches!
NOTE! When prying in location 2 make not to
pry over the portion of the antenna that
is visible.
NOTE! Be careful not to damage the RF port
when prying to release the latches at
location 2.
27. Once the latches holding the circuit board are
released, slightly lift up the side of the circuit
board the display is adjacent to and using a pry
tool, carefully disconnect the flex connection of
the display from the circuit board. Then set the
display aside.
28. Once the display is removed, increase the size of
the opening between the circuit board and the
back cover and locate the jog dial flex film
connection.
29. Using a pry tool, carefully disconnect the flex
connection of the jog dial from the circuit board.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
9(62)
Step-by-Step Instructions
30. Then lift the circuit board away from the back
cover.
3 Reassembly
Tools:
• Torque screwdriver • Orange stick
• JCIS No. 0 bit • Nylon pointer
• Style 2A ESD-safe tweezers (Blunt Tip) • Front opening tool
NOTE! Whenever the phrase “pry tool” is used, a nylon pointer, an orange stick, or a front
opening tool may be used, depending on the user’s preference.
Step-by-Step Instructions
NOTE! Make sure that the camera gasket is in
its correct position before proceeding so
that the circuit board fits correctly into
the back cover.
1. Lay the edge of the circuit board inside the edge
of the back cover so that the contact pads on the
board for audio jack are adjacent to the jack in
the back cover as shown.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
10(62)
Step-by-Step Instructions
NOTE! Be careful not to damage the vibrator
contacts or the audio jack contacts when
connecting the jog dial to the circuit
board.
2. Rotate the circuit board towards the back cover
so that the jog dial’s flex connection can reach
its corresponding connector on the board.
3. Plug the jog dial flex film connection to the
board and rotate the board down into the back
cover.
NOTE! Check the vibrator contacts and the
audio jack contacts to make sure that
you did not damage them during the
process of connecting the jog dial to the
circuit board.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
11(62)
Step-by-Step Instructions
4. If a new display is being installed, mount the two
cushions shown onto the display as indicated.
5. If a new display is being installed, mount a
display spacer onto the edge of the display as
shown. If the old display is being reinstalled,
verify that a display spacer is mounted onto the
edge of the display as indicated. If a display
spacer is not present, install one as shown.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
12(62)
Step-by-Step Instructions
6. Hold the partially assembled phone in your hand
with the board towards you and place the display
in the same hand beside the phone with the back
of the display as the visible side and its flex
connection orients towards the circuit board as
shown.
7. Rotate up the side of the circuit board that the
display attaches to and carefully connect the flex
connection of the display to the circuit board.
Then rotate the circuit board back down into the
back cover.
8. Make sure that the system connector and the
alignment pen are aligned with their
corresponding features.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
13(62)
Step-by-Step Instructions
9. Snap the circuit board into the back cover by
pressing the board in the 4 locations shown in
the order indicated so that 5 latches on the back
cover that hold the circuit board in place engage.
10. Place the shield can over the circuit board so that
the shield can matches up with the outline on the
circuit board.
11. Install two M1.4 x 4MM screws using a torque
of 7 N*cm in the two locations indicated.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
14(62)
Step-by-Step Instructions
12. Rotate the display so that it is laying on top of
the shield can.
NOTE! Hold the display in place while installed
the front cover so that the display does
not move around and put unnecessary
strain on the display’s flex film.
13. Work the top of the front cover down over the
three catches at the top of the back cover.
14. Once there is no gap between the top of the front
cover and back cover, rotate the rest of the front
cover down onto the phone and squeeze the front
cover and the back cover together until the front
cover snaps into place.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
15(62)
Step-by-Step Instructions
NOTE! The two M1.6 x 11MM screws that
mount in the back cover cannot be
reused and must be replaced if they are
removed. The M1.7 x 14.5MM screws
are self tapping and can be reused.
15. Using a torque screwdriver set to 15 N*cm and a
JCIS No. 0 bit, install two M1.6 x 11MM screws
in the screw locations nearest the system
connector. Using a torque screwdriver set to 24
N*cm and a JCIS No. 0 bit, install two M1.7 x
14.5MM screws in the screw locations nearest
camera window.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
16(62)
Step-by-Step Instructions
16. Orient the phone so that the side of the phone
with the camera is towards you and the end of
the phone with the system connector is the
bottom of the phone.
17. Remove the protective backing from the right
side screw cover.
18. Orient the right side screw cover so that its side
with adhesive is towards the back cover and the
screw cover’s shape matches up with the shape
of its cavity.
19. Insert the right side screw cover into its cavity
and apply pressure to it for 3 seconds so that a
good bond forms between the screw cover and
the back cover.
NOTE! When correctly installed the visible
surface of the screw cover should be
flush with the outer surface of the back
cover.
20. Remove the protective backing from the left side
screw cover.
21. Orient the left side screw cover so that its side
with adhesive is towards the back cover and the
screw cover’s shape matches up with the shape
of its cavity (the cavity adjacent to the RF port).
22. Insert the left side screw cover into its cavity and
apply pressure to it for 3 seconds so that a good
bond forms between the screw cover and the
back cover.
NOTE! When correctly installed the visible
surface of the screw cover should be
flush with the outer surface of the back
cover.
23. Insert the RF port cover into its RF port in the
back cover.
NOTE! When correctly installed the visible
surface of the RF port cover should be
flush with the outer surface of the back
cover.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
17(62)
Step-by-Step Instructions
NOTE! Be careful when handling and adjusting
the portion of the flip assembly that
contains the contacts so that
contamination of the contacts is
avoided.
24. Adjust the portion flip that contains the contacts
so that the contacts are visible when viewing the
side of the flip assembly with that standard
phone keypad.
25. Mate the contact portion of the flip assembly in
the corresponding features at the bottom of the
front cover.
NOTE! The screw holes in the contact portion of
the flip assembly should align with the
screw inserts in the front cover.
NOTE! The M1.4 x 3.5MM screws that hold the
flip assembly in place cannot be reused
and must be replace whenever they are
removed.
26. Using a torque driver set at 7 N*cm with a JCIS
No. 0 bit, install the two M1.4 x 3.5MM screws
that hold the flip assembly to the phone.
27. Rotate the flip assembly so that an angle of
~120º is formed between the flip and the display.
NOTE! You may have to hold the flip at the
120º angle.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
18(62)
Step-by-Step Instructions
28. Insert the edge of the hinge cover with the two
6.5MM tabs into the corresponding notch in the
front cover just below the bottom edge of the
display.
29. Press down on the logo on the hinge cover until
the hinge cover snaps onto the front cover.
NOTE! Make sure there is no gap along the
seam between the hinge cover and the
front cover that is just above the system
connector. If no gap is present the
hinge cover is correctly installed.
30. With the label side of the battery oriented away
from the phone, insert the end of the battery with
the three contact pads into the end of the battery
cavity where the battery connector is located.
The two corners of the battery closest to the
phone’s battery connector should slide under
catches in the corners of the battery cavity.
31. While pushing the battery towards camera,
simultaneously press the other end of the battery
down into the battery cavity.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
19(62)
Step-by-Step Instructions
32. Place the battery cover over the battery cavity, so
there is a 4 to 5 MM gap between the bottom of
camera window and top of the battery cover.
33. Press down on grip location on the battery cover
and simultaneously slide battery cover towards
the top of the phone (towards the camera
window).
4 Replacement of Mechanical Parts
4.1 Front Cover
Tools:
• 2A (blunt tip) ESD-safe tweezers • Lint-free wipes
• Perform the steps 1 - 22 of “Disassembly” section before proceeding
Step-by-Step Instructions
1. Using 2A (blunt tip) tweezers, slide the tip of one
of the tweezers’ arms under the lip of the
accessible leg of the speaker holder.
2. Place a finger over the speaker holder to keep it
from flying off when releasing it.
3. Twist the tweezers away from the speaker and the
holder should release from its catch on the front
cover.

Working Instruction, Mechanical
3/00021-1/FEA 209 544/90 A
Sony Ericsson Mobile Communications AB
20(62)
Step-by-Step Instructions
4. Lift the holder from atop the speaker and set it
aside.
5. Lift the speaker from front cover.
6. Obtain a new front cover.
7. Place the speaker into the new front cover’s
speaker area. When placing the speaker, orient it
so that the speaker’s contacts are within the gap in
the side of the speaker area that is opposite to the
location where the tab portion of the speaker cloth
extends for the speaker area.
8. Locate the two catch features that are in the
placement walls around the speaker area.
9. Hook one of the legs of the speaker holder into
one of the placement wall catches.
10. Rotate the speaker holder down over the speaker
and press down on the speaker holder until the
unlatched leg of the speaker holder snaps into it
corresponding catch feature.
• Perform the steps of “Reassembly” section starting at the note before step 13 to complete the
reassembly of this phone.
