SERVICE MANUAL

HOME THEATER SYSTEM

• This set is the Amplifier section in

HT-K215.

SPECIFICATIONS

This amplifier incorporates Dolby* Digital and Pro Logic

Surround and the DTS** Digital Surround System.

*

Manufactured under license from Dolby Laboratories.

“Dolby”, “AC-3”, “Pro Logic” and the double-D symbol aare

trademarks of Dolby Laboratories.

Amplifier section

POWER OUTPUT

Rated Power Output at Stereo mode

(8 ohms 1 kHz, THD

0.7%)

25W+25W

Reference Power Output

(8 ohms 1 kHz, THD

0.7%)

Front: 25W+25W

Center: 25 W

Rear: 25W+25W

Frequency response

DVD, TV, VIDEO, AUX:

20 Hz - 20 kHz + 0.5/

–2 dB

Inputs (Analog)

5.1CH/SAT, TV, VIDEO:

Sensitivity: 250 mV

Impedance: 50

kilohms

S/N

a)

: 96 dB (A, 250

mV

b)

)

Inputs (Digital)

DVD, AUX (optical):

Sensitivity: –

Impedance: –

S/N: 100 dB (A, 20

kHz LPF)

Outputs SUB WOOFER:

Voltage: 2 V

Impedance: 1

kilohms

General

Power requirements

220-230 V AC, 50/60 Hz

Power consumption

120 W

Dimensions 296.5 215 60 mm

including projecting

parts and controls

Mass (Approx.)

4.2 kg

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

2

TABLE OF CONTENTS

1. GENERAL ········································································· 3

2. TEST MODE····································································· 4

3. DIAGRAMS········································································ 5

3-1. Circuit Boards Location ·············································· 5

3-2. Block Diagram

– MAIN Section – ······················································· 6

– POWER Section – ···················································· 7

3-3. Printed Wiring Boards – DIGITAL Section – ··········· 8

3-4. Schematic Diagram – DIGITAL Section (1/2) – ········ 9

3-5. Schematic Diagram – DIGITAL Section (2/2) – ······ 10

3-6. Printed Wiring Boards

– OPTICAL / SIGNAL BRIDGE Section –············· 11

3-7. Schematic Diagram

– SIGNAL BRIDGE Section –·································· 11

3-8. Schematic Diagram – DISPLAY Section – ·············· 12

3-9. Printed Wiring Boards – DISPLAY Section –·········· 13

3-10. Printed Wiring Boards – MAIN Section – ··············· 14

3-11. Schematic Diagram – MAIN Section (1/2) – ··········· 15

3-12. Schematic Diagram – MAIN Section (2/2) – ··········· 16

3-13. Printed Wiring Boards – POWER Section – ············ 17

3-14. IC Pin Function Description ······································ 18

3-15. IC Block Diagrams ···················································· 19

4. EXPLODED VIEWS····················································· 20

5. ELECTRICAL PARTS LIST····································· 22

•Grounding connectionat thetwo pointsbetweenthe MAIN

board and the chassis is necessary while the main power

to the MAIN board is turned on.

• Jig is used to inspect the DIGITAL board.

1. Between the DIGITAL board CNS807 and OPTICAL board CNP807

8 P/L=300 (A-2501-2060A)

2. Between the DIGITAL board CNS808 and SIGNAL BRIDGE

board CNS808

18 P/L=300 (A-2501-207-A)

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH

MARK 0ON THE SCHEMATIC DIAGRAMS AND INTHE PARTS

LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE

COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS

APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS

PUBLISHED BY SONY.

Flexible Circuit Board Repairing

• Keep the temperature of soldering iron around 270˚C

during repairing.

• Do not touch the soldering iron on the same conductor of the

circuit board (within 3 times).

• Be careful not to apply force on the conductor when soldering

or unsoldering.
